Texas Instruments SimpleLink CC3200MOD User manual

EVM User’s Guide
TI Confidential – Strictly Private 2
CC3200MOD Launchpad (Evaluation board) User
Guide
ECS Applications
Table 1. Document Change Log
Date (Version)
Author
Approved by
Description
Initial Release
Contents
1 Getting Started.......................................................................................................................3
1.1 Introduction 3
1.2 Key Features 3
2Hardware............................................................................................................................4
2.1 Block Diagram 5
2.2 Hardware features of the CC3200MOD Launchpad (Evaluation board) 5
2.2.1Power connections 6
2.2.22x20 pin connector assignment 6
2.3 Power 7
2.4 PCB Layout information 8
2.5 Schematics 10
2.6 Bill of materials 14
2.7 Antenna information 16

EVM User’s Guide
TI Confidential – Strictly Private 3
Getting Started
1.1 Introduction
The CC3200MOD LaunchPad is an easy-to-use evaluation module for the CC3200 WIFI
microcontroller Module. It contains everything needed to start developing on a low-power
Arm Cortex M4F MCU, including onboard emulation for programming and debugging as
well as onboard buttons and LEDs for quick integration of a simple user interface.
The CC3200 supports growing applications with increased CPU speed, memory, and 32-
bit performance.
Rapid prototyping is a snap thanks to the 40-pin headers and a wide variety of
BoosterPack plug-in modules that enable technologies such as , graphical displays,
Audio codec, Antenna diversity, environmental sensing, and much more.
1.2 Key Features
•Low-Power ARM Cortex M4F CC3200MOD module with 802.11 bgn WIFI
•40-pin LaunchPad standard that leverages the BoosterPack ecosystem
•FTDI based JTAG emulation with Serial port for flash programming.
•Two buttons and three LEDs for user interaction
•Backchannel UART through USB to PC.
•On-board chip antenna with U.FL for conducted testing.
•On-board Accelerometer and Temperature sensor for Out of Box demo.
•Micro USB connector for power and debug connections.

EVM User’s Guide
TI Confidential – Strictly Private 4
2 Hardware
U.FL
CC3200
Chip Antenna
User LEDs
Push Button Push Button
Reset
JTAG
Headers
UART
Signals
20 pin
J1, J3
20 pin
J2, J4
Sensor
Area
FTDI
JTAG Emu
Murata
Conn
EVM Overview

EVM User’s Guide
TI Confidential – Strictly Private 5
2.1 Block Diagram
FTDI
FT2232D
+
SWD circuit
CC3200MOD
USB
Conn
LDO
3.3V
2xAA
Batt Conn
Acc
BMA222
Temp
Sensor
TMP006
Chip
ant
I
2
C
LEDs
GPIO9,10,11
Push buttons
GPIO13, 22
2x20 Launchpad headers
(Compatible with TI MCU Std*)
M25PX80-VMN6TP
W25Q80BLUXIG
VCC
JTAG/SWD
UART (Flashing)
U.FL
Filter
Reverse
Protection
INT(GPIO13)
DC/DC
3.3V
VDD_FLASH
Block Diagram
2.2 Hardware features of the CC3200MOD Launchpad (Evaluation board)
•CC3200MOD Module with CC3200 device with RF filter, serial flash and crystal.
•Low-Power ARM Cortex M4 with 802.11 bgn WIFI
•40-pin LaunchPad standard that leverages the BoosterPack ecosystem
•FTDI based JTAG emulation with Serial port for flash programming.
•Supports both 4 wire JTAG and 2 wire SWD
•Two buttons and three LEDs for user interaction
•Virtual COM port UART through USB on PC
•On-board chip antenna with U.FL for conducted testing.
•On-board Accelerometer and Temperature sensor for Out of Box demo with option to
isolate them from the I2C bus.
•Micro USB connector for power and debug connections.

EVM User’s Guide
TI Confidential – Strictly Private 6
•Headers for current measurement and external JTAG connection.
•Bus powered device with no external power required for WIFI.
•Long range transmission with highly optimized antenna (200m Typical in open air with a
6dBi antenna AP)
•Can be powered with external 2xAA or 2xAAA alkaline batteries working down to 2.3V typ.
2.2.1 Power connections
The board can be powered by using the on-board micro USB connector. An on-board
LDO provides 3.3V for the CC3200 and the rest of the board to operate. This supply can
be isolated from the LDO using the jumpers on the board.
J12 Current
measurement
Measure the current flowing into the CC3200
device.
J13 Board power Short: Supply the board power from the on-board
LDO.
Open : Supply the board power from the J20
(battery connector)
J19 5V power 5V output from the USB VBUS (has a diode drop of
up to 0.4V)
J20 3.3V power
input Can be used to power the board from an external 2XAA battery pack. It has in-built reverse voltage
protection to prevent the battery from being plugged
in the reverse manner.
Various powering options are discussed in subsequent sections.
2.2.2 2x20 pin connector assignment
The signal assignment on the 2x20 pin connector is shown below. The convention of J1..J4
is replaced with P1…P4 to avoid confusion with the actual board reference.

EVM User’s Guide
TI Confidential – Strictly Private 7
CC3200
P1 P3
Ref
Signal
Dev
Pin#
Dev
Pin#
Signal
1
3.3V
5V
2
ADC_CH1
58
GND
3
UART0_RX
457
ADC_CH0
4
UART0_TX
360
ADC_CH3
5
GPIO
61
58*
ADC_CH1
6
ADC_CH2
59
59*
ADC_CH2
7
SPI_CLK
563
AUD_SYNC
8
GPIO
62 53
AUD_CLK
9
I2C_SCL
164
AUD_DOUT
10
I2C_SDA
250
AUD_DIN
P4 P2
Signal
Dev
Pin#
Dev
Pin#
Signal
Ref
PWM
2*
GND
1
PWM
1*
18
GPIO
2
PWM
17*
8
SPI_CS
3
PWM
64*
45
GPIO
4
CCAP/GPIO
21*
RESET_OUT
5
CCAP/GPIO
18*
7
SPI_DOUT
6
GPIO
62*
6
SPI_DIN
7
GPIO
60*
21
GPIO
8
GPIO
16
55
GPIO
9
GPIO
17
15
GPIO
10
The signal mappings are as per the table above. All the signals are referred by the pin-no in the
SDK and the table above shows the default mappings. Note that some of the pins are repeated
across the connector. For e.g. pin 62 is available on P1 and P4, but only P1 is connected by
default. The signal on P4 is marked with a *(star) to signify that is not connected by default. It
can be routed to the pin by using a 0 Ohm resistor in the path. Please refer to the schematics
and placement diagram for the exact resistor placement.
2.3 Power
The Launchpad is designed to work from the USB provided power supply as it
enumerates as a bus-powered device. Care has been taken in the design to ensure that
the board does not violate the in-rush limits of the USB bus. The board can also be
powered by an external 2xAA or 2xAAA battery which is connected on J20.
