Texas Instruments TPS389006Q1EVM User manual

User's Guide
TPS389006Q1EVM Multichannel Voltage Supervisor with
I2C
ABSTRACT
This user's guide describes the operational use of the TPS389006Q1EVM evaluation module (EVM) as a
reference design for engineering demonstration and evaluation of the TPS389006-Q1 Multichannel Overvoltage
and Undervoltage I2C Programmable Voltage Supervisor and Monitor. This guide contains the EVM schematic,
bill of materials (BOM), assembly drawing, and top and bottom board layouts.
Table of Contents
1 Introduction.............................................................................................................................................................................3
1.1 Related Documentation......................................................................................................................................................4
1.2 TPS389006-Q1 Applications..............................................................................................................................................4
2 Schematic, Bill of Materials, and Layout.............................................................................................................................. 5
2.1 TPS389006Q1EVM Schematic..........................................................................................................................................6
2.2 TPS389006Q1EVM Bill of Materials.................................................................................................................................. 8
2.3 Layout and Component Placement.................................................................................................................................. 11
2.4 Layout...............................................................................................................................................................................11
3 EVM Connectors................................................................................................................................................................... 13
3.1 EVM Test Points...............................................................................................................................................................13
3.2 EVM Jumpers...................................................................................................................................................................14
4 EVM Setup and Operation....................................................................................................................................................15
4.1 Setup and GUI Installations............................................................................................................................................. 16
4.2 Quick Start to TPS389006Q1EVM GUI........................................................................................................................... 20
4.3 Example Operation of TPS389xxx-Q1............................................................................................................................. 25
5 Revision History................................................................................................................................................................... 27
List of Figures
Figure 1-1. TPS389006Q1EVM Board Top................................................................................................................................. 3
Figure 1-2. TPS389006Q1EVM Board Bottom............................................................................................................................4
Figure 2-1. TPS389006Q1EVM Main Schematic........................................................................................................................ 6
Figure 2-2. TPS389006Q1EVM I2C Schematic with Buffers....................................................................................................... 7
Figure 2-3. Component Placement—Top Assembly.................................................................................................................. 11
Figure 2-4. Component Placement—Bottom Assembly.............................................................................................................11
Figure 2-5. Layout—Top.............................................................................................................................................................11
Figure 2-6. Layout—Bottom.......................................................................................................................................................11
Figure 2-7. Top Layer.................................................................................................................................................................12
Figure 2-8. Bottom Layer........................................................................................................................................................... 12
Figure 2-9. Top Solder Mask......................................................................................................................................................12
Figure 2-10. Bottom Solder Mask.............................................................................................................................................. 12
Figure 3-1. TPS389006Q1EVM Jumper Locations................................................................................................................... 14
Figure 4-1. TPS389006Q1EVM Connection Description...........................................................................................................16
Figure 4-2. Setup License Agreement Window......................................................................................................................... 17
Figure 4-3. Setup Destination Window...................................................................................................................................... 17
Figure 4-4. Setup Window - Start Menu Selection.....................................................................................................................18
Figure 4-5. Setup Window - Additional Tasks............................................................................................................................ 18
Figure 4-6. Setup Installation Window....................................................................................................................................... 19
Figure 4-7. Installation Complete Window................................................................................................................................. 19
Figure 4-8. Fusion Welcome Window........................................................................................................................................20
Figure 4-9. Fusion Scan Window...............................................................................................................................................21
www.ti.com Table of Contents
SNVU785A – FEBRUARY 2022 – REVISED MAY 2023
Submit Document Feedback
TPS389006Q1EVM Multichannel Voltage Supervisor with I2C1
Copyright © 2023 Texas Instruments Incorporated

Figure 4-10. Fusion Scan Selection Window.............................................................................................................................21
Figure 4-11. Fusion Scan Window - Scanning for TPS389006Q1EVM.....................................................................................22
Figure 4-12. Fusion Scan Window - Scan for TPS389006Q1EVM Completed......................................................................... 22
Figure 4-13. Fusion Digital Power Device GUI - TPS389006Q1EVM (screenshot #1)............................................................. 23
Figure 4-14. Fusion Digital Power Device GUI - TPS389006Q1EVM (screenshot #2)............................................................. 23
Figure 4-15. Fusion Digital Power Device GUI - TPS389006Q1EVM (screenshot #3)............................................................. 24
Figure 4-16. TPS389006Q1EVM Monitoring Four Voltage Supply Rails...................................................................................25
Figure 4-17. TPS389006Q1EVM GUI Setup for Monitoring Four Voltage Supply Rails............................................................26
List of Tables
Table 2-1. Bill of Materials............................................................................................................................................................8
Table 3-1. Test Points................................................................................................................................................................ 13
Table 3-2. List of On-board Jumpers......................................................................................................................................... 14
Trademarks
All trademarks are the property of their respective owners.
Trademarks www.ti.com
2TPS389006Q1EVM Multichannel Voltage Supervisor with I2CSNVU785A – FEBRUARY 2022 – REVISED MAY 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

1 Introduction
The TPS389006Q1EVM is an evaluation module (EVM) for the TPS389006-Q1 Multichannel Overvoltage and
Undervoltage I2C Programmable Voltage Supervisor and Monitor. Test points are provided to give the user
additional access, if needed, for oscilloscope or multi-meter measurements.
The TPS389006Q1EVM comes pre-populated with TPS38900603NRTERQ1. This IC variant is configured for
six integrated multichannel window inputs to monitor six distinct input voltage rails with two remote sense
pins. The device also includes internal glitch immunity and noise filters to eliminate false resets resulting from
erroneous signals. The TPS389006-Q1 device does not require any external resistors for setting overvoltage
and undervoltage reset thresholds which optimizes and improves the reliability for safety systems.
I2C functionality gives flexibility in selecting thresholds, reset delays, glitch filters, and pin functionality. This
device offers CRC error checking, sequence logging during turn ON or turn OFF, and a built-in ADC for voltage
readouts to provide redundant error checking. In addition, TPS389006-Q1 offers a sync feature for tagging rails
coming up. Rail tagging works across multiple instances of TPS389006-Q1 devices. If users need a different
TPS389006-Q1 variant, the existing device must be removed from the board. The EVM board is designed to
support all possible options by changing jumper configurations and is capable of daisy-chaining, through 10-pin
ribbon, up to three evaluation boards.
Figure 1-1. TPS389006Q1EVM Board Top
www.ti.com Introduction
SNVU785A – FEBRUARY 2022 – REVISED MAY 2023
Submit Document Feedback
TPS389006Q1EVM Multichannel Voltage Supervisor with I2C3
Copyright © 2023 Texas Instruments Incorporated

Figure 1-2. TPS389006Q1EVM Board Bottom
1.1 Related Documentation
Data sheet: TPS389006-Q1 Multichannel Overvoltage and Undervoltage I2C Programmable Voltage Supervisor
and Monitor
1.2 TPS389006-Q1 Applications
•Advanced Driver Assistance System (ADAS)
•Sensor fusion
•Medical robotics
•Industrial robotics
Introduction www.ti.com
4TPS389006Q1EVM Multichannel Voltage Supervisor with I2CSNVU785A – FEBRUARY 2022 – REVISED MAY 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

2 Schematic, Bill of Materials, and Layout
This section provides a detailed description of the TPS389006Q1EVM schematic, bill of materials (BOM), and
layout.
www.ti.com Schematic, Bill of Materials, and Layout
SNVU785A – FEBRUARY 2022 – REVISED MAY 2023
Submit Document Feedback
TPS389006Q1EVM Multichannel Voltage Supervisor with I2C5
Copyright © 2023 Texas Instruments Incorporated

2.1 TPS389006Q1EVM Schematic
VAUX
R6
RCS06031R00FKEA
+
1
5
62
TLV4082DRYR
U4A
VAUX
1.0k
R7
VAUX
GND
10uF
25V
C2
GND
GND
25V
0.1µF
C1
P1V2
10uF
25V
C3
OUT 1
NC 2
GND 3
EN
4NC 5
IN
6
PAD 7
TLV75712PDRVR
U2
VDD
GND GND
10uF
25V
C5
GND
P1V8
1
2
J2
ED120/2DS
DNI
R3
GND
P1V8
10uF
25V
C4
PEXT
OUT 1
NC 2
GND 3
EN
4NC 5
IN
6
PAD 7
TLV75718PDRVR
U3
1
2 3
J4
EN/ACT
10.0k
R1
GND
NIRQ
GND
NSLEEP, [ESM / WDI] NSLEEP
P1V8
SCL
SDA
P1V8
10.0k
R2
DNI
R4
GND
GND
Super Red
21
D1
150060SS75000
1
2
J6
1
2
J5
VDD
8MON1 12
MON2 10
MON3 1
MON4 3
MON5 4
MON6 2
IRQ
13
ADDR
14
EN
5
EP 17
RS_1/2 11
SCL
16
SDA
15
SLEEP
7
SYNC 9
GND 6
TPS389006004RTERQ1
U1
1
2
J1
ED120/2DS
MON6/RS_3
MON5/RS_4
MON4
MON3
MON2
MON7/RS_1/2
MON1
GND GND GND GND
1
2
J3
ED120/2DS
GND
ADDR
SDA GND
SYNC
MON5
MON4
MON3
MON1
GND
GND
16V
1µF
C9
GND
GND
SCL
ADDR
MON1
MON2
VDD
NSLEEP
GND
MON5
SYNC/NRST/MON8
PEXT VDD
ADDR
SCL
NIRQ
EN
RS_1/2
MON2
MON6
SDA
NIRQ
RS_1/2
SYNC
EN
MON4
MON6
MON3
25V
0.1µF
C6
25V
0.1µF
C8
25V
0.1µF
C10
5.36k
R8
16.2k
R9
37.4k
R11
59.0k
R13
47.5k
R12
26.7k
R10
69.8k
R14
80.6k
R15
1
2
J10
1
2
J11
1
2
J12
1
2
J13
1
2
J14
1
2
J15
1
2
J16
1
2
J17
GND
10.0k
R5
10.0k
R20
PEXT P1V8
1 2 3
J35
+3
4
U4B
TLV4082DRYR
Rx
RCS06031R00FKEA
1.0k
Ry
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
GROUND
J7
QFN-16(24)BT-0.5-01-00
Super Red
21
D2
150060SS75000
VAUX
1
2
3
J36
VAUX
0
R21
0
R27
0
R22
0
R23
0
R24
0
R25
0
R26
0
R28
GND
DNI
50V
C19
DNI
50V
C20
DNI
50V
C21
DNI
50V
C22
DNI
50V
C23
DNI
50V
C24
DNI
50V
C25
DNI
50V
C26
16V
1µF
C27
GND
NIRQ
VDD
SYNC
GND GND GND GND
1
2 3
Q1
RUM001L02T2CL
GND
SYNC_PD
100
R31
10.0k
R32
Figure 2-1. TPS389006Q1EVM Main Schematic
Schematic, Bill of Materials, and Layout www.ti.com
6TPS389006Q1EVM Multichannel Voltage Supervisor with I2C SNVU785A – FEBRUARY 2022 – REVISED MAY 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

Figure 2-2. TPS389006Q1EVM I2C Schematic with Buffers
www.ti.com Schematic, Bill of Materials, and Layout
SNVU785A – FEBRUARY 2022 – REVISED MAY 2023
Submit Document Feedback
TPS389006Q1EVM Multichannel Voltage Supervisor with I2C 7
Copyright © 2023 Texas Instruments Incorporated

2.2 TPS389006Q1EVM Bill of Materials
Table 2-1. Bill of Materials
DESIGNATOR QTY VALUE DESCRIPTION PACKAGE
REFERENCE PART NUMBER MANUFACTURER
PCB 1 LP051 Printed Circuit Board TPS389006Q1EVM Any
C1, C6, C7, C8,
C10
5 0.1 µF CAP, CERM, 0.1 µF, 25 V,
+/- 10%, X5R, 0603
0603 CL10A104KA8NNNC Samsung Electro-
Mechanics
C2, C3, C4, C5,
C18
5 10 µF 10 µF ±10% 25 V Ceramic Capacitor
X7S 0805 (2012 Metric)
0805 C2012X7S1E106K125A
C
TDK
C9, C12, C14,
C17, C27
5 1 µF CAP, CERM, 1 µF, 16 V,+/- 10%, X7R,
AEC-Q200 Grade 1, 0805
0805 C0805C105K4RACAUT
O
Kemet
C11 1 0.1 µF CAP, CERM, 0.1 µF, 50 V, +/- 10%,
X7R, 0603
0603 06035C104KAT2A AVX
C13, C15,
C19(DNI),
C20(DNI),
C21(DNI),
C22(DNI),
C23(DNI),
C24(DNI),
C25(DNI),
C26(DNI)
2 0.1 µF CAP, CERM, 0.1 µF, 50 V, +/- 10%,
X7R, 0805 (C19 - C26 DO NOT
POPULATE)
0805 C0805C104K5RACTU Kemet
C16 1 10 µF 10 µF ±10% 10 V Ceramic Capacitor
X5R 0603 (1608 Metric)
0603 C1608X5R1A106K080A
C
TDK
D1, D2 2 Super Red LED, Super Red, SMD LED_0603 150060SS75000 Wurth Elektronik
EN/ACT, MON1,
MON2, MON3,
MON4, MON5/
RS_4, MON6/
RS_3, MON7,
NIRQ, NSLEEP/,
SYNC/NRST/
MON8,
SYNC_PD, TP6a,
TP6b, TP6c,
TP6d, TP_ADDR,
TP_EXT, VDD
19 Turret Terminal, Turret, TH, Triple Keystone
1598-2
1598-2 Keystone
GND1, GND2,
GND3, GND4
4 Test Point
(SMD)
Test Point, Miniature, SMT Miniature,
SMT
5019 Keystone
H1, H2, H3, H4 4 Bumpon
Pad
Bumpon, Hemisphere,
0.44 X 0.20, Clear
Transparent
Bumpon
SJ-5303 (CLEAR) 3M
J1, J2, J3 3 Terminal
Block
Terminal Block, 5.08 mm, 2x1, Brass,
TH
2x1 5.08 mm
Terminal
Block
ED120/2DS On-Shore
Technology
J4, J35, J36 3 Header Header, 100mil, 3x1, Gold, TH 3x1 Header TSW-103-07-G-S Samtec
J5, J6, J10, J11,
J12, J13, J14,
J15, J16, J17,
J19, J20, J21,
J22, J23, J24,
J26, J27, J28,
J29, J30, J31,
J32, J33, J34,
J37, J38, J39,
J40
29 Header Header, 100mil, 2x1, Gold, TH 2x1 Header TSW-102-07-G-S Samtec
J7 1 Socket QFN CLAMSHELL 16 PIN RTE
THRU HOLE WITH CENTER GND
16-Pin
Socket
QFN-16(24)BT-0.5-01 Enplas
J8, J18 2 Shrouded
Header
Header (shrouded), 100mil, 5x2,
Gold, TH
5x2
Shrouded
header
5103308-1 TE Connectivity
Schematic, Bill of Materials, and Layout www.ti.com
8TPS389006Q1EVM Multichannel Voltage Supervisor with I2CSNVU785A – FEBRUARY 2022 – REVISED MAY 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

Table 2-1. Bill of Materials (continued)
DESIGNATOR QTY VALUE DESCRIPTION PACKAGE
REFERENCE PART NUMBER MANUFACTURER
Q1 1 MOSFET MOSFET N-CH 20 V, 0.1 A, VMT3 SOT723 RUM001L02T2CL ROHM
Semiconductor
R1, R18, R19,
R32
4 10 kΩ RES, 10.0 kΩ, 1%, 0.1 W, 0603 0603 RC0603FR-0710KL Yageo
R2, R5, R20 3 10 kΩ RES, 10.0 kΩ, 1%, 0.1 W, 0603 0603 RCG060310K0FKEA Vishay Draloric
R3(DNI) 0 10 kΩ RES, DNP, 1%, 0.1 W, 0603 (DO
NOT POPULATE)
0603 RCG060310K0FKEA Vishay Draloric
R4(DNI) 0 21 kΩ RES, DNP, 1%, 0.1 W, 0603 (DO
NOT POPULATE)
0603 RC0603FR-0721KL Yageo
R6, Rx 2 1 Ω 1 Ohms ±1% 0.25 W, ¼
W Chip Resistor 0603 (1608
Metric) Automotive AEC-Q200, Pulse
Withstanding Thick Film
0603 RCS06031R00FKEA Vishay
R7, Ry 2 1 kΩ RES, 1.0 kΩ, 5%, 0.125 W, AEC-
Q200 Grade 0, 0805
0805 ERJ-6GEYJ102V Panasonic
R8 1 5.36 kΩ RES, 5.36 k, 1%, 0.125 W, AEC-
Q200 Grade 0, 0805
0805 ERJ-6ENF5361V Panasonic
R9 1 16.2 kΩ RES, 16.2 kΩ, 1%, 0.125 W, AEC-
Q200 Grade 0, 0805
0805 ERJ-6ENF1622V Panasonic
R10 1 26.7 kΩ RES, 26.7 kΩ, 1%, 0.125 W, AEC-
Q200 Grade 0, 0805
0805 ERJ-6ENF2672V Panasonic
R11 1 37.4 kΩ RES, 37.4 kΩ, 1%, 0.125 W, AEC-
Q200 Grade 0, 0805
0805 ERJ-6ENF3742V Panasonic
R12 1 47.5 kΩ RES, 47.5 kΩ, 1%, 0.125 W, AEC-
Q200 Grade 0, 0805
0805 ERJ-6ENF4752V Panasonic
R13 1 59 kΩ RES, 59 kΩ, 1%, 0.125 W, AEC-Q200
Grade 0, 0805
0805 ERJ-6ENF5902V Panasonic
R14 1 69.8 kΩ RES, 69.8 kΩ, 1%, 0.125 W, AEC-
Q200 Grade 0, 0805
0805 ERJ-6ENF6982V Panasonic
R15 1 80.6 kΩ RES, 80.6 kΩ, 1%, 0.125 W, AEC-
Q200 Grade 0, 0805
0805 ERJ-6ENF8062V Panasonic
R16, R17, R29,
R30
4 2.2 kΩ RES, 2.2 kΩ, 5%, 0.1 W, 0603 0603 RC0603JR-072K2L Yageo
R21, R22, R23,
R24, R25, R26,
R27, R28
8 0 Ω RES, 0 Ω, 5%, 0.125 W, 0805 0805 RC0805JR-070RL Yageo
R31 1 100 Ω RES, 100 Ω, 5%, 0.125 W, AEC-Q200
Grade 0, 0805
0805 ERJ-6GEYJ101V Panasonic
SCL, SDA 2 Test Points Test Point, Multipurpose, Purple, TH Purple
Multipurpose
Testpoint
5129 Keystone
U1 0 IC ASIL-D Multichannel Overvoltage
and Undervoltage I2C Programmable
Voltage Supervisor and Monitor
WQFN16 TPS389006004RTERQ1 TI
U2 1 IC 1 A Low-Quiescent-Current Low-
Dropout (LDO) Regulator, 1.2 V,
DRV0006A (WSON-6)
WSON-6 TLV75712PDRVR TI
U3 1 IC 1 A Low-Quiescent-Current Low-
Dropout (LDO) Regulator, 1.8
V,DRV0006A (WSON-6)
WSON-6 TLV75718PDRVR TI
U4 1 IC Dual-Channel, Low-Power
Comparator with Integrated
Reference
SON6 TLV4082DRYR TI
U5, U6 2 IC Automotive, Level-Shifting I2C Bus
Repeater, DGK0008A (VSSOP-8)
VSSOP-8
(DGK0008A)
TCA9517DGKRQ1 TI
www.ti.com Schematic, Bill of Materials, and Layout
SNVU785A – FEBRUARY 2022 – REVISED MAY 2023
Submit Document Feedback
TPS389006Q1EVM Multichannel Voltage Supervisor with I2C9
Copyright © 2023 Texas Instruments Incorporated

Table 2-1. Bill of Materials (continued)
DESIGNATOR QTY VALUE DESCRIPTION PACKAGE
REFERENCE PART NUMBER MANUFACTURER
FID1, FID2, FID3 0 Fiducial mark. There is nothing to buy
or mount.
Fiducial N/A N/A
Schematic, Bill of Materials, and Layout www.ti.com
10 TPS389006Q1EVM Multichannel Voltage Supervisor with I2CSNVU785A – FEBRUARY 2022 – REVISED MAY 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

2.3 Layout and Component Placement
Figure 2-3 and Figure 2-4 show the top and bottom assemblies of the printed circuit board (PCB) to show the
component placement on the EVM.
Figure 2-5 and Figure 2-6 show the top and bottom layouts, Figure 2-7 and Figure 2-8 show the top and bottom
layers, and Figure 2-9 and Figure 2-10 shows the top and bottom solder masks of the EVM.
2.4 Layout
Figure 2-3. Component Placement—Top Assembly Figure 2-4. Component Placement—Bottom
Assembly
Figure 2-5. Layout—Top Figure 2-6. Layout—Bottom
www.ti.com Schematic, Bill of Materials, and Layout
SNVU785A – FEBRUARY 2022 – REVISED MAY 2023
Submit Document Feedback
TPS389006Q1EVM Multichannel Voltage Supervisor with I2C11
Copyright © 2023 Texas Instruments Incorporated

Figure 2-7. Top Layer Figure 2-8. Bottom Layer
Figure 2-9. Top Solder Mask Figure 2-10. Bottom Solder Mask
Schematic, Bill of Materials, and Layout www.ti.com
12 TPS389006Q1EVM Multichannel Voltage Supervisor with I2CSNVU785A – FEBRUARY 2022 – REVISED MAY 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

3 EVM Connectors
This section describes the connectors, jumpers, and test points on the EVM as well as how to connect, set up,
and properly use the EVM. Each device has an independent supply connection, but all grounds are connected
on the board.
3.1 EVM Test Points
Table 3-1 lists the EVM test points as well as their functional descriptions. All TPS389006-Q1 pins have
a corresponding test point on the EVM. These test points are located close to the pins for more accurate
measurements. In addition to the test points listed below, the EVM also has four additional GND test points.
Table 3-1. Test Points
TEST POINT
SILKSCREEN LABEL FUNCTION DESCRIPTION
MON1 Connection to MON1 pin Allows the user to monitor voltage rail #1
MON2 Connection to MON2 pin Allows the user to monitor voltage rail #2
MON3 Connection to MON3 pin Allows the user to monitor voltage rail #3
MON4 Connection to MON4 pin Allows the user to monitor voltage rail #4
MON5/RS_4 Connection to MON5 pin Allows the user to monitor voltage rail #5
MON6/RS_3 Connection to MON6 pin Allows the user to monitor voltage rail #6
MON7/RS_1/2 Connection to RS_1/2 pin Allows the user to remote sense MON1 or MON2
SYNC/NRST/MON8 Connection to SYNC pin SYNC pin indicates the number of monitored rails that have exited
fault status and assigns tag values to each monitor voltage rail
SYNC_PD Connection to SYNC_PD
Forcing the SYNC pin to toggle during test and increments an
internal tag counter for each of the monitored channel (for debug
purposes only)
ADDR Connection to ADDR pin Allows the user to measure the I2C address voltage
NIRQ Connection to NIRQ pin Allows the user to monitor the interrupt (NIRQ) output
EN/ACT Connection to ACT pin Allows the user to set the ACT input to VDD or GND
SLEEP/ESM/WDI Connection to SLEEP pin Allows the user to set SLEEP input
SCL Connection to SCL pin Allows the user to monitor the clock signal input
SDA Connection to SDA pin Allows the user to monitor the data signal input
PEXT External power supply Allows the user to apply a power supply voltage that is not provided
from the EVM
GND GND for EVM GND for EVM
www.ti.com EVM Connectors
SNVU785A – FEBRUARY 2022 – REVISED MAY 2023
Submit Document Feedback
TPS389006Q1EVM Multichannel Voltage Supervisor with I2C13
Copyright © 2023 Texas Instruments Incorporated

3.2 EVM Jumpers
Table 3-2 lists the jumpers on the TPS389006Q1EVM. As ordered, the EVM has thirty-five (35) jumpers
installed. Figure 3-1 is provided as visual aid.
Table 3-2. List of On-board Jumpers
JUMPER JUMPER CONFIGUATION DESCRIPTION
J1 VAUX For connecting VAUX power to the EVM
J2 VDD For connecting VDD power to the EVM
J3 GND For connecting GND to the EVM
J4 Shunted (default) Pin 2 to Pin 3 For connecting ACT, NIRQ, and SLEEP to P1V8 or PEXT (Any external power)
J5 and J6 Open For manually pulling down SLEEP and ACT pins to GND
J10, J11, J12,
J13, J14, J15,
J16, and J17
J15 shunted Shunting any one of J10-J17 jumpers selects the I2C address for TPS389006-Q1 IC on
the EVM
J19, J20, and
J21 Open
For connecting to the on-board I2C buffer and pull-up voltage rail to either P1V8, PEXT
or P1V2. Only shunt one of these jumpers at a time. Please remove the shunt of J22
when using one of these jumpers.
J22 Shunt
For connecting to the on-board, buffer I2C and pull-up voltage rail to P3V3. During
daisy-chain configuration, J22 needs to be shunted and J19, J20, and J21 needs to be
open on the secondary EVMs.
J23 Shunted Disables (U5) I2C buffer
J24 Open Connects PEXT to VAUX
J26 and J29 Shunted Shunting both J26 and J29 bypasses the I2C (U5) buffer for SDA and SCL signal lines
J27, J28, J30,
and J31
Open Shunting these jumpers buffers SCL and SDA I2C signal lines by using the on-board
(U5) buffer.
J32 and J33 Shunted Shunting both J32 and J33 bypasses the I2C (U6) buffer for SDA and SCL signal lines
J34 Shunted Disables (U6) I2C buffer
J35 Shunted (default) Pin 1 to Pin 2 SYNC pin is pulled up to P1V8
J36 Shunted (default) Pin 2 to Pin 3 Input to one of (U4) comparators to indicate the SYNC pin has tagged a voltage rail that
is not in a fault condition
J37, J38, J39,
J40
Open If multiple EVMs are connected in a daisy-chain configuration, then the following EVM
boards needs to have J37, J38, J39, and J40 all shunted. By shunting these jumpers,
VDD, VAUX, SYNC, and NIRQ signals is provided as inputs from the primary EVM
board. Also, J22 needs to be shunted and J19, J20, and J21 needs to be open on the
secondary EVMs during daisy-chain configuration.
Figure 3-1. TPS389006Q1EVM Jumper Locations
EVM Connectors www.ti.com
14 TPS389006Q1EVM Multichannel Voltage Supervisor with I2CSNVU785A – FEBRUARY 2022 – REVISED MAY 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

4 EVM Setup and Operation
This section describes the functionality and operation of the TPS389006Q1EVM. Refer to the TPS389006-Q1
Multichannel Overvoltage and Undervoltage I2C Programmable Voltage Supervisor and Monitor data sheet for
details on the electrical characteristics of the device.
The TPS389006Q1EVM comes with the TPS38900603NRTERQ1 IC meaning the device is capable of
monitoring up to six separate voltage rails. The EVM is capable of many different configurations to fully
evaluate the functionality of all the TPS389006-Q1 device variants. The default jumper configuration of the
TPS389006Q1EVM is mentioned in Table 3-2.
The TPS389006Q1EVM comes with USB to GPIO connector, I2C bus repeaters, comparators, two LDOs, socket
and solder down footprints, the ability to monitor up to eight (8) voltage rails, the option to daisy-chain up to
three EVMs at a time via 10-pin connector, jumper selectable I2C address, I2C pullup voltage options, and
TPS38900603NRTERQ1 IC. The TPS389006Q1EVM also provides the ability for each monitored rail to be
voltage divided down by resistor dividers on each of the monitored and input lines. The user must choose
appropriately sized resistors such that the divided voltage is above, below or within the window of the voltage
threshold depending on the type of input sensing topology is setup for each monitored input channel. Consult the
Device Threshold Table in the TPS389006-Q1 data sheet to verify proper voltage monitored values.
The TPS389006Q1EVM is designed to be daisy-chain where the primary board is connected to the USB to
GPIO connector (J18) and the output connector (J8) provides VDD, VAUX, SYNC, SCL, SDA, NIRQ, and GND
to the (J18) connector of the secondary board through a 10-pin ribbon cable. When the daisy-chain option
is being used, jumpers on the secondary board (J19-J22 and J37-J40) must be configured properly or else
possible damage to the IC or EVM can occur. Jumper settings of J19, J20, and J21 must be left open whereas
J22, J37, J38, J39, and J40 need to be shunted with jumpers for proper setup of the secondary board during
daisy-chain setup. Also, the I2C rail voltage for the secondary board in the daisy-chain mode is defined as
VI2CPULLUP = VAUX = 3.3 V. See Figure 2-2 for reference.
Equipment Needed for TPS389006Q1EVM Evaluation:
• TPS389006Q1EVM
• TI's USB Interface Adapter (with ribbon cable)
• Power Supply (3.3 V)
• Multimeters
• Multi-channel Oscilloscope (review evaluation waveforms)
• Jumper Wires/Cables
www.ti.com EVM Setup and Operation
SNVU785A – FEBRUARY 2022 – REVISED MAY 2023
Submit Document Feedback
TPS389006Q1EVM Multichannel Voltage Supervisor with I2C15
Copyright © 2023 Texas Instruments Incorporated

4.1 Setup and GUI Installations
4.1.1 TPS389006Q1EVM Hardware Setup
Follow the steps below for TPS389006Q1EVM hardware setup:
1. Connect VAUX (J1) and VDD (J2) to 3.3 V from the power supply.
2. Connect GND (J3) to ground from the power supply.
3. Make sure the jumpers are connected as per the guidelines in the Table 3-2.
4. Before allowing the output of the power supply to be engaged, check if the power supply voltage is set at
3.3 V and the power supply output current is limited to 10 mA.
5. Connect the TI's USB Interface Adapter to J18 (USB2GPIO Connector) using a 10-pin ribbon cable.
6. Connect the TI's USB Interface Adapter to the computer's USB port.
7. Connect any voltage supply rail that needs monitoring to any of the voltage monitoring inputs (MON1 -
MON8).
8. The description of the TPS389006Q1EVM connections can be found in Figure 4-1.
Figure 4-1. TPS389006Q1EVM Connection Description
EVM Setup and Operation www.ti.com
16 TPS389006Q1EVM Multichannel Voltage Supervisor with I2CSNVU785A – FEBRUARY 2022 – REVISED MAY 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

4.1.2 TPS389006Q1EVM Software Setup
Follow the steps below for TPS389006Q1EVM GUI software installation:
1. Download the Fusion Digital Power Designer Platform GUI for TPS389006Q1EVM.
2. Open the downloaded file.
3. In the Welcome Wizard window, click Next.
4. Accept the license agreement and then click Next.
Figure 4-2. Setup License Agreement Window
5. The default destination folder works best. Click Next.
Figure 4-3. Setup Destination Window
www.ti.com EVM Setup and Operation
SNVU785A – FEBRUARY 2022 – REVISED MAY 2023
Submit Document Feedback
TPS389006Q1EVM Multichannel Voltage Supervisor with I2C17
Copyright © 2023 Texas Instruments Incorporated

6. Click Next for the Select Start Menu Folder option.
Figure 4-4. Setup Window - Start Menu Selection
7. There is no need to install additional options for this EVM. Click Next.
Figure 4-5. Setup Window - Additional Tasks
EVM Setup and Operation www.ti.com
18 TPS389006Q1EVM Multichannel Voltage Supervisor with I2CSNVU785A – FEBRUARY 2022 – REVISED MAY 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

8. Finally click Install to install the Fusion software.
Figure 4-6. Setup Installation Window
9. Click on Finish to complete the installation setup and launch the software.
Figure 4-7. Installation Complete Window
www.ti.com EVM Setup and Operation
SNVU785A – FEBRUARY 2022 – REVISED MAY 2023
Submit Document Feedback
TPS389006Q1EVM Multichannel Voltage Supervisor with I2C19
Copyright © 2023 Texas Instruments Incorporated

4.2 Quick Start to TPS389006Q1EVM GUI
Please follow the steps below precisely to quickly evaluate the TPS389006-Q1. In this quick start, the
TPS389006Q1EVM is se tup to monitor several power supply rails after the ACT pin is triggered.
1. Make the hardware connections and software installation described in Section 4.1 have been completed.
Feel free to skip the GUI installation if the Fusion Digital Power Designer for TPS389006Q1EVM GUI has
been installed already.
2. Power the EVM by turning on the power supply. Note that the voltage and current limits at the power supply
is set at 3.3 V and 10 mA.
3. Once the TI's USB Interface Adapter is connected to EVM and the laptop, launch the evaluation software
Fusion Digital Power Designer.
4. Click on I2C GUI on the bottom right of GUI.
Figure 4-8. Fusion Welcome Window
EVM Setup and Operation www.ti.com
20 TPS389006Q1EVM Multichannel Voltage Supervisor with I2CSNVU785A – FEBRUARY 2022 – REVISED MAY 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated
