Texas Instruments TPS61130EVM User manual

TPS61130EVM
May 2003 PMP Portable Power
User’s Guide
SLVU086

IMPORTANT NOTICE
Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications,
enhancements, improvements, and other changes to its products and services at any time and to discontinue
any product or service without notice. Customers should obtain the latest relevant information before placing
orders and should verify that such information is current and complete. All products are sold subject to TI’s terms
and conditions of sale supplied at the time of order acknowledgment.
TI warrants performance of its hardware products to the specifications applicable at the time of sale in
accordance with TI’s standard warranty. Testing and other quality control techniques are used to the extent TI
deems necessary to support this warranty. Except where mandated by government requirements, testing of all
parameters of each product is not necessarily performed.
TI assumes no liability for applications assistance or customer product design. Customers are responsible for
their products and applications using TI components. To minimize the risks associated with customer products
and applications, customers should provide adequate design and operating safeguards.
TI does not warrant or represent that any license, either express or implied, is granted under any TI patent right,
copyright, mask work right, or other TI intellectual property right relating to any combination, machine, or process
in which TI products or services are used. Information published by TI regarding third–party products or services
does not constitute a license from TI to use such products or services or a warranty or endorsement thereof.
Use of such information may require a license from a third party under the patents or other intellectual property
of the third party, or a license from TI under the patents or other intellectual property of TI.
Reproduction of information in TI data books or data sheets is permissible only if reproduction is without
alteration and is accompanied by all associated warranties, conditions, limitations, and notices. Reproduction
of this information with alteration is an unfair and deceptive business practice. TI is not responsible or liable for
such altered documentation.
Resale of TI products or services with statements different from or beyond the parameters stated by TI for that
product or service voids all express and any implied warranties for the associated TI product or service and
is an unfair and deceptive business practice. TI is not responsible or liable for any such statements.
Mailing Address:
Texas Instruments
Post Office Box 655303
Dallas, Texas 75265
Copyright 2003, Texas Instruments Incorporated

EVM IMPORTANT NOTICE
Texas Instruments (TI) provides the enclosed product(s) under the following conditions:
This evaluation kit being sold by TI is intended for use for ENGINEERING DEVELOPMENT OR EVALUATION
PURPOSES ONLY and is not considered by TI to be fit for commercial use. As such, the goods being provided
may not be complete in terms of required design-, marketing-, and/or manufacturing-related protective
considerations, including product safety measures typically found in the end product incorporating the goods.
As a prototype, this product does not fall within the scope of the European Union directive on electromagnetic
compatibility and therefore may not meet the technical requirements of the directive.
Should this evaluation kit not meet the specifications indicated in the EVM User’s Guide, the kit may be returned
within 30 days from the date of delivery for a full refund. THE FOREGOING WARRANTY IS THE EXCLUSIVE
WARRANTY MADE BY SELLER TO BUYER AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED,
IMPLIED, OR STATUTORY, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR ANY
PARTICULAR PURPOSE.
The user assumes all responsibility and liability for proper and safe handling of the goods. Further, the user
indemnifies TI from all claims arising from the handling or use of the goods. Please be aware that the products
received may not be regulatory compliant or agency certified (FCC, UL, CE, etc.). Due to the open construction
of the product, it is the user’s responsibility to take any and all appropriate precautions with regard to electrostatic
discharge.
EXCEPT TO THE EXTENT OF THE INDEMNITY SET FORTH ABOVE, NEITHER PARTY SHALL BE LIABLE
TO THE OTHER FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES.
TI currently deals with a variety of customers for products, and therefore our arrangement with the user is not
exclusive.
TI assumes no liability for applications assistance, customer product design, software performance, or
infringement of patents or services described herein.
Please read the EVM User’s Guide and, specifically, the EVM Warnings and Restrictions notice in the EVM
User’s Guide prior to handling the product. This notice contains important safety information about temperatures
and voltages. For further safety concerns, please contact the TI application engineer.
Persons handling the product must have electronics training and observe good laboratory practice standards.
No license is granted under any patent right or other intellectual property right of TI covering or relating to any
machine, process, or combination in which such TI products or services might be or are used.
Mailing Address:
Texas Instruments
Post Office Box 655303
Dallas, Texas 75265
Copyright 2003, Texas Instruments Incorporated

EVM WARNINGS AND RESTRICTIONS
It is important to operate this EVM within the input voltage range of 3.0 V to 5.5 V and the output
voltage range of 2.5 V to 5.5 V for the SEPIC output and 0.9 V to 5.5 V for the LDO output.
Exceeding the specified input range may cause unexpected operation and/or irreversible
damage to the EVM. If there are questions concerning the input range, please contact a TI
field representative prior to connecting the input power.
Applying loads outside of the specified output range may result in unintended operation and/or
possible permanent damage to the EVM. Please consult the EVM User’s Guide prior to
connecting any load to the EVM output. If there is uncertainty as to the load specification,
please contact a TI field representative.
During normal operation, some circuit components may have case temperatures greater than
85°C. The EVM is designed to operate properly with certain components above 60°C as long
as the input and output ranges are maintained. These components include but are not limited
to linear regulators, switching transistors, pass transistors, and current sense resistors. These
types of devices can be identified using the EVM schematic located in the EVM User’s Guide.
When placing measurement probes near these devices during operation, please be aware
that these devices may be very warm to the touch.
Mailing Address:
Texas Instruments
Post Office Box 655303
Dallas, Texas 75265
Copyright 2003, Texas Instruments Incorporated

Related Documentation From Texas Instruments
v
Preface

About This Manual
This user’s guide describes the characteristics, operation, and use of the
TPS61130EVM–206 SEPIC evaluation module (EVM). This EVM is a Texas
Instruments high-efficiency, single Li-Ion input, dual output (SEPIC and LDO)
converter that is configured to deliver 3.3 V at 300 mA and 1.5 V at 200 mA.
The 3.3-V output is provided by the SEPIC converter and the 1.5-V output is
provided by the integrated LDO. This user’s guide includes setup instructions,
a schematic diagram, a bill of materials (BOM), and PCB layout drawings for
the evaluation module.
How to Use This Manual
This document contains the following chapters:
-Chapter 1—Introduction
-Chapter 2—Setup
-Chapter 3—Board Layout
-Chapter 4—Schematic and Bill of Materials
Related Documentation From Texas Instruments
TPS61130 data sheet (SLVS431)
If You Need Assistance. . .
Contact your local TI sales representative.

Contents
vi
FCC Warning
This equipment is intended for use in a laboratory test environment only. It gen-
erates, uses, and can radiate radio frequency energy and has not been tested
for compliance with the limits of computing devices pursuant to subpart J of
part 15 of FCC rules, which are designed to provide reasonable protection
against radio frequency interference. Operation of this equipment in other en-
vironments may cause interference with radio communications, in which case
the user at his own expense will be required to take whatever measures may
be required to correct this interference.

Contents
vii

1 Introduction 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Setup 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1 Input/Output Connector Descriptions 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.1 J1 –VBAT 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.2 J2 –GND 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.3 J3 –VOUT 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.4 J4 –GND 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.5 J5 –LDOOUT 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.6 J6 –GND 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.7 J7 –PGOOD, LBO 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.8 JP1 –SKIPEN 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.9 JP2 –EN 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.10 JP3 –LDOEN 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.11 JP4 –LDOIN 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Setup 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Operation 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Board Layout 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1 Layout 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Schematic and Bill of Materials 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1 Schematic 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2 Bill of Materials 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents
viii

3–1 Top Layer 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–2 Bottom Layer 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–3 Top Assembly 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4–1 TPS61130EVM–206 Schematic 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4–1. TPS61130EVM–206 Bill of Materials 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-1

The Texas Instruments TPS61130EVM evaluation module (EVM) helps
designers evaluate the operation and performance of the TPS61130 family of
devices. These devices are high efficiency SEPIC converters that offer an
integrated LDO.
This EVM is specifically designed and optimized to operate from a Li-Ion input
(3.0 V to 4.2 V). Operation at input voltages less than 3.0 V is possible with
reduced output current. The default output voltages of this EVM are 3.3 V for
the SEPIC output and 1.5 V for the LDO output. If desired, this EVM can easily
be modified to supply higher or lower output voltages. The SEPIC converter
can be set up to provide an output voltage between 2.5 V and 5.5 V. The LDO
can be set up to provide an output voltage between 0.9 V and 5.5 V. Output
voltages other than the default values may be evaluated by adjusting the
appropriate feedback resistor dividers. Also, other fixed output voltage
versions of the devices can be easily evaluated using this EVM. Refer to the
data sheet (SLVS431) for the various fixed output voltage options available in
the TPS6113x device family as well as for more information on adjusting the
output voltage.
Chapter 1

1-2

2-1
Setup

This chapter describes the jumpers and connectors on the EVM as well as how
to properly connect, setup, and use the TPS61130EVM–206.
Topic Page
2.1 Input/Output Connector Descriptions 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Setup 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Operation 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 2

Input/Output Connector Descriptions
2-2
2.1 Input/Output Connector Descriptions
2.1.1 J1 – VBAT
This is the positive connection to the input power supply. The leads to the input
supply should be twisted and kept as short as possible to minimize EMI
transmission.
2.1.2 J2 – GND
This is the return connection for the input power supply.
2.1.3 J3 – VOUT
This is the positive connection from the output of the SEPIC power supply.
Connect this pin to the positive input of the load.
2.1.4 J4 – GND
This is the negative connection from the output of the SEPIC power supply.
Connect this pin to the negative input of the load.
2.1.5 J5 – LDOOUT
This is the positive connection from the output of the LDO power supply.
Connect this pin to the positive input of the load.
2.1.6 J6 – GND
This is the negative connection from the output of the LDO power supply.
Connect this pin to the negative input of the load.
2.1.7 J7 – PGOOD, LBO
Pin 1 of this jumper is the PGOOD output of the TPS61130. Pin 2 of this jumper
is the LBO output of the TPS61130. Both signals are pulled up to Vout through
a 1-MΩresistor on the PCB.
2.1.8 JP1 – SKIPEN
This jumper enables or disables SKIPEN by connecting the shorting jumper
to either the ON or OFF position. With SKIPEN set ON the part goes into a
more efficient pulse skip mode of operation at light loads.
2.1.9 JP2 – EN
This jumper enables and disables the SEPIC portion of the EVM.
2.1.10 JP3 – LDOEN
This jumper enables and disables the LDO portion of the EVM.

Setup
2-3
Setup
2.1.11 JP4 –LDOIN
This is the input connection to the integrated LDO of the TPS61130. Shorting
the VBAT pin and the center pin connects the VBAT input of the EVM to the
LDOIN on the TPS61130. Shorting the VOUT pin and the center pin connects
the VOUT pin of the EVM to the LDOIN on the TPS61130. This jumper may
be removed and any voltage up to 5.5 V can be applied to the input of the LDO
by directly connecting a voltage source to the center pin of JP4.
2.2 Setup
Connect an input supply between J1 and J2. The voltage range on this supply
should stay between 3.0 V and 5.5 V. Connect a load for the SEPIC converter
between J3 and J4. Connect a load for the LDO between J5 and J6. Configure
the SKIPEN jumper to the desired setting. Configure JP4 to provide power to
the LDO from the desired source.
2.3 Operation
The EVM has been optimized to operate from a Li-Ion battery input voltage
range (3.0 V to 4.2 V). The SEPIC output voltage is set to 3.3 V and is capable
of supplying 300 mA. The LDO output is set to 1.5 V and is capable of supplying
200 mA. After connecting the input and output connections, and setting the
SKIPEN jumper (JP1) to the desired setting, turn on the input supply, and then
enable the outputs as desired with JP2 and JP3.
The resistor divider on the LBI pin is designed to trip the LBO output when the
input supply voltage drops below 2.9 V.

2-4

3-1
Board Layout
 
This chapter provides the TPS61130EVM–206 board layout and illustrations.
Topic Page
3.1 Layout 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 3

Layout
3-2
3.1 Layout
Board layout is critical for all switch mode power supplies. Figures 1, 2, and
3 show the board layout for the TPS61130EVM–206 PWB. The nodes with
high switching frequencies and currents are short and are isolated from the
noise sensitive feedback circuitry. Careful attention has been given to the rout-
ing of high frequency current loops. Refer to the data sheet for specific layout
guidelines.
Figure 3–1.Top Layer
Figure 3–2.Bottom Layer

Layout
3-3
Board Layout
Figure 3–3.Top Assembly

3-4

4-1
Schematic and Bill of Materials
    
This chapter provides the TPS61130EVM–206 schematic and bill of materials.
Topic Page
4.1 Schematic 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2 Bill of Materials 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 4

Schematic
4-2
4.1 Schematic
Figure 4–1.TPS61130EVM–206 Schematic
+
4.2 Bill of Materials
Table 4–1.TPS61130EVM–206 Bill of Materials
COUNT Ref Des DESCRIPTION SIZE MFR PART NUMBER
3C1, C5, C6 Capacitor, ceramic, 2.2-µF, 6.3-V,
X5R, 10% 805 Murata GRM21BR60J225KC01B
1 C3 Capacitor, ceramic, 10-µF, 6.3-V,
X5R, 10% 805 Murata GRM21BR60J106KE01
1 C4 Capacitor, tantalum, 120-µF, 10-V,
140-mΩ, 20% 7343 (D) Vishay 595D127X0010D2T
1 C7 Capacitor, ceramic, 22-µF, 10-V,
X5R, 10% 1210 Murata GRM32ER61A226KA65
7J1–J7 Header, 2-pin, 100-mil spacing,
(36-pin strip) 0.100 In x 2 In Sullins PTC36SAAN
4 JP1–JP4 Header, 3-pin, 100-mil spacing,
(36-pin strip) 0.100 In x 3 In Sullins PTC36SAAN
1 L1 Inductor, SMT, 22-µH, 811-mA,
429-mΩ0.300 In x 0.300 In Coiltronics DRQ74–220
1 R1 Resistor, chip, 845-kΩ, 1/16-W, 1% 603 Std Std
3R2, R4, R6 Resistor, chip, 178-kΩ, 1/16-W, 1% 603 Std Std
3R3, R7, R9 Resistor, chip, 1-MΩ, 1/16-W, 1% 603 Std Std
1 R5 Resistor, chip, 357-kΩ, 1/16-W, 1% 603 Std Std
1 U1 IC, single cell or dual cell Li-Ion
boost/sepic converter TSSOP-16 TI TPS61130PW
1–– PCB, 2.6 In x 1.6 In x 0.062 In Any SLVP206
4–– Shunt, 100-mil, black 0.100 In 3M 929950–00
