Read This First

About This Manual
This users guide describes the characteristics, operation, and use of the
TPS61040EVM LCD bias supply evaluation module (EVM). This EVM is a
Texas Instruments high-efficiency boost converter that is configured to
generate 18 V at 20 mA, for LCD bias supply, from a single cell Li−Ion battery.
The users guide includes a schematic diagram, bill of materials (BOM), and
test data.
How to Use This Manual
This document contains the following chapters:
-Chapter 1—Introduction
-Chapter 2—Setup and Test Results
-Chapter 3—Board Layout
-Chapter 4—Schematic and Bill of Materials
Related Documentation From Texas Instruments
-TPS601040/41 data sheet (literature number SLVS413).
FCC Warning
This equipment is intended for use in a laboratory test environment only. It
generates, uses, and can radiate radio frequency energy and has not been
tested for compliance with the limits of computing devices pursuant to subpart
J of part 15 of FCC rules, which are designed to provide reasonable protection
against radio frequency interference. Operation of this equipment in other
environments may cause interference with radio communications, in which
case the user at his own expense will be required to take whatever measures
may be required to correct this interference.

vi

Running Title—Attribute Reference
vii
Contents

1 Introduction 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1 Background 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Performance Specification Summary 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Setup and Test Results 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1 Input/Output Connections 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 EVM Operation 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Start-Up 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.4 Output Voltage Ripple 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.5 Switching Waveforms 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.6 Input Voltage Ripple 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.7 Efficiency 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.8 Output Adjust 2-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.8.1 Variable Resistor Output Voltage Adjust 2-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.8.2 Variable Control Voltage Output Voltage Adjust 2-6. . . . . . . . . . . . . . . . . . . . . . . . . .
3 Board Layout 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1 Layout 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Schematic and Bill of Materials 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1 Schematic 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2 Bill of Materials 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−1 Start-Up Waveforms 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2−2 Output Ripple 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2−3 SW Waveform 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2−4 Input Ripple Voltage 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2−5 Typical Efficiency 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3−1 Assembly Layer 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3−2 Top Layer Routing 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3−3 Bottom Layer Routing 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4−1 TPS61040EVM−001 Schematic 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Running Title—Attribute Reference
viii

1−1 TPS61040 Performance Specification Summary 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2−1 Input/Output Connections 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4−1 TPS61040EVM−001 Bill of Materials 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-1
Introduction

This chapter contains background information for the TPS61040 and support
documentation for the TPS61040EVM−001 evaluation module.
Topic Page
1.1 Background 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Performance Specification Summary 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 1

Background
1-2 Introduction
1.1 Background
This TPS61040EVM uses the TPS61040 boost converter to generate an 18-V
output from a single cell Li-Ion battery (3 V to 4.2 V). This EVM operates over
an input voltage range of 1.8 V to 6 V, but has been optimized over the 3-V to
5-V input range. Operation with an input voltage down to 1.8 V is possible,
depending on the output current and voltage settings. The EVM includes an
adjust pin that allows the user to adjust the LCD bias with either a variable
resistance or an analog voltage.
The output voltage of the TPS61040EVM can be adjusted up to 28 V by
modifying the resistor values used in resistor divider R1 & R2. The EVM can
also be configured for higher or lower output currents. For lower currents, the
TPS61040 may be replaced by the pin for pin compatible TPS61041. More
information about output voltage adjustment and current ratings of
TPS61040/41 devices can be found in the data sheet Literature Number
SLVS413.
1.2 Performance Specification Summary
Table 1−1 provides a summary of the TPS61040EVM−001 performance
specifications. All specifications are given for an ambient temperature of 25°C.
The EVM may be modified to operate over different input and output currents
and voltages, per the TPS61040 data sheet specifications.
Table 1−1.TPS61040 Performance Specification Summary
Specification Test Conditions Min Typ Max Unit
Input voltage range IO= 20 mA 3 5 V
Output voltage 18 V
Output current 5 20 mA
Output voltage ripple 100 mV
Efficiency 88.5%

2-1
Setup and Test Results
   
This chapter describes how to properly connect, setup, and use the
TPS61040EVM−001. This chapter also presents the test results for this EVM.
Topic Page
2.1 Input/Output Connections 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 EVM Operation 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Start-Up 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.4 Output Voltage Ripple 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.5 Switching Waveforms 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.6 Input Voltage Ripple 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.7 Efficiency 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.8 Output Adjust 2-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 2

Input/Output Connections
2-2 Setup and Test Results
2.1 Input/Output Connections
The TPS61040EVM−001 PWB has several connections, which are described
in Table 2−1.
Table 2−1.Input/Output Connections
Reference
Designator Name Description
J1 Vin This is the positive connection to the input power supply. The leads to the input
supply should be twisted and kept as short as possible.
J2 GND This is the return connection to the input power supply.
J3 Adjust
A variable resistor may be connected between J3−1 and J3−2 to vary the output
voltage of the EVM. J3−1 has a square pad and is connected directly to the FB pin
of the TPS61040. J3−2 has a round pad and is connected directly to ground. The
output voltage may also be adjusted by connecting an analog voltage through a
resistor to J3−1.
J4 GND This is the return pin for the load.
J5 Vout This is the positive connection for the load.
JP1 Enable
Use this connector to enable and disable the power supply. Connect a jumper
between the ON pin and the center pin to enable the supply, and connect a jumper
between the Off pin and the center pin to disable the supply. When the EN pin of the
TPS61040 is left open, its state is undetermined. The jumper must either be
connected to On (Vin) or to Off (GND) for the EVM to operate correctly.
2.2 EVM Operation
Connect an input supply and a load to the appropriate connectors provided on
the EVM. The absolute maximum input voltage is 7 V. The TPS61040 is
designed to operate with a maximum 6-V input voltage. Move the adjust
jumper from the Off position to the On position to enable the supply.
Placing a variable resistor across the adjust pins of the EVM allows the user
to vary the output voltage. Specific design equations may be found in the
TPS61040 data sheet.
2.3 Start-Up
Figure 2−1 shows the startup voltage and current waveforms of the EVM.
When the EVM is enabled, the TPS61040 goes through its programmed
three-stage soft-start sequence to reduce inrush current at turn on.

Output Voltage Ripple
2-3
Setup and Test Results
Figure 2−1.Start-Up Waveforms
2.4 Output Voltage Ripple
Figure 2−2 shows the output voltage ripple with IO= 20 mA. The top trace
shows the ripple with 3.6-V input, and the bottom trace shows the ripple with
a 4.2-V input. The difference in switching frequency between the two traces
is expected and is explained in the data sheet.
Figure 2−2.Output Ripple

Switching Waveforms
2-4 Setup and Test Results
2.5 Switching Waveforms
Figure 2−3 shows the switching waveform at the SW pin of the TPS61040.
When the internal FET turns on, the voltage at the SW pin is pulled to ground
until the inductor current reaches 450 mA. When the inductor current reaches
450 mA, the FET turns off and the voltage at the SW pin rises to the output
voltage plus the forward voltage drop of the diode. During this time, the
inductor transfers its stored energy to the load and the output capacitor. When
the inductor current decays to zero, the SW node rings at a frequency
determined by the output inductor and the drain capacitance of the internal
FET. This ringing is indicative of a discontinuous boost power supply topology.
Figure 2−3.SW Waveform
2.6 Input Voltage Ripple
Figure 2−4 shows the input voltage and current ripple of the supply with
Vin = 3.6 V and IO= 20 mA. The input capacitance of the TPS61040 and the
impedance of the input voltage supply largely determine the input voltage and
current ripple. Increasing the input capacitance or lowering the source
impedance reduces the input voltage and current ripple.

Efficiency
2-5
Setup and Test Results
Figure 2−4.Input Ripple Voltage
Input Ripple Voltage
Input Ripple Current
2.7 Efficiency
Figure 2−5 shows the measured efficiency of the TPS61040.
Figure 2−5.Typical Efficiency
80
81
82
83
84
85
86
87
88
89
90
2.5 5 7.5 10 12.5 15 17.5 20
VI= 6 V
VI= 4.2 V
VI= 3.6 V
VI= 2.5 V
Efficiency − %
IO− Output Current − mA

Output Adjust
2-6 Setup and Test Results
2.8 Output Adjust
The TPS61040EMV−001 provides two methods of output voltage adjustment
for LCD contrast control. The first method of output voltage adjustment is
accomplished with a variable resistor, while the second method is
accomplished using a variable control voltage.
2.8.1 Variable Resistor Output Voltage Adjust
This method is accomplished by removing R2 on the EVM and then placing
a variable resistor between J3−1 and ground. The equations provided below
calculate the range of the variable resistor where:
-R(adjust),min = minimum value for R2
-R(adjust),max = maximum value for R2
-R1 = value for R1
-VO,max = maximum desired output voltage
-VO,min = minimum desired output voltage
Radjust,min +1.233 V R1
ǒVO,max *1.233 VǓ(1)
Radjust,max +1.233 V R1
ǒVO,min *1.233 VǓ(2)
For example, if VO,max = 19 V, VO,min = 17 V, and R1 = 2.21 MΩ, then
R(adjust),min = 153.4 kΩ, and R(adjust),max = 172.8 kΩ. This scenario is best
implemented using a 154-kΩresistor in series with a 20-kΩpotentiometer.
2.8.2 Variable Control Voltage Output Voltage Adjust
This method is accomplished by connecting a variable control voltage through
a resistor, R(adjust), to J3−1. The equations provided below calculate R2 and
R(adjust) where:
ǒVadjust,max *Vadjust,minǓ
ƪ1.233 VǒVO,min *VO,max )Vadjust,min *Vadjust,maxǓ*Vadjust,min xV
O,min )Vadjust,max xV O,maxƫ
(
3)
R2
+
1.233 V
R1
Radjust +R2 R1 ǒVadjust,max *1.233 VǓ
ƪ1.233 V(R2 )R1)*VO,min R2ƫ(4)
For example, if VO,max= 19 V, VO,min = 17 V, V(adjust),min = 0 V, V(adjust),max =
3.3 V, and R1 = 1 MΩ, then R2 = 72.4 kΩ, and R(adjust) = 1.65 MΩ. When
V(adjust) = 0 V then VO= 19 V. When V(adjust) = 3.3 V then VO= 17 V.

3-1
Board Layout
 
This chapter provides the TPS61040EVM−001 board layout and illustrations.
Topic Page
3.1 Layout 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1 Layout Board layout is critical for all switch mode power supplies. Figures 3−1, 3−2
and 3−3 show the board layout for the TPS61040EVM−001 PWB. The nodes
with high-switching frequency are short and isolated from the noise-sensitive
feedback circuitry. Careful attention has been given to the routing of
high-frequency current loops. Refer to the data sheet for specific layout
guidelines.
Figure 3−1.Assembly Layer
Chapter 3

Layout
3-2 Board Layout
Figure 3−2.Top Layer Routing
Figure 3−3.Bottom Layer Routing

4-1
Schematic and Bill of Materials
    
This chapter provides the TPS61040EVM−001 schematic and bill of materials.
Topic Page
4.1 Schematic 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2 Bill of Material 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 4

Schematic
4-2 Schematic and Bill of Materials
4.1 Schematic
Figure 4−1.TPS61040EVM−001 Schematic
L1
10 µHD1
MBR0530
U1
TPS61040DBV
VIN
EN
SW
GND
FB
5
4
1
2
3
1
JP1
C1
4.7 µF
1
2
1
2
J1
J2
VI
GND
J3
Adjust 1
2
R1
2.21 MΩ
R2
162 kΩ
C3
1 µF
C2
22 pF
1
2
1
2
J5
J4
VO
GND
4.2 Bill of Materials
Table 4−1.TPS61040EVM−001 Bill of Materials
Reference Description Size Qty. MFG Part #
C1 Capacitor, ceramic, 4.7 µF, 6.3 V, X5R, 15% 0805 1 Murata GRM21B60J475KA11
C2 Capacitor, ceramic, 22 pF, 50 V, C0G, 5% 0603 1 Murata GRM1885C1H220JZ01
C3 Capacitor, ceramic, 1 µF, 25 V, X7R, 10% 1206 1 Murata GRM31MR7E105KC01
D1 Diode, Schottky 0.5 A 30 V SOD−123 1 On Semi MBR0530T1
J1 − J5 Header, 2-pin, 100-mil spacing (36-pin strip) 0.1 x 2” 5 Sullins PTC36SAAN
JP1 Header, 3-pin, 100-mil spacing (36-pin strip) 0.1 x 3” 1 Sullins PTC36SAAN
L1 Inductor, SMT, 10 µH, 0.76 A, 0.23 Ω0.15 x
0.162 1 Sumida CR32−100
R1 Resistor, chip, 2.21 MΩ, 1/16 W, 1% 0603 1 Standard Standard
R2 Resistor, chip, 162 kΩ, 1/16 W, 1% 0603 1 Standard Standard
U1 IC, high efficiency boost converter SOT23−5
(DBV) 1 TI TPS61040DBV
PCB, 1.5’ x 1” x 0.062” 1 Any SLVP209
Shunts, 100-mil, black 0.1 mm 1 3M 929950-00
