1 Hardware Overview
User's GuideSLVU184A – March 2007 – Revised February 2008
UCD9080 Power Supply Sequencer and MonitorEvaluation Module
This user’s guide describes how to install and operate the UCD9080 Power Supply Sequencer evaluationmodule (EVM) and graphical user interface (GUI) application. The guide covers the UCD9080EVM boardfunctionality and installation, the I
2
C adapter, plus how to install and use the application software.
Contents1 Hardware Overview.......................................................................................................... 12 System Overview ............................................................................................................ 43 GUI Overview ................................................................................................................ 54 EVM Design Configuration Information .................................................................................. 105 EVM Schematic and Bill of Materials .................................................................................... 126 Related Documentation From Texas Instruments ..................................................................... 14
List of Figures
1 UCD9080EVM ................................................................................................................ 32 System Block Diagram ...................................................................................................... 43 GUI Main Window ........................................................................................................... 64 GUI System Configuration Window ....................................................................................... 75 GUI Rail Configuration Window ............................................................................................ 86 GUI GPO Configuration Window .......................................................................................... 9
List of Tables
1 UCD9080 Jumpers .......................................................................................................... 4
The UCD9080 Power Supply Sequencer EVM is an evaluation module from Texas Instruments for theUCD9080 Power Supply Sequencer and Monitor. The UCD9080 is a highly configurable, 8-channel powersupply sequencer (see SLVS692 data sheet) with four additional general-purpose digital outputs.
The hardware can be configured and monitored through a Windows™ interface running on a PC. The GUIcommunicates with the hardware through the provided USB Interface Adapter, which acts as an I
2
Cmaster for the board.
This UCD9080EVM has this functionality:•Sequencing for up to eight power supplies on the board using digital enable signals•Monitoring for up to eight voltage rails on the board using analog signals•Power supply enables can be sent off board via a header for sequencing external power supplies(controlled using jumpers for each rail)•External voltage rails can be connected to a header on the board for monitoring external powersupplies (controlled using jumpers for each rail)•Sequencing for up to four digital outputs for reset circuits, etc.•Jumpers for configuring the I
2
C address of the UCD9080 (detected at start-up)•Standard 100-kHz I
2
C communication via I
2
C connector to USB adapter for connection toWindows is a trademark of Microsoft Corporation.Windows is a trademark of Microsoft Corporation.
SLVU184A – March 2007 – Revised February 2008 UCD9080 Power Supply Sequencer and Monitor Evaluation Module 1Submit Documentation Feedback

www.ti.com
1.1 Voltage Reference
1.2 EVM Operation
Hardware Overview
Windows-based PC•LEDs for board power and power supply enables for quick visible indication of power supply status•Eight onboard LDOs and power supplies for sequencing and monitoring testing
The eight power supplies, provided on the UCD9080EVM, are a combination of low-dropout regulators(LDO), power converter ICs, and power converter modules, all from Texas Instruments.
Rails 1-6 have a TI TPS76901 LDO for generating voltages from 1.4 V to 2.4 V. Rail 7 has a TI PTH04070switching power supply IC for generating a 2.6 V output. Rail 8 has a TI PTH05050 power module usedfor generating a 2.8 V output. This set of power supplies are provided for generating different outputvoltages on the board for testing of different sequencing and monitoring conditions.
Users can communicate with the board using the I
2
C protocol through the supplied USB Interface Adapterand GUI. The GUI helps users to change the sequencer configuration, plus monitor voltage and devicestatus from a Windows PC.
Because the UCD9080 monitors analog signals (voltage), its ability to accurately convert the value of therail voltages to digital values (for conversion to volts for the user) is a function of the quality of the voltagereference on the device.
The UCD9080 IC can run in one of two modes: internal reference or external reference (selectable via theGUI). When operating with the internally generated 2.5-V reference, the sampling accuracy is not as goodas is possible with the external reference (see data sheet SLVS692 for details). If measuring voltageaccurately to 5 mV is not required, then the internal reference is sufficient.
If the application requires better voltage monitoring accuracy, then the external reference (derived from theUCD9080 VCC pin) should be used. This EVM uses a shunt regulator that produces a clean 3.3-V supplyvoltage to the UCD9080. This regulator is only required to supply the UCD9080 VCC pin if the voltagereference is set to internal.
The default behavior of the device (and EVM) is for an external voltage reference.
The UCD9080EVM requires power from an AC wall adapter through J1 or from a laboratory power supplythrough J5. This provides 5 V to power the LEDs, power supplies, and the UCD9080 (using a 3.3-V boardregulator). The UCD9080 begins operation as soon as power is applied to the EVM. The UCD9080EVMhas several LEDs to indicate board power and active enables for each onboard power supply.
Connect the power source to the board and enable the power source. The red LED labeled D4 illuminatesto indicate that the board has power . You should then observe D1 and D5–D11 illuminate, indicating theapplication is running.
Next, connect the USB interface adapter to the UCD9080EVM via the provided ribbon cable. Plug theUSB cable into the adapter and the other end into your PC. Instructions about how to run the GUI appearin a later section in this document.
Before power up, remove the jumper JP29. This jumper disconnects the I
2
C addresses from beingchanged during start-up. (This is one of the signals that the UCD9080 uses to detect and learn its I
2
Caddresses.)
2UCD9080 Power Supply Sequencer and Monitor Evaluation Module SLVU184A – March 2007 – Revised February 2008Submit Documentation Feedback

www.ti.com
RAIL 1-RAIL8
TP1-TP8
PS Input/UV Fault
JP21-JP28
PS Monitor
JP1-JP8
Ext, ENx and MONx
J4
PS Enable PU/PD
JP9-JP16
I C Address Selection
JP17-JP20
2
UCD9080
I C Communication
2
J3
5 V AC Adapter In
J1
5 V Lab Supply In
J5
1.3 Connectors
Hardware Overview
Figure 1. UCD9080EVM
The UCD9080EVM has connectors for power and I
2
C communications. J1 is the connector for theexternal 5-V AC adapter. The J5 connector provides a laboratory power supply to power the EVM.
Connector J3 is for the I
2
C communication provided by the USB Interface Adapter included with this EVMkit. The USB Interface Adapter includes a ribbon cable that can be connected to J3. The adapter isconnected to a Windows-based PC via USB protocol.
The J4 header allows users to be able to sequence and monitor their own external power supplies, ratherthan the eight supplies provided on this board. Each of the eight power supply rails supported by theUCD9080 has an enable and a monitoring pin. Connect the power supply that you want to monitor to theappropriate enable and monitoring pins on this header. Then, move the corresponding jumpers (describedin the next section) so that the power supply rail is monitored using this header, instead of on the board.
CAUTION
Ensure that if you are configuring the UCD9080EVM to monitor an externalpower supply, the voltage is appropriately scaled down to between 0 V – 2.5 V(if using the internal reference) or between 0 V – 3.3 V (if using the externalreference).
SLVU184A – March 2007 – Revised February 2008 UCD9080 Power Supply Sequencer and Monitor Evaluation Module 3Submit Documentation Feedback

www.ti.com
1.4 Jumpers
1.5 Test Points
2 System Overview
System Overview
The UCD9080 EVM operation can be configured with different jumpers, that include these functions:•Monitoring onboard or external power supply voltages•Generating enable signals for driving onboard or external power supplies•Setting of the I
2
C address for the system•Creating undervoltage faults for the onboard power supplies
See Table 1 for descriptions and default settings of all jumpers included on the UCD9080EVM.
Table 1. UCD9080 Jumpers
Number Function Default Setting
JP1–JP8 Power supply monitoring through onboard power supplies or externally connected. Pins 1-2 (onboardConnect to pins 1-2 for monitoring onboard supplies and pins 2-3 for external supplies via supplies)connector J4.JP9–JP16 Power supply enable signal configuration ( pullup or pulldown). Enable pins for each of Pins 1-2 (pullup to 3.3 Vthe channels can be either pulled up to 3.3 V or down to ground to support power for active-low supplysupplies that have either active-high or active-low enables. Connect to pins 1-2 for pulling enables).up to 3.3 V and connect to pins 2-3 for pulling down to ground.JP17–JP20 I
2
C address detection. Four digital signals on the UCD9080 are sampled at start-up to Pins 2-3 (pulldown todetermine its I
2
C address. These four jumpers control, if the signals are pulled up to 3.3 V ground for all zero).or down to ground. Connect to pins 1-2 for 3.3 V and connect to pins 2-3 for ground.JP21–JP28 Undervoltage fault. For each rail, you can generate an undervoltage fault by removing this Jumper on pins 1-2 forjumper. Removal of these jumpers removes input from the power supplies, causing the no undervoltage fault.output voltage being monitored by the UCD9080 to fall below the configured undervoltagethreshold. If the UV threshold is zero, no undervoltage occurs.JP29 Enable8 shared with I
2
C address detection. Remove this jumper when communicating Jumper on pins 1-2.with the GUI.
The UCD9080EVM comes with a set of test points that can be used for evaluation. All eight power supplyrails have test points on the right side of the board for monitoring the power supply voltages and theUCD9080EVM supply voltage (3.3 V).
The system block diagram is shown in Figure 2 .
Figure 2. System Block Diagram
4UCD9080 Power Supply Sequencer and Monitor Evaluation Module SLVU184A – March 2007 – Revised February 2008Submit Documentation Feedback

www.ti.com
3 GUI Overview
3.1 Installing the GUI
GUI Overview
The system consists of these components:•Host (PC)—a Windows PC – used to configure and monitor the UCD9080EVM. The GUI (explained inthe GUI section) runs on the host. For the GUI to execute properly, the host needs to have theWindows .NET v2.0 Framework installed.•USB-to-I
2
C adapter—UCD9080EVM uses the I
2
C interface for communication with the host. TheTI-supplied USB-to-I
2
C adapter does the appropriate conversion so the host can use the USB interfacefor communication.
•Power source—UCD9080EVM needs 5-V power source to drive. This power is used by the UCD9080(by regulating to 3.3 V), LEDs, as well as the onboard rails, if used.•External voltage rails—when configured properly, UCD9080EVM can sequence and monitor externalvoltage source as well.•UCD9080EVM—EVM board that houses the UCD9080 and peripheral circuits. The EVM can sequenceand monitor onboard as well as external voltage rails, as previously explained.
The UCD9080EVM comes with a Windows application that can be used to configure and monitor theEVM. The GUI can be used to configure all available options of the EVM such as sequencing andshutdown order, over/undervoltage timing, etc. It also can be used to monitor the operation of thesequencer by reporting current readings of voltage and error conditions on all the rails.
Before running the GUI application, ensure that the target hardware is connected and that the Microsoftlibraries are up-to-date.1. Remove JP29 and ensure that the EVM is powered on by connecting the power source to the boardand then enabling the power source.2. Connect the ribbon cable from the USB Interface adapter to the EVM board connector.3. Connect the PC USB cable to the USB Interface Adapter.
Note: The UCD9080EVM application GUI is written using Microsoft .NET version 2 software andtherefore requires the .NET Framework installed on the PC to run the application. No otherdrivers or libraries are required to run the application.
4. To determine the .NET Framework software version you must use the Windows Control Panel andselect Add/Remove Programs. The Control Panel lists all the installed PC software and you candetermine if the proper Microsoft .NET Framework version is installed.
Note: To update your .NET Framework to version 2.0, go this URL:
http://www.microsoft.com/downloads/details.aspx?FamilyID=0856EACB-4362-4B0D-8EDD-
AAB15C5E04F5&displaylang=en
5. To install the GUI, unzip the zip file that containing the GUI binary onto your PC. You must have atleast version 2.0 of the Microsoft .NET Framework installed on your PC in order to run the GUI.6. Once you have installed the .NET Framework and the UCD9080EVM GUI, you can launch theapplication.
SLVU184A – March 2007 – Revised February 2008 UCD9080 Power Supply Sequencer and Monitor Evaluation Module 5Submit Documentation Feedback

www.ti.com
3.2 UCD9080 GUI Main Window
System Status
STATUS register
Statistics
Communication
Statistics (GUI only)
Rail Status
RAILSTATUS
and RAIL registers
Update Parameters and Sequence
Updates device configuration
parameters and sequences
Detect I C address
0x60 - 0x6F
2Sequence
RESET register
Error Log
ERROR registers
GUI Overview
The GUI main window helps you monitor the EVM sequencer status and configure the EVM sequencerthrough the File and View menus.
Figure 3. GUI Main Window
The UCD9080 EVM main window GUI has these areas:•System Status—parameters including I2C Error, Rail Error, and Error Logs in Flash indication. Redbox fill indicates an error.•Error Log—contains error messages that inform the user about the operation of the sequencer.•Rail Status—information including monitored voltage (scaled to user-entered divider ratios) and railerror status.•Statistics—I2C communication statistics.•Update Parameters and Sequence button—Updates buffer-stored GUI information to device userflash memory and initiates a device sequence. This process takes a couple seconds, and then thesequencer is able to be monitored again.•Sequence button—causes the system sequence.•Menu bar— selects File and View menu items
The File menu includes these commands:•Load Configuration—loads a previously saved parameter (*.par) file.•Save Configuration—saves the current GUI configuration to a user parameter file.•Save I2C Transactions—generates an ASCII text file containing configuration-specific I
2
Ctransactions (to be used by a master host to configure the UCD9080).•Auto-Refresh—refresh the window contents periodically, if selected. If you want to refresh the windowcontents manually, click the Refresh button (not available when auto-refresh is enabled).•Discover—discover the slave (EVM as jumper-configured) I
2
C address (displayed at the bottom of theform).
•Exit—stop the GUI application
6UCD9080 Power Supply Sequencer and Monitor Evaluation Module SLVU184A – March 2007 – Revised February 2008Submit Documentation Feedback

www.ti.com
3.2.1 I
2
C Addresses
3.3 GUI System Configuration Window
Shutdown Delays
GPO
Voltage Reference
Function Select
Store to Buffer
I2C Configuration
GUI Overview
The View menu includes these commands:•System Configuration—provides system voltage reference and shutdown delay field entries.•Rail Configuration—provides rail configuration field entries. All Rails simultaneously opens all railforms for comparison setup.•GPO Configuration—provides GPO configuration field entries. All genral-purpose outputs (GPOs)simultaneously open all GPO windows for setup comparisons.•User Data—provides specific user data to be uploaded to the device, such as customer specificidentification.
Users can change the detected I
2
C address on the EVM by modifying the state of jumpers JP17–JP20. Ifthe jumpers are changed during GUI operation, the user has to perform an I2C Discover command, aspreviously described.
The System Configuration window on the GUI is shown in Figure 4 and allows the following to beconfigured in the UCD9080:
Figure 4. GUI System Configuration Window
•Shutdown Delays—specify shutdown delays for rails and GPOs. If a rail or GPO is marked to shutdown, then it shuts down according to the shutdown delays entered here. These shutdown delay fieldscorrespond to the UnsequenceTime registers in the UCD9080 device data sheet (SLVS692 ).•Voltage Reference—selects the device voltage reference. The UCD9080EVM is configured by defaultto use the external reference (VCC supply for the sequencer). When VCC is selected as the reference,the GUI provides for actual VCC calibration to be entered. For example, if the actual device VCCvoltage is 3.1 V the GUI can use this to properly scale the displayed voltages.
Note: When the reference is changed and stored to the GUI buffer, the displayed rail voltages areincorrectly scaled, until the device parameters are updated.
•Function Select—helps you select the EN8 or GPO1 function. The function selected disables theother function from being configured.
SLVU184A – March 2007 – Revised February 2008 UCD9080 Power Supply Sequencer and Monitor Evaluation Module 7Submit Documentation Feedback

www.ti.com
3.4 GUI Rail Configuration Window
Max Time for Regulation
Ramp Time registers
Out of Regulation Time
Out Of Regulation Width
registers
UV Threshold
Under Voltage Thresholds
registers
Active Low (Rail Polarity)
Enable Polarity register
OV Threshold
Over Voltage Thresholds
registers
Sequencing Conditions
Sequence Event Parameters
registers (ENABLE bits)
Sequencing Conditions
Sequence Event Data registers
(RAILDATA bits)
Sequencing Conditions
Sequence Event Link registers
(PARENTRAIL bits)
Alarm Processing
Sequence Event Data
registers (SEQPARAM bits)
Rails/GPOs to shutdown
Dependency Masks
registers (RAIL & GPO bits)
Sequence after Shutdown
Sequence Event Link
registers (RESEQ bit)
Rail Configuration Window
Sequence Event Parameters
registers (RAIL/GPO bits)
Voltage Divider
Used by GUI to calculate scale
factor for displayed Rail
Voltage & internal UV/OV trip
Log Errors to Flash
Save Rail Log registers
3.4.1 General Rail Windows Selections
GUI Overview
•Store to Buffer and Close Buttons—The Store to Buffer button saves the current window entries to aGUI buffer and the Close button closes the window without saving the form entries.
The Rail Configuration window on the GUI is shown in Figure 5 and permits you to configure theseUCD9080 items:
Figure 5. GUI Rail Configuration Window
•Active Low (Polarity)—specify enable pin polarity.•UV/OV Threshold—specify undervoltage and overvoltage trip points. Note that UV values of zeroessentially cause the device to ignore any undervoltage conditions and that OV values which areexcessively high cause the device to ignore any undervoltage conditions.•Out of Reg Time (ms)—specify the maximum amount of time (or glitch width) that the rail can be outof the UV/OV range before an alarm is declared.•Max Time for Regulation (ms)—specify the maximum amount of time a rail is allowed to achieveregulation (rail voltage must be within the UV/OV range) before an alarm is declared.•Log Errors to Flash—log rail errors to nonvolatile memory for later evaluation.•Voltage Divider—specify the user rail voltage divider values. The GUI uses these values to properlyscale and display the voltages received through the UCD9080 monitors. Note that zero value dividerresistor values cause the divider ratio to be evaluated as unity (no scaling).•Sequence after Shutdown—specify the UCD9080 ENx and GPOx output to be marked tore-sequence the system (as defined by the current sequencer configuration) if they are specified as adependency in the DependencyMasks register.
UCD9080 Power Supply Sequencer and Monitor Evaluation Module8 SLVU184A – March 2007 – Revised February 2008Submit Documentation Feedback

www.ti.com
3.4.2 Sequencing Conditions Selections
3.4.3 Alarm Actions
3.5 GUI GPO Configuration Window
GPO Configuration Window
Sequence Event Parameters
registers (RAIL/GPO bits)
Active Low (GPO Polarity)
Enable Polarity register
Sequence after Shutdown
Sequence Event Link
registers (RESEQ bit)
Sequencing Conditions
Sequence Event Parameters
registers (ENABLE bits)
Sequencing Conditions
Sequence Event Data registers
(RAILDATA bits)
Sequencing Conditions
Sequence Event Link registers
(PARENTRAIL bits)
3.5.1 General GPO Window Selections
GUI Overview
Voltage rail sequencing conditions are:•None—rail is not sequenced.•Time—number of milliseconds before this rail is enabled.•Parent (Reg)—number of milliseconds to delay after the parent rail achieves regulation beforeenabling this rail.•Parent (V)—voltage at which the parent rail should be before this rail is enabled
The alarm actions are:•Log Only—ignore any failures on this rail, and keep it enabled.•Retry—continue to retry a configurable number of times (n = 0,1,2,3,4), then shut down according tothe DependencyMasks and UnsequenceTime registers.•Retry Continuously—when an error on the selected rail happens, a retry occurs. A retry is an attemptby the UCD9080 to restart the corresponding power supply by disabling the rail (with ENx pin) andthen re-enabling the rail. This repeats until the power supply rail alarm clears.•Sequence—when there is an error on this rail, resequence the system according to the currentsequencer configuration.
The GPO Configuration windows displays in Figure 6 and provides for these UCD9080 configurationsettings:
Figure 6. GUI GPO Configuration Window
•Active Low (Polarity)—specifies GPO pin polarity•Sequence after Shutdown—UCD9080 ENx and GPOs output can be marked to re-sequence thesystem (as defined by the current sequencer configuration) if they are specified as a dependency inthe DependencyMasks register.
SLVU184A – March 2007 – Revised February 2008 UCD9080 Power Supply Sequencer and Monitor Evaluation Module 9Submit Documentation Feedback

www.ti.com
3.5.2 Sequencing Conditions Selections
4 EVM Design Configuration Information
4.1 Voltage Rail Set Points
VRAILx +VREF ǒ1)RUP
RDNǓ; VREF +0.6663 typical for TPS76201
Set RDN +66.5 kW(max); RUp +ǒVRAILx
VREF *1Ǔ RDN
(1)
Set R5 +10 kW 0.891
VRAIL7 *0.891 *3.24 kW
(2)
Set R2 +10 kW 0.8
VRAIL8 *0.8 *2.49 kW
(3)
4.2 Rail Bleed-Down Considerations
EVM Design Configuration Information
Sequencing conditions for a GPO•None—GPO is not sequenced•Time—number of milliseconds before this GPO is enabled•Parent (Reg)—number of milliseconds to delay after the parent rail achieves regulation beforeenabling this GPO•Parent (V)—voltage at which the parent rail should be before this GPO is enabled
The EVM rail output voltage Set points are configurable by changing the output voltage set-point resistors.RAIL1, RAIL2, RAIL3, and RAIL4 are monitored directly by the UCD9080 (no feedback divider resistors)and these rail output voltages should never be set above the reference voltage being used. RAIL5, RAIL6,RAIL7, and RAIL8 have the feedback divider resistors present and as such, these rail output voltages canbe higher than the currently used voltage reference.•RAIL1 through RAIL6: TPS76201 100-mA LDO
Note: R
DN
has been set to 49.9 Ωon the EVM to more quickly discharge the rails during shutdown(see the rail bleed down considerations section).
•RAIL7: PTH04070 3A Switching Regulator
•RAIL8: PTH05050 6A Switching Regulator
When considering system shutdown (or unsequence time), loading on the power supply rails must betaken into account. The rail bleed-down times are a function of the loading and the total (load and powersupply) output capacitance. As previously noted for RAIL1-RAIL6, the output voltage set-point resistorshave been chosen to provide a much quicker bleed-down time than could be achieved with a light load.For RAIL7 and RAIL8, the feedback divider resistors have been sized to provide more loading for thesame reasons. If the user chooses to provide external rail loading, the output voltage set-point resistorvalues can be adjusted. The EVM rail bleed-down times using the values shown in the BOM are on theorder of <10 ms, whereas for no-load conditions the rail bleed-down times can approach several seconds.
UCD9080 Power Supply Sequencer and Monitor Evaluation Module10 SLVU184A – March 2007 – Revised February 2008Submit Documentation Feedback

www.ti.com
4.3 Rail and GUI Divider Selection
Required DE+ǒ1)TOLR
100 Ǔ VRAILE ǒ1)TOLRAILE 100 Ǔ
VREF ǒ1)TOLREF
100 Ǔ
4.4 ENx and GPOx Pin Default Voltage Levels
4.5 Reset
EVM Design Configuration Information
Use these equations to choose the external Rail and GUI divider resistor values.
Note: Setting R
pullup
and R
pulldown
to 0 in the GUI yields a D
G
value of 1.
•To accurately calculate the correct EVM divider ratio D
E
the rail, divider resistor, and reference voltagetolerances must be taken into account so that the monitor input voltage does not exceed the devicereference voltage.
•Use the following equations to calculate the minimum divider ratio, D
E
:
TOL
R
= Divider resistor toleranceTOL
RAILE
= V
RAILE
toleranceTOL
REF
= V
REF
toleranceV
RAILE
= Rail voltage being monitored via dividerV
REF
= Reference voltageR
PU
= R
PD
×(D
E
– 1); Choose R
PD
≤10 k Ω•EVM Actual Voltages:– EVM divider, D
E
= R
HI
+ R
LO
) / R
LO
= 2– RAIL1 through RAIL4: No dividers; V
MON
= V
RAILE
; V
MON
= MONx pin voltage, V
RAILE
= EVM RAILxvoltage
– RAIL 5 through RAIL8: Divider, D
E
= 2; V
MON
= V
RAIL
/ 2•GUI Calculated Voltages:– GUI divider, D
G
= R
PULLDOWN
+ R
PULLUP
) / R
PULLDOWN– Displayed rail voltages, V
RAILG
= V
MON
×D
G
= V
RAILE
×D
G
/ D
E
; V
RAILG
= GUI displayed voltage
When the device is reset (see the Reset section), the ENx and GPOx outputs go to a high-impedancestate (3-state). Pullup or pulldown resistors on these signals are recommended to cause the signals to goto the desired voltage level during reset. For example, if it is desired to keep a RAILx enabled during resetand the enable is active-low, then a pulldown resistor should be located on the corresponding ENx output.Note that on the EVM, the ENx and GPOx outputs have selectable pullup or pulldown jumpers installed.Also note that for the ENx outputs, the ENx status LEDs provide a stronger pullup current than the jumperpulldowns so that the power supplies become disabled during reset.
Device reset occurs when:•Power is applied to the device (power on reset) or power is cycled.•The external RST pin is driven low.•The GUI Update Parameters and Sequence button is pressed, causing new configuration data to bewritten to the device.•The GUI Sequence button is pressed, causing the device to sequence.•A Sequence occurs as a result of a configured rails alarm event.
Any of these reset conditions causes the device I
2
C address to be re-evaluated. Keep in mind that theEN8/GPO1 pin, as well as GPO2, GPO3, and GPO4 pins, provide the I
2
C address inputs that are sampledduring device reset. If the pin pullup/pulldown configuration jumpers are changed while the GUI isoperating and a device reset occurs, then the GUI communication may be affected (perform Discover tore-acquire the EVM I
2
C address.
SLVU184A – March 2007 – Revised February 2008 UCD9080 Power Supply Sequencer and Monitor Evaluation Module 11Submit Documentation Feedback

www.ti.com
5 EVM Schematic and Bill of Materials
5.1 EVM Schematic
++
+ + + + +
+
+ +
EVM Schematic and Bill of Materials
UCD9080 Power Supply Sequencer and Monitor Evaluation Module12 SLVU184A – March 2007 – Revised February 2008Submit Documentation Feedback

www.ti.com
5.2 Bill of Materials
EVM Schematic and Bill of Materials
Count RefDes Value Description Size Part Number MFR
2 C1, C4 100 µF Capacitor, Tantalum, 10V, 10% 6032 TAJC107K010R AVX
1 C10 2.2 µF Capacitor, Ceramic, 6.3V, X7R, 20% 0805 STD Murata
1 C11 1 µF Capacitor, Ceramic, 10V, X7R, 20% 0603 STD Murata
1 C2 10 µF Capacitor, Tantalum, 16V, 10% 6032 TAJC106K016R AVX
1 C3 10 µF Capacitor, Tantalum, 10V, 10% 3216 T491A106K010AT KEMET
2 C5, C6 47 µF Capacitor, Ceramic, 6.3V, X5R, 20% 1206 C3216X5R0J476M TDK
6 C7, C13, C15, 1 µF Capacitor, Ceramic, 10V, X7R, 20% 0603 STD MurataC17, C19, C21
6 C8, C14, C16, 4.7 µF Capacitor, Tantalum, 6.3V, 20% 0805 TCP0J475M8R RohmC18, C20, C22
1 C9 0.01 µF Capacitor, Ceramic, 10V, X7R, 20% 0603 STD Murata
9 D1, D4–D11 Diode, LED, Red, 100 mA 0805 SML-LXT0805SRW-TR Lumex
1 D2 Diode, Schottky, 1A, 15V SMB 10BQ015 IR
1 D3 IC, Adj., 3.3 V, 800mA LDO Voltage Regulators SOT-223 TLV1117-33CDCY TI
1 J1 Connector, Pin diameter 2,5 mm, DC Jack 0.57 ×0.35 inch RAPC 712 Switchcraft
1 J2 Connector, Male Straight 2 ×7 pin, 100 mil spacing, 4 0.100 inch ×2X7 2514-6002UB 3MWall
1 J3 Connector, Male Straight 2 ×10 pin, 100 mil spacing, 4 0.338 ×0.788 inch 2510-6002UB 3MWall
1 J4 Header, 2 ×9 pin, 100 mil spacing (36 pin strip) 0.100 ×2×9 inch PTC36DAAN Sullins
1 J5 Terminal Block, 2-pin, 15-A, 5,1 mm 0.40 ×0.35 inch ED1609 OST
20 JP1–JP20 Header, 3-pin, 100 mil spacing, (36-pin strip) 0.100 inch ×3 PTC36SAAN Sullins
9 JP21–JP29 Header, 2-pin, 100 mil spacing, (36-pin strip) 0.100 inch ×2 PTC36SAAN Sullins
2 Q1, Q2 MOSFET, Nch, 50V, 0.22A, 3.5 ΩSOT23 BSS138 Fairchild
8 R1, R4, R6, R15, 300 Resistor, Chip, 1/16W, 5% 0603 Std StdR25, R32, R37,R45
10 R13, R17, 49.9 Resistor, Chip, 1/10W, 1% 0603 Std StdR18–R21, R27,R36, R39, R47
1 R16 115 Resistor, Chip, 1/10W, 1% 0603 Std Std
1 R2 1.50k Resistor, Chip, 1/16W, 1% 0603 Std Std
1 R26 100 Resistor, Chip, 1/10W, 1% 0603 Std Std
1 R3 590 Resistor, Chip, 1/16W, 5% 0603 Std Std
1 R33 84.5 Resistor, Chip, 1/10W, 1% 0603 Std Std
1 R38 69.8 Resistor, Chip, 1/10W, 1% 0603 Std Std
1 R46 54.9 Resistor, Chip, 1/10W, 1% 0603 Std Std
1 R48 100k Resistor, Chip, 1/16W, 1% 0603 Std Std
5 R5, R28, R29, 2k Resistor, Chip, 0.05W, 1% 0603 Std StdR34, R35
1 R60 1.6K Resistor, Chip, 1/16W, 0.1% 0603 Std Std
1 R61 2.67K Resistor, Chip, 1/16W, 0.1% 0603 Std Std
1 R62 180 Resistor, Chip, 1/10W, 1% 0805 Std Std
1 R7 130 Resistor, Chip, 1/10W, 1% 0603 Std Std
27 R8–R12, R14, 10k Resistor, Chip, 1/16W, 5% 0603 Std StdR22–R24, R30,R31, R40–R44,
R49–R59
10 TP1–TP8, TP11, 5012 Test Point, White, Thru Hole 0.125 x 0.125 inch 5012 KeystoneTP12
3 TP9, TP10, TP13 5011 Test Point, Black, Thru Hole 0.125 ×0.125 inch 5011 Keystone
1 U1 Module, Wide Output Adj, 6A, 0.8V to 3.6V, 5V Input 0.870 ×0.495 PTH05050WAH TI
1 U10 IC, Micropower Shunt Voltage Reference 100 ppm/ °C, SOT23 LM4041BIDBZ TI45 µA-12 mA, Adjustable
1 U2 Module, 3A, 3.3/5V Input Adjustable Switching 0.400 ×0.495 inch PTH04070WAH TIRegulator
6 U3–U8 IC, Micro-Power 100 mA LDO Regulator SOT23-5 TPS76201DBV TI
SLVU184A – March 2007 – Revised February 2008 UCD9080 Power Supply Sequencer and Monitor Evaluation Module 13Submit Documentation Feedback

www.ti.com
6 Related Documentation From Texas Instruments
Related Documentation From Texas InstrumentsCount RefDes Value Description Size Part Number MFR
1 U9 IC, Power Supply Sequencer and Monitor QFN-32 UCD9080RHB TI
29 — Shunt, 100-mil, Black 0.1 929950-00 3M
1 — PCB, 5.3 In ×4.2 In ×0.062 Inch HPA199 Any
4 Bumpons 2567 SPC
•USB Interface Adapter User’s Guide (SLLU093 )•UCD9080, 8-Channel Power Supply Sequencer and Monitor data sheet (SLVS692 )•TPS76901, Ultralow-Power 100-mA Low-Dropout Linear Regulator data sheet (SLVS203 )•PTH04070W, 3-A, 3.3/5-V Input Adjustable Switching Regulator data sheet (SLTS227 )•PTH05050, 6-A, 5-V Input Non-Isolated Wide-Output Adjust Power Module data sheet (SLTS213 )
14 UCD9080 Power Supply Sequencer and Monitor Evaluation Module SLVU184A – March 2007 – Revised February 2008Submit Documentation Feedback

EVALUATION BOARD/KIT IMPORTANT NOTICE
Texas Instruments (TI) provides the enclosed product(s) under the following conditions:This evaluation board/kit is intended for use for ENGINEERING DEVELOPMENT, DEMONSTRATION, OR EVALUATION PURPOSESONLY and is not considered by TI to be a finished end-product fit for general consumer use. Persons handling the product(s) must haveelectronics training and observe good engineering practice standards. As such, the goods being provided are not intended to be completein terms of required design-, marketing-, and/or manufacturing-related protective considerations, including product safety and environmentalmeasures typically found in end products that incorporate such semiconductor components or circuit boards. This evaluation board/kit doesnot fall within the scope of the European Union directives regarding electromagnetic compatibility, restricted substances (RoHS), recycling(WEEE), FCC, CE or UL, and therefore may not meet the technical requirements of these directives or other related directives.Should this evaluation board/kit not meet the specifications indicated in the User’s Guide, the board/kit may be returned within 30 days fromthe date of delivery for a full refund. THE FOREGOING WARRANTY IS THE EXCLUSIVE WARRANTY MADE BY SELLER TO BUYERAND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED, IMPLIED, OR STATUTORY, INCLUDING ANY WARRANTY OFMERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE.The user assumes all responsibility and liability for proper and safe handling of the goods. Further, the user indemnifies TI from all claimsarising from the handling or use of the goods. Due to the open construction of the product, it is the user’s responsibility to take any and allappropriate precautions with regard to electrostatic discharge.EXCEPT TO THE EXTENT OF THE INDEMNITY SET FORTH ABOVE, NEITHER PARTY SHALL BE LIABLE TO THE OTHER FOR ANYINDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES.TI currently deals with a variety of customers for products, and therefore our arrangement with the user is not exclusive.
TI assumes no liability for applications assistance, customer product design, software performance, or infringement of patents orservices described herein.
Please read the User’s Guide and, specifically, the Warnings and Restrictions notice in the User’s Guide prior to handling the product. Thisnotice contains important safety information about temperatures and voltages. For additional information on TI’s environmental and/orsafety programs, please contact the TI application engineer or visit www.ti.com/esh .No license is granted under any patent right or other intellectual property right of TI covering or relating to any machine, process, orcombination in which such TI products or services might be or are used.FCC Warning
This evaluation board/kit is intended for use for ENGINEERING DEVELOPMENT, DEMONSTRATION, OR EVALUATION PURPOSESONLY and is not considered by TI to be a finished end-product fit for general consumer use. It generates, uses, and can radiate radiofrequency energy and has not been tested for compliance with the limits of computing devices pursuant to part 15 of FCC rules, which aredesigned to provide reasonable protection against radio frequency interference. Operation of this equipment in other environments maycause interference with radio communications, in which case the user at his own expense will be required to take whatever measures maybe required to correct this interference.
EVM WARNINGS AND RESTRICTIONS
It is important to operate this EVM within the input voltage range of 0 V to 5 V and the output voltage range of 0 V to 3.3 V.Exceeding the specified input range may cause unexpected operation and/or irreversible damage to the EVM. If there are questionsconcerning the input range, please contact a TI field representative prior to connecting the input power.Applying loads outside of the specified output range may result in unintended operation and/or possible permanent damage to the EVM.Please consult the EVM User's Guide prior to connecting any load to the EVM output. If there is uncertainty as to the load specification,please contact a TI field representative.During normal operation, some circuit components may have case temperatures greater than 50 °C. The EVM is designed to operateproperly with certain components above 50 °C as long as the input and output ranges are maintained. These components include but arenot limited to linear regulators, switching transistors, pass transistors, and current sense resistors. These types of devices can be identifiedusing the EVM schematic located in the EVM User's Guide. When placing measurement probes near these devices during operation,please be aware that these devices may be very warm to the touch.
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265Copyright © 2008, Texas Instruments Incorporated

IMPORTANT NOTICE
Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications, enhancements, improvements,and other changes to its products and services at any time and to discontinue any product or service without notice. Customers shouldobtain the latest relevant information before placing orders and should verify that such information is current and complete. All products aresold subject to TI’s terms and conditions of sale supplied at the time of order acknowledgment.TI warrants performance of its hardware products to the specifications applicable at the time of sale in accordance with TI’s standardwarranty. Testing and other quality control techniques are used to the extent TI deems necessary to support this warranty. Except wheremandated by government requirements, testing of all parameters of each product is not necessarily performed.TI assumes no liability for applications assistance or customer product design. Customers are responsible for their products andapplications using TI components. To minimize the risks associated with customer products and applications, customers should provideadequate design and operating safeguards.TI does not warrant or represent that any license, either express or implied, is granted under any TI patent right, copyright, mask work right,or other TI intellectual property right relating to any combination, machine, or process in which TI products or services are used. Informationpublished by TI regarding third-party products or services does not constitute a license from TI to use such products or services or awarranty or endorsement thereof. Use of such information may require a license from a third party under the patents or other intellectualproperty of the third party, or a license from TI under the patents or other intellectual property of TI.Reproduction of TI information in TI data books or data sheets is permissible only if reproduction is without alteration and is accompaniedby all associated warranties, conditions, limitations, and notices. Reproduction of this information with alteration is an unfair and deceptivebusiness practice. TI is not responsible or liable for such altered documentation. Information of third parties may be subject to additionalrestrictions.
Resale of TI products or services with statements different from or beyond the parameters stated by TI for that product or service voids allexpress and any implied warranties for the associated TI product or service and is an unfair and deceptive business practice. TI is notresponsible or liable for any such statements.TI products are not authorized for use in safety-critical applications (such as life support) where a failure of the TI product would reasonablybe expected to cause severe personal injury or death, unless officers of the parties have executed an agreement specifically governingsuch use. Buyers represent that they have all necessary expertise in the safety and regulatory ramifications of their applications, andacknowledge and agree that they are solely responsible for all legal, regulatory and safety-related requirements concerning their productsand any use of TI products in such safety-critical applications, notwithstanding any applications-related information or support that may beprovided by TI. Further, Buyers must fully indemnify TI and its representatives against any damages arising out of the use of TI products insuch safety-critical applications.TI products are neither designed nor intended for use in military/aerospace applications or environments unless the TI products arespecifically designated by TI as military-grade or "enhanced plastic." Only products designated by TI as military-grade meet militaryspecifications. Buyers acknowledge and agree that any such use of TI products which TI has not designated as military-grade is solely atthe Buyer's risk, and that they are solely responsible for compliance with all legal and regulatory requirements in connection with such use.TI products are neither designed nor intended for use in automotive applications or environments unless the specific TI products aredesignated by TI as compliant with ISO/TS 16949 requirements. Buyers acknowledge and agree that, if they use any non-designatedproducts in automotive applications, TI will not be responsible for any failure to meet such requirements.Following are URLs where you can obtain information on other Texas Instruments products and application solutions:Products ApplicationsAmplifiers amplifier.ti.com Audio www.ti.com/audioData Converters dataconverter.ti.com Automotive www.ti.com/automotiveDSP dsp.ti.com Broadband www.ti.com/broadbandClocks and Timers www.ti.com/clocks Digital Control www.ti.com/digitalcontrolInterface interface.ti.com Medical www.ti.com/medicalLogic logic.ti.com Military www.ti.com/militaryPower Mgmt power.ti.com Optical Networking www.ti.com/opticalnetworkMicrocontrollers microcontroller.ti.com Security www.ti.com/securityRFID www.ti-rfid.com Telephony www.ti.com/telephonyRF/IF and ZigBee® Solutions www.ti.com/lprf Video & Imaging www.ti.com/videoWireless www.ti.com/wireless
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265Copyright © 2008, Texas Instruments Incorporated
