Texas Instruments TPS6120 EVM-179 Series User manual

User's GuideSLVU207 – April 2007
TPS6120xEVM-179
The TPS6120xEVM-179 is specially designed and optimized to operate from asingle-cell, two-cell, or three-cell alkaline, NiCd or NiMH, as well as a one-cell Li-Ion orLi-polymer battery. It is also used in single-cell fuel cell or solar cell battery applicationswhere the input voltage is as low as 0.3V.
The TPS6120xEVM-179 operates from a 0.3V to 5.5V (starts up ≥0.5V) input rail andprovides a single output voltage up to 5.5V.
The TPS6120xEVM-179 has three orderable EVMs shown in Table 1 .
Table 1. EVM Description
Build EVM Note
-001 TPS61200EVM-179 Evaluates the TPS61200. Adjustable output voltage version which default output voltage is 3.3V.-002 TPS61201EVM-179 Evaluates the TPS61201. Fixed 3.3V_output voltage version-003 TPS61202EVM-179 Evaluates the TPS61202. Fixed 5.0V_output voltage version
Contents1 Introduction ................................................................................................................... 22 Setup and Operation ........................................................................................................ 23 Board Layout ................................................................................................................. 54 Schematic and Bill of Materials ............................................................................................ 7
List of Figures
1 Maximum Output Current vs VBAT ....................................................................................... 42 Efficiency vs Output Current................................................................................................ 43 Top Assembly Layer ......................................................................................................... 54 Top Layer ..................................................................................................................... 65 Bottom Layer ................................................................................................................. 66 TPS6120xEVM-179 Schematic ............................................................................................ 7
List of Tables
1 EVM Description ............................................................................................................. 12 Specification Summary ...................................................................................................... 23 Default Jumper Settings .................................................................................................... 24 Bill of Materials ............................................................................................................... 8
SLVU207 – April 2007 TPS6120xEVM-179 1Submit Documentation Feedback

www.ti.com
1 Introduction
1.1 Specifications
1.2 Modifications
2 Setup and Operation
2.1 Connections and Jumpers
Introduction
This chapter contains background information for the TPS6120xEVM-179 evaluation module.
Table 2 provides a summary of the TPS6120xEVM-179 performance specifications. All specifications aregiven for an ambient temperature of 25 °C.
Table 2. Specification Summary
Voltage Range Current Range(V) (A)Build Specification
Min Typ Max Min Typ Max
-001, -002, -003 VBAT 0.3 5.5-001, -002 VOUT 3.2 3.3 3.4 1.5-003 VOUT 4.85 5 5.15 1.1
This EVM facilitates user evaluation of the TPS61200/01/02. To facilitate user customization of the EVM,the board is designed with devices having 603 or larger footprints. Normal applications will likely occupyless total board space.
The TPS61200 provides adjustable output capability. The output is user adjustable using the feedbackresistors (R4 and R5). The values for these resistors are chosen using the method described in theProgramming the Output Voltage section of the data sheet (SLVS577 ). The output voltage of theTPS61201 and TPS61202 is factory programmed and cannot be changed.
This chapter explains the input, output, and jumper connections of the TPS6120xEVM-179. It alsoprovides guidance on how to set up test equipment for evaluating the EVM and provides test results.
The DEFAULT jumper settings for the EVM are shown in Table 3 .
Table 3. Default Jumper Settings
Jumper Default Setting
JP1 – EN GNDJP2 – PS VBAT
J1 - VBAT: This is the positive connection to the input power supply.J2 - GND: This is the ground connection for input power supply.J3 – VOUT: This is the positive connection to the output voltage. VOUT regulates to 3.3V for theTPS61200 and TPS61201 EVMs, and VOUT regulates to 5V for the TPS61202 EVM.J4 – GND: This is the ground connection for the output voltage.JP1 - EN: This is the enable input for the device. Place a shunt across the VBAT and EN pins of JP1to enable the IC. Place a shunt across the GND and EN pins of JP1 to disable the IC. Ashunt must be installed on JP1 in either VBAT or GND positions and EN should not be leftunconnected.
2TPS6120xEVM-179 SLVU207 – April 2007Submit Documentation Feedback

www.ti.com
2.2 Setup
2.3 Operation
Setup and Operation
JP2 - PS: This jumper enables or disables the power save mode at light load. Place a shunt acrossthe VBAT and PS pins of JP2 to disable power save mode. Place a shunt across the GNDand PS pins of JP2 to enable power save mode. Note that while operating in downconversion mode (VBAT > Vout), power save mode is always enabled and the devicecannot be forced into fixed frequency operation. A shunt must be installed on JP2 in eitherVBAT or GND positions and PS should not be left unconnected.
The power supply should have at least 2A capability. Connect an input power supply between J1 and J2.Initially the voltage range on this supply to start up the converter should be between 0.5V and 5.5V due tothe minimum start up voltage requirement. Following startup, the input can be as low as 0.3V. Connect theload between J3 and J4.
Before enabling this device by connecting the EN pin to VBAT at JP1, make sure the measured inputvoltage between J1 and J2 does not exceed 5.5V and JP2 (PS pin) is connected to the desired setting.
In order to avoid voltage drop through the input power supply line, use at least 20 gauge wire. The outputvoltages can be monitored by voltmeters and/or an oscilloscope with standard high impedance voltageprobes.
Once the input voltage is connected and verified, connect the EN pin to VBAT at JP1. The converter startsup and regulates to the set output voltage. The range for the output regulation is shown in Table 2 .
After the converter starts up, the input voltage can go down to 0.3V. Figure 1 and Figure 2 showmeasured data from the EVM for maximum output current and efficiency at various input/output voltagecombinations.
SLVU207 – April 2007 TPS6120xEVM-179 3Submit Documentation Feedback

www.ti.com
Maximum Output Current vs Input Voltage
0
0.2
0.4
0.6
0.8
1
1.2
1.4
1.6
0 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 5.5
Input Voltage (V)
Max Output Current (A)
TPS61200/01_3.3Vout
TPS61202_5Vout
Efficiency vs Output Current
at Vin=1.8V, Pow e r Save Disabled
0%
10%
20%
30%
40%
50%
60%
70%
80%
90%
100%
0.001 0.01 0.1 1
Output Current (A)
Efficiency %
TPS61202_5Vout
TPS61200/01_3.3Vout
Setup and Operation
Figure 1. Maximum Output Current vs VBAT
Figure 2. Efficiency vs Output Current
TPS6120xEVM-179 4 SLVU207 – April 2007Submit Documentation Feedback

www.ti.com
3 Board Layout
3.1 Board Layout Recommendations
3.2 Board Layers
Board Layout
This chapter provides board layout recommendations as well as figures of the EVM board layers.
As for all switching power supplies, the layout is an important step in the design, especially at high peakcurrents and high switching frequencies. If the layout is not carefully done, the regulator could showstability problems as well as EMI problems. Therefore, use wide and short traces for the main current pathand for the power ground tracks. The input and output capacitor, as well as the inductor should be placedas close as possible to the IC. Use a common ground node for power ground and a different one forcontrol ground to minimize the effects of ground noise. Connect these ground nodes at any place close toone of the ground pins of the IC.
The feedback divider should be placed as close as possible to the control ground pin of the IC. To layoutthe control ground, it is recommended to use short traces as well, separated from the power groundtraces. This avoids ground shift problems, which can be due to superimposition of power ground currentand control ground current.
Figure 3. Top Assembly Layer
SLVU207 – April 2007 TPS6120xEVM-179 5Submit Documentation Feedback

www.ti.com
Board Layout
Figure 4. Top Layer
Figure 5. Bottom Layer
TPS6120xEVM-179 6 SLVU207 – April 2007Submit Documentation Feedback

www.ti.com
4 Schematic and Bill of Materials
4.1 Schematic
Schematic and Bill of Materials
Figure 6. TPS6120xEVM-179 Schematic
SLVU207 – April 2007 TPS6120xEVM-179 7Submit Documentation Feedback

www.ti.com
4.2 Bill of Materials
Schematic and Bill of Materials
Table 4. Bill of MaterialsCount
RefDes Value Description Size Part Number MFR-001 -002 -003
1 1 1 C1 10 µF Capacitor, Ceramic, 10V, X5R, 10% 0805 GRM21BR61A106KE19L muRata
2 2 2 C2,C3 0.1 µF Capacitor, Ceramic, 16V, X7R, 10% 0603 C1608X7R1C104K TDK
0 0 0 C4 Open Capacitor, Ceramic 0603
2 2 2 C5C6 10 µF Capacitor, Ceramic, 10V, X5R, 10% 0805 GRM21BR61A106KE19L muRata
4 4 4 J1 – J4 Header, 2 pin, 100mil spacing, (36-pin strip) 0.100 X 2 PTC36SAAN Sullins
2 2 2 JP1, JP2 Header, 3 pin, 100mil spacing, (36-pin strip) 0.100 X 3 PTC36SAAN Sullins
1 1 1 L1 2.2 µH Inductor, SMT, 1.5A, 110milliohm 0.118 X 0.118 LPS3015-222ML Coilcraft
1 1 1 R1 100 ΩResistor, Chip, 1/16W, 1% 0603 Std Std
1 1 1 R2 0 ΩResistor, Chip, 1/16W, 5% 0603 Std Std
0 0 0 R3 Open Resistor, Chip, 1/16W 0603
1 0 0 1.00M ΩResistor, Chip, 1/16W, 1% 0603 Std StdR40 1 1 0 ΩResistor, Chip, 1/16W, 1% 0603 Std Std
1 0 0 R5 178k ΩResistor, Chip, 1/16W, 1% 0603 Std Std
1 0 0 IC, Very Low Input Voltage Sync. Boost Converter w/1.5A SON-10 TPS61200DRC TISwitches, Adj V
0 1 0 IC, Very Low Input Voltage Sync. Boost Converter w/1.5A SON-10 TPS61201DRC TIU1
Switches, 3.3V
0 0 1 IC, Very Low Input Voltage Sync. Boost Converter w/1.5A SON-10 TPS61202DRC TISwitches, 5V
1 1 1 – PCB, 1.3 In x 1.15 In x 0.062 In HPA179 Any
2 2 2 – Shunt, 100 mil, Black 0.100 929950-00 3M
TPS6120xEVM-179 8 SLVU207 – April 2007Submit Documentation Feedback
