TPP Mini Case Instructions Addendum
FOR ASSISTANCE EMAIL [e-mail]
TPP Mini™Case Instructions
Thank you for purchasing the TPP Mini Kayak Propulsion System. The TPP Mini
offers users the ability to utilize their own battery source to power the control case
and motor. In order to ensure proper performance, the battery used must be able
to supply a continuous current of 25 amps. A minimum battery capacity of 20 amp
hours is needed but we recommend a 50ah or higher to equal the performance of
our original case. If you have questions about this requirement, please contact us
directly.
Getting Started
•Attach the leads to the battery ensuring that the red lead corresponds to the
(+) positive terminal on the battery and the black lead corresponds to the
(–) negative terminal on the battery.
Secure the battery
on the kayak deck or
in a hatch. The
battery cable
provided is 8 feet
long to provide
flexibility in the
install process.
Expected Run Time using a Dakota Lithium 12 volt 54ah battery
Low Power: 8 hours Medium Power: 6 hours High Power: 2.5 hours

2
TPP Mini Case Instructions Addendum
FOR ASSISTANCE EMAIL [e-mail]
Connecting Throttle, Battery, and Motor to Waterproof Control Case:
The motor, battery, and the throttle cables need to be connected to the control
case. The throttle connector (three pin) attaches to the receptacle on the right
and the motor connector (four pin)
attaches to the receptacle on the
left. The battery attaches to middle
receptacle. These receptacles are
keyed and will only connect when
oriented properly. Rotate the red
portion of the connector to find the
correct orientation.
Operating Instructions
Once the unit is on, the power button and LCD will illuminate, and the case should
be closed and latched during use to keep waterproof.
•Rotate the throttle control
knob fully counterclockwise to
arm system (this prevents the
motor from starting
unexpectantly when the unit is
first turned on)
•When the kayak is in the water
turn the throttle knob
clockwise to activate the
motor. At least a quarter turn
of the knob will be required
before activation. The motor
will then start and deploy
*Refer to the main install instructions for model specific information and detailed
guide for connecting the rudder or motor to your specific kayak*
