texet X-Driver TM-4082R Installation instructions

X-driver Disassembly steps
Step 1: prepare to disassembly Step 2: Remove all 10 pcs screw cap
Step 3: Remove 4 corner screw. (M1.6) Step 4: Remove 6 screw. (M1.4)

X-driver Disassembly steps
Step 5: remove rear cover Step 6: After remove rear cover
Step 7: remove four PCBA frame screw Step 8: After remove four screws

X-driver Disassembly steps
Step 9: remove Torch FPC connector Step 10: Remove T flash card FPC
Step 11: After remove T-flash card FPC Step 12: Remove PCBA Frame

X-driver Disassembly steps
Step 13: Remove Camera Step 14: After remove Camera
Step 15: Remove T flash card FPC tape Step 16: After remove tape

X-driver Disassembly steps
Step 17: Remove Camera rubber Step 18: After remove camera rubber
Step 19: Remove T flash card FPC Step 20: After Remove FPC

X-driver Disassembly steps
Step 21: remove main FPC connector Step 22: Remove Display connector
Step 23:Remove touch panel connector Step 24: After remove connector

X-driver Disassembly steps
Step 25: Side key FPC connector Step 26: Remove PCBA
Step 27:Remove 3 screws to disassemble
Sub-PCBA Step 28: After remove antenna frame

X-driver Disassembly steps
Step 29: Remove screw to get Sub-PCBA Step 30: Remove Sub-PCBA
Disassembly already

Step 1: Make sure power key, volume key, receiver & P-sensor rubber was put into
front cover already.
X-driver Assembly steps
power key, volume key receiver P-sensor rubber
Step 2: Display & metal case into front cover

X-driver Assembly steps
Step 3: assemble main
FPC connector into Sub-
PCBA
Step 4: assemble Sub-
PCBA Step 5: assemble Antenna
frame
Step 6: assemble RF connector Step 7: assemble Side key connector

X-driver Assembly steps
Step 8: assemble main
FPC connector into
PCBA
Step 9: assemble Display
FPC connector Step 10: assemble Touch
panel connector
Step 11: assemble
Camera rubber Step 12: assemble T flash card FPC Step 13: assemble
camera

X-driver Assembly steps
Step 14: assemble PCBA
frame Step 15: Screw it Step 16: assemble torch
FPC connector
Step 17: assemble seal ring Step 18: After assemble seal ring

X-driver Assembly steps
Step 19: Screw all 10 screws
Assembled whole unit
Step 20: assemble assemble
screw cap
