OPERATION MANUAL
GATOR®EK628L
Battery-powered
Crimping Tool
52047662 REV 3 © 2012 Greenlee Textron Inc. 3/12
Serial Number
Read and understand all of the instructions and
safety information in this manual before operating
or servicing this tool.
Register this product at www.greenlee.com

EK628L Battery-powered Crimping Tool
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
2
Description
The EK628L Battery-powered Crimping Tool is a
hand-held, self-contained crimping tool with removable
crimping jaws.
This tool is protected by U.S. Patent No. 6,276,186,
6,401,515, 6,718,870, 7,086,979, 7,216,523, and
7,254,982.
Safety
Safety is essential in the use and maintenance of
Greenlee tools and equipment. This manual and any
markings on the tool provide information for avoiding
hazards and unsafe practices related to the use of this
tool. Observe all of the safety information provided.
Purpose of this Manual
This manual is intended to familiarize all personnel with
the safe operation and maintenance procedures for the
following Greenlee tool:
EK628L Battery-powered Crimping Tool
Keep this manual available to all personnel.
Replacement manuals are available upon request
at no charge at www.greenlee.com.
Do not discard this product or throw away!
For recycling information, go to www.greenlee.com.
All specications are nominal and may change as design
improvements occur. Greenlee Textron Inc. shall not be liable for
damages resulting from misapplication or misuse of its products.
GATOR is a registered trademark of Greenlee Textron Inc.
Blackburn is a registered trademark of Thomas & Betts.
KEEP THIS MANUAL
Table of Contents
Description ..................................................................... 2
Safety ............................................................................. 2
Purpose of this Manual .................................................. 2
Important Safety Information ..................................... 3–4
Identication................................................................... 5
Specications................................................................. 5
Operation.................................................................... 6–7
Die and Connector Selection ......................................... 8
Maintenance................................................................... 9
Troubleshooting............................................................ 10

EK628L Battery-powered Crimping Tool
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
3
IMPORTANT SAFETY INFORMATION
SAFETY
ALERT
SYMBOL
This symbol is used to call your attention to hazards
or unsafe practices which could result in an injury or
property damage. The signal word, dened below,
indicates the severity of the hazard. The message
after the signal word provides information for pre-
venting or avoiding the hazard.
Immediate hazards which, if not avoided, WILL result
in severe injury or death.
Hazards which, if not avoided, COULD result in
severe injury or death.
Hazards or unsafe practices which, if not avoided,
MAY result in injury or property damage.
Read and understand all of the
instructions and safety information
in this manual before operating or
servicing this tool.
Failure to observe this warning
could result in severe injury or death.
Electric shock hazard:
This tool is not insulated. When
using this unit on or near energized
electrical lines, use proper personal
protective equipment.
Failure to observe this warning
could result in severe injury or death.
Wear eye protection when operating
or servicing this tool.
Failure to wear eye protection could
result in serious eye injury from
ying debris or hydraulic oil.
Skin injection hazard:
Do not use hands to check for oil
leaks. Oil under pressure easily
punctures skin. If injured, seek
medical attention immediately to
remove oil.
Failure to observe this warning
could result in serious injury, gan-
grene, or death.
Do not use solvents or ammable
liquids to clean the tool body.
Solvents or ammable liquids could
ignite and cause serious injury or
property damage.
An incomplete crimp can cause a re.
• Use proper die, connector, and cable combina-
tions. Improper combinations can result in an
incomplete crimp.
• The relief valve sounds and the ram automatically
retracts to indicate a completed crimp. If you do
not hear the sound of the relieve valve or the ram
does not automatically retract, the crimp is not
complete.
Failure to observe these warnings could result in
severe injury or death.

EK628L Battery-powered Crimping Tool
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
4
Pinch points:
• Remove battery before changing
dies, adapters, or jaws.
• Keep hands away from the crimp-
ing tool head when crimping.
Failure to observe these warnings
could result in severe injury or death.
Do not dispose of batteries in a re. They will vent
fumes and may explode.
Failure to observe this warning could result in severe
injury from harmful fumes or burns from ying
debris.
Inspect tool and dies before use. Replace any
worn or damaged parts. A damaged or improp-
erly assembled tool can break and strike nearby
personnel.
Failure to observe this warning could result in severe
injury or death.
• Do not use this tool for continuous use. After 30 to
40 cycles, allow the tool to cool for 15 minutes.
• Do not secure this tool in a vise. This tool is
designed for hand-held operation.
• This tool may be used in damp or wet environ-
ments; however, air-drying is recommended before
use if the tool becomes soaked. Damage may
result when the tool is operated prior to thorough
drying when electrical components are soaked.
• Use this tool for the manufacturer’s intended
purpose only.
Failure to observe these precautions may result in
injury or property damage.
Do not allow anything to contact the battery
terminals.
• Do not immerse the batteries in liquid. Liquid may
create a short circuit and damage the battery.
If batteries are immersed, contact your service
center for proper handling.
• Do not place the battery into a pocket, tool pouch,
or tool box with conductive objects. Conductive
objects may create a short circuit and damage the
battery.
• Do not place a battery on moist ground or grass.
Moisture may create a short circuit and damage
the battery.
Failure to observe these precautions may result in
injury or property damage.
• Do not store the battery at more than 122 °F
(50°C) or less than –4 °F (–20 °C). Damage to the
battery can result.
• Do not use another manufacturer’s charger. Other
manufacturers’ chargers may overcharge and
damage the battery.
• Do not attempt to open the battery. It contains no
user-serviceable parts.
Failure to observe these precautions may result in
injury or property damage.
Do not perform any service or maintenance other
than as described in this manual. Injury or damage
to the tool may result.
Failure to observe this precaution may result in injury
and property damage.
Note: Keep all decals clean and legible, and replace
when necessary.
IMPORTANT SAFETY INFORMATION

EK628L Battery-powered Crimping Tool
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
5
Identification
2
5
4
3
7
9
1
6
8
1. Lock Pin
2. Crimping Jaws
3. Crimping Die Release
4. Retract Button
5. LED Indicator (red)
6. Battery Lock
7. Battery Cartridge
8. LED Work Light (white)
9. Trigger
Specifications
Crimping Tool
Length........................................................................................................ 18.50" (470 mm)
Width .......................................................................................................... 2.87" (72.9 mm)
Depth........................................................................................................ 4.50" (114.3 mm)
Weight................................................................................................................ 6.5 lb (3 kg)
Crimping Force...............................................................................................6 tons (53 kN)
Hydraulic Oil ......................................................... 52057878 biodegradable hydraulic uid
Recommended Operating Temperature Range...................5 °F to 122 °F (–15 °C to 50°C)
Battery Charger........................................................................ Read the instructions supplied
with the battery charger
52047087 120 VAC corded adapter
52047088 230 VAC corded adapter
52049190 18 V, 1.5 Ah lithium-ion battery
52049189 18 V, 3.0 Ah lithium-ion battery
52054992 Li (18 V) to NiCd, NiMH (12 V) charger adapter
52049201 120 VAC, 18 V charger
52049202 230 VAC, 18 V charger
52049204 12 VDC, 18 V charger

EK628L Battery-powered Crimping Tool
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
6
Operation
Inspect tool and dies before use. Replace any
worn or damaged parts. A damaged or improp-
erly assembled tool can break and strike nearby
personnel.
Failure to observe this warning could result in severe
injury or death.
Electric shock hazard:
This tool is not insulated. When
using this unit on or near energized
electrical lines, use proper personal
protective equipment.
Failure to observe this warning
could result in severe injury or death.
Wear eye protection when operating
or servicing this tool.
Failure to wear eye protection could
result in serious eye injury from
ying debris or hydraulic oil.
Pinch points:
• Remove battery before changing
dies, adapters, or jaws.
• Keep hands away from the crimp-
ing tool head when crimping.
Failure to observe these warnings
could result in severe injury or death.
• Do not use this tool for continuous use. After 30 to
40 cycles, allow the tool to cool for 15 minutes.
• Do not secure this tool in a vise. This tool is
designed for hand-held operation.
• This tool may be used in damp or wet environ-
ments; however, air-drying is recommended before
use if the tool becomes soaked. Damage may
result when the tool is operated prior to thorough
drying when electrical components are soaked.
• Use this tool for the manufacturer’s intended
purpose only.
Failure to observe these precautions may result in
injury or property damage.
Charging the Battery
Read the instructions supplied with the battery charger.
LED Work Light (white)
This LED automatically turns on when the trigger is
pulled. It remains on for 10 seconds after the trigger is
released.
LED Indicator (red)
This tool is equipped with a special circuit board incor-
porating several important features to inform the user
about the current status of the unit. The LED signals in
the following cases:
What happens Signal What it means
Flashing light for 2seconds Battery is inserted in tool
Constant light for 20seconds
at end of cycle
Battery charge is below
17V at beginning of cycle
Tool will not start, and
constant light for 20seconds
when trigger is released
Battery charge is below
16V at beginning of cycle
Tool will stop, and constant
light for 20seconds after
trigger is released
Battery voltage drops
below 13V during cycle
Tool will stop, and flashing
light for 20seconds when
trigger is released
Motor current exceeds
20A during cycle
Circuit has become too hot
Pressure Sensor
This tool is equipped with a pressure sensor that alerts
the user of an incomplete crimp.
• If the tool is manually retracted before completion of a
crimp, the red LED and an audible beep will be active
for 2 seconds.
• If the tool is unable to reach the required crimp force,
the red LED, work light, and an audible beep will pulse
until after the trigger is released.

EK628L Battery-powered Crimping Tool
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
7
Operation (cont’d)
Installing Dies
1. Select the proper dies for the connector to be
crimped.
2. Install dies in jaws making certain that they are
properly secured by the spring-loaded, positive
lock, die buttons.
Preparing Cable
Follow the lug manufacturer’s instructions for appropri-
ate cable strip length.
Crimping Direction
First Compression
Crimping Direction
SIDE A
Crimping Direction
SIDE B
First Compression
SIDE A
First Compression
SIDE B
Crimping Procedure
1. Insert conductor into the connector and align the
tool and die on the connector. Start in the center
for splices; start on the end, nearest the pad, for
terminals.
2. Activate the tool by pulling the trigger. Continue to
hold the trigger until the ram retracts. This is the
signal that the crimp is complete.
3. Continue crimping the connector until the correct
number of crimps has been completed. Work from
the center to the outer edges for splices, alternat-
ing sides, if possible, for the best compression
connections.
An incomplete crimp can cause a re.
• Use proper die, connector, and cable combina-
tions. Improper combinations can result in an
incomplete crimp.
• The relief valve sounds and the ram automatically
retracts to indicate a completed crimp. If you do
not hear the sound of the relieve valve or the ram
does not automatically retract, the crimp is not
complete.
Failure to observe these warnings could result in
severe injury or death.

EK628L Battery-powered Crimping Tool
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
8
CJ22 Jaw and KA22/KC22-type Die Selection
Note: This tool will provide a cUL and UL classified crimp ONLY when used with the CJ22 jaws
and KA22- or KC22-type dies.
Note: This tool will provide 53 kN (6 tons) of crimping force when used with the CJ22 jaws.
Crimps made on copper cable with Greenlee KC22-type dies and the copper connectors listed here are cUL and UL classied.
Crimps made on copper or aluminum cable with Greenlee KA22-type dies and the dual-rated aluminum connectors listed
here are cUL and UL classied.
Refer to “Connector Selection” for brand names and model numbers of appropriate lugs as well as crimping instructions.
95R7
Dies for Dual-rated Aluminum Connectors
Catalog Number UPC Number Cable Size
KA22-8 06744 8 AWG
KA22-6 06745 6 AWG
KA22-4 06746 4 AWG
KA22-2 06747 2 AWG
KA22-1 06749 1 AWG
KA22-1/0 06750 1/0 AWG
KA22-2/0 06751 2/0 AWG
KA22-3/0 06752 3/0 AWG
KA22-4/0 06753 4/0 AWG
KA22-250 06754 250 kcmil
KA22-300 06755 300 kcmil
KA22-350 06756 350 kcmil
Dies for Copper Connectors
Catalog Number UPC Number Cable Size Color Code
KC22-8 03079 8 AWG Red
KC22-6 03080 6 AWG Blue
KC22-4 03081 4 AWG Gray
KC22-2 03082 2 AWG Brown
KC22-1 03083 1 AWG Green
KC22-1/0 03084 1/0 AWG Pink
KC22-2/0 03085 2/0 AWG Black
KC22-3/0 03086 3/0 AWG Orange
KC22-4/0 03087 4/0 AWG Purple
KC22-250 03088 250 kcmil Yellow
KC22-300 03089 300 kcmil White
KC22-350 03090 350 kcmil Red
KC22-400 03091 400 kcmil Blue
KC22-500 03092 500 kcmil Brown
KC22-600B 03094 600 kcmil Green
Connector Selection
CJ22 Crimping Jaw Range: Copper — 8 AWG to 600 kcmil†; Dual-rated Aluminum — 8 AWG to 350 kcmil
When used with KC22-type dies, this tool is cUL and UL classied for use with the following connector brands:
Connector
Type
Barrel
Type Anderson Blackburn®Burndy ILSCO Panduit T&B Penn-
Union†
No. of
Crimps*
Copper
Splice
Short VHSS CSP YS-LsCT SCSS/SCS 54504-54518 BCU
A
Long VHS CU YSsCTL SCL/SCH 54804-54818 BBCU
Copper
Lugs
Short VHCS CTL-2/CTL
YA-2LN/YA-L/YA-2L
YA/YA-L-TC/YA-L-2TC
CSW
CRA/CRB
LCAS/LCA
LCD
54104-54118
54204-54218 BLU
Long VHCL CTL-L/LCN YA-2N
CLN/CLW
CRA-L/CRB-L
CRA-2L/CRB-2L
LCB/LCC 54930BE-54918BE
54850BE-54876BE BBLU
When used with KA22-type dies, this tool is cUL and UL classied for use with the following connector brands:
Connector Type Barrel Type Anderson Blackburn®Burndy ILSCO Panduit** T&B Penn-
Union
No. of
Crimps*
Dual-rated
Aluminum Splice — VACS ASP YS-A AS SA 60501-60565 PIK
B
Dual-rated
Aluminum Lugs — VACL ATL YA-A
YA-ATN
ACL/ACN
2ACL/2ACN LAA/LAB 60101-60166
60230-60267 BLUA
* Use the number of crimps listed in the last column instead of the number provided with the connector:
A — 8 to 1/0 AWG: 1 crimp B — 8 to 2 AWG: 2 crimps
2/0 AWG to 600 kcmil: 2 crimps 1 to 3/0 AWG: 3 crimps
4/0 AWG to 350 kcmil: 4 crimps
** 6 AWG to 350 kcmil
† 500 kcmil maximum with Penn-Union connectors
s 8 AWG to 350 kcmil with Burndy copper splices

EK628L Battery-powered Crimping Tool
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
9
Maintenance
Wear eye protection when operating
or servicing this tool.
Failure to wear eye protection could
result in serious eye injury from
ying debris or hydraulic oil.
Skin injection hazard:
Do not use hands to check for oil
leaks. Oil under pressure easily
punctures skin. If injured, seek
medical attention immediately to
remove oil.
Failure to observe this warning
could result in serious injury, gan-
grene, or death.
Do not use solvents or ammable
liquids to clean the tool body.
Solvents or ammable liquids could
ignite and cause serious injury or
property damage.
Pinch points:
• Remove battery before changing
dies, adapters, or jaws.
• Keep hands away from the crimp-
ing tool head when crimping.
Failure to observe these warnings
could result in severe injury or death.
Relief valve adjustments must be done by an
authorized service center.
Daily
Before use:
1. Inspect the tool for wear or damage, such as cracks,
gouges, or chips.
2. Inspect the tool for damage or leaks.
3. Inspect the rotation of the head assembly. Fully
retract the ram. The head should rotate no more
than 360°. If damage is detected, send the tool to a
Greenlee Authorized Service Center for inspection.
After use:
1. Use a damp cloth and mild detergent to clean the
housing. Allow the housing to dry.
2. Fully retract the ram. Place the tool in the carrying
case and store in a cool, dry place.
3. If necessary, recharge the batteries. Refer to the
instructions supplied with the battery charger.
Monthly
1. Thoroughly clean all surfaces.
2. Check the oil level.
Annually or After 10,000 Crimps
1. Replace the hydraulic oil.
2. Send the tool to a Greenlee Authorized Service
Center for inspection.
Checking the Oil Level
1. Remove the screws holding the housing cover
together.
2. Point the crimping head downward and remove the
oil reservoir plug. Fill reservoir if necessary.
3. Replace the oil plug and housing cover.

EK628L Battery-powered Crimping Tool
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
10
Problem Possible Cause Probable Remedy
Tool is inoperative. Dirt, contaminants, etc., in
ram area oftool.
Clean tool.
Tool battery contacts damaged. Reform contacts.
Tool components worn or
damaged.
Return tool to a Greenlee Authorized Service
Center.
Motor is inoperative. Low or uncharged battery. Try known charged battery. Inoperative battery
may be discharged or may have reached life
expectancy.
Broken switch components. Return tool to a Greenlee Authorized Service
Center.
Motor runs but tool will not
complete a cycle.
Oil level low. Return tool to a Greenlee Authorized Service
Center.
Air in hydraulic system. Pull trigger and hold retract button simultane-
ously. Run for approximately 10 seconds, and
then attempt to crimp. If unsuccessful, return
tool to a Greenlee Authorized Service Center.
Cold oil. Pull trigger and hold retract button simultane-
ously to warm oil. Store tool in warm area.
Dies stop during operation. Oil level low. Return tool to a Greenlee Authorized Service
Center.
Air in hydraulic system. Pull trigger and hold retract button simultane-
ously. Hold for approximately 10 seconds.
LED glows for 20 seconds. Battery charge low. Charge or replace battery.
Tool loses oil. Damaged internal seal. Return tool to a Greenlee Authorized Service
Center.
Troubleshooting
Before You Begin
1. Make sure that the battery is charged. Recheck
the battery after several minutes to make sure the
battery is holding its charge.
2. Use a nonflammable contact cleaner or pencil
eraser to clean the electrical contacts on the battery
and tool.
3. Reinstall the battery and check the tool again.

EK628L Battery-powered Crimping Tool
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
11

4455 Boeing Drive • Rockford, IL 61109-2988 • USA • 815-397-7070
An ISO 9001 Company • Greenlee Textron Inc. is a subsidiary of Textron Inc.
USA Tel: [phone]
Fax: [phone]
Canada Tel: [phone]
Fax: [phone]
International Tel: [phone]
Fax: [phone]
www.greenlee.com
