The Land of Nod SIMPLE Twin-over-twin Bunk Bed User manual

WARNING: Failure to follow these warnings and
instructions could result in serious injury or death
!
Follow the information and warnings on bunk end structure and carton. Do not remove
these labels.
Always use the recommended size mattress to help prevent the likelihood of entrap-
ment or falls.
• Surface of mattress must be at least 5" (127 mm) below the upper edge of guardrails.
The maximum thickness of the bunk mattress is 10”
• Use only mattress which is 74” – 75” long and 37 1/2” – 38 1/2” wide
• Never allow a child under 6 years on the upper bunk.
• Prohibit more than one person on upper bunk.
• Periodically check to ensure guardrail, ladder and other components are in their
proper position, free from damage, and that all connectors are tight.
• Do not allow horseplay on or under the bed and Prohibit jumping on the bed.
• Always use the ladder for entering and leaving the upper bunk.
• Do not use substitute parts. Contact the Land of Nod for replacement parts at
800.933.9904
• Use of a night light may provide added safety precaution for a child using the upper
bunk.
• Always use the guardrails on both sides of the upper bunk. If the bunk bed will be
placed next to the wall, the guardrail that runs the full length of the bed should be
placed against the wall to prevent entrapment between bed and wall.
• The use of water or sleep flotation mattresses is prohibited.
STRANGULATION HAZARD!
• Never attach or hang items to any part of the bunk that are not designed for use with
the bed; for example, but not limited to, hooks, belts and jump ropes.
• Keep these instructions for future reference.
SIMPLE
TWIN-OVER-TWIN BUNK BED

WARNING: Adult Assembly Required
!
SIMPLE
TWIN-OVER-TWIN BUNK BED
Made in Vietnam - r13 Page 1 of 3
COMPONENTS
Thank you for purchasing the Simple Twin-Over-Twin
Bunk Bed.This page lists all the contents included in
the box. Please take the time to identify the hardware as
well as the individual components to this product. As
you unpack and prepare for assembly, place the
contents on a carpeted or padded area to protect them
from damage.
Note: 2 people are required to safely assemble this product.
Customer Service 800.933.9904 | Latest instructions available on www.landofnod.com
2 - top frames 2 - slat assemblies2- bottom frames 1 - small guard rail
1 - large guard rail
4 - caps
1 - ladder
4 - side rails
(2 left, 2 right)
TOOLS REQUIRED
phillips head screwdriver allen wrench (included)
(We recommend the use of hand tools instead of power tools)
Missing hardware? Please call 800.933.9904 for replacements.
NOTE: Contains small parts. Keep away from small children.
GUARD RAIL/LADDER HARDWARE
BED HARDWARE
12 - large
screws
3 - allen
bolts
24 - phillips
bolts
24 - flat
washers
24 - spring
washers
10 - phillips
bolts
13 - spring
washers
13 - flat
washers
2 - small
screws
4 - metal
dowels

Made in Vietnam - r13 Page 2 of 3
Customer Service 800.933.9904 | Latest instructions available at www.landofnod.com
12
With the assistance of another adult, place slat
assembly into bottom bed assembly. Secure, but
do not over tighten with 6 large screws. Make
sure straps face upwards during assembly as
shown.
With assistance of another adult, attach side rails
to bottom frames with 3 phillips bolts,3spring
washers and 3 flat washers per bracket as
shown. Secure, but do not over tighten, bolts with
a phillips head screwdriver.
NOTE: Do not over
tighten screws
34With the assistance of another adult, place slat
assembly into top bed assembly and secure with 6
large screws as shown.
With assistance of another adult, attach side rails
to top frames with 3 phillips bolts,3spring
washers and 3 flat washers per bracket as
shown.
NOTE: Do not
over tighten bolts
side
rail
side
rail
SIMPLE
TWIN-OVER-TWIN BUNK BED

Made in Vietnam - r13 Page 3 of 3
Customer Service 800.933.9904 | Latest instructions available at www.landofnod.com
5
Fit hooks of ladder over top bed assembly as
shown. Make sure holes of ladder are aligned with
corresponding holes of bed. At this point, secure
ladder with 2 small screws, using a screwdriver.
Assembly is now complete.
A. Insert 4 metal dowels into bottom frame
assembly as shown.
B. With assistance of another adult, fit holes of top
bed assembly onto corresponding dowels of
bottom bed assembly as shown.
A. Determine desired orientation of bunk beds. Attach
small guard rail to top frame assembly with 4 phillips
bolts, 4 spring washers, 4 flat washers as shown,
using a screwdriver. Secure small guard rail to
footboard with 1 allen bolt, 1 spring washer, 1 flat
washer as shown, using an allen wrench.
B. Attach large guard rail to top frame assembly with
6 phillips bolts, 6 spring washers, 6 flat washers..
Secure large guard rail to headboard/footboard with 2
allen bolts, 2 spring washers, 2 flat washers. 6
7
small
guard rail
large
guard rail
A
B
A
B
SIMPLE
TWIN-OVER-TWIN BUNK BED
CLEANING AND CARE
Clean surfaces with a dry or damp soft cloth. Do not use
abrasive cleaners. Do not use furniture wax or polish as the
unit is finished with a protective clear lacquer.
