Winco 4220 Reference guide

Page 1 of 4
006285 Rev H Date 01-07-14 JWC
1. READ AND FOLLOW ALL DIRECTIONS.
2. NEVER place stool on a cart, table, stand or other objects; Stool could fall and INJURY MAY OCCUR.
3. DO NOT allow children to play with stool; INJURY MAY OCCUR.
4. Periodically, recheck tightness of all nuts, bolts and screws.
5. Stool must ALWAYS be positioned on level surface.
6. DO NOT use stool in or with ANY type of vehicle or trailer. Winco stools have not been tested or approved for use
by an occupant in any type of vehicle or trailer.
7. Immediately remove from service; Any stool with broken or missing parts, or other visible damage.
8. USE ONLY WINCO AUTHORIZED REPLACEMENT PARTS.
9. NEVER EXCEED the recommended weight capacity of 300 lbs. (136 kg).
10. SAVE THESE INSTRUCTIONS for future reference and training.
4220
Chrome Steel Footstool
4230
Chrome Steel Footstool w/Handle
CUSTOMER INSTRUCTIONS
Tools needed:
•Scissors or box cutter
•Box-wrench (provided)
After checking your product for any shipping damage, remove all packing material and hardware that was
secured for shipping. Cut tape and/or plastic with scissors, being careful not to damage product.
HANDLE INSTALLATION – Model 4230 ONLY (FIG.1)
1. Line up the holes in the handle with holes in the 4230 stool legs and insert
the (4) phillips-head screws.
2. Place (1) nylon lock-nut onto the end of each screw.
3. Tighten all (4) nylon lock-nuts to a snug fit using a phillips-head
screwdriver and a box wrench (provided).
4. The footstool is now ready for use. Please keep safety first, and follow the
guidelines below, during use.
CARE & MAINTENANCE OF YOUR FOOTSTOOL
1. Periodically check all fasteners for tightness.
2. Do not use on uneven, soft surfaces.
3. Do not use in a wet environment
4. Replace worn or cracked crutch tips.
PLEASE READ AND FAMILIARIZE YOURSELF WITH ALL INSTRUCTIONS BEFORE PROCEEDING WITH ASSEMBLY
PLEASE READ AND FAMILIARIZE YOURSELF WITH ALL INSTRUCTIONS BEFORE USING THIS PRODUCT.
If you have trouble understanding these instructions contact your dealer or Winco customer support, [phone]
before attempting to use this product; otherwise injury may occur.
4220-4230 Weight Capacity = 300 lbs. (136 kg.)
Winco assumes no responsibility for damage or injury caused by improper assembly,
installation, use, or maintenance of these products.
FIG.1
Screws
&
Lock-nuts

Page 2 of 4
006285 Rev H Date 01-07-14 JWC
Parts List:Qty. Part Number
(1) Handrail (4230 ONLY) 1 480030
(2) Footstool w/ Handrail holes (4230 ONLY) 1 210423
(3) Crutch Tip (replacements are gray) 4 701700
(4) ¼-20 Nylon Lock-Nut (4230 ONLY) 4 566204
(5) ¼-20 x 2” Phillips Mach. Screw (4230 ONLY) 4 566539
(1)
(5)
(4)
(3)
(2)
Model 4220
Model 4230

Page 3 of 4
006285 Rev H Date 01-07-14 JWC
Other Quality Winco Medical Furnishings You May Be Interested In:
Visit us online at www.wincomfg.com

Page 4 of 4
006285 Rev H Date 01-07-14 JWC
Design, appearance, parts, & construction are subject to change without notice
