The Splash Lab TSL.GR45.18 Maintenance and service guide

installation + maintenance
TSL.GR45.18
straight grab rail

2Technical Data
3Before You Install
4How to Install
5Cleaning
5 Maintenance
5Operation
6Warranty
7Contact Details
contents
Finishes CS(Brushed satin stainless steel)
CP (Brushed copper finish)
BK (Brushed black finish)
BR (Brushed brass finish)
Weight TSL.GR45.18 - 2lb 14oz
Stainless steel grade AISI 304 stainless steel
Warranty 2 years from date of purchase
technical data
2TSL.GR45.18 / TSL.GR45.600 STRAIGHT GRAB RAIL MANUAL

TSL.GR45.18 / TSL.GR45.600 STRAIGHT GRAB RAIL MANUAL 3
Location
The rail is to be installed in accordance with the current ADA regulations in force. The
rail must be mounted with fixings appropriate to the wall construction.
before you install
SIDE FIXING
TSL.GR45.18
3-15/16"
21-7/16"
18"
1-15/16"
16 1/16"
1-15/16"
1-15/16
"
Ø
1/4 "

4 TSL.GR45.18 / TSL.GR45.600 STRAIGHT GRAB RAIL MANUAL
how to install
1
Prise the cover plates off that conceals
the fixing holes.
2
Position the rail on the wall at the desired
location and mark the fixing holes.
3
Using appropriate fixings (not supplied),
fasten the rail to the wall and tighten
securely
4
Refix the cover plates

TSL.GR45.18 / TSL.GR45.600 STRAIGHT GRAB RAIL MANUAL 5
cleaning
All grades of stainless steel will stain or discolour if due care and attention is not taken.
The surface must be regularly cleaned to ensure a long service life of the bin.
Use a soft cloth or sponge with a mild solution of soapy water as part of the regular
washroom janitorial routine. Do not use abrasive or cream cleaners as these will damage
the surface finish.
If the rail is subjected to a highly-chlorinated environment eg swimming pools or marine
coastal locations, a further treatment, in addition to the regular cleaning as described
above, is recommended by the application of a household cleaning product containing
silicone.
Contact The Splash Lab technical team for more detailed stainless steel care guidelines.
maintenance
The fixings securing the rail should be periodically inspected to ensure the rail is firmly
attached to the wall.
operation
The user is to grasp the rail firmly to provide sucient support to enable them to change
their position.

6 TSL.GR45.18 / TSL.GR45.600 STRAIGHT GRAB RAIL MANUAL
warranty
We believe the future is personal. With a global mindset, we challenge conventional
restroom norms via product innovation to create considered restroom solutions for
corporate and educational spaces. We use rich raw materials, cutting-edge automation
and considered restroom design to powerfully and positively influence the lives of
people. We are The Splash Lab.
Demonstrating our commitment to quality and our belief in the strength of our designs,
we can offer the following warranties.
The Splash Lab will warrant that its products will be free of manufacturing and material
defects during normal use and environmental conditions as detailed below:
Straight Grab Rail 2 years
If a defect is found in normal use, The Splash Lab. will, at their discretion, repair, provide
a replacement part or product, or make appropriate adjustments. Damage caused by
accident, misuse, or abuse is not covered by this warranty. Improper care and cleaning
will void the warranty.
Non-operation of the product due to environmental conditions beyond our control,
installation error, incorrect maintenance, water quality, fair wear and tear, incorrect or
inappropriate installation, misuse and abuse is not covered by the warranty.
Proof of purchase (original sales receipt) must be provided to The Splash Lab with all
warranty claims.
The above warranty is valid for goods supplied within North America.
For goods supplied outside of North America, The Splash Lab will honour the above
stated warranty periods for the parts only.
THE SPLASH LAB DISCLAIM ANY LIABILITY FOR SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES.

TSL.GR45.18 / TSL.GR45.600 STRAIGHT GRAB RAIL MANUAL 7
contact
General information
310 410 5008
Studio D, 8745 Washington Blvd, Culver city, CA 90232
Technical support
[e-mail]
For further contact information visit:
thesplashlabusa.com

TSL.GR45.18/TSL.GR45.600 • (US) • REV 3-26/11/19
