Thermador Pro Harmony Professional Series User manual

Use and care GUIDE
Professional Series Pro Harmony® Induction
Ranges
PRI30LBHU PRI30LBHC PRI36LBHU
PRI36LBHC
THERMADOR.COM

en-us
2
Table of contents
1 IMPORTANT SAFETY INSTRUCTIONS.................... 3
1.1 Safety definitions....................................................... 3
1.2 General information................................................... 3
1.3 Proper installation and maintenance ......................... 3
1.4 Safe use.................................................................... 5
1.5 Child safety ............................................................... 8
1.6 Cleaning function ...................................................... 8
1.7 Electromagnetic interference..................................... 9
1.8 Remote operation ..................................................... 9
1.9 State of California Proposition 65 Warnings .............. 9
2 Preventing material damage .................................. 10
2.1 Preventing oven cavity damage .............................. 10
2.2 Preventing cooktop damage.................................... 10
3 Environmental protection and energy-saving ...... 11
3.1 Disposal of packaging............................................. 11
3.2 Saving energy when using the oven........................ 11
3.3 Saving energy when using the cooktop................... 11
4 Familiarizing yourself with your appliance ........... 12
4.1 Appliance................................................................ 12
4.2 Oven control panel.................................................. 14
4.3 Cooktop control panel ............................................. 16
5 Accessories............................................................. 19
5.1 Oven accessories ................................................... 19
5.2 Other accessories ................................................... 19
5.3 Rack positions......................................................... 20
5.4 Safe use of oven racks............................................ 20
5.5 Inserting the wire rack............................................. 20
5.6 Inserting the telescopic rack.................................... 20
6 Before using for the first time ................................ 21
6.1 Start-up settings...................................................... 21
6.2 Cleaning the appliance before using it for the first
time......................................................................... 22
7 Oven operation........................................................ 22
7.1 Setting the heating mode and temperature ............. 22
7.2 Heating time limitation............................................. 22
7.3 Fast preheat............................................................ 22
7.4 Meat probe.............................................................. 23
7.5 Turning the panel lock on or off............................... 23
7.6 Timer functions ....................................................... 23
7.7 Basic Settings - Oven.............................................. 24
7.8 Getting the most out of your appliance.................... 25
8 Cooktop operation .................................................. 28
8.1 Suitable cookware................................................... 28
8.2 Turning the cooktop on or off .................................. 28
8.3 Cooking zone settings............................................. 29
8.4 Liberty® cooking zone............................................. 30
8.5 FlexPlus cooking zone (onlyfor30"appliances) ..... 31
8.6 HeatShift® function ................................................. 32
8.7 Kitchen timer ............................................................ 33
8.8 Stopwatch ................................................................ 33
8.9 PowerBoost® .......................................................... 33
8.10 PanBoost®............................................................. 34
8.11 MoveMode®........................................................... 34
8.12 CookSmart® .......................................................... 35
8.13 Cooktop panel lock................................................. 39
8.14 Wipe protection ...................................................... 39
8.15 Energy consumption display................................... 39
8.16 Power limitation...................................................... 39
8.17 Basic Settings - Cooktop ........................................ 39
8.18 Cooktop - Hood Sync ............................................. 40
9 HomeConnect® ...................................................... 42
9.1 Setting up HomeConnect®...................................... 42
9.2 HomeConnect® settings ......................................... 43
9.3 Changing the settings via the HomeConnect®
app........................................................................... 44
9.4 Remote start - oven cavity feature............................ 44
9.5 Setting remote control - oven cavity feature.............. 45
9.6 Remote diagnostics.................................................. 45
9.7 Software update ....................................................... 45
9.8 Data Protection ........................................................ 45
10 Cleaning and maintenance.................................... 45
10.1 Cooktop cleaning and maintenance ....................... 46
10.2 Oven cleaning and maintenance ............................ 47
11 Troubleshooting..................................................... 51
12 Disposal .................................................................. 55
12.1 Disposal of your old appliance................................ 55
13 Customer Service................................................... 55
13.1 Model number (E-Nr.), production number (FD)
and consecutive numbering (Z-Nr.) ........................ 55
13.2 Rating plate location............................................... 55
14 STATEMENT OF LIMITED PRODUCT
WARRANTY ............................................................ 56
14.1 What this warranty covers & Who it applies to........ 56
14.2 How long the warranty lasts ................................... 56
14.3 Repair/replace as your exclusive remedy ............... 56
14.4 Out of warranty product.......................................... 57
14.5 Warranty exclusions............................................... 57
14.6 Obtaining warranty service..................................... 57
14.7 Product information ................................................ 57

en-us
3
Read all instructions carefully before use. These precautions will reduce the risk of electrical shock, fire and injury to
persons. When using kitchen appliances, basic safety precautions must be followed including those in the following
pages.
1.1 Safety definitions
Here you can find explanations of the safety signal words
used in this manual.
WARNING
This indicates that death or serious injuries may occur as
a result of non-observance of this warning.
CAUTION
This indicates that minor or moderate injuries may occur
as a result of non-observance of this warning.
NOTICE:
This indicates that damage to the appliance or property
may occur as a result of non-compliance with this
advisory.
Note:This alerts you to important information and/or tips.
1.2 General information
This Use and Care Guide explains the basics of operating
your appliance and those safety measures that must be
followed. For complete and safe installation information,
refer to the Installation Instructions included with the
appliance.
All product manuals may be downloaded online at
www.thermador.com/us/support/owner-manuals.
INSTALLER: Please leave these instructions with this unit
for the owner.
OWNER: Please retain these instructions for future
reference. Read all safety instructions before operating
the appliance. Have the installer show you where the
electric circuit breaker is located so you know how and
where to turn off the electricity to the appliance.
1.3 Proper installation and maintenance
WARNING
When properly cared for, your new appliance has been
designed to be safe and reliable.
▶Read all instructions carefully before use. These
precautions will reduce the risk of burns, electric shock,
fire, and injury to persons.
▶When using kitchen appliances, basic safety
precautions must be followed, including those in the
following pages.
WARNING
DANGER OF TIPPING ON RANGES
▶All ranges can tip and injury can result. To prevent
accidental tipping of the range, attach it to the floor,
wall, or cabinet by installing the anti-tip bracket
supplied.
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS

en-us
4
▶A child or adult can tip the range over and be killed or
seriously injured. Verify that the anti-tip bracket is
securely installed. Ensure the anti-tip bracket is
engaged when the range is moved.
▶DO NOT operate the range without the anti-tip bracket
in place. Failure to follow the instructions in this manual
can result in death or serious burns to children and
adults.
▶If the range is moved for cleaning, service, or any other
reason, ensure that the anti-tip bracket is properly
reengaged when the range is pushed back into place.
In the event of abnormal usage (such as a person
standing, sitting, or leaning on an open door), failure to
take this precaution can result in tipping of the range.
Personal injury might result from spilled hot liquids or
from the range itself.
▶Check for proper installation and use of anti-tip bracket.
Carefully tip range forward pulling from the back to
ensure that the anti-tip bracket engages the range and
prevents tip-over. Range should not move more than 1''
(2.5cm).
WARNING
In the event of a malfunction, it might become necessary
to turn off the power supply.
▶Have the installer show you the circuit breaker or fuse.
Mark it for easy reference.
To avoid electrical shock hazard, before servicing the
appliance, turn power off at the service panel and lock the
panel to prevent the power from being switched on
accidentally.
Proper Installation - Be sure your appliance is properly
installed and grounded by a qualified technician.
User Servicing - Do not repair or replace any part of the
appliance unless specifically recommended in this
manual.
▶All other servicing should be referred to an authorized
service provider.
Light socket is live when door is open if main power
supply is not turned off.
▶Turn off main power supply at the service panel before
changing the light bulbs.
WARNING
Make sure the appliance and lights are cool and power to
the appliance has been turned off before replacing the
light bulb(s). Failure to do so could result in electrical
shock or burns.
▶The lenses must be in place when using the appliance.
▶The lenses serve to protect the light bulb from breaking.
▶The lenses are made of glass. Handle carefully to avoid
breaking. Broken glass can cause an injury.
Failure to follow these instructions when removing the
oven door may lead to personal injury or product damage.
▶Make sure oven is cool and power to the oven has
been turned off before removing the door. Failure to do
so could result in electrical shock or burns.
▶The oven door is heavy and parts of it are fragile. Use
both hands to remove the oven door.
▶The door front is glass. Handle it carefully to avoid
breakage.
▶Grasp only the side of the oven door. Do not grasp the
handle. It may swing in your hand and cause damage
or injury. Failure to grasp the oven door firmly and
properly could result in personal injury or product
damage.
▶To avoid injury from hinge bracket snapping closed, be
sure both levers are securely in place before removing
the door.
▶Do not force the door open or closed. The hinge could
be damaged and cause damage or injury.
▶Do not lay the removed door on sharp or pointed
objects as this could break the glass. Lay it on a flat,
smooth surface, positioned so that the door cannot fall
over.
WARNING
If the supply cord is damaged, it must be replaced by the
manufacturer, its authorized service provider or similar
qualified persons in order to avoid hazard.
WARNING
Grease and fat can ignite when heated.
▶Keep the oven free from grease build up.
CAUTION
In the event of an error the display flashes and beeps
continuously.
▶Disconnect appliance from the power supply and call
an authorized service provider.
WARNING
Malfunctions can cause injuries.
▶Do not operate this appliance if it is not working
properly, or if it has been damaged. Contact an
authorized service provider.
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS

en-us
5
1.4 Safe use
WARNING
This appliance is intended for normal family household
use only.
▶It is not approved for outdoor use.
▶See the Statement of Limited Product Warranty. If you
have any questions, contact the manufacturer.
WARNING - TO REDUCE THE RISK OF INJURY TO
PERSONS IN THE EVENT OF A RANGE TOP GREASE
FIRE, OBSERVE THE FOLLOWING.
▶SMOTHER FLAMES with a close-fitting lid, cookie
sheet, or metal tray, then turn off the burner. BE
CAREFUL TO PREVENT BURNS. If the flames do not
go out immediately, EVACUATE AND CALL THE FIRE
DEPARTMENT.
▶NEVER PICK UP A FLAMING PAN – You may be
burned.
▶DO NOT USE WATER, including wet dishcloths or
towels – a violent steam explosion will result.
▶Use an extinguisher ONLY if:
- You know you have a Class ABC extinguisher, and
you already know how to operate it.
- The fire is small and contained in the area where it
started.
- The fire department is being called.
- You can fight the fire with your back to an exit.
To eliminate the risk of burns or fire by reaching over
heated surface units, cabinet storage space located above
the surface units should be avoided.
CAUTION
The oven vents are important for air circulation. Covering
the oven vents will cause the oven to overheat. Refer to
the appliance overview for the location of the oven vents.
→
"Appliance", Page12 → "Appliance", Page12
▶Do not obstruct oven vents.
WARNING
Do not heat or warm unopened food containers. Build-up
of pressure may cause the container to burst and cause
injury.
WARNING
A fire could occur during cooking.
▶Always have a working smoke detector near the
kitchen.
▶Have an appropriate fire extinguisher available, nearby,
highly visible and easily accessible near the appliance.
In the event that personal clothing or hair catches fire,
drop and roll immediately to extinguish flames.
Do Not Use Water on Grease Fires.
▶Smother fire or flame or use dry chemical or foam-type
extinguisher.
Wear Proper Apparel - Loose-fitting or hanging garments
should never be worn while using the appliance.
Storage in or on appliance – Flammable materials should
not be stored in or near the appliance.
▶DO NOT store or use corrosive chemicals, vapors,
flammables, or nonfood products in or near this
appliance. It is specifically designed for use when
heating or cooking food. The use of corrosive
chemicals while heating or cleaning will damage the
appliance and could result in injury.
Never use your appliance for warming or heating the
room.
WARNING
Avoid reaching or leaning over the appliance.
▶Be aware that certain clothing and hair sprays may
contain flammable chemicals that could be ignited if
brought in to contact with hot surface units or heating
elements and may cause severe burns.
Use Only Dry Potholders - Moist or damp potholders on
hot surfaces may result in burns from steam.
▶Do not let potholders touch hot heating elements.
▶Do not use a towel or other bulky cloth.
WARNING
Moisture intrusion may cause an electric shock.
▶Do not use any steam cleaners or high-pressure
cleaners to clean the appliance.
Safe use of the cooking surface
WARNING
Overheated materials can cause fire or burns.
▶Do not allow aluminum foil, plastic, paper or cloth to
come in contact with a hot surface element, burner or
grate.
▶Do not allow pans to boil dry.
Unattended cooking on a cooktop with fat or oil can be
dangerous and may result in a fire.
▶Do not leave the cooktop unattended when in use.
If the cooktop is near a window, forced air vent or fan, be
certain that flammable materials such as window
coverings do not blow over or near the burners or heating
elements. They could catch on fire.
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS

en-us
6
WARNING
TO REDUCE THE RISK OF A RANGE TOP GREASE
FIRE
▶Never Leave Surface Units Unattended at High
Settings - Boilovers cause smoking and greasy
spillovers that may ignite. Heat oils slowly on low or
medium settings.
▶Always turn hood ON when cooking at high heat or
when flambeing food (i.e. Crepes Suzette, Cherries
Jubilee, Peppercorn Beef Flambe’).
▶Clean ventilating fans frequently. Grease should not be
allowed to accumulate on fan or filter.
▶Use proper pan size. Always use cookware appropriate
for the size of the surface element.
Flames can be drawn into the ventilation system.
▶Whenever possible, do not operate the ventilation
system during a cooktop fire. However, do not reach
through fire to turn it off.
Cookware Handles Should be Turned Inward and Not
Extend Over Adjacent Surface Units.
▶To reduce the risk of burns, ignition of flammable
materials, and spillage due to unintentional contact with
the cookware, the handle of a cookware should be
positioned so that it is turned inward, and does not
extend over adjacent surface units.
Use Proper Pan Size - This appliance is equipped with
one or more surface units of different sizes.
▶Select cookware having flat bottoms large enough to
cover the surface unit cooking zone.
▶The use of undersized cookware will expose a portion
of the cooking zone to direct contact and may result in
ignition of clothing. Proper relationship of cookware to
cooking zone will also improve efficiency.
Controls may be operated unintentionally by spills
covering the control panel.
▶Never use the appliance if liquids or foods have spilled
around the control panel.
▶Always turn off the cooktop and dry the control panel.
Boilovers can cause smoke and some foods and oils may
catch fire if left on high temperature settings.
▶When using a timer, always supervise the cooktop.
▶Do not allow anything to boil over or burn.
WARNING
If the frying sensor is not working properly, overheating
may result causing smoke and damage to the pan or fire.
WHEN COOKING WITH THE FRYING SENSOR
FUNCTION OBSERVE THE FOLLOWING
▶Always use a sensor frying pan.
▶Always put the pan in the center of the cooking zone.
▶Do not place a lid on the pan.
▶Never leave hot fat or oil unattended.
If the cooktop turns off automatically and can no longer be
operated, it may turn itself on unintentionally at a later
point.
▶Switch off the circuit breaker or fuse in the electrical
panel.
▶Contact Customer Service for support.
If the display does not work when a cooking area is
heating up disconnect the circuit breaker or fuse in the
electrical panel.
▶Contact an authorized service provider.
To avoid risk of fire do not store items on the cooking
surfaces.
WARNING
Hot oil is capable of causing extreme burns and injury.
▶Use high heat settings on the cooktop only when
necessary.
▶To avoid bubbling and splattering, heat oil slowly on no
more than a low-medium setting.
▶Never move a pan of hot oil, especially a deep fat fryer.
Wait until it is cool.
Spills of hot food may cause burns.
▶Hold the handle of the pan when stirring or turning food.
This helps prevent spills and movement of the pan.
Use extreme caution when moving the grease kettle or
disposing of hot grease.
DO NOT TOUCH SURFACE UNITS OR AREAS NEAR
UNITS. Surface units may be hot even though they are
dark in color. Areas near surface units may become hot
enough to cause burns.
▶During and after use, do not touch, or let clothing,
potholders, or other flammable materials contact
surface units or areas near units until they have had
sufficient time to cool. Among these areas are the
cooktop and areas facing the cooktop.
WARNING
Do not place metallic objects such as knives, forks,
spoons, and lids on the cooktop surface since they can
get hot.
Do not clean the appliance while it is still hot. Some
cleaners produce noxious fumes when applied to a hot
surface. Wet clothes and sponges can cause burns from
steam.
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS

en-us
7
WARNING
The pan detection shut-off feature may not turn off the
cooking zone due to spilled food or objects placed on the
cooktop.
▶Keep the cooktop clean and do not store objects on the
cooking zones.
WARNING
Liquid between the pot base and the cooktop may build up
steam pressure. This may cause the pot to jump suddenly
causing injury.
▶Always keep the cooktop and bases of pots dry.
When cooking with a double-boiler, the cooktop and
cooking vessel may crack due to overheating.
▶The cooking vessel in the double-boiler must not come
in direct contact with the bottom of the pot filled with
water.
▶Use only heat-resistant cookware.
WARNING
If the surface is cracked, switch off the appliance to avoid
the possibility of electric shock.
Do Not Cook on a Broken Cooktop - If the cooktop should
break, cleaning solutions and spillovers may penetrate the
broken cooktop and create a risk of electric shock.
▶Contact an authorized service provider immediately.
Safe use of the oven cavity
WARNING
If materials inside an oven or warming drawer should
ignite, keep door closed.
▶Turn off the appliance and disconnect the circuit at the
circuit breaker box.
NEVER cover any slots, holes or passages in the oven
bottom or cover an entire rack with materials such as
aluminum foil.
▶Doing so blocks air flow through the oven.
▶Aluminum foil linings may also trap heat, causing a fire
hazard.
Keep oven vent ducts unobstructed.
WARNING
DO NOT TOUCH HEATING ELEMENTS OR INTERIOR
SURFACES OF OVEN - Heating elements may be hot
even though they are dark in color. Interior surfaces of an
oven become hot enough to cause burns.
▶During and after use, do not touch, or let clothing,
potholders, or other flammable materials contact
heating elements or interior surfaces of oven until they
have had sufficient time to cool. Other surfaces of the
appliance may become hot enough to cause burns.
Among these surfaces are oven vent openings,
surfaces near these openings and oven doors.
CAUTION
Use caution when cooking foods with high alcohol content
(e.g. rum, brandy, bourbon) in the oven. Alcohol
evaporates at high temperatures. There is a risk of
burning as the alcohol vapors may catch fire in the oven.
▶Use only small quantities of alcohol in foods, and open
the oven door carefully.
WARNING
Use Care When Opening Door - Let hot air or steam
escape before removing or replacing food.
▶Standing to the side, open the door (or drawer) slowly
and slightly to let hot air and/or steam escape.
▶Keep your face clear of the opening and make sure
there are no children or pets near the appliance.
▶After the release of hot air and/or steam, proceed with
your cooking.
▶Keep doors shut unless necessary for cooking or
cleaning purposes.
▶Do not leave open doors unattended.
CAUTION
Placement of Oven Racks - Always place oven racks in
desired location while oven is cool. If the rack must be
moved while the oven is hot, do not let potholders contact
the hot heating elements in the oven. Use caution when
removing oven racks from the lowest rack position to
avoid contact with the hot oven door.
CAUTION
To avoid possible injury or damage to the appliance,
ensure oven rack is installed exactly per installation
instructions and not backwards or upside down.
Do not place anything on the oven cavity bottom. Do not
cover it with aluminum foil. A build-up of heat could
damage the appliance or cause injury.
WARNING
Scratched glass in the appliance door may develop into a
crack.
▶Do not use any harsh or abrasive cleaners or sharp
metal scrapers to clean the glass on the oven door, as
they may scratch the surface.
WARNING
Protective Liners - Do not use aluminum foil to line surface
unit drip bowls or oven bottoms. Improper installation of
these liners may result in a risk of electric shock, or fire.
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS

en-us
8
Safe use of the meat probe
WARNING
The oven interior and the meat probe become very hot.
▶Use oven mitts to plug and unplug the meat probe.
WARNING
Use of a wrong meat probe can damage the insulation.
Use only the meat probe intended for this appliance.
1.5 Child safety
This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
When children become old enough to use the appliance, it
is the responsibility of the parents or legal guardians to
ensure that they are instructed in safe practices by
qualified persons.
Children should be supervised to ensure that they do not
play with the appliance.
WARNING
Do not allow children to use this appliance unless closely
supervised by an adult.
▶Children and pets should not be left alone or
unattended in the area where the appliance is in use.
They should never be allowed to play in its vicinity,
whether or not the appliance is in use.
Do not allow anyone to climb, stand, lean, sit, or hang on
any part of an appliance, especially a door, warming
drawer, or storage drawer.
▶This can damage the appliance, and the unit may tip
over, potentially causing severe injury.
CAUTION
Do not store items of interest to children in cabinets above
a range or on the backguard of a range. Children climbing
on the range to reach items could be seriously injured.
Do Not Leave Children Alone.
▶Children should not be left alone or unattended in the
area where the appliance is in use.
▶They should never be allowed to sit or stand on any
part of the appliance.
▶Always check inside the oven before turning it on.
WARNING
To avoid the risk of suffocation:
▶Do not allow children to play with packaging material.
1.6 Cleaning function
Follow these safety instructions when using the cleaning
function.
WARNING
Do not block the oven vent(s) during the self-cleaning
cycle. Doing so may cause injury or damage to the
appliance.
WARNING
The oven heats up to a very high temperature during self
cleaning. Opening the door can result in injury.
▶When self-cleaning, confirm that the door locks and will
not open.
▶If the door does not lock, do not run Self Clean. Contact
Customer Service.
WARNING
The outside of the appliance gets very hot when the
cleaning function is in progress.
▶Never touch the appliance door.
▶Allow the appliance to cool down.
▶Keep children at a safe distance.
WARNING
Do not leave food or cooking utensils, etc., in an oven
during the pyrolytic self-cleaning mode of operation.
CAUTION
Remove broiler pans, pots, and other utensils and excess
spillage before self-cleaning.
CAUTION
Birds have very sensitive respiratory systems.
▶Keep pet birds out of the kitchen or other rooms where
kitchen fumes could reach them.
▶During self clean, fumes are released that may be
harmful to birds.
WARNING
Do not clean the door gasket – The door gasket is
essential for a good seal. Care should be taken not to rub,
damage, or move the gasket.
WARNING
Do not use a protective coating to line the oven and do not
use commercial oven cleaner.
Clean only parts listed in this manual.
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS

en-us
9
Please note that some pets or humans can be sensitive to
the odors created during the self-cleaning process
whether it is a manufacturing residue burn off or food. It is
recommended that those potentially affected be removed
from the kitchen area during the self-clean process.
1.7 Electromagnetic interference
WARNING
This induction cooktop generates and uses ISM frequency
energy that heats cookware by using an electromagnetic
field. It has been tested and complies with Part 18 of the
FCC Rules for ISM equipment. This induction cooktop
meets the FCC requirements to minimize interference with
other devices in residential installation. Induction cooktops
may cause interference with television or radio reception.
If interference occurs, the user should try to correct the
interference by
▶Relocating the receiving antenna of the radio or
television.
▶Increasing the distance between the cooktop and the
receiver.
▶Connecting the receiver into an outlet different than the
cooktop.
▶It is the user's responsibility to correct any interference.
CAUTION
Persons with a pacemaker or similar medical device
should exercise caution when standing near an induction
cooktop while it is in use.
▶Consult your doctor or the manufacturer of the
pacemaker or similar medical device for additional
information about its effects with electromagnetic fields
from an induction cooktop.
1.8 Remote operation
CAUTION
This appliance may be configurable to allow remote
operation at any time.
▶Do not store any flammable materials or temperature
sensitive items inside, on top or near surface units of
the appliance.
1.9 State of California Proposition 65
Warnings
This product may contain a chemical known to the State
of California, which can cause cancer or reproductive
harm. Therefore, the packaging of your product may bear
the following label as required by California:
IMPORTANT SAFETY NOTICE: The California Safe
Drinking and Toxic Enforcement Act requires the
Governor of California to publish a list of substance known
to the state to cause cancer, birth defect or other
reproductive harm, and requires businesses to warn
customers of potential exposure to such substances. The
burning of gas cooking fuel and the elimination of soil
during self-cleaning can generate small amounts of
carbon monoxide. The fiberglass insulation in self clean
ovens gives off very small amounts of formaldehyde
during the first several cleaning cycles. California lists
formaldehyde as a potential cause of cancer. Carbon
monoxide is a potential cause of reproductive toxicity.
Exposure to these substances can be minimized by:
¡Providing good ventilation when cooking with gas.
¡Providing good ventilation during and immediately after
self-cleaning the oven.
¡Operating the unit according to the instructions in this
manual.
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS

en-us Preventing material damage
10
Preventing material damage
2 Preventing material damage
Preventing material damage
2.1 Preventing oven cavity damage
NOTICE:
The presence of objects on the oven cavity bottom will
cause heat to build up. The baking and roasting times will
no longer be correct and the enamel will be damaged.
▶Do not cover the oven cavity bottom with any sort of foil
or greaseproof paper.
▶Do not place accessories on the oven cavity bottom.
Do not allow aluminum foil in the oven cavity to come into
contact with the door glass, it could cause permanent
discoloration.
Never pour water into the oven cavity when it is still hot.
Never place cookware containing water on the oven cavity
bottom.
The prolonged presence of moisture in the oven cavity
leads to corrosion.
▶Allow the oven cavity to dry after use.
▶Do not keep moist food in the oven cavity for a long
time with the door closed.
▶Do not store food in the oven cavity.
Leaving the appliance to cool down with the door open will
damage the front of neighboring kitchen units over time.
▶Always allow the oven cavity to cool down with the door
closed after cooking at high temperatures. Only leave
the oven cavity to dry with the door open if a lot of
moisture was produced during operation.
Fruit juice dripping from the baking tray leaves stains that
cannot be removed.
▶When baking very juicy fruit pies, do not pack too much
on the baking tray.
If the seal is very dirty, the appliance door will not close
properly when the appliance is in operation. This may
damage the front of adjacent kitchen units.
▶Never operate the appliance if the seal is damaged or
missing.
Sitting or placing objects on the appliance door may
damage it.
▶Do not place or hang objects on the appliance door.
▶Do not place cookware or accessories on the appliance
door.
With certain models, accessories may scratch the door
glass when closing the appliance door.
▶Always push accessories fully into the oven cavity.
Carrying the appliance by the door handle could break it.
The door handle cannot support the weight of the
appliance.
▶Do not carry or hold the appliance by the door handle.
2.2 Preventing cooktop damage
NOTICE:
Cookware with rough bottoms scratch the glass ceramic
surface.
▶Check the bottom of the cookware before setting it
down.
Salt, sugar or grains of sand scratch the glass ceramic
surface.
▶Never use the cooktop as a working surface or for
setting things down.
Overheating can damage the cookware.
▶Do not heat empty pots or pans.
Hot cookware can cause the electronics to overheat.
▶Never set down hot pans and pots on the control panel
or the cooktop frame.
When hard or sharp objects fall on the cooktop, they can
cause damage.
▶Do not let hard or pointed objects fall on the cooktop.
Aluminum foil and plastic melt on hot cooking zones.
▶Do not let aluminum foil or plastic come into contact
with hot cooking zones.
▶Do not use cooktop protective film.
Unsuitable cleaning agents can cause shimmering metallic
discolorations on the glass ceramic surface.
▶Refer to the cleaning recommendations in this manual.
Overview of the most common types of damage
Here you can find an overview of the most common types
of damage and suggestions how to avoid them.
Stains
Cause How to avoid
Boiled-over food Remove boiled-over food
immediately with a glass scraper.
Unsuitable cleaning
agents
Use cleaning agents that are
suitable for glass ceramic
cooktops.
Scratches
Cause How to avoid
Salt, sugar and sand Do not use the cooktop as a work
surface or storage space.
Cookware with rough
bases
Check the cookware.
Discolorations
Cause How to avoid
Unsuitable cleaning
agents
Use cleaning agents that are
suitable for glass ceramic
cooktops.
Pot abrasion (e.g.
aluminum)
Lift pots and pans when moving
them.
Blisters
Cause How to avoid
Sugar, food with a
high sugar content
Remove boiled-over food
immediately with a glass scraper.

Environmental protection and energy-saving en-us
11
Environmental protection and energy-saving
3 Environmental protection and
energy-saving
Environmental protection and energy-saving
3.1 Disposal of packaging
The packaging materials are environmentally compatible
and can be recycled.
▶Sort the individual components by type and dispose of
them separately.
3.2 Saving energy when using the oven
If you follow these tips, your appliance consumes less
energy.
Only preheat the appliance if the recipe or the
recommended settings tell you to do so.
aNot preheating the appliance can reduce the energy
used.
Use dark-colored, black-coated or enameled baking pans.
aThese types of baking pans absorb the heat particularly
well.
Open the appliance door as little as possible during
operation.
aThis will maintain the temperature in the oven cavity
and eliminate the need for the appliance to reheat.
When baking multiple dishes, do so in succession or at
the same time.
aThe oven cavity is heated after baking the first dish.
This reduces the baking time for the second dish.
If the cooking time is relatively long, you can switch the
appliance off 10minutes before the cooking time ends.
aThere will be enough residual heat to finish cooking the
dish.
Remove any accessories that are not being used from the
oven cavity.
aAn extra pan without food affects the browning and
cooking.
Allow frozen food to defrost before cooking.
aThis will save the energy that would otherwise be
required to defrost it.
3.3 Saving energy when using the cooktop
If you follow these tips, your appliance consumes less
energy.
Select cookware with a base diameter that matches the
cooking zone. Center the cookware on the cooking zone.
Tip:Cookware manufacturers usually state the top
diameter of the cookware. The diameter of the cookware
base is usually smaller.
aThe energy is targeted at the cookware.
If you use cookware that is too small, energy is wasted.
If the cookware is too large, much energy is used to
heat up the cookware.
Close cookware with a fitting lid.
aCooking without a lid consumes more energy.
Only lift the lid when necessary.
aIf you lift the lid, a lot of energy can escape.
Use a glass lid.
aIf you use a glass lid, you can look inside the cookware
without lifting the lid.
Use cookware with a solid flat bottom.
aCurved cookware bases increase energy consumption.
Use a cookware size that matches the amount of food you
want to cook.
aCookware with little content consumes a lot of energy.
Cook with a small amount of water.
aMore water requires more energy to heat it up.
Select a lower power level as soon as possible. Select a
suitable power level to continue cooking.
aFor ongoing cooking a lower power level is sufficient.

en-us Familiarizing yourself with your appliance
12
Familiarizing yourself with your appliance
4 Familiarizing yourself with your appliance
Familiarizing yourself with your appliance
This Use and Care Guide covers several models. Your model may have some but not all of the features listed.
4.1 Appliance
Here you can find an overview of the parts of your appliance.
Notes
¡This Use and Care Guide covers several models. Your model may have some but not all of the features listed.
¡The graphics are representative. Your appliance may have different graphic or design appearances.
1
2
3
5
6
4
7
1
Cooktop control panel
2
Oven control panel
3
Oven door
4
Toe kick panel
5
Rear vent trim/oven vent
6
Door handle
7
Range feet
Oven cavity
Here you can find information about the features of the
oven cavity.
CAUTION
Do not place anything on the oven cavity bottom. Do not
cover it with aluminum foil. A build-up of heat could
damage the appliance or cause injury.

Familiarizing yourself with your appliance en-us
13
Oven cavity components
7
1
2
3
4
5
6
1
Door gasket
2
Broil element
3
Oven rails
4
Socket for meat probe
5
Convection fan
6
Oven cavity bottom
7
Door hinges
Oven light
Your appliance is equipped with an oven light.
To turn the oven light on or off, flip the light switch on the
oven control panel up or down.
Convection fan
Convection baking uses a fan to circulate the oven’s heat
evenly and continuously within the oven.
This improved heat distribution allows for even cooking
and excellent results using multiple racks at the same
time.
Cooling fan
The cooling fan runs during all cooking modes.
The fan can be heard when it is running, and warm air
may be felt as it is released from the oven vent. The fan
may also run after the oven is off.
Oven vent
Warm air may be released from the oven vent before,
during and after cooking. It is normal to see steam
escaping from the vent, and condensation may collect in
this area. This area may be warm when the oven is in use.
CAUTION
The oven vents are important for air circulation. Covering
the oven vents will cause the oven to overheat. Refer to
the appliance overview for the location of the oven vents.
→
Page12
▶Do not obstruct oven vents.
Cooking zones
Here you can find an overview of the cooking zones
available on your cooktop. Place the cookware on the
cooking zone that best matches its size.
Only use cookware that is suitable for induction cooking.
30" Ranges
1 1
2 2
1
Flex zone dimensions:
8½" x 15" (21.5cm x 39cm)
2
FlexPlus zone dimensions:
3⁹⁄₁₆" x 11¼" (9.2cm x 28.5cm)
36" Ranges
121
1
Flex zone dimensions:
8½" x 15" (21.5cm x 39cm)
2
Middle cooking zone dimensions:
9⁷⁄₁₆" x 11¹⁄₁₆" (24cm x 28.4cm)

en-us Familiarizing yourself with your appliance
14
Cooking zone symbols on the control panel
Symbol Cooking zone Function
Single cooking zone Use cookware that matches the size of the cooking zone.
Middle single cooking
zone
Use cookware that matches the size of the cooking zone.
Flexible cooking zone Use with larger size cookware by combining the cooking zones.
/ FlexPlus zone The FlexPlus cooking zones always switch on in conjunction with either the right or
the left FlexZone.
→
"FlexPlus cooking zone (onlyfor30"appliances)", Page31
Residual heat indicator
The cooktop is equipped with a residual heat indicator for
each cooking zone. The residual heat indicator lights up
when a cooking zone is turned off. Do not touch the
cooking zone when the residual heat indicator lights up.
Display Meaning
The cooking zone is hot.
The cooking zone is warm.
If you remove the cookware from the cooking zone during
cooking, the residual heat indicator and the selected
power level flash alternately.
4.2 Oven control panel
1 32
5 4
1
Mode selection knob Use to select the oven heating mode.
2
Display The display shows cooking times and timer values.
In standby mode the display shows the time of day.
3
Temperature selection knob Use to select the heating mode temperature.
4
Oven light switch Use to turn the oven light on or off.
5
Touch keys Touch keys are touch sensitive areas. You only have to press on the
keys lightly to operate them. The touch keys will not work if you press
several of them at once, such as when cleaning them.
Oven touch keys
Here you can find information on the basic operating
features of your oven.
Touch key Function
⁠ Navigate through display options
TIMERS Enter the timer menu

Familiarizing yourself with your appliance en-us
15
Touch key Function
SETTINGS Access the basic settings
ENTER Confirm entered values / Start heating
mode
Oven display
The display shows the current settings of your appliance.
1 2 3
4 5
1
Operating mode
Currently selected heating mode or function
2
Clock
Displays the time of day during all operating
modes
3
Mode setting
Heating mode settings, e.g. temperature
4
Progress bar
Fills up to indicate progress, e.g. for
¡preheating
¡meat probe temperature
5
Information area
Displays instructions or information
Oven heating modes and functions
Here you can find a list of heating modes and other features of your appliance.
This Use and Care Guide covers several models. Your model may have some but not all of the features or displays listed.
Heating mode/function Display symbol How it works and what it is used for
BAKE Cooks with dry, heated air.
Use for a variety of foods, such as cakes, cookies, pastries, quick
breads, quiche and casseroles.
CONV BAKE Similar to bake, but air is circulated by a fan at the back of the
oven.
Best for baked goods such as cakes, cornbread, pies, quick
breads, tarts, and yeast breads.
TRUE CONV Cooks with heat from a third element at the back of the oven. The
heat is circulated throughout the oven by the convection fan.
Well suited for cooking individual serving-sized foods such as
cookies and pastries.
BROIL Uses intense heat radiated from the upper element.
Use for tender cuts of meat 1" (2.5cm) or less thick, poultry,
browning bread and casseroles.
CONV BROIL Combines intense heat from the upper element with fan
circulation.
Best for tender cuts of meat 1" (2.5cm) or less thick, poultry and
fish. Do not use this mode for browning.
ROAST Uses more intense heat from the upper element, to achieve more
browning of exterior.
Best suited for meats, poultry, less tender cuts of meats and
roasting vegetables.
CONV ROAST Uses lower and more intense heat from the upper element than
convection bake with air circulated by a fan.
Use for tender cuts of meat and poultry and roasting vegetables.
Meats are more juicy and moist than results with roast mode.

en-us Familiarizing yourself with your appliance
16
Heating mode/function Display symbol How it works and what it is used for
SABBATH
EXTEND BAKE
The Sabbath mode enables those of particular faiths to use their
ovens on the Sabbath.
SELF CLEAN
lights up when door
lock is activated.
The oven reaches a high temperature to burn off food soil.
REMOTE START Allows user to start, pause, and abort oven programs remotely
via the HomeConnect® app on a mobile device.
FAST PREHEAT Fast preheat heats the oven quicker than standard preheat.
PROBE Use to determine the internal temperature of many foods,
especially meats and poultry during cooking.
KITCHEN TIMER The kitchen timer is a countdown timer that has no affect on oven
heating. The kitchen timer is used for general kitchen timing
needs.
OVEN TIMER The oven timer is a countdown timer which upon reaching 00:00
turns the oven off, stopping the current mode. The oven timer is
used to set how long a mode will run.
DELAY COOK Allows the oven to be programmed to finish a timed cooking
mode at a predetermined time.
PANEL LOCK Prevents the oven from being turned on or its settings from being
changed accidentally.
Remote service Symbol is displayed if Customer Service is connected during
remote access.
4.3 Cooktop control panel
You can use the cooktop control panel to configure all
functions of your rangetop and to obtain information about
the operating status.
The control panel image is representative. Your appliance
may vary slightly.
This Use and Care Guide covers several models. Your model may have some but not all of the features listed.
36" appliances

Familiarizing yourself with your appliance en-us
17
30" appliances
Cooktop touch keys
Touch keys are touch sensitive areas. Touch a symbol to
activate the corresponding function.
¡The indicators above the touch keys that currently can
be selected light up.
¡The touch keys for functions that currently cannot be
selected do not light up.
¡The indicators for selected functions or cooking zones
light up brighter.
Touch key Function
ON I OFF Main switch
⁠ ⁠ ... Settings area
Select cooking zone
LOCK Wipe protection / Panel lock
POWER
BOOST
PowerBoost® and PanBoost® function
HEAT SHIFT HeatShift® function
COOK SMART CookSmart® function
JOIN I SPLIT Liberty® flexible cooking zone
KITCHEN
TIMER
Kitchen timer
STOP WATCH Stopwatch
CONFIRM HomeConnect® confirmation key
HOOD SYNC Hood control function
Touch key Function
LIGHT Hood light control
Notes
¡Keep the controls clean and dry. Moisture can impair
the function of the controls.
¡Do not place cookware close to the displays and
sensors. The electronics may overheat.
Cooktop displays
The displays show active settings and functions.
When you select a cooking zone, the settings for this
cooking zone light up brighter.
Display Name
⁠. Cooktop ready
- Power levels
/ Residual heat indicator
⁠ Indicated function active
⁠. PowerBoost® function active
⁠ ⁠. Short Boost function active
CookSmart® active
Timer value
Wi-Fi
Cooktop-Hood sync
Cooktop cooking modes and functions
Here you can find a list of heating modes and other features of your cooktop.
This Use and Care Guide covers several models. Your model may have some but not all of the features or displays listed.
Cooking mode/function Touch key Display symbol How it works and what it is used for
PowerBoost® POWER
BOOST
⁠. Use this function to heat larger quantities of
water faster than with power level 9.
→
"PowerBoost® ", Page33
PanBoost® POWER
BOOST
Use this function to heat cookware, such as a
frying pan, faster than with power level 9⁠.
→ "PanBoost®", Page34

en-us Familiarizing yourself with your appliance
18
Cooking mode/function Touch key Display symbol How it works and what it is used for
HeatShift® HEAT SHIFT Use this function on the flexible cooking zone
to move an item of cookware to another
cooking area with a different power level during
the cooking process, without changing any
settings.
→
"HeatShift® function", Page32
CookSmart™ frying function COOK SMART With this function, a sensor controls the
temperature of the pan. You can fry while the
pan maintains the selected temperature.
→
"CookSmart® ", Page35
Liberty® flexible cooking zone JOIN I SPLIT You can use the flexible cooking zone as one
large cooking zone, or as two separate cooking
zones.
→
"Liberty® cooking zone", Page30
Cooktop-Hood sync HOOD SYNC You can connect your appliance to a hood and
control the functions of your hood via the
cooktop.
→
"Cooktop - Hood Sync", Page40
HomeConnect® CONFIRM Connect the cooktop to a mobile device and
control its functions via the Home Connect™
app.
→
"HomeConnect® ", Page42

Accessories en-us
19
Accessories
5 Accessories
Accessories
Only use original accessories. These are designed especially for your appliance.
5.1 Oven accessories
Your appliance includes the following oven accessories.
Other accessories Use
Wire rack ¡These racks can be used for most
cooking.
¡You can use multiple racks at the
same time.
Note:Do not clean using the SELF
CLEAN function.
Telescopic rack Use with heavier dishes to make
placement into the oven easier.
Note:Do not clean using the SELF
CLEAN function.
Meat probe The meat probe can be used to
determine the internal temperature of
many foods, especially meats and
poultry.
Notes
¡Do not clean using the SELF
CLEAN function.
¡Do not clean in the dishwasher.
Broiler pan and grid Use for broiling and roasting.
Notes
¡Do not clean using the SELF
CLEAN function.
¡You can clean this accessory in the
dishwasher.
5.2 Other accessories
You can purchase other accessories from our Customer
Service, specialist retailers or online.
You will find a comprehensive range of products for your
appliance in our brochures and online:
www.thermador.com
Accessories are appliance-specific. When purchasing,
always check for compatibility with your appliance model
number (E-Nr).
You can find out which accessories are available for your
appliance in our online shop or from our Customer
Service.
Cooktop accessories (optional)
The following accessories suitable for your induction
cooktop can be purchased separately.
CHEFSPAN08
¡Sensor frying pan, Ø10" (26cm)
¡Suitable for Liberty® cooking zones
TGRILLPANX
¡Non-stick induction griddle plate, 9"x17"
(230x430mm)
TROASTERT
¡Stainless steel roaster, 10"x16" (255x400mm)
TEPPAN1013
¡Teppan Yaki pan (small), 10"x13" (25.5x33cm)
TEPPAN1016 (only suitable for 36" appliances)
¡Teppan Yaki pan (large), 10"x16" (25.5x40.5cm)

en-us Accessories
20
5.3 Rack positions
Your oven has 5 rack positions. The rack positions are
counted from bottom to top.
Use rack positions 1 through 5 only. DO NOT attempt to
use the top guide to support an oven rack, it may tip.
Refer to our recommendations for selecting the suitable
rack position.
5.4 Safe use of oven racks
For your safety, follow these recommendations on how to
use the oven racks correctly.
CAUTION
To avoid possible injury or damage to the appliance,
ensure oven rack is installed exactly per installation
instructions and not backwards or upside down.
Do not slide any accessories between the rack positions,
or they may tip.
5.5 Inserting the wire rack
The wire rack can be used in the conventional oven on
level 1 to 5.
Requirement:You have read the recommendation on
→
"Safe use of oven racks", Page20 .
1. Grasp the rack firmly on both sides.
2. Tilt the rack up to allow the stop into rack guide.
3. Bring the rack to a horizontal position and push it in the
rest of the way.
The rack should be straight and flat, not crooked.
5.6 Inserting the telescopic rack
Requirement:You have read the recommendation on
→
"Safe use of oven racks", Page20 .
1. Hold the telescopic rack at a slight angle and engage
the rear hooks in the oven rails on both sides of the
oven cavity.
2. Hold the rack straight to allow the second tab to rest
over the oven rail.
