Care & Use Manual
© 2001 BSH HomeAppliances Corp.
for
Thermador Built-In Ovens
Models
C302, C272
C301, C271

A Special Message
to Our Customers
Thank you for buying aThermador oven.We recommend
that you take the time to read this entire booklet before
using your new appliance.
We hope that the information in this manual will help you
easily operate and care for your oven for years of
satisfaction.
Please contact us if you have any questions or comments.
Phone us at 1-800-735-4328 or write to us at:
Customer Support Call Center
Thermador
5551 McFaddenAvenue
Huntington Beach,CA 92649
Sincerely,
ThermadorTest Kitchen Consumer Scientists

C Oven Care and Use Manual
Page 1
Table of Contents
Important Safety Instructions. 2-3
GeneralAppliance and
Oven Safety Features ...............................2
Oven Features...................................... 4-9
Features of Your Oven.............................4
Oven Control Features ...........................5
UsingThe Control Panel..........................6
Child Lockout / Panel Lock ...................... 6
Sights & Sounds .........................................7
Voltage Connection..................................7
Oven Modes...............................................8
General OvenTips.................................... 9
Oven Operations ........................ 10 - 27
Setting the Clock ....................................10
Setting the Lights.....................................10
Setting theTimer.....................................11
Bake............................................................12
Baking Chart ............................................13
Convection Mode Operation...............14
Convection Chart...................................15
Convection Bake Mode Operation.....16
Convection Bake Chart.........................17
Roast Mode Operation .........................18
Roasting Chart.........................................19
Convection Roast Mode
and Probe Operation.......................20
Convection Roast Chart .......................21
Broil and Convection Broil
Mode Operation...............................22
Broil Chart ...............................................23
Convection Broil Chart.........................23
Proof Mode Operation..........................24
Dehydrate Mode Operation ................25
Timed Oven Feature Operation .........26
Setting the Sabbath Mode .....................27
Care and Cleaning.................28-31
Self CleaningThe Oven..........................28
Self Clean Mode ......................................29
Oven Cleaning Chart.............................30
Oven Finishes/Cleaning Method..........31
Do-It-Yourself Maintenance ..32-34
Removing the Oven Door ....................32
Replacing the Oven Light ......................33
Changing to 24-Hour Clock.................33
Changing to Centigrade ........................34
Calibrating OvenTemperature.............34
Problem Solving ....................35-36
Solving Baking Problems........................35
Solving Operational Problems .............36
Consumer Service .................... 36
How to Obtain Service .........................36
Thermador®Warranty...........................37
Service Data Record..............................37

C Oven Care and Use Manual
Page 2
Safety Precautions
Please read all instructions before using this appliance.
• This appliance must be properly installed and
grounded by a qualified technician. Connect
only to properly grounded outlet. See
“GroundingInstructions”foundintheInstallation
Instructions.
• Thisapplianceshouldbeservicedonlybyqualified
service technician. Contact the nearest
authorized service center for examination,
repair or adjustment.
•Do not repair or replace any part of the oven
unless specifically recommended. Refer service
to an authorized servicer.
•Donotoperatethisapplianceifitisnotworking
properly or if it has been damaged, until an
authorized servicer has examined it.
• Installorlocatethisapplianceonlyinaccordance
with the Installation Instructions.
• Use this oven only as intended by the
manufacturer.Ifyouhaveanyquestions,contact
the manufacturer.
•Do not cover or block any openings on this
appliance.
• Use this appliance only for its intended use as
described in this manual. Do not use corrosive
chemicals, vapors, or nonfood products in this
appliance.Thistypeofovenisspecificallydesigned
to heat or cook. It is not designed for industrial
orlaboratoryuse.Theuseofcorrosivechemicals
inheatingorcleaning will damage theappliance.
• In the event that personal clothing or hair catches
fire,DROPANDROLLIMMEDIATELYtoextinguish
flames.
GeneralAppliance and Oven
SAFETY PRECAUTIONS
▲
!WARNING
When properly cared for, your new Thermador
ovenhasbeendesignedtobeasafe,reliableappliance.
Read all instructions carefully before using this
oven. These precautions will reduce the risk of
burns, electric shock, fire, and injury to persons.
When using kitchen appliances, basic safety
precautions must be followed, including the
following:
Continued on next page
•Do not allow children to use this appliance,
unless closely supervised by an adult. Children
andpetsshouldnotbe left alone or unattended
in the area where the appliance is in use. Never
allow children to sit or stand on any part of the
oven.
•Do not store items of interest to children
above the oven. If children should climb onto
the appliance to reach these items, they could
be seriously injured.
To reduce the risk of fire in the oven cavity:
1. Donotstoreflammablematerialsinornearthe
oven.
2. Donotusewateronagreasefire.Smotherfire
oruseadrychemicalorfoam-typeextinguisher.
3. Itishighlyrecommendedthatafireextinguisher
bereadilyavailableandhighlyvisiblenexttoany
cooking appliance.
4. Do not overcook food. Carefully attend oven
if paper, plastic or other combustible materials
are placed inside the oven.
5. Donotusethecavityforstoragepurposes.Do
not leave paper products, cooking utensils or
food in the cavity when not being used.
6. If materials inside the oven should ignite, keep
ovendoorclosed.Turnovenoffanddisconnect
the circuit at the circuit breaker box.
7. Do not block any vent openings.
8. Besuretheblowerfanrunswhenevertheoven
is in operation. If the fan does not operate, do
not use the oven. Call an authorized service
center.
9. Never use the oven to warm or heat a room.
This can damage the oven parts.
10. Forpersonalsafety,wearproperclothing.Loose
fitting or garments with hanging sleeves should
never be worn while using this appliance.

C Oven Care and Use ManualSafety Precautions
Page 3
SAFETY FOR THE OVEN
• Tie long hair so that it doesn't hang loose.
• Do not touch heating elements or interior surfaces
of oven.
• The heating elements may be hot even though they
are dark in color. Interior surfaces of an oven
become hot enough to cause burns.
• Duringandafteruse,donottouchorletclothingor
other flammable materials contact the heating
elements or the interior surfaces of the oven until
they have had sufficient time to cool.
• Thetrimonthetop andsidesof theovendoormay
become hot enough to cause burns.
• Use care when opening the door. Open the door
slightlytolethotairorsteamescapebeforeremoving
or replacing food.
• Donotheatunopenedfoodcontainers. Build-upof
pressure may cause the container to burst and
result in injury.
• Always place oven racks in desired location while
oven is cool. If a rack must be moved while oven is
hot, do not let potholder contact the hot heating
elements.
• Use only dry pot holders. Moist or damp pot
holders on hot surfaces may result in burns from
steam. Do not let pot holder touch hot eating
elements. Do not use a towel or other bulky cloth.
IMPORTANT SAFETY INSTRUCTIONS
Please read all instructions before using this appliance.
SAFETY FOR THE SELF-CLEANING OVEN
• Confirmthat the doorlocks and willnot open once
START is touched and the door lock icon appears.
Ifdoor doesnotlock, touchOVEN OFFanddo not
runSelfClean.Phone[phone]forservice(see
Page 36 for obtaining service).
• Do not clean the door gasket. It is essential for a
goodseal. Careshouldbetakennottorub,damage,
move or remove the door gasket.
• Donot use commercialoven cleaners oroven liner
protectivecoatingsofanykindinoraroundanypart
of the oven.
• Clean only oven parts listed in this manual.
• Before self-cleaning the oven, remove the broiler
pan, oven racks, other utensils and excess soft
spillage.
• Listenforfan.Afannoiseshouldbeheardsometimes
during the cleaning cycle. If no fan is heard, call for
service.
The California Safe Drinking Water and
Toxic Enforcement Act requires
businessestowarncustomersofpotential
exposuretosubstanceswhichareknown
bytheStateofCaliforniatocausecancer
or reproductive harm.
The elimination of soil during self-
cleaning generates some by-products
which are on this list of substances.
To minimize exposure to these
substances, always operate this oven
according to the instructions in this
manual and provide good ventilation to
the room during and immediately after
self-cleaning the oven.
▲
!
WARNING

C Oven Care and Use Manual
Page 4
# Item
12 Front Frame
13 Automatic Door Lock Latch
14 Halogen Oven Lamps (2)
15 Convection Fan and Cover
16 Side Trim
17 Door Hinge
18 Removable Door
19 Door Cooling Vents
20 Probe Receptacle
21 Vent Trim
22 Probe
23 Broiler Pan and Grid
MODELS C301, C271
SINGLE OVENS MODELS C302, C272
DOUBLE OVENS
# Item
1Door Handle
2Oven Door Gasket
3Window
4Bake Element, under oven floor
5Removable Oven Racks
6Rack Supports*
7Broil Element
8Glass Touch Control Panel
9Clock/Time Display & Control Display
10
Model & Serial No. Location, (look through slot)
11 Oven Cooling Vents
1
2
3
4
7
6
5
9
1011
12
13
14
15
16
17
18
19
21
Features of Your Oven
8
20
Oven Features
23
22
*Rack support positions are numbered from the bottom rack
support(#1) to the top (#6).Cooking charts in this manual refer to
the recommended rack positions.

C Oven Care and Use Manual
Page 5
CONTROL MENU
1. Oven Mode Pads
• Probe – selects doneness temperatures.
• Convection – selects the Convection mode and
may be used in combination with Bake,Roast or
Broil.
• Bake – selects the Bake mode.
• Roast – selects the Roast mode.
• Broil – selects the Broil mode.
• Proof/Dehydrate – touch once to select proof;
touch twice to select dehydrate.
• Self Clean – selects a Self-Clean mode.
2. Timed Cooking Pads
• CookTime – selects the hours to cook.
• StopTime – selects the time of day the oven is
to automatically turn off.
3. Oven Selector Pads
• Upper/Lower – (double oven models only).
touchonceto selecttheupper oven;touchtwice
to select the lower oven.
• Upper Off – turns the upper oven off.
• Lower Off – turns the lower oven off.
DISPLAYWINDOWS
4. Clock
• Displays the time of day.
• Displays timer(s) countdown.
• Displays“Panel Lock” affirmation.
5. Oven
• Displays selected words,numbers and symbols.
NUMBER PADS
6. Number pads – 1 to 0 – selects a time of day,
temperatures,cook and stop time,or timer(s).
7. Start pad – touch this pad last to start cooking
modes or timing functions.
LIGHT, PANEL LOCK, CLOCK,and
TIMER(S) MENU
8. Light – turns oven lights on/off.
9. Panel Lock – locks the cooking modes in the off
position.
10. Clock – selects the time of day on the 12-hour
clock.
11. Timers
• Timer 1 – sets a kitchen timer.
• Timer 2 – sets a second kitchen timer.
• Timer Off – turns timer(s) off.
SPECIAL FEATURES
• Sabbath Mode Setting – complies with some
religious requirements.
• 12 or 24 hour clock choice – clock setting
options.
• Fahrenheit or Centigrade – temperature
setting options.
• Panel Lock / Child Lockout – Panel lock
prevents any cooking mode from being set when
oven is not being used.
Oven Control Features
1
2
3
4
56
7
89
10
11
Oven Features
PROBE CONVECTION BAKE UPPER
LOWER
SELF CLEAN BROIL ROAST UPPER
OFF
PROOF STOP COOK LOWER
DEHYDRATE TIME TIME OFF
LIGHT PANEL LOCK CLOCK
TIMER 1 TIMER OFF TIMER 2
12 3
45 6
78 9
START 0

C Oven Care and Use ManualOven Features
Page 6
1
2
3
4
5
UsingThe Control Panel
11
11
1
22
22
2 :
00
00
0
00
00
0
11
11
1
::::: 00
00
0
00
00
0
CONVECTION
ROAST
325325
325325
325
o
COOK TIME
1
2
3
4
5
1. CONTROL MENU
Thesepads setthe ovenmodes andselect theoven
to be used - in double oven models.
2. CLOCK /TIMER DISPLAYWINDOW
Clock andTimer settings are displayed in this win-
dow.TheTimer settings countdownin minutesand
seconds or in hours and minutes.
3. MODE DISPLAYWINDOW
The settings are shown in this window to verify
whathas beenselected.
Thedisplayshowsthe oven
selected(in doubleovenmodels),cookingortimed
mode,elements oninthe oven,oven temperature,
and the preheat function.
4. NUMBER PADS and START
The number pads select temperatures and time
settings in seconds,minutes and hours.It is neces-
saryto selecttheSTARTpad tocompleteanymode
or timed entry.
5. CLOCK andTIMER MENU
These pads select the Clock and minute Timers
that operate independently of any oven mode.
These pads control the interior oven lights and
Panel Lock.
PANEL LOCK
/ Child Lockout
The Panel Lock is selected to prevent the control
pads from being activated when the oven is not
being used.Touch and hold for 5 seconds to acti-
vate;repeat to cancel.
TOUCH 'n' TILT PANEL
This panel is on single oven C301U model
only. It can be used in the tilt or flush-to-oven
position. Push in along the center, bottom of the
paneltoreleaselatch and raisepanelupward.Push
again to release latch and lower the panel.
Single oven models,C301U and C271U,will
have only one oven displayed on the control
panel and menu. Instructions and illustra-
tions for double oven models are used
throughout this manual.
The control panel contains a series of electronic touch pads that enable you to set the oven. As
you touch these pads,words and numbers appear in the display windows. These word and number
displays arecalled“prompts”and show whathasbeen selected and whatmustbe donenext.
Touch
only one mode or number pad at a time.
6
6
7
7
C301U model control panel shown in 20º open position.
➥
PROBE CONVECTION BAKE UPPER
LOWER
SELF CLEAN BROIL ROAST UPPER
OFF
PROOF STOP COOK LOWER
DEHYDRATE TIME TIME OFF
LIGHT PANEL LOCK CLOCK
TIMER 1 TIMER OFF TIMER 2
12 3
45 6
78 9
START 0

C Oven Care and Use ManualOven Features
Page 7
Interpreting the Control Panel:Sights & Sounds
The directions in the Care and Use Manual for setting the oven and its various modes are based on the
assumption that the panel displays and sounds will“lead” or help you set the controls easily. To aid in this
path the following descriptions provide a basis for interpreting what is seen and heard.
Flashing Symbols or Numbers
Signals an incomplete setting;calls for another step or
START to be touched.
I Beep
Signals the receipt of an entry.
2 Beeps
Signal an error in entry.
4 Chimes
Signal the end of a setting.
Probe Symbol
Displays the internal temperature of the meat rather
than the oven roasting temperature.
Oven tempera-
ture can be seen briefly by touching the cook mode
after touching START.
Lock Symbol
Displays during the Microwave, CookSmart, and Self
Clean modes whenever the door is locked. Door can
be opened when symbol no longer appears.
PAU
Displays when a Microwave or Cooksmart program is
paused or interrupted and door unlocks.
Err
Displays if an invalid temperature or time is entered.
Power Failure
After the power returns to the oven,the clock displays
the time when the power was lost or turned off.
UPPER
LOWER
(Double oven models only) Selects the
active oven to be set by highlighting the
oven in the mode display window.
Default Settings
The cooking modes automatically select a suitable
temperature. These can be changed when a different
one is needed.
START
Touch to complete an entry and before entering an
additional one.
UPPER OFF and LOWER OFF
Touch to cancel a mode that has already been started
or completed.
COOK TIME
Sets the number of hours and minutes the oven will be
“on”. UnlikeTimer 1 or 2, the oven turns“off” auto-
matically when the time elapses. This pad is used with
the automatic timed oven control.
F Number Codes
Thesecodesaredisplayedwhen thereis aproblem with
thesignalsent totheelectroniccontrolboard.See Solv-
ing Operational Problems,Page 36.
Convection Fan
Operates during any convection mode.The fan turns
off if the door is opened.
Component Cooling Fan
Activates during any cooking or self-cleaning mode to
cool inner components and outer door surfaces.This
air is exhausted through the vent located below the
lower oven in double oven models. It continues to run
until components have cooled sufficiently.
120/208 Volt Connection
• Preheat the oven for all cooking modes.
Preheat time will be slightly longer.
• Preheatthe broil element withthedoor open
for 3 to 4 minutes or until the top element is
red.Do not preheat with the broil pan in the
oven.
• The Self-Clean mode may need a longer clean
time than normal, depending on the amount
of soil.

C Oven Care and Use Manual
Heating Modes Available in Each Oven
Oven Features
Page 8
The following illustrations give an overview of what happens in the oven with each mode setting. The arrows repre-
sent the location of the heat source during specific modes.The lower element is concealed under the oven floor.
CONVECTION BROIL
Convection broiling combines the
intenseheatfromthe upper element
with the circulation assisted by
convection fan.This air circulation
crisps the exterior surface and
retains inner moisture in meats
more than 1-1/2" thick.
CONVECTION ROAST
Convection roasting combines the
heat from the lower concealed ele-
ment with additional heat from the
convection element and fan and the
top element. The result is a crispier
exterior that seals in the interior
juices. It is perfect for roasting ten-
dermeats inanuncovered,low-sided
pan.
CONVECTION BAKE
Convection Bake has heat from the
upper and lower element with
circulationassisted bythe convection
fan.Thismodeis designed forbreads
and pastries.
CONVECTION or
DEHYDRATE
Convection is cooking with heat
from a third element concealed
behind the back wall of the oven.It
is used with a fan to speed up the
circulation of heated air throughout
the oven. Dehydrating is similar to
convection cooking and holds an
optimum low temperature while
circulating the heated air to remove
moisture slowly for food
preservation.
BROIL
Broiling uses intense heat radiated
from the upper element to give ex-
cellent top browning or searing.
ROAST
Roast has more top heat than bake.
This additional top heat is for con-
ventional open roasting when drip-
pingsaredesiredorforcovered-dish
roasting.
BAKE or PROOF
Baking is cooking with heated air.
Both upper and lower elements are
used to heat the air and cycle to
maintainthe temperature.Proofing,
while similar to bake,holds an opti-
mum low temperature for yeast to
rise.

C Oven Care and Use ManualOven Features
Page 9
PREHEATINGTHE OVEN*
• Preheat the oven when using the BAKE,
CONVECTION and ROAST modes.
• Preheat is not necessary for BROIL and
CONVECTION BROIL modes.
• Preheat is optional for CONVECTION ROAST.
Preheating is not recommended for
CONVECTION ROAST when using the PROBE.
A hot oven impairs connecting the meat probe
into the receptacle.
• Ovenis notpreheatedfor CONVECTIONBAKE,
to take advantage of the lower heat yielding a
better crust on baked items.
• Place racks in the oven before preheating.
• Duringpreheat,the selected cookingtemperature
is displayed and alternates with a display of the
actual oven temperature.
• The oven chimes once when it is preheated and
the selected cooking temperature is displayed.
OPERATIONAL SUGGESTIONS
• Use the cooking charts as a guide.
• Do not set pans on the opened oven door.
• Use the interior oven light to view the food
through the oven door window rather than
opening the door frequently.
• UseTIMER1 ORTIMER 2to keeptrackof cooking
times.
UTENSILS
• Reduceoventemperature25ºwhen bakinginglass.
• Usepansthatgivethe desiredbrowning.Fortender,
golden brown crusts, use light nonstick/anodized
or shiny metal utensils.
• Forbrown,crispcrusts,usedarknonstick/anodized
or dark, dull metal utensils or glass bakeware.
Insulated baking pans may increase the length of
cooking time.
• Do not cook with the empty broiler pan in the
oven, as this could change cooking performance.
Store the broil pan outside of the oven.
• Tips for“Solving Baking Problems” are found on
Page 35.
GeneralTips
HIGH ALTITUDE BAKING
• Whencooking athighaltitude,recipesand cooking
times will vary from the standard. For accurate
information,writethe ExtensionService,Colorado
State University, Fort Collins, Colorado 80521.
There may be a cost for the bulletins.
CONDENSATION
/ TEMPERATURESENSOR
• It is normal for a certain amount of moisture to
evaporate from the food during any cooking
process. The amount depends on the moisture
content of the food. The moisture may condense
on any surface cooler than the inside of the oven,
such as the control panel.
• Your new Thermador®oven has an electronic
temperature sensor that accurately maintains the
temperature selected. Your previous oven may
have had a mechanical thermostat that drifted
gradually over time to a higher temperature.It is
common to experience an adjustment period
when cooking your favorite recipes in the new
oven.
OVEN RACKS
• Rackpositionsarenumberedfromthe bottomrail
guide (#1) to the top (#6). Check the cooking
charts for the recommended position.
• To insert racks into the oven,hold the rack with
the back rail up and toward the back. Place the
safety hooks under the front of the rail guides.
Push the rack into the oven,lifting the rack stops
over the front of the rail guides. Slide the rack
into position.
• To remove racks or reposition racks in the oven,
pull the rack towards the front of the oven.Lift up
the front of rack over the safety stops and pull
from the oven.
• Rack rail supports should not be removed from
the oven.
• CAUTION! Never use aluminum foil to cover the
ovenracks or toline theoven. Itcan causedamage
to the oven can liner if heat is trapped under the
foil.
• When placing food on a rack, pull the rack out to
the stop position. The racks are designed to lock
when pulled forward.

C Oven Care and Use Manual
Setting the Clock
• Always set the clock immediately after installation
or after a power failure. Once power returns to
the oven, the clock displays the time of day when
power was turned off or lost.
1. Select the CLOCK pad. Touch
CLOCK
2. Set the current time of day. Touch
(Example shows 8 o’clock set for 8
the time of day.) 0
0
3. Select START or CLOCK. Touch
START
Setting the Lights
Touch
UPPER
LOWER
Touch
LIGHT
YouWill See
• If 15 seconds elapse between touching the clock
pad or number pads,the mode is automatically can-
celled. Set again.
• The time of day clock can be set when an auto-
matic timed cooking mode is in operation.
YouWill See
8:00
1. Select the“active” oven by touching once or
twice to highlight oven display.
2. Touch LIGHT once to turn light on or off.
• Oven lights turn on automatically when the door is opened and off when closed.
• To set manually, always start by highlighting the oven,whether it is“active” or not.
(Touch the UPPER / LOWER pad to display the“active” oven; flashing outline is the active oven.)
• A single LIGHT pad activates the lights in either oven.
• The lights do not operate in the Self-Clean mode.
To manually control the interior oven lights if
either oven is in use:
SET CLOCK
––:––
8:00 SET CLOCK
OR
Oven Operations
To Set the CLOCK:
Page 10

C Oven Care and Use Manual
Setting theTimer
To Change aTimer:
1. TouchTIMER 1 orTIMER 2.
2. Enter the new desired time.
3. Touch the START pad.
To Set BothTIMER 1 andTIMER 2:
Follow the steps above to set eachTimer. TheTimer with the least amount of countdown time has display
priority. The countdown display for the second timer is shown automatically when the first timer has ended.
The words“TIMER 1” and“TIMER 2” are both displayed along with the number countdown.
The word,“TIMER 1” or“TIMER 2”,with the least remaining countdown time is more brightly lit
than the other word.
During the countdown,touch CLOCK orTIMER. Depending on the pad touched,either the time of day
or the remaining time is briefly displayed.
• The oven has twoTimers,which are independent of each other.
Neither timer controls oven operations.
• Touch once and theTimer is set in minutes and seconds.
• Touch twice and theTimer is set in hours and minutes.
To Cancel anActiveTimer:
1. SelectTimer in use. Touch
TIMER 1 or 2
2
. CancelTimer. Touch
TIMER OFF
1. Select Timer 1 or 2. Touch
TIMER 1
2. Set the amount of time. Touch
(Example shows a 3-minute 3
setting withTimer 1.) 0
0
3. StartTimer. Touch
START
4. When set time is complete, Touch
“End” is displayed and 4 chimes sig- TIMER OFF
nal. When turned off,display reverts
to time of day.
Tip: If timer is not turned off,chimes will continue every 30 seconds. After 5 minutes,chimes stop
and the display reverts to the time of day.
MIN SEC TIMER 1
3:00
SET
MIN SEC TIMER 1
––:––
MIN SEC TIMER 1
3:00
TIMER 1
End
YouWill See
To Set TIMER 1 or TIMER 2:
Oven Operations
Page 11

C Oven Care and Use Manual
Bake Mode Operation
Oven Operations
Page 12
BAKE TIPS
• Preheat when using the Bake mode.
• Use BAKE for general cooking on one or two racks.
To set BAKE mode:
1. Select twice for LOWER OVEN.
2. Select BAKE.
The temperature is automatically set at 350ºF.
3. Optional step:
To change the temperature from 350ºF, select
another temperature immediately before starting.
4. Select START.
The temperature display alternates between the
set temperature and the actual temperature,
beginning with 100°F. The actual temperature
counts up in 5°F increments.
Theovenis preheatedwhenthechimesignalsonce.
PREHEAT disappears from the display.
5. To end this mode, select the oven OFF pad.
YouWill See
• Follow the recipe,package directions,or the cooking
chart on next page for baking temperatures, time
and rack position.
• Baking time will vary with the size, shape and finish
of the baking utensil. Dark metal pans or nonstick
coatingswill cookfasterwith darkerresults.Insulated
bakeware will lengthen the cooking time for most
foods.
• For best results, bake food on a single rack with at
least 1-1/2" space between utensils and oven walls.
Touch
UPPER
LOWER
Touch
BAKE
Touch
3
7
5
Touch
START
Touch
LOWER
OFF
100
o
/375
o
PREHEAT
375
o
BAKE
350
o
BAKE
• Use a maximum of 2 racks when selecting the bake
mode. Stagger pans or baking sheets so that one is
not directly above another.
• Eliminateheat lossfromthe ovenbyusing thewindow
to periodically check food for doneness.
• Do not use any aluminum foil or a disposable
aluminum tray to line any part of the oven.Foil is an
excellent heat insulator and heat will be trapped
beneath it.This will alter the cooking performance
and can damage the finish of the oven.

C Oven Care and Use Manual
Baking Chart
Oven Operations
Page 13
Food Item OvenTemp Rack Position Time
Breads
White Bread,Scratch 400°F (205°C) 3 30 to 35 minutes
Breads,Specialty
Biscuits,scratch 450°F (232°F) 3 10 to 12 minutes
Biscuits,canned
Large 375°F (190°C) 3 11 to 15 minutes
Medium 400°F (205°C) 3 8 to 11 minutes
Small 450°F (232°F) 3 8 to 10 minutes
Cornbread,mix or 400°F (205°C) 3 20 to30 minutes
Scratch
Gingerbread 350°F (177°C) 3 35 to 40 minutes
Muffins 425°F (219°C) 3 15 to 20 minutes
Quick Breads 350°F (177°C) 3 50 to 60 minutes
Cakes
Angel Food Mix 350°F (177°C) 1 37 to 47 minutes
Cake Mix,
8" or 9" round(s) 350°F (177°C) 3 or 2 and 5 30 to 35 minutes
9" x 13" rectangle 350°F (177°C) 3 30 to 35 minutes
Scratch 350°F (177°C) 3 30 to 40 minutes
Cakes,Specialty
Bundt Cakes 350°F (177°C) 3 40 to 45 minutes
Cupcakes 350°F (177°C) 3 18 to 21 minutes
Pound Cakes 350°F (177°C) 2 48 to 58 minutes
Carrot Cake,Scratch 350°F (177°C) 3 30 to 40 minutes
Casseroles
9" x 13", Scratch 350°F (177°C) 3 30 to 50 minutes
40 oz.,frozen 375°F (190°C) 3 55 to 65 minutes
96 oz.,frozen 400°F (205°C) 3 110 to 130 minutes
Cookies
Bar 375°F (190°C) 3 18 to 23 minutes
Drop 375°F (190°C) 3 8 to 10 minutes
Sliced 375°F (190°C) 3 8 to 10 minutes
Desserts
Custard 350°F (177°C) 2 40 to 50 minutes
Fruit, Crisps and 350°F (177°C) 3 40 to 45 minutes
Cobblers 45 to 55 minutes
Pies,frozen 400°F (205°C) 3 60 to 65 minutes
Pudding
Bread Pudding 350°F (177°C) 2 50 to 60 minutes
Rice Pudding 325°F (163°F) 2 40 to 50 minutes
Fruits andVegetables
Apples,Baked (4) 400°F (205°C) 3 40 to 45 minutes
Potatoes,Baked (4), 400°F (205°C) 3 60 to 70 minutes
6 to 8 oz each
Squash,Winter, 350°F (177°C) 3 50 to 55 minutes
Baked,1-1/2 Ibs
*This chart is a guide.Follow recipe or package.

C Oven Care and Use ManualOven Operations
Page 14
• Use low-sided pans, such as a jelly roll pan, cookie
sheets with 1 or 2 sides,and the 2-piece broil pan.
• Shiny aluminum pans are best, unless otherwise
specified.
• Darkfinish metal pansand heatproofglassor ceramic
bakeware may require oven temperature to be
reduced or the time shortened.
•Preheat when using the convection mode.
• For a quick recipe conversion,reduce the oven temperature 25°from the bake setting.
• Cook food in low-sided,uncovered pans.
• SetTimer 1 or 2 as a reminder to check doneness of the food at minimum time.
Convection Mode Operation
• Foods cooking in less than 15 minutes requires the
same time as in bake mode.
• Foods taking 30 minutes or more to cook will have
a 10 to 15% time savings.
• Check doneness 5 to 10 minutes sooner than the
minimum time for foods taking 30 minutes or more
to cook.
CONVECTION TIPS
1. Select twice for LOWER oven.
2. Select CONVECTION.
The temperature is automatically set at 325°F.
3. Optional step:
To change the temperature from 325ºF, select
another temperature immediately before starting.
4. Select START.
The temperature display alternates between the
set temperature and the actual temperature,
beginning with 100°F. The actual temperature
counts up in 5°F increments
Theovenis preheatedwhenthe chimesignals once.
PREHEAT disappears from the display.
5. To end this mode, select the oven OFF pad.
YouWill See
Touch
UPPER
LOWER
Touch
CONVECTION
Touch
3
7
5
Touch
START
Touch
LOWER
OFF
100
o
/375
o
PREHEAT
CONVECTION
375
o
325
o
CONVECTION
To Set the CONVECTION Mode:

C Oven Care and Use ManualOven Operations
Page 15
Convection Cooking Chart
FOOD ITEM OVEN RACK TIME*
TEMPERATURE
Cakes,mix or scratch:
Angel Food 325°F (163º C) 1 40 to 45 minutes
Layers (8" or 9") 325°F (163º C) 2 and 5 32 to 35 minutes
Rectangle (9 x 13) 325ºF (163º C) 3 31 to 34 minutes
Cupcakes 325ºF (163º C) 1,3,and 5 17 to 20 minutes
Biscuits:
Scratch or 425°F (219º C) 3 10 to 12 minutes
Refrigerator
Cookies:
Drop or Sliced 350°F (177º C) 3 or more racks 8 to 10 minutes
any combination
Cream puffs 375°F (190º C) 3 20 to 30 minutes
Meringues 325°F (163º C) 2 20 minutes
Souffles 350°F (177º C) 3 35 to 40 minutes
* This chart is a guide.Follow recipe or package directions.

C Oven Care and Use ManualOven Operations
Page 16
1. Select OVEN.
• Select twice for LOWER oven..
2. Select CONVECTION BAKE.
The temperature is automatically set at 325°F.
3. Optional step:
To change the temperature from 325ºF, select another
temperature immediately before starting.
4. Select START.
The temperature display alternates between the set
temperatureandtheactual temperature,beginningwith
100°F. The actual temperature counts up in 5°F
increments.
The oven is preheated when the chime signals once.
PREHEAT disappears from the display.
5. To end this mode, select the oven OFF pad.
CONVECTION BAKE TIPS
• Most recipes are cooked on rack positions 1 or 2 to take advantage of bottom heat.
• When a recipe has a two-step temperature cooking method (ex: pumpkin pie),
use the lower temperature for the entire cooking time given.
• For extra crisp bottom crusts (ex:scratch pizza),place the metal pan directly on the oven floor.
• Oven is not preheated for CONVECTION BAKE to take advantage of the lower heat yielding a
better crust on baked items.
• Use the conventional baking temperature and cooking time given in the recipe.
• Cook using only one rack at a time.
To Set the CONVECTION BAKE Mode:
Convection Bake Mode Operation
YouWill See
Touch
UPPER
LOWER
Touch
CONVECTION
then
BAKE
Touch
3
7
5
Touch
START
Touch
LOWER
OFF
325
o
CONVECTION BAKE
CONVECTION
375
o
BAKE
100
o
/375
o
PREHEAT

C Oven Care and Use ManualOven Operations
Page 17
Convection Bake Chart
* This chart is a guide. Follow recipe or package directions.
** No pan used
FOOD ITEM RACK OVEN TIME*
TEMPERATURE
Breads-Yeast:
Bread 2 350°F (177º C) 25 to 35 minutes
Dinner Rolls 2 or 3 400°F (205º C) 15 to 20 minutes
Sweet Rolls 2 or 3 375°F (190º C) 20 to 25 minutes
Frozen Dough I or 2 400°F (205º C) 25 to 35 minutes
Pizza:
Prebaked crust** I 450°F (232º C) 12 to 20 minutes
Scratch*** Oven Floor 450°F (232º C) 20 to 25 minutes
Refrigerator 1 425°F (219º C) 18 to 22 minutes
Frozen** 1 400°F (205º C) 18 to 25 minutes
Pies:
2 Crust Fruit, scratch I 375°F (190º C) 45 to 60 minutes
or frozen 2 400°F (205º C) 60 minutes
Pumpkin,scratch 2 350°F (177º C) 50 to 60 minutes
or frozen 2 400°F (205º C) 55 to 60 minutes
Meringue toppings 2 350°F (177º C) 15 to 20 minutes
Nut pies 1 350°F (177º C) 40 to 50 minutes
Pastry Crust:
Scratch 2 425°F (219º C) 15 to 20 minutes
Graham Cracker 2 375ºF (190º C) 8 to 10 minutes
Refrigerator 2 450°F (232º C) 10 to 15 minutes
Frozen 2 Follow directions
Puff Pastries:
Frozen or scratch I 400°F (205º C) 20 to 25 minutes
Turnovers 1 400°F (205º C) 20 to 25 minutes
Strudel 1 350°F (177º C) 35 to 40 minutes

C Oven Care and Use ManualOven Operations
Page 18
To set ROAST mode:
Roast Mode Operation
1. Select OVEN.
• Select twice for LOWER oven.
2. Select ROAST.
The temperature is automatically set at 350º F.
3. Optional step:
To change the temperature from 350ºF, select
another temperature immediately before
starting.
4. Select START.
The temperature display alternate between the
set temperature and the actual temperature,
beginning with 100ºF.The actual temperature
counts up in 5ºF increments.
The oven is preheated when the chime signals
once.PREHEAT disappears from the display.
5. To end this mode,select the OFF pad.
YouWill See
• This may be used to roast meats, poultry and
vegetables,which would be covered or cooked in a
high-sided open roaster.
• Add liquids, such as water, juice, wine, bouillon or
stock for flavor and moisture.
ROAST TIPS
Touch
UPPER
LOWER
Touch
ROAST
Touch
3
7
5
Touch
START
Touch
LOWER
OFF
• Roasting bags are suitable to use in this mode.
• Whenroasting whole chickens orturkey,tuck wings
behind back and loosely tie legs with kitchen string.
100
o
/375
o
PREHEAT
375
o
ROAST
350
o
ROAST
• Use ROAST for conventional open roasting when drippings are desired.
• Roast mode is excellent for less tender meats or poultry when meat is brasied and a covered dish is used.
• Use a high-sided roasting pan or cover dish with a lid or foil.
