Thermador KBULT3651A User manual

INSTALLATION
INSTRUCTIONS
For Built-in Refrigerators
INSTRUCCIONES DE
INSTALACIÓN
Para los refrigeradores
empotrados
INSTRUCTIONS
D’INSTALLATION
Pour réfrigérateurs encastrés
Bottom Mount Models/
Modelos con montaje inferior/
Modèles superposés
KBULT3651A, KBURT3651A
KBULT3661A, KBURT3661A
KBULT3671A, KBURT3671A
2300134B

2
TABLE OF CONTENTS
REFRIGERATOR SAFETY .............................................................3
DESIGN SPECIFICATIONS............................................................4
Models..........................................................................................4
Product Dimensions.....................................................................5
Tipping Radius .............................................................................6
Door Swing Dimensions...............................................................6
Handle and Door Clearances for Custom Panel Series ..............7
Custom Panels.............................................................................9
Full-Overlay Custom Panels ......................................................10
Curved Handle and Professional Handle Series Side Panels ...11
Custom Panel Series Side Panels .............................................12
INSTALLATION REQUIREMENTS..............................................13
Tools and Parts ..........................................................................13
Location Requirements..............................................................13
Electrical Requirements .............................................................14
Water Supply Requirements ......................................................15
INSTALLATION INSTRUCTIONS ................................................15
Unpack the Refrigerator.............................................................15
Reduce Tipping Radius..............................................................16
Install Anti-Tip Boards................................................................16
Connect the Water Supply.........................................................17
Plug in Refrigerator.....................................................................18
Move Refrigerator to Final Location...........................................18
Lower Leveling Legs ..................................................................18
Install Custom Panels.................................................................19
Level Refrigerator .......................................................................20
Adjust Door Swing......................................................................20
Install Side Panel ........................................................................21
Install Base Grille........................................................................21
Complete Installation..................................................................21
ÍNDICE
SEGURIDAD DEL REFRIGERADOR...........................................22
ESPECIFICACIONES DE DISEÑO ..............................................23
Modelos......................................................................................23
Medidas del producto................................................................24
Arco de vuelco ...........................................................................25
Medidas de oscilación de la puerta...........................................25
Espacios para la agarradera y
la puerta para la serie de paneles a la medida..........................26
Paneles a la medida...................................................................28
Paneles a la medida totalmente recubiertos .............................29
Paneles laterales de la serie de agarradera
curva y de agarradera profesional .............................................30
Paneles laterales a la medida para
la serie de paneles a la medida..................................................31
REQUISITOS DE INSTALACIÓN.................................................32
Piezas y Herramientas ...............................................................32
Requisitos de ubicación.............................................................32
Requisitos eléctricos ..................................................................33
Requisitos del suministro de agua.............................................34
INSTRUCCIONES DE INSTALACIÓN.........................................34
Cómo desempacar su refrigerador............................................34
Cómo reducir el arco de vuelco.................................................35
Cómo instalar los tableros antivuelco........................................36
Conexión del suministro de agua ..............................................36
Cómo enchufar el refrigerador...................................................38
Ubicación final del refrigerador..................................................38
Baje las patas niveladoras .........................................................38
Cómo instalar los paneles a la medida......................................38
Cómo nivelar el refrigerador.......................................................39
Cómo ajustar la oscilación de las puertas.................................40
Cómo instalar el panel lateral.....................................................40
Cómo instalar la rejilla de la base ..............................................41
Cómo terminar la instalación .....................................................41
TABLE DES MATIÈRES
SÉCURITÉ DU RÉFRIGÉRATEUR ..............................................42
SPÉCIFICATIONS DE DESIGN....................................................43
Modèles......................................................................................43
Dimensions du produit...............................................................44
Rayon de basculement ..............................................................45
Dimensions pour le pivotement des portes...............................45
Dégagements pour les poignées et portes ...............................46
Panneaux personnalisés............................................................48
Panneaux personnalisés à recouvrement complet ...................49
Séries de panneaux latéraux à poignée
galbée et Professional................................................................50
Panneaux latéraux de la série de panneaux personnalisés ......51
EXIGENCES D’INSTALLATION...................................................51
Outillage et pièces nécessaires .................................................51
Exigences d’emplacement.........................................................52
Spécifications électriques .........................................................53
Spécifications de l’alimentationen eau ......................................53
INSTRUCTIONS
D’INSTALLATION .........................................................................54
Déballage du réfrigérateur..........................................................54
Réduction du rayon de basculement.........................................54
Installation de planches antibasculement..................................55
Raccordement de la canalisation d'eau ....................................55
Brancher le réfrigérateur.............................................................57
Déplacement du réfrigérateur àl'emplacement final.................57
Déploiement des pieds de nivellement......................................57
Installation des panneaux personnalisés...................................57
Nivellement du réfrigérateur.......................................................58
Ajustement de l’ouverture des portes........................................59
Installation du panneau latéral ...................................................59
Installation de la grille de la base ...............................................60
Achever l’installation ..................................................................60

3
REFRIGERATOR SAFETY
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure do so can result in death or serious injury.

4
DESIGN SPECIFICATIONS
Models
Curved Handle Series
Features stainless steel exterior styling complemented by curved
door handles.
KBULT3651A KBURT3651A
Professional Handle Series
Features stainless steel exterior styling with professional-look door
handles.
KBULT3661A KBURT3661A
Custom Panel Series
Features factory-installed, traditional style trim to provide a
“framed”look. This series requires the installation of custom
panels that are not included.
KBULT3671A KBURT3671A
TRIMKITBM - Trimless Trim Kit
On the Custom Panel Series, you can create a “frameless”look
using full-overlay custom panels. You will need to order a Trimless
Trim Kit for 36 in. Bottom Mounts TRIMKITBM. This accessory kit
contains parts to replace the factory trim.
Full-overlay custom panels and handles are required but not
included in the accessory kit. Create the panels according to the
specifications in the “Full-Overlay Custom Panels”section. You can
order a set of Thermador’s Curved Handles or select handles from
other sources. For door clearances, see “Handle and Door
Clearances for Custom Panel Series.”
CURVEDHAND - Curved Handle Kit
For use with full-overlay custom panels, you can order Thermador’s
Curved Handle Kit. The kit contains 2 handles, screws, and
installation instructions.
EXTHANDBM - Extended Handle Kit for 36" Bottom-mount
This kit may be required if you insatll a custom raised panel. See
“Handle and Door Clearances for Custom Panel Series.”

5
Product Dimensions
Side View
■The depth from the front of the top grille to the back of the
refrigerator cabinet is 25¹⁄₈" (64 cm).
■The power cord is 84" (213 cm) long.
■The water line attached to the back of the refrigerator is 5 ft
(1.5 m) long. Height dimensions are shown with leveling legs
extended ¹⁄₈" (3 mm) below the rollers.
*When leveling legs are fully extended to 1¹⁄₄" (32 mm) below
rollers, add 1¹⁄₈" (29 mm) to the height dimensions.
Top View
Front View
■Width dimensions were measured from trim edge to trim
edge.
■Height dimensions are shown with leveling legs extended ¹⁄₈"
(3 mm) below the rollers.
*When leveling legs are fully extended to 1¹⁄₄" (32 mm) below
rollers, add 1¹⁄₈" (29 mm) to the height dimensions.
25¹⁄₈"
(64 cm)
23¹⁄₂"
(60 cm)
84" (213 cm)
Power Cord
*83¹⁄₈"
(211 cm)
*3¹⁄₂" (9 cm)
25
1
/ 8 "
(64 cm)
35
7
/ 16 "
(90 cm)
36¹⁄₄" (92 cm)
*83¹⁄₈"
(211 cm)

6
Tipping Radius
Be sure there is adequate ceiling height to stand the refrigerator
upright when it is moved into place.
■The dolly wheel height must be added to the tipping radius
when a dolly is used.
■If needed, the tipping radius can be reduced. See “Reduce
Tipping Radius.”
Side Tipping Radius
NOTE: Tip on side only.
Door Swing Dimensions
The location must permit the door to open to a minimum of 90°.
Allow 4¹⁄₂" (11.4 cm) minimum space between the side of the
refrigerator and a corner wall.
NOTE: More clearance may be required if you are using overlay
panels or custom handles.
To adjust the door swing, see “Adjust and Remove Door.”
36" (91 cm) Models
A. Tip this side only
90
1
/ 2 "
(229.9 cm)
A
110˚
90˚
23"
(58 cm)
51"
(130 cm)
59"
(150 cm)
130˚

7
Handle and Door Clearances for Custom Panel Series
If you are installing custom panels, the panels must allow certain clearances for the handles and for the doors to swing open. An
Extended Handle Kit may be required if you install a custom raised panel. See the “Models”section under “Design Specifications.”
1/4" (6.35 mm)
1/2" (1.3 cm)
3/4" (1.9 cm)
1" (2.5 cm)
11/4" (3.2 cm)
11/2" (3.8 cm)
13/4" (4.4 cm)
2" (5.1 cm)
21/4" (5.7 cm)
21/2" (6.4 cm)
23/4" (7 cm)
3" (7.6 cm)
1"
(2.5 cm)
2"
(5.1 cm)
3"
(7.6 cm)
Door
Custom Panel
Handle Dimensions
Actual Size
Custom
Panel
Series
Handle
Optional
Extended
Handle

8
Door Swing 110˚
Actual Size
Custom Panel Series
Clearances for
Full-Overlay Custom Panels
NOTE: To use full-overlay custom panels, you
must order the Trimless Trim Kit. Additionally,
you will need to order either a set of
Thermador's Curved Handles or select
handles from another source. See the
“Models” section of “Design Specifications” for
more information and specific kit.
1/4" (6.35 mm)
3/4" (1.9 cm)
1" (2.5 cm)
11/4" (3.2 cm)
11/2" (3.8 cm)
1/2" (1.3 cm)
1/4"
1/2"
3/4"
1"
11/4"
11/2"
13/4"
2"
3/4"
1"
(2.5 cm)
1
(3.2 cm)
1/4"
1
(3.8 cm)
1/2"
1/2"
Refrigerator
Side Trim
Door
Hinge
Backer Panel
Spacer Panel
Custom Panel
(6.35 mm)
(1.3 cm)
(1.9 cm)
(2.5 cm)
(3.2 cm)
(3.8 cm)
(4.4 cm)
(5.1 cm)
(1.9 cm)
(1.3 cm)

9
Custom Panels
If you plan to install custom wood panels, you will need to create
the panels yourself or consult a qualified cabinetmaker or
carpenter. See dimension drawings for panel specifications.
IMPORTANT: Panels weighing more than recommended may
cause damage to your refrigerator.
NOTE: Dimensions shown have a (±) ¹⁄₁₆" (1.5 mm) tolerance.
Panels that are more than ¹⁄₄" (6.35 mm) thick must be routed. If
panels are less than ¹⁄₄" (6.35 mm) thick, install a filler panel
between the door and the decorative panel.
Top Grille Panel
The top panel should not weigh more than 10 lbs (4.5 kg) total
weight.
Refrigerator and Freezer Panels
The freezer panel should not weigh more than 30 lbs (13.5 kg)
total weight. The refrigerator panel should not weigh more than
60 lbs (27 kg) total weight.
Top Grille Panel –Routing Requirements
Top and bottom edges of the top panel should be edge routed
¹⁄₂" (1.3 cm) and ³⁄₈" (9.5 mm), respectively. Both ends should be
edge-routed ⁷⁄₈" (2.2 cm) as shown.
NOTE: When creating a panel with face detail, the offsets will be
hidden and must be accounted for in order to center the detail in
the top grille.
Door Panel –Routing Requirements
If an extended handle kit is used, then routing the handle side of
the door and drawer panels is not required. See “Handle and
Door Clearances for Custom Panel Series”for more information
on ordering extended handles.
If the standard handle is used, route the entire handle side 3¹⁄₄"
(8.25 cm) to allow for finger clearance. Then route the other side
1" (2.54 cm).
Standard Handle –Top View
34¹⁄₂"
(87.63 cm)
7¹⁄₄"
(18.4 cm)
341 / 4"
(87 cm)
341 / 4"
(87 cm)
49"
(124.5 cm)
201 / 8"
(51.1 cm)
1
/ 4 "
(6.35 mm)
max.
7
/ 8 "
(2.2 cm)
Top
Grille
1
/ 4 "
(6.35 mm
)
max.
7
/ 8 "
(2.2 cm)
Top
Grille
1
/ 2"
(1.3 cm)
min.
1
/ 4"
(6.35 mm) ma
x
Top
Bottom
3
/ 8"
(9.5 mm)
min.
1
/ 4"
(6.35 mm) ma
x
Center face
detail between
offsets
2" (5 cm)
min.
1
/ 4" (6.35 mm) max.
31 / 4"
(8.25 cm)
min.
Door
Panel
Handle
1"
(2.54 cm)
Door
Panel
Hinge Side

10
Door Panel - Side View
Full-Overlay Custom Panels
Custom overlay panels allow you to blend the exterior of your
refrigerator into the overall kitchen décor and to use custom
handles for additional design flexibility.
NOTE: To use full-overlay custom panels, a Trimless Trim Kit for
36" Bottom-mounts is required (TRIMKITBM). Full-overlay
custom panels and handles are required but not included. Create
the panels according to these specifications. You may order
Thermador’s Curved Handle Kit (CURVEDHAND) or select
handles from another source. See the “Models”section under
“Design Specifications”for additional information.
The custom panels must have backer panels attached in order to
mount them to the refrigerator. It is most common to work with
three panels, as shown in the following graphic: a decorative
overlay panel, a ¹/₈" (3.18 mm) spacer panel or spacer strips and
a ¹/₄" (6.35 mm) backer panel.
In some cases, your cabinet manufacturer may choose to work
with one panel routed for the different dimensions. Follow these
panel dimension and placement instructions to be sure that the
custom overlay panels will fit properly.
IMPORTANT:
■The total weight of the refrigerator door overlay panel cannot
exceed 60 lbs (23 kg).
■The total weight of the freezer drawer overlay panel cannot
exceed 30 lbs (13.5 kg).
■The total weight of the top grille overlay panel cannot exceed
10 lbs (4.5 kg).
To minimize panel weight, you may use 2" (5.08 cm) spacer strips
around the perimeter in place of full-sheet solid spacer panels.
The spacer strips must be set in at least 1" (2.54 cm) from the
top, bottom and sides edges of the backer panel. If you use
spacer strips, it is also recommended that you use two - 2"
(5.08 cm) strips horizontally centered for added support.
¹⁄₂" (1.3 cm)
min.
¹⁄₄"
(6.35 mm)
max.
Panel
Overlay Panel Spacer Panel
Backer Panel
5/8" to 3/4"
(15.88 to
19.05 mm) 1/8"
(3.18 mm)
1/4"
(6.35 mm)
1" minimum
(2.54 mm)
Door/Grille Trim
Spacer Panel
Offset Dimension
1/8"
(3.18 mm)
341 / 2"
(87.63 cm)
341 / 2"
(87.63 cm)
491 / 8"
(124.78 cm)
203 / 16"
(51.28 cm)
50"
(127.0 cm)
209 / 16"
(52.23 cm)
345 / 16"
(87.15 cm)
345 / 16"
(87.15 cm)
Bottom Offset
7
/ 16" (11.1 mm)
Bottom Offset
1
/ 16" (1.6 mm)
Center
Backer
Panel
left to
right
Center
Backer
Panel
left to
right
353 / 8"
(89.85 cm)
73
/ 8"
(18.73 cm)
81 / 2"
(21.59 cm)
Bottom Offset
1" (2.54 cm)
345 / 8" (87.95 cm)
Center
Backer
Panel
left to
right

11
Curved Handle and Professional Handle Series Side Panels
Custom side panels may be needed when not enough space is
available to have cabinets on both sides of the refrigerator or
when the refrigerator is placed at the end of a cabinet run. You
may choose an Inset, Flush, or Recessed Inset panel installation.
Refrigerator and Side Trim Dimensions
The width and height of a side panel are determined by the type
of installation you are planning.
NOTES:
■The dimensions shown are actual product dimensions
and may not reflect the needed panel installation
dimensions.
■The side panel should be a minimum of ¹⁄₂" (12 mm) thick
to prevent warping.
■If the opening depth is 25" (63.5 cm) or more, you may
want to install a support board on the rear wall.
Refrigerator
Side Trim
Inset Installation Dimensions
1. Measure the distance from point A (as shown) to the back
wall. Add ⁷⁄₃₂" (5.6 mm) to this measurement to allow the side
panel to fit into the trim.
2. If the panel is more than ¹⁄₄" (6.35 mm) thick, route the front
edge to allow the side panel to fit into the trim.
Flush Installation Dimensions
1. Measure the distance from point A (as shown) to the back
wall.
2. Attach the support board with a screw or adhesive that is
compatible with aluminum and wood.
Recessed Inset Installation Dimensions
1. Measure the distance from point A (as shown) to back wall.
2. Route the front edge of the support board or attach a ¹⁄₄"
(6.35 mm) board to hold the panel in the cabinet side trim.
241 / 8"
(61.3 cm)
231
/ 2"
(59.7 cm)
2311 / 16"
(60.3 cm)
11
/ 64 "
(4.5 mm)
1
/ 4 "
(6.5 mm)
3
/ 16 "
(4.7 mm)
7
/ 32 "
(5.5 mm)
13
/ 32 " (10 mm)
5
/ 8 "
(15.7 mm)
A
A
A

12
Custom Panel Series Side Panels
Custom side panels may be needed when not enough space is
available to have cabinets on both sides of the refrigerator or
when the refrigerator is placed at the end of a cabinet run. You
may choose an Inset or Recessed Inset panel installation.
Refrigerator and Side Trim Dimensions
The width and height of a side panel are determined by the type
of installation you are planning.
NOTES:
■The dimensions shown are actual product dimensions
and may not reflect the needed installation dimensions.
■The side panel should be a minimum of ¹⁄₂" (1.27 cm) thick
to prevent warping.
■If the opening depth is 25" (63.5 cm) or more, you may
want to install a support board on the rear wall.
Refrigerator
Side Trim
Inset Installation Dimensions
1. Measure the distance from point A (as shown) to the back
wall. Add ¹⁄₃₂" (0.8 mm) to this measurement to allow the side
panel to fit into the trim.
2. If the panel is more than ³⁄₈" (9.5 mm) thick, route the front
edge to allow the side panel to fit into the trim.
Recessed Inset Installation Dimensions
1. Measure the distance from point A (as shown) to back wall.
2. Route the front edge of the support board or attach a ³⁄₈"
(9.5 mm) board to hold the panel in the cabinet side trim.
23
3
/ 8 "
(59.40 cm)
Overlay
3
/ 16 "
(4.5 mm)
3
/ 8 "
(9.7 mm)
1
/ 16 "
(1.5 mm)
1
/ 8 "
(3.2 mm)
A
A

13
INSTALLATION REQUIREMENTS
Tools and Parts
IMPORTANT:
■Installer: Leave Installation Instructions with the homeowner.
■Homeowner: Keep Installation Instructions for future
reference. Save these Installation Instructions for the local
electrical inspector’s use.
Tools needed:
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
Parts needed:
■#8 x 3" (7.6 cm) or longer wood screws (6)
■2" x 4" x 32" (5 cm x 10 cm x 81 cm) wood board (1 or 2)
■Make custom or overlay panels or consult a qualified
cabinetmaker or carpenter to make the panels. See
“Installation Requirements”and “Design Specifications.”
■If you are connecting the water line directly to copper tubing
and not to a shutoff valve, you need a ferrule, a union, and a
¹⁄₄" (6.35 mm) compression fitting.
Location Requirements
The refrigerator can be recessed in an opening between cabinets
or installed at the end of a cabinet run using a side panel to
enclose the refrigerator.
IMPORTANT:
■Observe all governing codes and ordinances.
■It is recommended that you do not install the refrigerator
near an oven, radiator, or other heat source.
■Do not install in a location where the temperature will fall
below 55°F (13°C).
■Floor must support the refrigerator weight, more than
600 lbs (272 kg), door panels and contents of the
refrigerator.
■Ceiling height must allow for side tipping radius. See
“Tipping Radius.”
■Location should permit door to open fully. See “Door
Swing Dimensions.”
■Location must permit top grille removal. See “Opening
Dimensions.”
Opening Dimensions
■The solid soffit must be within 1" (2.5 cm) maximum above
the refrigerator. If the solid soffit is higher than 1" (2.5 cm) or
one is not available, then the refrigerator must be braced to
prevent tipping during use.
If the anti-tip boards are needed, they must be attached to
the rear wall studs 80" to 90" (203 - 229 cm) above the floor.
See “Install Anti-Tip Boards”for more information.
NOTE: A clearance of ¹⁄₂" (1.3 cm) must be maintained in front
of the refrigerator’s side trim in order for the top grille to be
removed.
■Hand drill or electric drill
(properly grounded)
■T27 flat-head six-point
driver
■Drill bits ■¹¹⁄₃₂" nut driver
■Adjustable wrenches (2) ■³⁄₈" and ¹⁄₂" open-end
wrenches
■Phillips screwdriver ■⁵⁄₃₂" Allen wrench
■Small level ■⁵⁄₁₆" socket wrench
■Appliance dolly ■Tape measure
WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from refrigerator.
Failure to do so can result in death, explosion, or fire.
1
/ 2"
(1.3 cm)

14
■A grounded 3 prong electrical outlet should be placed within
4" (10.2 cm) of the right side cabinets or end panel. See
“Electrical Requirements”for additional information.
■The water shutoff should be located in the base cabinet on
either side of the refrigerator or some other easily accessible
area. If the water shutoff valve is not in the cabinets, the
plumbing for the water line can come through the floor or the
back wall. See “Water Supply Requirements”for more
specific information.
Electrical Requirements
Before you move your refrigerator into its final location, it is
important to make sure you have the proper electrical
connection.
Recommended Grounding Method
A 115 Volt, 60 Hz., AC only 15- or 20- amp fused, grounded
electrical supply is required. It is recommended that a separate
circuit serving only your refrigerator be provided. Use an outlet
that cannot be turned off by a switch. Do not use an
extension cord.
IMPORTANT: If this product is connected to a GFCI (Ground
Fault Circuit Interrupter) protected outlet, nuisance tripping of the
power supply may occur, resulting in loss of cooling. Food quality
and flavor may be affected. If nuisance tripping has occurred,
and if the condition of the food appears poor, dispose of it.
NOTE: Before performing any type of installation, cleaning, or
removing a light bulb, remove the top grille and turn the master
power switch to OFF or disconnect power at the circuit breaker
box.
When you are finished, turn ON the master power switch or
reconnect power at the circuit breaker box. Then reset the control
to the desired setting.
80" - 90"
(203-229 cm) 4"
(10.2 cm)
6"
(15.2 cm)
3"
(7.6 cm)
831/4" (211.5 cm) min.
843/4" (215 cm) max.
to bottom of solid soffit
231
/2"
(60 cm) min.
11"
(28 cm)
77"
(196 cm)
351/2"
(90.2 cm)
6"
(15.2 cm)
6"
(15.2 cm)
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING

15
Water Supply Requirements
■All installations must meet local plumbing code requirements.
■The water shutoff should be located in the base cabinet on
either side of the refrigerator or some other easily accessible
area. The right-hand side is recommended. The access hole
through the right-hand side cabinet must be within ¹⁄₂"
(12.7 mm) of the rear wall.
■If the water shutoff valve is not in the cabinets, the plumbing
for the water line can come through the floor or the back wall.
A ¹⁄₂" (12.7 mm) hole for plumbing should be drilled 6"
(15.2 cm) to 12" (30.4 cm) from the right-hand side cabinet or
panel. On the floor, the hole should be no more than 11"
(28 cm) away from the back wall. On the wall, the hole should
be no more than 3" (7.6 cm) up from the floor. See “Connect
the Water Supply.”
If this recommended water line location is used, no additional
plumbing must be purchased.
■If additional tubing is needed, use copper tubing and check
for leaks. Install the copper tubing only in areas where the
household temperatures will remain above freezing.
■Do not use a piercing-type or ³⁄₁₆" (4.76 mm) saddle valve
which reduces water flow and clogs more easily.
NOTE: Your refrigerator dealer has a kit available with a ¹⁄₄"
(6.35 mm) saddle-type shutoff valve, a union, and copper
tubing. Before purchasing, make sure a saddle-type valve
complies with your local plumbing codes.
Water Pressure
A cold water supply with water pressure between 30 and 120 psi
(207 - 827 kPa) is required to operate the water dispenser and ice
maker. If you have questions about your water pressure, call a
licensed, qualified plumber.
Reverse Osmosis Water Supply
IMPORTANT: The pressure of the water supply coming out of a
reverse osmosis system going to the water inlet valve of the
refrigerator needs to be between 30 and 120 psi (207 - 827 kPa).
If a reverse osmosis water filtration system is connected to your
cold water supply, the water pressure to the reverse osmosis
system needs to be a minimum of 40 to 60 psi (276 - 414 kPa).
If the water pressure to the reverse osmosis system is less than
40 to 60 psi (276 - 414 kPa):
■Check to see whether the sediment filter in the reverse
osmosis system is blocked. Replace the filter if necessary.
■Allow the storage tank on the reverse osmosis system to refill
after heavy usage.
■If your refrigerator has a water filter cartridge, it may further
reduce the water pressure when used in conjunction with a
reverse osmosis system. Remove the water filter cartridge.
If you have questions about your water pressure, call a licensed,
qualified plumber.
INSTALLATION
INSTRUCTIONS
Unpack the Refrigerator
IMPORTANT:
■Do not remove the protective film until the refrigerator is in its
operating position.
■All four leveling legs must contact the floor to support and
stabilize the full weight of the refrigerator.
■Keep the cardboard shipping piece or plywood under the
refrigerator until it is installed in the operating position.
1. Remove and save the literature package and parts bag taped
to the refrigerator door. Remove the four4 brackets (two on
each side) that attach the shipping base to the refrigerator
bottom.
NOTE: Do not remove tape and door bracing until the
refrigerator is in its final position.
2. Place an appliance dolly under the freezer side of the
refrigerator. Be sure to protect the side trims and handles.
Place the corner posts from the packing materials over the
trims and handles as appropriate. Be sure not to damage the
handles when tightening the strap.
3"
(7.6 cm)
231
/2"
(60 cm) min.
11"
(28 cm)
6"
(15.2 cm)
6"
(15.2 cm)
6"
(15.2 cm)
WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure do so can result in death or serious injury.

16
NOTE: Pass the dolly strap under the handles for the Curved
and Professional Series.
3. Place pieces of the shipping carton on the floor when rolling
the dolly and refrigerator into the house. Move the refrigerator
close to the built-in opening.
NOTE: If necessary, reduce the tipping radius. See “Reduce
Tipping Radius.”
Reduce Tipping Radius
(if required)
Before bringing the refrigerator into the home, be sure there is
adequate ceiling height to stand the refrigerator upright. See
“Tipping Radius”in the “Design Specifications”section for more
information.
If you do not have adequate ceiling height to stand the
refrigerator upright, the tipping radius can be reduced by
removing the top grille and side trims (see the following chart).
Custom Panel Series
1. Grasp both ends of the top grille.
2. Push the top grille straight up; then pull straight out. Lay the
grille on a soft surface.
3. Remove the six screws attaching each cabinet side trim to
the refrigerator and remove the side trims.
4. Stand the refrigerator up. First, place the left bottom edge of
the refrigerator on the floor, stand the refrigerator upright, and
then lower the right-hand side of the refrigerator to the floor.
5. Reassemble the trim and top grille after the dolly has been
removed from the refrigerator.
Curved Handle and Professional Handle Series
1. Grasp both ends of the top grille. Push the top grille straight
up; then pull straight out. Lay the top grille on a soft surface.
2. Remove the six screws attaching each cabinet side trim to
the refrigerator and remove the side trims.
3. Stand the refrigerator up by first placing the left bottom edge
of the refrigerator on the floor, standing the refrigerator
upright, and then lowering the right-hand side of the
refrigerator down to the floor.
4. Reassemble the trim and top grille after the dolly has been
removed from the refrigerator.
Install Anti-Tip Boards
IMPORTANT:
■The solid soffit must be within 1" (2.5 cm) maximum above
the refrigerator. If the solid soffit is higher than 1" (2.5 cm) or
one is not available, prevent the refrigerator from tipping
during use.
■It is recommended that board(s) be installed before the
refrigerator is installed.
■Board(s) must be long enough to fully cover the width of the
compressor cover.
■Locate the board(s) so the bottom surface(s) of the board(s)
is(are) 84" (213 cm) from the floor.
■During installation, raise the refrigerator up so there is ¹⁄₄"
(6.35 mm) maximum between the top of the refrigerator and
the bottom of the anti-tip board(s). Do not crush the
condenser cover when raising the rear leveling legs.
Model Reduced Tipping Radius
36" (91.4 cm) 88" (223.5 cm)
A. Top grille
B. Cabinet side trim
B BA
A. Top grille
B. Cabinet side trim
B BA

17
To Install Anti-tip Boards
1. Mark the stud locations on rear wall 80" to 90" (203 cm to
229 cm) above floor.
2. Securely attach one or two 2" x 4" x 32" (5 cm x 10 cm x
81 cm) boards to wall studs behind refrigerator. Use six
#8 x 3" (7.6 mm) (or longer) wood screws. The wood screws
must be screwed into the studs at least 1½" (3.8 cm). The
board(s) must overlap the compressor cover.
Connect the Water Supply
Read all directions before you begin.
IMPORTANT: If you turn the refrigerator on before the water line
is connected, turn the ice maker OFF.
Connect to Water Line
1. Unplug refrigerator or disconnect power.
2. Turn OFF main water supply. Turn ON nearest faucet long
enough to clear line of water.
3. Locate a ½" to 1¹⁄₄" (1.25 cm to 3.18 cm) vertical cold water
pipe near the refrigerator.
IMPORTANT:
■Make sure it is a cold water pipe.
■Horizontal pipe will work, but drill on the top side of the
pipe, not the bottom. This will help keep water away from
the drill and normal sediment from collecting in the valve.
4. Determine the length of copper tubing you need. Measure
from the connection on the lower left rear of refrigerator to the
water pipe. Add 7 ft (2.1 m) to allow for cleaning. Use ¹⁄₄"
(6.35 mm) O.D. (outside diameter) copper tubing. Be sure
both ends of copper tubing are cut square.
5. Using a grounded drill, drill a ¹⁄₄" hole in the cold water pipe
you have selected.
6. Fasten the shutoff valve to the cold water pipe with the pipe
clamp. Be sure the outlet end is solidly in the ¹⁄₄" drilled hole
in the water pipe and that the washer is under the pipe clamp.
Tighten the packing nut. Tighten the pipe clamp screws
carefully and evenly so washer makes a watertight seal. Do
not overtighten, or you may crush the copper tubing.
7. Slip the compression sleeve and compression nut on the
copper tubing as shown. Insert the end of the tubing into the
outlet end squarely as far as it will go. Screw compression nut
onto outlet end with adjustable wrench. Do not overtighten
the clamp or the sleeve. This will crush the copper tubing.
8. Before attaching copper tubing to the refrigerator place the
free end of the tubing in a container or sink and turn on the
main water supply. Flush at least 2 qt (1.9 L) of water through
the copper tubing until water is clear to get rid of any particles
in the water line. Turn off the shutoff valve on the water pipe.
Coil the copper tubing.
9. Check for leaks around the saddle valve.
Connecting to Refrigerator
Style 1 - Copper Line Connection
1. Unplug refrigerator or disconnect power.
2. Remove the shipping tape from the gray, coiled water tubing
on the rear of the refrigerator.
3. A ¹⁄₄" x ¹⁄₄" coupling is needed in order to connect the water
tubing to an existing household water line. Thread the
provided nut onto the coupling on the end of the copper
tubing.
NOTE: Tighten the nut by hand. Then tighten it with a wrench
two more turns. Do not overtighten.
4. Turn shutoff valve ON.
5. Check for leaks. Tighten any nuts or connections (including
connections at the valve) that leak.
6. Plug in refrigerator or reconnect power.
7. Flush the water system.
NOTE: Allow 24 hours to produce the first batch of ice. Discard
the first three batches of ice produced. Allow 3 days to
completely fill ice container.
A. Center board ¹⁄₄ " (6.35 mm) max. above refrigerator
B. Two 2" x 4" x 32" (5 cm x 10 cm x 81 cm) boards
C. Attach to studs with six #8 x 3" (7.6 cm) screws
D. Compressor cover
BA
C
2" (5 cm)
D
A. Cold water pipe
B. Pipe clamp
C. Copper tubing
D. Compression nut
E. Compression sleeve
F. Shu toff v al ve
G. Packing nut
A. Refrigerator water tubing
B. Nut (provided)
C. Bulb
D. Coupling (provided)
E. Ferrule (purchased)
F. Nut (p urch ased )
G. Household water
line
A
B
C
DEF
G
A B C D E F G

18
Style 2 - Shutoff Valve Connection
1. Unplug refrigerator or disconnect power.
2. Remove the shipping tape from the gray, coiled water tubing
on the rear of the refrigerator.
3. Thread the provided nut onto the water valve as shown.
NOTE: Tighten the nut by hand. Then tighten it with a wrench
two more turns. Do not overtighten.
4. Turn shutoff valve ON.
5. Check for leaks. Tighten any nuts or connections (including
connections at the valve) that leak.
6. Plug in refrigerator or reconnect power.
7. Flush the water system.
NOTE: Allow 24 hours to produce the first batch of ice. Discard
the first three batches of ice produced. Allow 3 days to
completely fill ice container.
Plug in Refrigerator
1. Set control switch at top of cabinet to the OFF position.
2. Plug into grounded 3 prong outlet.
Move Refrigerator to Final
Location
IMPORTANT: To prevent floor damage, make sure levelers are
raised (not touching floor) and refrigerator is on rollers before
moving.
1. Place top of cardboard carton or plywood under refrigerator.
Remove dolly.
2. Do not remove protective film or cover.
3. Move the refrigerator straight back and evenly into the
opening. Be sure that water tubing is not kinked and the
power supply cord is on top of the refrigerator next to the
cover.
Lower Leveling Legs
NOTE: All four leveling legs must contact the floor to support and
stabilize the full weight of refrigerator. Rollers are for moving
refrigerator and not for permanent support.
Use socket wrench to turn leg levelers on both sides of
refrigerator to the right (clockwise) until refrigerator weight is
supported by leveling legs. The rollers should be off the floor. To
avoid cabinet damage, do not apply more than 50 inch-pounds
(58 cm - kg) of torque to the leveling legs.
A. Bulb
B. Nut (provided)
A
B
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
A. Rear leveling legs
B. Front leveling legs
WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure do so can result in death or serious injury.
AB

19
Install Custom Panels
IMPORTANT: Thermador is not responsible for the removal or
addition of molding or decorative panels that would prevent the
refrigerator from being serviced.
NOTE: To install full-overlay custom panels, refer to the
installation instructions included with the Trimless Trim Kit. See
“Design Specifications”for more information.
Door and Drawer Panels
1. Remove all tape and door bracing from the refrigerator door
and freezer drawer.
2. Remove the screws that attach the handle to the frame.
3. Slide the decorative door panel into the frame.
4. If needed, route the door and drawer panels or install a filler
panel between the door and drawer and the decorative
panels. See “Custom Panels.”
5. Replace the door and drawer handles. Check to be sure that
the door and drawer are aligned.
6. Remove the protective skin from the screw covers. Snap the
screw covers into the handle trim section.
Top Grille Panel
1. Grasp both ends of the top grille.
2. Push straight up; then pull straight out. Place the top grille
panel side down on a soft working surface.
3. Remove one end cap by loosening the nuts and sliding off the
end cap.
4. Slide the backer panel into the top grille channel and reattach
the end caps.
5. Replace the top grille in the cabinet side trims and pull the
panel down slightly to lock it into place.
A. Door panel
B. Drawer panel
A
B
A. Top grille
B. Cabinet side trim
A. Bottom rail
B. Nuts
C. End cap
D. Top rail
A. Backer panel
A. Top grille
B. Cabinet side trim
B BA
C
B
A
D
A
B BA

20
Level Refrigerator
NOTE: Custom or full-overlay door panels must be installed
before leveling.
1. Open the door and place the level on top of the refrigerator
frame as shown. Check to see whether the refrigerator is level
from left to right.
2. Use the leveling bolts to adjust the leveling legs until the
refrigerator is level from left to right.
3. Place the level(s) on shelf or shelves. Check to see whether
the refrigerator is level from front to back.
4. Use the leveling bolts to adjust the leveling legs until the
refrigerator is level from front to back.
5. Be sure that all four leveling legs contact the floor and
support the full weight of the refrigerator.
6. Make final check to ensure the refrigerator is level.
Adjust Door Swing
1. Check that the refrigerator door can open freely. If the door
opens too wide or you are installing full-overlay custom
panels using a Trimless Trim Kit, you should adjust the door
swing.
2. Remove the door stop screw from the bottom hinge.
3. Hold the door open to a position that is less than 90°.
4. Replace the door stop screw in the bottom hinge and tighten.
NOTE: If you are using full-overlay custom panels with the
Trimless Trim Kit, the door stop should be replaced in either
the 90°or 110°position. See “Handle and Door Clearances
for Custom Panel Series.”
A. Level to check left to right leveling
B. Level to check front to back leveling
A. Rear leveling bolt
B. Front leveling bolt
A
B
A
BA
B
A. 130°
B. 110°
C. 90°
A. Door stop screw in 110° position
ABC
A
