ThermaQuiet DL65-WM Quick start guide

INSTALLATION INSTRUCTIONS • TYPES DL65-WM,DL145-WM
TQII-2
J17-63967
HEATER
GENERAL DESCRIPTION
ThermaQuiet heatersareforuse withforcedhot waterin
residentialheating systemsand consistof acopper tube,
aluminumfinned heatingelement, witha singlephase
motorand centrifugal fandesign.Theirpurposeis todeliver
acomfortablestream ofwarmed air,and theirconstruction
isextremelycompact sominimum spaceis requiredfor
installation.ThermaQuiet isused forvertical mounting,
withthe airdischarged upwardthrough aflush mounted,
louveredoutercasing.
Alltypes haveheating elementswith 1/2"nominal copper
tubeconnections, andcome witha quickconnect thatcan
bequickly andeasily removed(the quickconnect accepts
1/2"copper orpextubing. Theyare alsoequipped witha
115Velectricfan/motorassembly, intertwinedwith anair
andwater temperaturesensorto preventoperationuntil
hotwater iscirculating.Theseunits areNOTintended to
beused onone ortwo pipesteam systems.
THERMAQUIET Q & A
FOR INSTALLERS
Q. How is ThermaQuiet piped?
ThermaQuiet is piped with 3/4" supply and return pipe.
Connections to ThermaQuiet from supply/return in 1/2"
(Quick Connect).
Q. Can I use 1/2" pipe for Supply and Return?
No, because the ThermaQuiet is designed to have a high
resistance to flow so that the influence of pipe runs is minimized.
Q.What type of pump must I use?
Any 20 ft head pump (i.e. 0011) should suffice, but a high head
pump must be used.
Q. How manyThermaQuiet’s can I put on a 3/4" circuit?
Depending on the length of run, 2-3 is usually fine. For longer
runs use larger diameter pipe.
Q. How do I know if I have adequate flow?
There should be 8-10 degrees difference between supply and
return. If it is much higher, or if you feel a large difference with
your hand, then you have low flow.
ATTENTION: READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO INSTALL, OPERATE, OR
SERVICETHETHERMAQUIET HEATERS! RETAINTHESE INSTRUCTIONS FOR FUTURE REFERENCE.
INSPECT THE SHIPMENT IMMEDIATELY WHEN RECEIVEDTO DETERMINE IF ANY DAMAGE HAS OCCURRED
DURING SHIPMENT.
PRIORTO INSTALLATION, CHECK FOR ANYVISIBLE DAMAGE.MAKE CERTAINTHAT ANY LOOSE PARTICLES ARE
REMOVED (ESPECIALLY INTHE BLOWER ASSEMBLY AREA).
9/12
260 NORTH ELM STREET •WESTFIELD, MA 01085
7555 TRANMERE DRIVE • MISSISSAUGA, ONTARIO L5S 1L4 CANADA
www.designlineonline.com
Figure A: DL65-WM
Figure B: DL145-WM

2.
Figure C: DL65-WM Mounting Hole Locations
Figure D: DL145-WM Mounting Hole Locations
DATA AND RATINGS
InstallingThermaQuiet
Type DL65-WM & DL145-WM
1. Determine the area on the wall in which the Therma-
Quiet unit will be installed. Reference Figure C for the
DL65-WM or Figure D for the DL145-WM and drill
three 7/16" holes in the marked locations at least 3-4"
above finished floor.
2. Insert three supplied hollow wall expansion anchors
into the three newly drilled holes.
3. Screw theThermaQuiet to framed opening at both
sides using 1/4" screws.
4. If quick connect is not used, solder the 15mm heating
element from the unit to a 3/4" connection.
5. Electrical connections for the wall units are to be made
as shown on page 3.
6. Make final piping and electrical connections (see page
3) to the system.Turn the power switch on, purge of
air, check blower operation, and check for any possible
leaks in the piping.
DL65-WM DL145-WM
Low Boost Low Boost
CFM 29 36 59 118
Voltage 115 115
dBa 22 33 22 33
Velocity (ft/sec) 1.31 2.30 1.48 2.23
Dimensions 16.14H x 24W x 4.25D 16.14H x 38.78W x 4.25D
GPM 1414
Pressure Drop (psi) 0.34 4.70 0.43 6.40
GPM Fan
Speed Entering Water Temperature
120°F 130°F 140°F 150°F 160°F 170°F 180°F
DL65-WM
1Low 1402 1926 2487 2971 3296 3550 3858 Normal 2049 2628 3158 3756 4057 4333 4609
Boost 2876 3358 3922 4644 5144 5693 6487
4Low 1584 2176 2810 3357 3724 4012 4360 Normal 2315 2970 3569 4244 4584 4896 5208
Boost 3250 3795 4432 5248 5813 6433 7330
DL145-WM
1Low 3152 3877 4501 5463 6855 7654 8195 Normal 4923 5388 6845 8536 9192 10258 11609
Boost 5805 6215 8352 10243 11865 12951 14340
4Low 3562 4381 5086 6173 7746 8649 9260 Normal 5563 6088 7735 9646 10387 11592 13118
Boost 6560 7023 9438 11575 13407 14635 16204
BTU/hr Output based on 65°F entering air
INSTALLATION OF THERMAQUIETWALL MODELTYPE “WM”
PIPING
SCHEMATIC
Shown is the
piping schematic
for ThermaQuiet
WM-65 and WM-145.
The reverse-return piping
is self balancing and is
preferable.Add balancing
valves to the conventional
piping arrangement to
insure proper balance.

3.
Diagram 2: Double Fan Motor - DL145-WM
ELECTRICAL CONNECTIONS
All electrical connections must conform to local
and national codes.
CAUTION! For Supply Connections, use wires
suitable for at least 194°F (90°C).
A single phase motor is used to drive the ThermaQuiet
blower on 115 – 120 V. 60 Hz. Since current drain is very
small, wiring codes for short circuit protection only will
apply.The motor is connected to a circuit board that has
sensors for both air and water temperature.
Diagram 1: Single Fan Motor - DL65-WM
Electrical Connections are to be made to all units following
the diagrams below. Choose the diagram that best suits
your application.
Since the blower runs on allThermaQuiet models only
when the system circulator pumps hot water through
the unit, simply connect it to the 115V line.If water
temperature sensor reads adequate temperature (greater
than 79°F) the blower then starts after a short warm-up
and stops a few minutes after the circulator shuts off.
Boost
Momentarypressingboost/cool willresult intemperature
controlbeing abandonedfor20 minutesand willenablea
higheroutput settingnot normally accessedin comfort
settings.Note, thisalso dependsonwater temperature
beinghigh enough.Systemwill revert totemperature
controlafter thistime.
Summer Cooling
Insummer,itis desirableto initiateair movement inwarm
conditions.If theOn/Off ANDthe Boost/Coolingbuttonsare
depressedsimultaneously for morethan onesecond, then
thewater temperaturewillbe ignored,and theairflow will
rampup toboost levelsuntil theThermaQuietisswitchedoff.
Request for Heat LED
This will flash Blue if heating is requested and the water
temperature is less than 79°F.
USER ACCESS
On/Off
Whenon/off buttonis pressedand heldformorethan
onesecond, ifwater temperatureisgreater than79°F,
andif roomtemperature isbelowthe comfortsetting,
ThermaQuiet beginsoperation.
Comfort Setting
Whenthe unitis on,if theon/off buttonis depressedless
thanhalf asecond theselected settingis incremented
upwardsbyapproximately3°F.Repeatedpressing will
incrementto thehighest settingand willscroll backto
lowestagain,etc.
LED Indicators
Thesetting LED’s fromleft toright represent65, 68,72,
75°Frespectivelytarget temperatures.
Pleasenote thatthese levelsareactually compensatedlevels,
andforinstance if68°F isselected, thisis comparedto the
compensatedtemperature measuredat lowlevelwhichis the
predictedtemperature atoccupant level.Theselected LEDwill
flashslowly whilethe temperatureisbeing raised.Whenthe
temperaturereaches setpoint,the LEDwill turn solid.

260 NORTH ELM STREET •WESTFIELD, MA 01085
7555 TRANMERE DRIVE • MISSISSAUGA, ONTARIO L5S 1L4 CANADA
www.designlineonline.com
LIMITEDWARRANTY
ThermaQuiet Heaters
The “Manufacturer” warrants to the original owner at the
original installation site that the ThermaQuiet Heaters (the
“Product”) will be free from defects in material or
workmanship for five (5) years from the date of shipment
from the factory. If upon examination by the Manufacturer
the Product is shown to have a defect in material or
workmanship during the warranty period, the Manufacturer
will repair or replace, at its option, that part of the Product
which is shown to be defective.
This limited warranty does not apply:
(a) if the Product has been subjected to misuse or neglect,
has been accidentally or intentionally damaged, has
not been installed, maintained or operated in
accordance with the furnished written instructions, or
has been altered or modified in any way.
(b) to any expenses, including labor or material, incurred
during removal or reinstallation of the defective Product
or parts thereof.
(c) to any workmanship of any installer of the Product.
This limited warranty is conditional upon:
(a) shipment, to the Manufacturer, of that part of the
Product thought to be defective. Goods can only be
returned with prior written approval from the
Manufacturer.All returns must be freight prepaid.
(b) determination, in the reasonable opinion of the
Manufacturer, that there exists a defect in material or
workmanship.
Repair or replacement of any part under this Limited
Warranty shall not extend the duration of the warranty with
respect to such repaired or replaced part beyond the stated
warranty period.
THIS LIMITED WARRANTY IS IN LIEU OF ALL OTHER
WARRANTIES, EITHER EXPRESS OR IMPLIED, AND ALL
SUCH OTHER WARRANTIES, INCLUDING WITHOUT
LIMITATION IMPLIED WARRANTIES OF MERCHANT-
ABILITY OR FITNESS FOR A PARTICULAR
PURPOSE,
ARE HEREBY DISCLAIMED AND EXCLUDED
FROM THIS
LIMITED WARRANTY. IN NO EVENT SHALL THE
MANUFACTURER BE LIABLE IN ANY WAY FOR ANY
CONSEQUENTIAL, SPECIAL, OR INCIDENTAL DAMAGES
OF ANY NATURE WHATSOEVER, OR FOR ANY
AMOUNTS IN EXCESS OF THE SELLING PRICE OF THE
PRODUCT OR ANY PARTS THEREOF FOUND TO BE
DEFECTIVE. THIS LIMITED WARRANTY GIVES THE
ORIGINAL OWNER OF THE PRODUCT SPECIFIC LEGAL
RIGHTS.YOU MAY ALSO HAVE OTHER RIGHTS WHICH
MAYVARY BY EACH JURISDICTION.
REPLACEMENT PARTS LIST
Description 65 145 Part No.
InsulationFoam, adhesive
1/2x 2-3/4x 18 X H06R08833-03
InsulationFoam, adhesive
1/2x 2-3/4x 32 X H06R08833-06
InsulationFoam,
1/2x 2-3/4x 18 X H06R08834-03
InsulationFoam,
1/2x 2-3/4x 32 X H06R08834-06
PlasticCover Assy X H10R08871-03
X H10R08871-06
Grille X H10R08819-03
X H10R08819-06
Wire Harness X J09R08806-01
X J09R08806-02
Wire Harness,Ground Wire X X J09R08806-03
RibbonCable X X J09R08822
Capacitor5uf X J09R08826
Capacitor10uf X J09R08939
On/OffSwitch X X J11R08807
Sensor- Water X X J11R08814
Sensor- Air X X J11R08815
ControlBoard X X J11R08816
KeypadBoard X X J11R08821
Transformer X X J14R08803
Coil X J60R08790-03
X J60R08790-06
WallAnchorKit X X J20R08869
Fan X X J35R08800
ACCESSORIES
QuickConnect Adapters X X J40-09114
