Frico PA2500C Series User manual

Instrukcja obsługi
PA2500C
.... 15
GB .... 21 PL

PA2500C
2
The introduction pages consist mainly of pictures. For translation of the
English texts used, see the respective language pages.
GB
Początkowe strony zawierają głównie rysunki. Tłumaczenie wykorzystanych
tekstów angielskich znajduje się na odpowiednich stronach językowych.
PL

ø17, 5ø17,5
ø32,5
ø25,5
ø20,5
ø1
7, 5
345
min 500
min 500 min 500
157
157157
90,5
10
20
40
22
210
165
184
1026 / 1536 / 2026
1050 / 1560 / 2050
Cu ø1
5
53
71 40
min 500 min 500 157157
PA2500C
3
PA2500C
Gland
Knock-out
Knock-out
Knock-out
Gland
Fig. 1
Fig. 2
2 m
W/A
Gland
E

PA2500C
4
Fig. 3: Open the unit.
A
B
C
TX20

30 mm 60 mm
min 60
PA2500C
5
Fig. 4
Fig. 5
Minimum distance

min 500 mm
203575
210
33
ø8 (3x)
ø5
ø10
162
PA2500C
6
Fig. 6: Mounting with wall brackets
Mounting with wall brackets
AB
C
PA2510C 2 pcs
PA2515C 2 pcs
PA2520C 3 pcs
D

VOS
PA34TR PA2P
PA2PF PAMLK
PA2EF
PAWAK FHDN15
PA2DR
VOT
PA2500C
7
PA2DR
VOT15 DN15
VOT20 DN20
VOT25 DN25
VOS15LF DN15
VOS15NF DN15
VOS20 DN20
VOS25 DN25
PA34TR15 PA2510C, PA2515C, 1 m
PA34TR20 PA2520C, 1 m
PA2P15 PA2510C, PA2515C, 1 m
PA2P20 PA2520C, 1 m
PA2PF15 PA2510C, PA2515C
PA2PF20 PA2520C
PAMLK PA2500C
PA2EF10 PA2510C W
PA2EF15 PA2515C W
PA2EF20 PA2520C W
PAWAK PA2500C W
FHDN15 PA2500C W
Accessories

PA2500C
8
2Water heat - PA2500C W
Type Output*3
[kW]
Airflow
[m3/h]
∆t*2,3
[°C]
Water
volume
[l]
Sound
level*1
[dB(A)]
Voltage
motor
[V]
Amperage
motor
[A]
Length
[mm]
Weight
[kg]
PA2510CW 4 900/1300 10,5/8,5 0,38 41,5/50 230V~ 0,45 1050 17
PA2515CW 6,5 1250/2100 11,5/10 0,81 41/53,5 230V~ 0,6 1560 25,5
PA2520CW 8 1800/2600 11/9 0,74 44,5/54 230V~ 0,9 2050 34,5
3Electrical heat - PA2500C E
Type Output
step
[kW]
Airflow
[m3/h]
∆t*2
[°C]
Sound
level*1
[dB(A)]
Voltage
motor
[V]
Amperage
motor
[A]
Voltage [V]
Amperage [A]
(heat)
Length
[mm]
Weight
[kg]
PA2510CE03 2/3 900/1450 11/6,5 41/51 230V~ 0,5 230V~/13 1050 19
PA2515CE08 4/8 1400/2200 17,5/11 42/51 230V~ 0,7 400V3~/11,5 1560 30
PA2520CE10 5/10 1800/2900 17/10,5 43/53 230V~ 1,0 400V3~/14,4 2050 36
1Ambient, no heat - PA2500C A
Type Output
[kW]
Airflow
[m3/h]
Sound
level*1
[dB(A)]
Voltage
motor
[V]
Amperage
motor
[A]
Length
[mm]
Weight
[kg]
PA2510CA 0 900/1300 43/53 230V~ 0,5 1050 16
PA2515CA 0 1250/2100 44/54 230V~ 0,7 1560 23,5
PA2520CA 0 1800/2600 44/55 230V~ 1,0 2050 32
*1) Conditions: Distance to the unit 5 metres. Directional factor: 2. Equivalent absorption area: 200 m². At
lowest/highest airflow.
*2) ∆t = temperature rise of passing air at maximum heat output and lowest/highest airflow.
*3) Applicable at water temperature 60/40 °C, air temperature, in +18 °C.
Protection class for units with electrical heating: IP20.
Protection class for units without heating and units with water heating: IP21.
CE compliant.
Type C1 Mid
[mF]
C2 Low
[mF]
C2 Run
[mF]
PA2510CA 10 6 4
PA2515CA 14 10 4
PA2520CA 10 6 4
PA2510CE03 10 6 4
PA2515CE08 14 10 4
PA2520CE10 10 6 4
PA2510CW 10 6 4
PA2515CW 14 10 4
PA2520CW 10 6 4

PA2210CA PA2215CA PA2220CA
Right motorLeft motor
Only 2 m version
PA2500C
9
PA2510CA / PA2515CA / PA2520CA
PA2510CA PA2515CA PA2520CA

5A x 3
5A
16A
NH1H2
N
1
On
Off
F1 F2 F3
on/off2
N
LPE NL
PE
~
0 -10V
0 - 10V HEAT
ALARM
WATER
INTERNAL SENSOR
IR
M
Blue
Black
Brown
C°
~
Over heat cut-out
°C
C1
L2 PE
L1 LN
L3
400V 3N~
L2 PE
L1 LN
L3
230V~
2210CE03
2210CE05
PA2210CE03 PA2210CE05
C3
Run
C2 Lo
C1
Mid
PA2500C
10
PA2510CE03
PA2510CE03

5A x 3
5A
16A
NH1H2
N
1
On
Off
F1 F2 F3
on/off2
N
LPE NL
PE
~
0 -10V
0 - 10V HEAT
ALARM
WATER
INTERNAL SENSOR
IR
C2
Over heat cut-out
°C
C1
L2 PE
L1 LN
L3
400V 3N~
Over heat
°C
cut-out
PA2215CE08 PA2220CE10
M
Blue
Black
Brown
C°
~
Right motor
M
Blue
Black
Brown
C°
~
C3
Run
C2 Lo
C1
Mid
Left motor
Only 2 m version
C3
Run
C2 Lo
C1
Mid
C4
C3
L2 PE
L1
L3
400V3~
PA2500C
11
PA2515CE08 / PA2520CE10
PA2515CE08 PA2520CE10

5A x 3
5A
16A
NH1H2
N
1
On
Off
F1 F2 F3
on/off2
N
LPE NL
PE
~
0 -10V
0 - 10V HEAT
ALARM
WATER
INTERNAL SENSOR
IR
PA2210CW PA2215CW PA2220CW
M
Blue
Black
Brown
C°
~
Right motor
M
Blue
Black
Brown
C°
~
C3
Run
C2 Lo
C1
Mid
Left motor
Only 2 m version
C3
Run
C2 Lo
C1
Mid
Black
Brown Blue
PA2500C
12
PA2510CW / PA2515CW / PA2520CW
PA2510CW PA2515CW PA2520CW

M
Blue
Black
Brown
C°
~
Lo
Mid
Run
Right motor
NF1F2F3
OUT PAMLK
CNC NO
Motor alarm (pot. free contact)
M
Blue
Black
Brown
C°
~
Lo
Mid
Run
Left motor
Only 2 m version
5A x 3
5A
16A
NH1H2
N
1
On
Off
F1 F2 F3
on/off 2
N
LPE NL
PE
~
0 -10V
0 - 10V HEAT
ALARM
WATER
INTERNAL SENSOR
IR
On
Off
M
C°
~
PA2500C
13
PAMLK, motor alarm card

PA2500C
14
Output charts water
Water temperature: 80/60 °C
Room temperature: +18 °C
Type Fan
position
Airflow
[m3/h]
Output*
[kW]
Outlet
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
PA2510CW max 1300 7, 2 34,3 0,09 8,2
min 900 5,8 37,3 0,07 5,5
PA2515CW max 2100 12,0 35,2 0,15 11,1
min 1250 8,6 39,4 0,11 6,1
PA2520CW max 2600 15,1 35,1 0,18 10,1
min 1800 12,0 38,2 0,15 6,7
Water temperature: 70/50 °C
Room temperature: +18 °C
Type Fan
position
Airflow
[m3/h]
Output*
[kW]
Outlet
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
PA2510CW max 1300 5,6 30,6 0,07 5,3
min 900 4,4 32,9 0,05 3,6
PA2515CW max 2100 9,4 31,4 0,11 7, 3
min 1250 6,7 34,7 0,08 4,0
PA2520CW max 2600 11,6 31,2 0,14 6,5
min 1800 9,3 33,6 0,11 4,3
Water temperature: 60/40 °C
Room temperature: +18 °C
Type Fan
position
Airflow
[m3/h]
Output*
[kW]
Outlet
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
PA2510CW max 1300 3,7 26,7 0,05 2,9
min 900 3,1 28,3 0,04 1,9
PA2515CW max 2100 6,6 27,5 0,08 4,1
min 1250 4,8 29,8 0,06 2,3
PA2520CW max 2600 8,1 27,2 0,10 3,5
min 1800 6,4 28,9 0,08 2,4
*) Nominal output at given supply and return water temperature.
See www.frico.se for additional calculations.

PA2500C GB
15
Assembly and operating instructions
General Instructions
Read these instructions carefully before
installation and use. Keep this manual for
future reference.
The product may only be used as set out in
the assembly and operating instructions. The
guarantee is only valid if the product is used
in the manner intended and in accordance
with the instructions.
Application area
The PA2500C air curtain unit is supplied
without heating, with electrical heating or
hot water heating. PA2500C is intended for
installation heights up to 2.5 metres. The air
curtain has an integrated control system and
can be remotely controlled. Protection class
for units with electrical heating: IP20.
Protection class for units without heating and
units with water heating: IP21.
Operation
Air is drawn in at the top of the unit and
blown out downwards so that it shields the
door opening and minimizes heat loss. To
achieve the optimum curtain effect the
unit must extend the full width of the door
opening.
The grille for directing exhaust air is
adjustable and is normally angled outwards to
achieve the best protection against incoming
cold air.
The efficiency of the air curtain depends
on the air temperature, pressure differences
across the doorway and any wind pressure.
NOTE! Negative pressure in the building
considerably reduces the efficiency of the air
curtain. The ventilation should therefore be
balanced.
Mounting
The air curtain unit is installed horizontally
with the supply air grille facing downwards
as close to the door as possible. Minimum
distance from outlet to floor for electrically
heated units is 1800 mm. For other minimum
distances, see fig. 4.
Mounting with wall brackets (fig. 6)
1.Mount the brackets on the wall, see fig.6A
and dimension drawing fig.1. If the wall is
uneven the brackets must be compensated
for this.
2.Hook on the unit at the lower edge of the
brackets. (Fig.6B-C)
3.Bend the top of the console over the the
unit and slide the units screws along the
rail into the slots on the consoles. (Fig.6D)
When the bracket is bent once, it must be
replaced if bent back more than 45 °.
4.Lock the nuts against the brackets. (Fig.6E)
Horizontal mounting on the ceiling
Threaded rods, hanging brackets and ceiling
mounting brackets for ceiling mounting are
available as accessories, see accessories pages
and separate manuals.
Electrical installation
The installation, which should be preceded by
an omnipolar switch with a contact separation
of at least 3 mm, should only be wired by a
competent electrician and in accordance with
the latest edition of IEE wiring regulations.
The control system is pre-installed in the air
curtain.
Unit without heating
Connected via the built-in control board with
1,5 m cord and plug.
Unit with water heating
Connected via the built-in control board with
1,5 m cord and plug.
Unit with electrical heating
The electrical connection is made on the
top of the unit. See Fig.2. The 3 kW unit is
connected via the integrated control card
using a 1,5 m cable and plug. Other units are
intended for permanent installation. Control
(230V~) and power supply for heat (400V3~)
should be connected to a terminal block in
the terminal box. 2-metre and longer units
require dual power supplies.
The largest cable diameter for the terminal
block is 16 mm². The cable glands used must
meet the protection class requirements. In

Type Output
[kW]
Voltage
[V]
Minimum
area*
[mm2]
Control 0 230V~ 1,5
PA2510CE03 3 230V~ 1,5
PA2515CE08 8 400V3~ 2,5
PA2520CE10 10 400V3~ 2,5
PA2500C
GB
16
Start-up (E)
When the unit is used for the first time or
after a long period of disuse, smoke or odour
may result from dust or dirt that has collected
on the element. This is completely normal
and disappears after a short time.
Connecting the water coil (W)
The installation must be carried out by an
authorised installer.
The water coil has copper tubes with
aluminium fins and is suitable for connection
to a closed water heating system. The heating
coil must not be connected to a mains
pressure water system or an open water
system.
Note that the unit shall be preceded by a
regulating valve, see Frico valve kit.
The water coil is connected on the upper
side of the unit with ø15 mm smooth copper
pipe with a suitable coupling or soldering.
The connections to the heating coil must be
equipped with shut off valves to allow problem
free removal. Water coil is equipped with a
drain valve. A vent valve should be connected
at a high point in the pipe system.
Air valves are not included. NOTE: Care must
be taken when connecting the pipes. Use
a wrench or similar to hold the air curtain
connections to prevent straining of the
pipes and subsequent water leakage during
connection to water supply pipe-work.
*) Dimensioning of external wiring shall comply
with applicable regulations and local deviations
may occur.
the distribution board it is to be indicated
that ”the air curtains can be supplied from
more than one connection”.
See wiring diagrams.
Adjustment of the air curtain and air flow
The direction and speed of the air flow should
be adjusted considering the load on the
opening. Pressure forces affect the air stream
and make it bend inwards into the premises
(when the premises are heated and the
outdoor air is cold).
The air stream should therefore be directed
outwards to withstand the load. Generally
speaking, the higher the load, the greater the
angle that is needed.
Basic setting fan speed
The fan speed when the door is open is set
using the control. Note that the air flow
direction and fan speed may need fine
adjustment depending on the loading of the
door.
Filter (W)
The water coil is protected against dirt and
blockage by an internal air filter which covers
the coil face. In environments where the filter
needs cleaning often, it is advisable to use an
external intake filter (see accessories pages),
which provides an easier maintenance, since
the unit does not need to be opened. When
an external filter is used, the internal filter is
removed.
Service, repairs and maintenance
For all service, repair and maintenance first
carry out the following:
1.Disconnect the power supply.
2.The front hatch is removed by removing
the screws on the top of the unit and then
detach the bent edge at the bottom. (Fig.3)
3.After the service, repair and maintenance
reattach the front hatch. Place the hatch
at the lower edge with the bent edge and
fasten on top with screws.

PA2500C GB
17
Maintenance
Unit with water heating
The appliance filter should be cleaned
regularly to ensure the air curtain effect and
the heat emission from the device. How often
depends on local circumstances. A clogged
filter is not a risk, but the appliance function
can fail.
1.Disconnect the power supply.
2.The front hatch is removed by removing
the screws on the top of the unit and then
detach the bent edge at the bottom. (Fig.3)
3.Remove the filter and vacuum clean or
wash it. If the filter is clogged or damaged, it
may need to be changed.
All units:
Since fan motors and other components are
maintenance free, no maintenance other than
cleaning is necessary. The level of cleaning
can vary depending on local conditions.
Undertake cleaning at least twice a year. Inlet
and exhaust grilles, impeller and elements
can be vacuum cleaned or wiped using a
damp cloth. Use a brush when vacuuming
to prevent damaging sensitive parts. Avoid
the use of strong alkaline or acidic cleaning
agents.
Replacing motor or impeller
1.Remove gable end.
2.Remove the screw between motor and fan.
3.Disconnect the cables to the motor.
4.Remove the screws securing the motor and
lift it out together with the impeller.
5.Install the new motor and/or the new
impeller as above in reverse order.
Replacing the water coil (W)
1.Shut off the water supply to the unit.
2.Disconnect the connections to the water
coil.
3.Remove the mounting screws securing the
coil in the unit and lift the coil out.
4.Install the new coil in reverse order to the
above.
Draining the water coil (W)
The drain valve is on the underside of the coil
on the connector side. It can be accessed via
the front hatch.
Replacing heating elements/heating
package (E)
1.Mark and disconnect the cables to the
heating elements/package
2.Remove the mounting screws securing the
heating elements/package in the unit and
lift the heaging elements/package out.
3.Install the new heating elements/package in
reverse order to the above.
Overheating
The air curtain unit with electric heater is
equipped with an overheat protector. If it is
deployed due to overheating, reset as follows:
1.Disconnect the electricity with the fully
isolated switch.
2.Determine the cause of overheating and
rectify the fault.
3.Remove the front hatch.
4.Press the red button located inside the
air curtain unit, at the inner gable of the
terminal box.
5.Reattach the front hatch and connect the
unit again.
All motors are equipped with an integral
thermal safety cut-out. This will operate,
stopping the air curtain should the motor
temperature rise too high. The cut-out
will automatically reset when the motor
temperature has returned to within the
motor’s operating limits.
Temperature control
See control pages.

PA2500C
GB
18
Trouble shooting
If the fans are not working or do not blow pro-
perly, check the following:
• The functions and settings of the built-in
control system.
• That the intake grille/filter is not dirty.
If there is no heat, check the following:
• The functions, internal sensor and settings
of the built-in control system.
For units with electrical heating, also check the
following:
• Power supply to electric heater coil; check
fuses and circuit-breaker (if any).
• That the overheat protection for the motors
has not been deployed.
For units with water coil, also check the follo-
wing:
• That the water coil is air free.
• That there is enough water flow.
• That incoming water is heated enough.
If the fault cannot be rectified, please contact
a qualified service technician.
Residual current circuit breaker (E)
When the installation is protected by means
of a residual current circuit breaker, which
trips when the appliance is connected,
this may be due to moisture in the heating
element. When an appliance containing a
heater element has not been used for a long
period or stored in a damp environment,
moisture can enter the element.
This should not be seen as a fault, but is
simply rectified by connecting the appliance
to the main supply via a socket without a
safety cut-out, so that the moisture can be
eliminated from the element. The drying
time can vary from a few hours to a few days.
As a preventive measure, the unit should
occasionally be run for a short time when it is
not being used for extended periods of time.
Safety
•For all installations of electrically heated
products should a residual current circuit
breaker 300 mA for fire protection be used.
•Keep the areas around the air intake
and exhaust grilles free from possible
obstructions!
•The unit may have hot surfaces during
operation and when cooling down!
•The unit must not be fully or partially
covered with clothing, or similar
materials, as overheating can result in a
fire risk! (E)
•This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or
mental capabilities or lack of experience
and knowledge if they have been given
supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved. Children
shall not play with the appliance. Cleaning
and user maintenance shall not be made
by children without supervision.

1234
ON
1234
ON
PA2500C GB
19
230V~
Controls
The air curtain has an integrated control
system and can be remotely controlled.
ON
Factory setting dip-switches - Unit with water
heating
Dip-switch 3 is used for PA2DR (optional).
OFF
Actuator SD230
(remove the quick
connector)
Black
Brown
Blue
External on/off
Eg time switch.
External potential
free closure = off
PA2DR
(accessory)
21
3
Factory setting dip-switches - Unit without heating
or with electrical heating
Dip-switch 3 is used for PA2DR (optional).

1
3
2
PA2500C
GB
20
Functional test
Functional test is started using the remote
control.
Push
and
in 5 seconds
Fan and heatings steps are tested in
10-second intervals which is indicated by
lighted LEDs. When the test is completed, all
LEDs will flash for 30 seconds.
On/off
~20 °C
Temperature control
If the temperature exceeds 50 °C, the fan
runs at full speed for 2 minutes to vent out
the heat, if the temperature rises above
50 °C again during the following 5 minutes
overheating alarm is deployed. The red LEDs
flash and all the buttons are locked.
1.Disconnect the electricity with the fully
isolated switch.
2.Determine the cause of overheating and
rectify the fault.
3.Connect the unit again.
Fan step 1/2/3
On/off
Fan step 1/2/3
Remote control - on/off, fan steps and heating steps
Heat step
Electric: Half/full power
Water: On/off (1 LED)
Control panel - Unit without heating
Control panel - Unit with electrical heating or water
heating
