Thinkrider A1 User manual

Please add the personnel of customer
service on WeChat for more technical support.
Wuxi ThinkRider Technology Co.,Ltd.
The company reserves the right to interpret the above content.
(Please refer to the relevant content of WeChat official account of ThinkRider)
INSTRUCTIONS
1.Product introduction
Thank you for purchasing the ThinkRider A1Bike Trainer.
Please read the instructions carefully before use.
2. Product composition
① A1 smart trainer *1
② Quick release level *1 ③ Quick release converter *1
(Compatable with 130/135mm Q.R.)
Construction: steel triangletype
Power accuracy : ±3%
Wireless connection: ANT+(connect to PC),
bluetooth 4.0(connect to smartphones and tablets)
Device system: IOS/Android/Windows
Drive type: direct drive
Application: cycling simulation
Weight: about 15kg
Simulated slope: fixed 3%
Maximum resistance power: about 1200 watts
Noise level :58 db (@1.0m& 30KPH)
Warranty period:1 year
Battery: CR 2032
Rim size:Road bike:650c /700c, MTB:24"/26"/29"
Hub type:130/135QR,12x142 and 12x148 thru axle(optional)
Cassettes:Shimano / SRAM 8,9,10,11 Speed
Software adaptation:Powerfun,Rouvy,Zwift,PerfPRO,ONELAP,etc.
Bicycle adaptation
* Due to the rapid upgrades of third party software,we will not notify you of
adaptation changes of third-party software.
Note:1.Products and accessories may be changed due to different batches.
Please refer to the actual products.
2.Please keep the box and foam for future transportation and storage.

3.Trainer Installation
Place the trainer on a level surface,install two horizontal feet.
Note that the length of the two feet is not the same, left and right direction
can not be installed in the opposite direction. Refer to the top view below.
There is a freehub on the cycling trainer,which supports the standard
shimano and sram 8-11 speed cassettes
Install your bike on the trainer,just like install the rear wheel on the bike.
The installation method of Q.R./Thru Axle converters is shown below.
Make sure your bike is LOCKED to the trainer,in case it comes loose and
causes harm.
5.Special remind
ThinkRider A1 is a direct-drive trainer of pure power meter. When you're
using all kinds of cycling software (Such as Zwift,Powerfun App), on the
connect device page,you need to select the connection “power meter”
or “power equipment”, please don't choose Smart trainer options.
A1 trainer don't need calibration.
Trainer A1 firmware upgrade tool:
For iPhone, download the app from the App Store: Thinkrider tools
For Androids, please download the app from Google Play: Thinkrider
tools
If the belt skids, it should be tightened according to the videos. (The belt is
consumption items,it is recommended to replace it once a year.)
Please pay attention when installing the horizontal bracket. There is a
difference between front and back and left and right.
6.Warranty
a）The product is guaranteed for one year. If the product fails during the
warranty period and the failure is casused by original device quality problem
or assembly process,the company will provide free maintenance and spare
parts replacement.
b）If it needs to be sent back for repair, the freight shall be borne by the customer.
(Please use the original packing materials when you need to ship the package.)
c）Product damage or malfunction caused by the following reasons is not covered
by the warranty.
1. Damage caused by use or installation in accordance without the
instructions.
2. Product damage caused by human factors or accident.
3. If you have not contacted the company or the dealer to confirm and
disassemble the product yourself without authorization.
4. Ingress of water causes equipment failure.
5. Aging and scratches caused by normal use.
* After the expiration of the warranty period, the company will still provide
maintenance services, but the corresponding maintenance costs are charged.
4. Caveat
Do not let children and pets get close to the bike trainer.
Please use the trainer on a stable ground.
Please consult your doctor before starting or modifying any exercise program.
Do not touch the moving parts of the trainer with your hands or objects.
The flywheel will generate high temperatures after using for a long time.
Do not touch it.
Do not touch the flywheel or disassemble the bicycle while the flywheel is
still rotating.
Be careful when standing on the trainer.
Keep the trainer away from fire, water and other obstacles.
It is strictly forbidden for people with heart or brain diseases and other users
who are not suitable for high-intensity exercise to use the trainer.
Users who are not responsible for their own behavior should not use the trainer.
Rotate 180°
Quick release
Make sure your bike is LOCKED.
Suitable for 130mm spacing
Suitable for 135mm spacing
Rotate 180°
Thru axle(Optional)
Suitable for 142mm spacing
Suitable for 148mm spacing
（Top View ）
6.
1.
2.
3.
4.
5.

FCC Statement
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause
undesired operation.
