thomann Startone MKR 62 User manual

MKR 62
Roll-up Keyboard
User Manual

Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
Internet: www.thomann.de
24.02.2023, ID: 546944

Table of contents
1 General information................................................................................................................................. 4
1.1 Further information........................................................................................................................... 5
1.2 Notational conventions.................................................................................................................... 5
1.3 Symbols and signal words............................................................................................................... 6
2 Safety instructions..................................................................................................................................... 8
3 Features....................................................................................................................................................... 10
4 Installation.................................................................................................................................................. 11
4.1 Dealing with lithium batteries..................................................................................................... 11
5 Connections and operating elements........................................................................................... 13
6 Demo pieces............................................................................................................................................... 19
7 Sound list..................................................................................................................................................... 20
8 Style list........................................................................................................................................................ 25
9 Technical specications....................................................................................................................... 30
10 Protecting the environment.............................................................................................................. 33
Table of contents
MKR 62 3
Roll-up Keyboard

1 General information
This user manual contains important information on the safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to another user, be sure
that they also receive this manual.
Our products and user manuals are subject to a process of continuous development. We there‐
fore reserve the right to make changes without notice. Please refer to the latest version of the
user manual which is ready for download under www.thomann.de.
General information
4MKR 62
Roll-up Keyboard

1.1 Further information
On our website (www.thomann.de) you will nd lots of further information and details on the
following points:
Download This manual is also available as PDF le for you to download.
Keyword search Use the search function in the electronic version to nd the topics of
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the customer service will
gladly assist you.
1.2 Notational conventions
This manual uses the following notational conventions:
General information
MKR 62 5
Roll-up Keyboard

The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
Texts and values displayed on the device are marked by quotation marks and italics.
Examples: ‘24ch’ , ‘OFF’ .
References to other locations in this manual are identied by an arrow and the specied page
number. In the electronic version of the manual, you can click the cross-reference to jump to
the specied location.
Example: See Ä ‘Cross-references’ on page 6.
1.3 Symbols and signal words
In this section you will nd an overview of the meaning of symbols and signal words that are
used in this manual.
Letterings
Displays
Cross-references
General information
6MKR 62
Roll-up Keyboard

Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
WARNING! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in death or serious
injury if it is not avoided.
CAUTION! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in minor injury if it
is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – danger zone.
General information
MKR 62 7
Roll-up Keyboard

2 Safety instructions
This device is intended to be used for electronic sound generation using a piano keyboard. Use
the device only as described in this user manual. Any other use or use under other operating
conditions is considered to be improper and may result in personal injury or property damage.
No liability will be assumed for damages resulting from improper use.
This device may be used only by persons with sucient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Safety
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not within reach of babies and young children. Choking
hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit. They could swallow the pieces and
choke! Never let children unattended use electrical devices.
WARNING!
Incorrect handling of lithium batteries can result in injury
In the event of a short circuit, overheating or mechanical damage, lithium batteries can cause severe injuries. Follow the advice on
the correct handling of lithium batteries in the present section.
Intended use
Safety instructions
8MKR 62
Roll-up Keyboard

CAUTION!
Possible hearing damage
With loudspeakers or headphones connected, the device can produce volume levels that may cause temporary or permanent
hearing impairment. Do not operate the device permanently at a high volume level. Decrease the volume level immediately if you
experience ringing in your ears or hearing impairment.
NOTICE!
Possible damage by leaking batteries
Leaking batteries can cause permanent damage to the device. Take batteries out of the device if it is not going to be used for a
longer period.
NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid
direct sunlight, heavy dirt, and strong vibrations. Only operate the device within the ambient conditions specied in the chapter
‘Technical specications’ of this user manual. Avoid heavy temperature uctuations and do not switch the device on immediately
after it was exposed to temperature uctuations (for example after transport at low outside temperatures). Dust and dirt inside can
damage the unit. When operated in harmful ambient conditions (dust, smoke, nicotine, fog, etc.), the unit should be maintained by
qualied service personnel at regular intervals to prevent overheating and other malfunction.
NOTICE!
Possible damage to lithium-ion batteries through incorrect storage
By deep discharge, lithium-ion batteries can be permanently damaged or lose some of their capacity. Before long breaks, charge the
batteries to around 50 % of their capacity and then switch o the device. Store the device at room temperature or cooler in an envi‐
ronment as dry as possible. If the batteries are stored for a longer period, recharge them to 50 % every three months. Fully charge
the batteries only shortly before use at room temperature.
Safety instructions
MKR 62 9
Roll-up Keyboard

3 Features
The Roll-up keyboard is characterized by the following features:
n61 keys
n128 preprogrammed sounds
n128 preprogrammed styles
n15 demo pieces
nRecord and playback function
nSingle-nger and multi-nger automatic
nSustain
nVibrato
nDigital display
nBuilt-in speakers
nAutomatic shutdown function
nIncl. USB charging cable, power adapter optionally available (item no. 278119)
nConnections: headphones output, USB charging connection / MIDI output, microphone
input, sustain pedal input
Features
10 MKR 62
Roll-up Keyboard

4 Installation
The device is powered by a rechargeable lithium-ion battery. Use only the included lithium-ion
battery or a spare battery with identical specications (see Ä Chapter 9 ‘Technical specications’
on page 30).
Use the included USB charging cable for charging the inserted battery. Connect the device to
the USB port of a PC for charging via this cable.
After playing the Silicone keyboard, roll it up loosely and keep the unit in its original pack‐
aging. Do not kink the Silicone keyboard.
The device automatically switches to standby mode when you don't press any key for about 15
minutes. To reactivate the device into normal operating mode press any key of the keyboard
or of the control panel.
4.1 Dealing with lithium batteries
WARNING!
Incorrect handling of lithium batteries can result in injury
In the event of a short circuit, overheating or mechanical damage, lithium bat‐
teries can cause severe injuries.
Follow the advice on the correct handling of lithium batteries in the present sec‐
tion.
Installation
MKR 62 11
Roll-up Keyboard

When handled correctly and appropriately lithium batteries pose no risk.
Store lithium batteries in a cool, dry place, ideally in the original packaging.
Store lithium batteries away from heat sources (e.g. radiators or sunlight). Lithium batteries are
hermetically sealed. Never attempt to open a lithium battery.
If the battery housing is damaged small amounts of the electrolyte may leak out. If this should
happen, seal the lithium battery in airtight packaging and wipe up the traces of electrolyte
using absorbent paper towels. You must wear protective rubber gloves when doing so. Clean
your hands and the aected surface thoroughly with cold water.
Never attempt to recharge non-rechargeable lithium batteries. When charging lithium bat‐
teries you must use a suitable charging device intended for the purpose.
Before disposing of the device remove the lithium batteries. Protect used lithium batteries
against potential short circuits, e.g. by covering the poles with adhesive tape.
Only use powder extinguishers or other suitable extinguishing agents to extinguish a burning
lithium battery.
Installation
12 MKR 62
Roll-up Keyboard

5 Connections and operating elements
ö #
%
$
&
- 0
.
/
'
(
)
3 4
: ;
<
6
7
5
8
9
+*,
2 1
Control panel
Connections and operating elements
MKR 62 13
Roll-up Keyboard

1[REC] | button to activate the ‘recording’ mode (display shows ‘REC’ ).
In this mode, you can record your own sequences. Press [PLAY] to stop recording and play the recording (display shows
‘REP’ ). The sequence is automatically played once after stopping the recording. To stop playing the recording, press .
When pressing [REC] again and starting a recording, the previous sequence will be overwritten.
2| button to start and stop style and demo piece playback.
3[PLAY] | button to play your own recordings in recording mode.
4[INSERT] | button to insert a ll when playing styles. Press the button once to insert a ll at the end of the currently playing
style.
5[Program] | button to automatically record drum sequences.
In this mode, you can record your own short drum sequences. Press [PLAY] to stop recording and play the recording. To
stop playing the recording, press .
When pressing [Program] again and starting a recording, the previous sequence will be overwritten.
6[Synch] | button to enable the synchro start. Playing a key automatically starts the rhythm.
7[Single] | button to activate the single-nger mode.
Press to start playback of the selected style. Press [Single] (display shows ‘CH1’ ) to activate the single-nger mode.
Then the keyboard automatically plays a suitable chord accompaniment when playing individual notes in the left area of
the keyboard.
Press [Single] again to deactivate the single-nger mode.
Connections and operating elements
14 MKR 62
Roll-up Keyboard

8[Finger] | button to activate the multi-nger mode.
Press to start playback of the selected style. Press [Finger] (display shows ‘CH2’ ) to activate the multi-nger mode.
Then the keyboard automatically plays a suitable chord accompaniment when playing individual notes in the left area of
the keyboard.
Press again to deactivate the multi-nger mode.
9 Display
10 | button to decrease the volume
11 | button to increase the volume
12 [Demo] | button to activate the ‘Demo’ mode.
Press [Demo] to activate the selection. The display shows ‘001’ and the rst demo piece will be played immediately. Press
repeatedly [Demo] and select between the preprogrammed demo pieces ‘000’ … ‘014’ .
Press to stop playing demo pieces.
13 [Tone+] | button to select sounds.
Press [Tone+] to activate the selection. The display shows ‘000’ . Press [Tone+] again to select between the preprog‐
rammed sounds ‘000’ … ‘127’ . Alternatively, use the number buttons to select the desired sound.
14 [Tone-] | button to select sounds.
Press [Tone-] to activate the selection. The display shows ‘000’ . Press [Tone-] again to select between the preprogrammed
sounds ‘000’ … ‘127’ . Alternatively, use the number buttons to select the desired sound.
15 Number buttons | buttons to enter sounds directly.
Connections and operating elements
MKR 62 15
Roll-up Keyboard

16 [RHY+] | button to select styles
Press . The display shows ‘000’ . Press [RHY+] to select between the preprogrammed styles ‘000’ … ‘127’ . Press
again to stop playing styles.
Press [Insert] to insert a ll at the end of the currently playing style.
17 [RHY-] | button to select styles
Press . The display shows ‘000’ . Press [RHY-] to select between the preprogrammed styles ‘000’ … ‘127’ . Press
again to stop playing styles.
Press [Insert] to insert a ll at the end of the currently playing style.
18 [Drum Kit] | button to activate the ‘Drum Kit’ mode.
In this mode you create drum sounds using the various keys, (bass drum, snare, hi-hat, cymbals and eects). Press
[Drum Kit] to activate the mode. Press [Drum Kit] again to deactivate the mode.
19 [Tutorial] | button to activate the learning mode.
Press [Tutorial] to activate the learning mode. Then start the playback of the various demo pieces using the keys of the
keyboard. You have now the option to accompany the playing track. Press again to exit the learning mode.
20 | button to activate the metronome.
Press repeatedly to select between the time signatures 1/4, 2/4, 3/4 or 4/4. Press to desactivate the metronome.
21 [Sustain] | button to activate / deactivate the Sustain eect.
22 [Vibrato] | button to activate / deactivate the Vibrato eect.
23 | button to increase the playback speed of styles and demo pieces.
Connections and operating elements
16 MKR 62
Roll-up Keyboard

24 | button to decrease the playback speed of styles and demo pieces.
25 Battery charging indicator | this LED lights green during charging. Once the installed battery pack is fully charged, the LED
turns o.
26 Power indicator | this LED lights constantly red during operation.
27 | main switch to turn the device on and o.
Connections and operating elements
MKR 62 17
Roll-up Keyboard

= > ? A B
28 [HEADPHONE] | output for headphones or external audio devices, as i.e. active speakers or ampliers, 3.5 mm jack
socket
29 [SUSTAIN PEDAL] | input for an optional sustain pedal, 3.5 mm jack socket
30 [LINE IN] | input for an external audio device (as MP3 or CD player), 3.5 mm jack socket
31 [MICROPHONE] | input for an optional microphone, 3.5 mm jack socket
32 [USB 5V | MIDI OUT] | connection for the supplied USB cable to charge the installed battery pack via the USB port of
a computer and for transferring MIDI data.
Connections
Connections and operating elements
18 MKR 62
Roll-up Keyboard

6 Demo pieces
No. Name No. Name
000 By Alice 008 Les premiers sourires de Vanessa
001 Croatian Rhapsody 009 Snowdreams
002 A comme amour 010 Bandari
003 Green Sleeves 011 Castle in the Sky
004 Dream Wedding 012 Song of Joy
005 Romance De Amor 013 Edelweiss
006 Dancing Girl 014 Dance of reie
007 CrystlLake
Demo pieces
MKR 62 19
Roll-up Keyboard

7 Sound list
No. Name No. Name
Piano 012 Marimba
000 Piano 1 013 Xylophone
001 Piano 2 014 Tubular Bells
002 Piano 3 015 Santur
003 Honky-Tonk Piano Organ
004 Rhodes Piano 016 Hammond Organ
005 Chorused Piano 017 Percussive Organ
006 Harpsichord 018 Rock Organ
007 Clavinet 019 Church Organ
Percussion 020 Reed Organ
008 Celesta 021 Accordion
009 Glockenspiel 022 Harmonica
010 Music box 023 Bandoneon
011 Vibraphone
Sound list
20 MKR 62
Roll-up Keyboard
