thomann Millenium MPS-500 USB User manual

MPS-500 USB
e-drum module
user manual

Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
E-mail: [email protected]
Internet: www.thomann.de
04.12.2015, ID: 305855 (V3)

Table of contents
1 General notes............................................................................................................................................... 5
1.1 Further information........................................................................................................................... 6
1.2 Notational conventions.................................................................................................................... 7
1.3 Symbols and signal words............................................................................................................... 9
2 Safety instructions.................................................................................................................................. 11
3 Features....................................................................................................................................................... 14
4 Installation.................................................................................................................................................. 15
5 Controls........................................................................................................................................................ 17
6 Operation.................................................................................................................................................... 24
6.1 Functions............................................................................................................................................. 24
6.2 Playing, customising and accompanying songs.................................................................. 28
6.3 Drum kits ............................................................................................................................................ 32
6.4 Pad settings........................................................................................................................................ 38
6.5 Metronome click settings.............................................................................................................. 44
6.6 Recording function.......................................................................................................................... 47
Table of contents
MPS-500 USB
3

6.7 Resetting to factory defaults........................................................................................................ 49
7 Technical specifications....................................................................................................................... 51
8 Connector and pin assignments...................................................................................................... 52
9 Cleaning....................................................................................................................................................... 54
10 Protecting the environment.............................................................................................................. 55
11 Appendix..................................................................................................................................................... 56
11.1 Kit list.................................................................................................................................................. 56
11.2 MIDI implementation................................................................................................................... 58
Table of contents
e-drum module
4

1 General notes
This manual contains important instructions for the safe operation of the unit. Read and follow
the safety instructions and all other instructions. Keep the manual for future reference. Make
sure that it is available to all those using the device. If you sell the unit please make sure that
the buyer also receives this manual.
Our products are subject to a process of continuous development. Thus, they are subject to
change.
General notes
MPS-500 USB
5

1.1 Further information
On our website (www.thomann.de) you will find lots of further information and details on the
following points:
Download This manual is also available as PDF file for you to download.
Keyword search Use the search function in the electronic version to find the topics of
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the
customer service will gladly assist you.
General notes
e-drum module
6

1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
Texts and values displayed on the device are marked by quotation marks and italics.
Examples: ‘24ch’, ‘OFF’.
Letterings
Displays
General notes
MPS-500 USB
7

The individual steps of an instruction are numbered consecutively. The result of a step is
indented and highlighted by an arrow.
Example:
1. Switch on the device.
2. Press [Auto].
ðAutomatic operation is started.
3. Switch off the device.
Text inputs that are carried out on the device are indicated by typewriter font.
Example: 2323
References to other locations in this manual are identified by an arrow and the specified page
number. In the electronic version of the manual, you can click the cross-reference to jump to
the specified location.
Example: See Ä ‘Cross-references’ on page 8.
Instructions
Text input
Cross-references
General notes
e-drum module
8

1.3 Symbols and signal words
In this section you will find an overview of the meaning of symbols and signal words that are
used in this manual.
Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
CAUTION! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in minor injury if it
is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
General notes
MPS-500 USB
9

Warning signs Type of danger
Warning – danger zone.
General notes
e-drum module
10

2 Safety instructions
Drum modules are intended to be used for converting digital trigger signals from drum pads
to various percussion sounds. Use the unit only as described in this manual. Any other use or
use under other operating conditions is considered to be improper and may result in personal
injury or property damage. No liability will be assumed for damages resulting from improper
use.
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Intended use
Safety instructions
MPS-500 USB
11

DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
CAUTION!
Possible hearing damage
With loudspeakers or headphones connected, the device can produce volume
levels that may cause temporary or permanent hearing impairment.
Do not operate the device permanently at a high volume level. Decrease the
volume level immediately if you experience ringing in your ears or hearing
impairment.
Safety
Safety instructions
e-drum module
12

NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
NOTICE!
External power supply
The device is powered by an external power supply. Before connecting the
external power supply, ensure that the input voltage (AC outlet) matches the
voltage rating of the device and that the AC outlet is protected by a residual cur‐
rent circuit breaker. Failure to do so could result in damage to the device and pos‐
sibly the user.
Unplug the external power supply before electrical storms occur and when the
device is unused for long periods of time to reduce the risk of electric shock or
fire.
Safety instructions
MPS-500 USB
13

3 Features
n418 sounds
n50 drum kits, 30 user kits
n52 songs, 10 user songs
nMetronome
nStroke counter
nRecording function
nMIDI functions
nFlexible assignment of pad voices
nConnections for headphones, AUX and MIDI
nAutomatic switch-off
Features
e-drum module
14

4 Installation
Setup and installation of the pads and pedals are described in detail in the included setup
guide. Finally, check that all connecting cables between the pads and the drum module are
connected correctly.
Connect the supplied power adapter to the ‘POWER’ input on the rear panel of the drum
module. Then insert the mains plug into a mains wall outlet.
Connect the supplied sub-D plug of the pad connector cable to the sub-D input socket on the
rear panel of the drum module.
Connect your computer (Windows Vista/XP®, Mac) to the USB connection on the rear panel of
the drum module.
Connect the inputs of your amplifier or powered speaker to the ‘LINE OUT’ output jack on the
rear panel of the drum module.
Setup, connecting pads and
pedals
Connecting the power supply
Connecting the pads
Connecting USB devices
Connecting audio devices
Installation
MPS-500 USB
15

Connect your stereo headphones to the PHONE output on the rear panel of the drum module.
Connect audio devices like CD or MP3 player, etc. to the ‘LINE IN’ input on the rear panel of the
drum module.
Connecting headphones
Connecting CD or MP3 player
Installation
e-drum module
16

5 Controls
Front panel
Controls
MPS-500 USB
17

1 Backlit LCD
Displays the Song, Kit and Voice numbers and various setting parameters.
2[TEMPO]
Adjusts the tempo of the click and of the song playback.
3[CLICK]
Turns the metronome on and off and opens the click menu.
4[MODE]
Use this button to toggle operating modes.
5[ENTER]
Input button to confirm a selection or adjustment.
6[EDIT]
Use this button to open the programming menu.
Controls
e-drum module
18

7[SETUP]
Use this button to open the device settings menu.
8[EXIT]
Return key to exit a menu or to discard changes.
9 Pad selection area
Use this buttons to activate pads and kits.
10 Rotary control [–] / [+]
To increase or decrease the value of the currently selected parameter.
11 Record button
Use this button to start the recording.
12 Start / stop button
Use this button to start or stop song playback and to stop the recording.
13 [COUNT]
Use this button to activate the Count mode (stroke counter).
Controls
MPS-500 USB
19

14 [SONG]
Use this button to activate the Demo mode and to playback user songs.
15 [KIT]
Opens the KIT menu.
Controls
