thomann The Box Pro CX 5 User manual

CX 5
active full-range
speaker
user manual

Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
E-mail: [email protected]
Internet: www.thomann.de
17.02.2017, ID: 402318

Table of contents
1 General information................................................................................................................................. 4
1.1 Further information........................................................................................................................... 5
1.2 Notational conventions.................................................................................................................... 6
1.3 Symbols and signal words............................................................................................................... 6
2 Safety instructions..................................................................................................................................... 8
3 Features....................................................................................................................................................... 12
4 Notes on use............................................................................................................................................... 13
5 Connections and operating elements........................................................................................... 14
6 Technical specifications....................................................................................................................... 20
7 Protecting the environment.............................................................................................................. 21
Table of contents
CX 5
3

1 General information
This manual contains important instructions for the safe operation of the unit. Read and follow
the safety instructions and all other instructions. Keep the manual for future reference. Make
sure that it is available to all those using the device. If you sell the unit please make sure that
the buyer also receives this manual.
Our products are subject to a process of continuous development. Thus, they are subject to
change.
General information
active full-range speaker
4

1.1 Further information
On our website (www.thomann.de) you will find lots of further information and details on the
following points:
Download This manual is also available as PDF file for you to download.
Keyword search Use the search function in the electronic version to find the topics of
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the customer service will
gladly assist you.
General information
CX 5
5

1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
1.3 Symbols and signal words
In this section you will find an overview of the meaning of symbols and signal words that are
used in this manual.
Letterings
General information
active full-range speaker
6

Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
CAUTION! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in minor injury if it
is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – high-voltage.
Warning – danger zone.
General information
CX 5
7

2 Safety instructions
This device is intended to be used in a sound reinforcement system. Use the device only as
described in this user manual. Any other use or use under other operating conditions is consid‐
ered to be improper and may result in personal injury or property damage. No liability will be
assumed for damages resulting from improper use.
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
Intended use
Safety
Safety instructions
active full-range speaker
8

DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
DANGER!
Electric shock caused by short-circuit
Always use proper ready-made insulated mains cabling (power cord) with a pro‐
tective contact plug. Do not modify the mains cable or the plug. Failure to do so
could result in electric shock/death or fire. If in doubt, seek advice from a regis‐
tered electrician.
Safety instructions
CX 5
9

CAUTION!
Possible hearing damage
The device can produce volume levels that may cause temporary or permanent
hearing impairment. Over an extended period of time, even levels that seem to
be uncritical can cause hearing damage.
Decrease the volume level immediately if you experience ringing in your ears or
hearing impairment. If this is not possible, keep a greater distance or use suffi‐
cient ear protectors.
NOTICE!
Risk of fire
Do not cover the device nor any ventilation slots. Do not place the device near
any direct heat source. Keep the device away from naked flames.
Safety instructions
active full-range speaker
10

NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
NOTICE!
Power supply
Before connecting the device, ensure that the input voltage (AC outlet) matches
the voltage rating of the device and that the AC outlet is protected by a residual
current circuit breaker. Failure to do so could result in damage to the device and
possibly injure the user.
Unplug the device before electrical storms occur and when it is unused for long
periods of time to reduce the risk of electric shock or fire.
Safety instructions
CX 5
11

3 Features
ncoaxial 5.25" driver
nbuilt-in 120 watt RMS Class-D power amp
n3-channel mixer with 2 × MIC/Line inputs and 1 × RCA and mini jack input
nadditional Line-in on the rear panel
n3-band EQ
nDirect-out on the rear panel
nFrequency range 70 Hz – 20 kHz
nAuto shut-off without signal (deactivatable)
ncan be mounted on microphone stands via 3/8" tripod bracket
Features
active full-range speaker
12

4 Notes on use
Unpack and carefully check that there is no transportation damage before using the unit. Keep
the equipment packaging. To fully protect the device against vibration, dust and moisture
during transportation or storage use the original packaging or your own packaging material
suitable for transport or storage, respectively.
Handle the device with care.
Do not try to disassemble or repair the device yourself if it should not work.
Set the unit's volume to minimum before plugging or unplugging a cable. This prevents loud
noises.
Do not use solvents such as alcohol to clean the device.
Notes on use
CX 5
13

5 Connections and operating elements
Front panel
Connections and operating elements
active full-range speaker
14

1[Bass]
Bass control.
2[Mid]
Mids control.
3[Treble]
Treble control.
4[Main Level]
Overall volume control.
5[Line | 0 dB | Mic]
Gain control for the second Line/Mic input. Turning clockwise increases the input gain for connecting microphones.
Turning counterclockwise decreases the input gain for connecting instruments or devices with line level outputs.
6[Clip]
LED to indicate overload in the channel. If the LED is lit frequently, turn the gain control on this channel slightly back.
Connections and operating elements
CX 5
15

7[Line/Mic]
XLR / 1/4" combo socket to connect microphones, instruments or devices with line level output.
8 Handle to carry or position the device.
9[MP3]
3.5 mm phone socket for connecting line level devices such as MP3 or CD players. Stereo signals are combined.
10 [Line/Mic]
XLR / 1/4" combo socket to connect microphones, instruments or devices with line level output.
11 RCA sockets for connecting line level devices such as MP3 or CD players. Stereo signals are combined.
12 [Clip]
LED to indicate overload in the channel. If the LED is lit frequently, turn the gain control on this channel slightly back.
13 [MP3/RCA]
Volume control for the MP3/RCA inputs.
14 [Line | 0 dB | Mic]
Gain control for the first Line/Mic input. Turning clockwise increases the input gain for connecting microphones.
Turning counterclockwise decreases the input gain for connecting instruments or devices with line level outputs.
Connections and operating elements
active full-range speaker
16

15 [On | Signal | Limit | Protect]
The [On] LED lights when the device is turned on.
The [Signal] LED lights up when a signal is present at at least one input and that input's gain or volume controller is
turned up sufficiently far to reproduce the signals.
The [Limit] LED lights up when the circuit to limit the overall signal is activated. This is to protect the device against
overload. In this case, reduce the overall volume.
The [Protect] LED lights up when the internal protection circuit intervenes and prevents further operation. Then turn
the device off and wait a minute before you turn it back on again.
16 Speaker.
17 3/8" thread for mounting a microphone.
Connections and operating elements
CX 5
17

Rear panel
Connections and operating elements
active full-range speaker
18

18 [Line in]
XLR / 1/4" combo socket as additional Line in to feed in a monitor mix e. g.
19 [Auto Power off]
When this switch is in the [Enable] position, the device will turn off after approx. 30 minutes without input signal. To
turn it then back on again, switch the [Power] button off and on again.
20 [Power]
Switches the device on and off.
21 IEC chassis plug with fuse holder for the power supply. To replace the fuse, carefully take out the fuse holder with a
small screwdriver, replace the defective fuse with a new one of the same type and push the fuse holder back in until
it snaps into place.
22 Housing recess for the included tripod peg, which has previously been screwed onto a tripod, allows the device to be
placed in three different vertical angles.
23 [Direct out]
The signal from the [Line in] input is looped through this XLR chassis plug, e. g. to be sent to other devices.
Connections and operating elements
CX 5
19

6 Technical specifications
Operating supply voltage AC 100 – 240 V~, 50/60 Hz
Fuse 5 mm × 20 mm, 2 A, 250 V, slow-blow
Speaker coaxial 5.25" driver
Frequency response 70 – 20.000 Hz
Amp Class-D, 120 watt RMS
Sound pressure level 90 dB / 1 W / 1 m
Bass, mid, treble control ± 8 dB
Dimensions (W × H × D) 323 mm × 180 mm × 205 mm
Weight approx. 3.5 kg
Technical specifications
active full-range speaker
20
