THORLABS CAB-DCU-T1 User manual
Trigger Cables
CAB-DCU-T1, CAB-DCU-T2,
CAB-DCU-T3
CAB-WFS10-T1
2018
Version:
Date:
2.0
7/9/2018
Copyright © 2018 Thorlabs
We aim to develop and produce the best solution for your application in the field of
optical measurement technique. To help us to live up to your expectations and improve
our products permanently we need your ideas and suggestions. Therefore, please let us
know about possible criticism or ideas. We and our international partners are looking
forward to hearing from you.
Thorlabs GmbH
Foreword
Contents
0
1Cable Types 2
21.1 CAB-DCU-T1
31.2 CAB-DCU-T2
41.3 CAB-DCU-T3
51.4 CAB-WFS10-T1
2 Warranty 6
3Copyright and Exclusion of Reliability 7
4Thorlabs 'End of Life' Policy (WEEE) 8
5Thorlabs Worldwide Contacts 9
© 2018 Thorlabs2
CAB-xxx-Tx
1 Cable Types
CAB-xxx-Tx cables are accessories to Thorlabs DCU22xX and DCC3240X cameras, WFS150x,
WFS300x and WFS10x Wavefront sensors.
1.1 CAB-DCU-T1
USB cable with cables for trigger, flash and digital I/Os
CAB-DCU-T1 (angled Micro D SUB camera connector)
Dedicated Product
DCU223x, DCU224x CCD and DCC1240x CMOS Cameras;
WFS150x and WFS300x Wavefront Sensors
Length
3 m
Cable Type
USB cable, 28AWG/1PR and 24AWG/2C,
additional cable for digital I/O, 4 wire, open wires
Shielding
double shielded
Connector, Camera Side
Micro D-SUB, screw lockable, 90° angled
Connector, PC Side
Male, USB 2.0, Type A
Color Coding
Trigger IN
white
Trigger GND
brown
Flash OUT
green
Digital OUT
yellow
Weight
~ 0.1 kg
Usage Instruction:
First remove the dust cover from the I/O port of the DCU22x camera or WFS150x / WFS300x
Wavefront Sensor. Connect the cable to camera and then to the PC, to ensure that the camera is
being recognized correctly.
© 2018 Thorlabs
1 Cable Types
3
1.2 CAB-DCU-T2
USB cable with cable for Trigger Input
CAB-DCU-T2 (straight Micro D SUB camera connector)
Dedicated Product
DCU223x, DCU224x CCD and DCC1240x CMOS Cameras;
WFS150x and WFS300x Wavefront Sensors
Length
3 m
Cable Type
USB cable, 28AWG/1PR and 24AWG/2C,
additional cable for trigger input, 2 wire, open wires
Shielding
double shielded
Connector, Camera Side
Micro D-SUB, screw lockable, straight
Connector, PC Side
Male, USB 2.0, Type A
Color Coding
Trigger IN
red
Trigger GND
black
Weight
~ 0.1 kg
Usage Instruction:
First remove the dust cover from the I/O port of the DCU22x camera or WFS150x / WFS300x
Wavefront Sensor. Connect the cable to camera and then to the PC, to ensure that the camera is
being recognized correctly.
© 2018 Thorlabs4
CAB-xxx-Tx
1.3 CAB-DCU-T3
Cable for trigger, flash and GPIO
CAB-DCU-T3 (HIROSE 8 pin camera connector)
Dedicated Product
DCC3240x USB 3.0 CMOS Cameras
Length
2 m
Cable Type
High-flexible control cable 8 x0.1mm, Ø 4.9mm
Shielding
single shielded
Connector, Camera Side
HIROSE HR25-7TP-8S (72)
Connector, PC Side
open wires
Pin Assignment and
Color Coding
Hirose connector female,
cable tip view
Pin #
Description
Cable Color
1
Ground (GND)
gray
2
Flash output, opto-decoupled (-)
green
3
GPIO 1, 3.3V LVCMOS
blue
4
Trigger input, opto-decoupled (-)
brown
5
Flash output, opto-decoupled (+)
yellow
6
GPIO 2, 3.3V LVCMOS
red
7
Trigger input, opto-decoupled (+)
white
8
Output supply voltage, 5V (100mA)
pink
Weight
< 0.1 kg
© 2018 Thorlabs
1 Cable Types
5
1.4 CAB-WFS10-T1
Trigger cable
CAB-WFS10-T1 (HIROSE 12 pin camera connector)
Dedicated Product
WFS10x Wavefront Sensors
Length
2 m
Cable Type
2-wire flexible control cable
Shielding
none
Connector, Camera Side
HIROSE HR25 12 pin
Connector, PC Side
open wires
Pin Assignment and Color Coding
Hirose connector female,
cable tip view
Pin #
Description
Cable Color
1 - 10
No connection
-
11
Ground (GND)
black
12
TTL Trigger input
brown
Weight
< 0.1 kg
© 2018 Thorlabs6
CAB-xxx-Tx
2 Warranty
Thorlabs warrants material and production of the CAB-xxx-Tx for a period of 24 months starting
with the date of shipment. During this warranty period Thorlabs will see to defaults by repair or by
exchange if these are entitled to warranty.
For warranty repairs or service the unit must be sent back to Thorlabs. The customer will carry the
shipping costs to Thorlabs, in case of warranty repairs Thorlabs will carry the shipping costs back
to the customer.
If no warranty repair is applicable the customer also has to carry the costs for back shipment.
In case of shipment from outside EU duties, taxes etc. which should arise have to be carried by the
customer.
Thorlabs warrants the hard- and/or software determined by Thorlabs for this unit to operate fault-
free provided that they are handled according to our requirements. However, Thorlabs does not
warrant a fault free and uninterrupted operation of the unit, of the software or firmware for special
applications nor this instruction manual to be error free. Thorlabs is not liable for consequential
damages.
Restriction of Warranty
The warranty mentioned before does not cover errors and defects being the result of improper
treatment, software or interface not supplied by us, modification, misuse or operation outside the
defined ambient stated by us or unauthorized maintenance.
Further claims will not be consented to and will not be acknowledged. Thorlabs does explicitly not
warrant the usability or the economical use for certain cases of application.
Thorlabs reserves the right to change this instruction manual or the technical data of the described
unit at any time.
© 2018 Thorlabs
3 Copyright and Exclusion of Reliability
7
3 Copyright and Exclusion of Reliability
Thorlabs has taken every possible care in preparing this document. We however assume no
liability for the content, completeness or quality of the information contained therein. The content of
this document is regularly updated and adapted to reflect the current status of the hardware and/or
software. We furthermore do not guarantee that this product will function without errors, even if the
stated specifications are adhered to.
Under no circumstances can we guarantee that a particular objective can be achieved with the
purchase of this product.
Insofar as permitted under statutory regulations, we assume no liability for direct damage, indirect
damage or damages suffered by third parties resulting from the purchase of this product. In no
event shall any liability exceed the purchase price of the product.
Please note that the content of this document is neither part of any previous or existing agreement,
promise, representation or legal relationship, nor an alteration or amendment thereof. All
obligations of Thorlabs result from the respective contract of sale, which also includes the
complete and exclusively applicable warranty regulations. These contractual warranty regulations
are neither extended nor limited by the information contained in this document. Should you require
further information on this product, or encounter specific problems that are not discussed in
sufficient detail in the document, please contact your local Thorlabs dealer or system installer.
All rights reserved. This document may not be reproduced, transmitted or translated to another
language, either as a whole or in parts, without the prior written permission of Thorlabs.
Copyright © Thorlabs 2018. All rights reserved.
© 2018 Thorlabs8
CAB-xxx-Tx
4 Thorlabs 'End of Life' Policy (WEEE)
As required by the WEEE (Waste Electrical and Electronic Equipment Directive) of the European
Community and the corresponding national laws, Thorlabs offers all end users in the EC the
possibility to return “end of life” units without incurring disposal charges.
This offer is valid for Thorlabs electrical and electronic equipment
·
sold after August 13th 2005
·
marked correspondingly with the crossed out “wheelie bin” logo (see figure below)
·
sold to a company or institute within the EC
·
currently owned by a company or institute within the EC
·
still complete, not disassembled and not contaminated
As the WEEE directive applies to self contained operational electrical and electronic products, this
“end of life” take back service does not refer to other Thorlabs products, such as
·
pure OEM products, that means assemblies to be built into a unit by the user (e. g. OEM
laser driver cards)
·
components
·
mechanics and optics
·
left over parts of units disassembled by the user (PCB’s, housings etc.).
Waste treatment on your own responsibility
If you do not return an “end of life” unit to Thorlabs, you must hand it to a company specialized in
waste recovery. Do not dispose of the unit in a litter bin or at a public waste disposal site.
WEEE Number (Germany) : DE97581288
Ecological background
It is well known that waste treatment pollutes the environment by releasing toxic products during
decomposition. The aim of the European RoHS Directive is to reduce the content of toxic
substances in electronic products in the future.
The intent of the WEEE Directive is to enforce the recycling of WEEE. A controlled recycling of
end-of-life products will thereby avoid negative impacts on the environment.
Crossed out
"Wheelie Bin" symbol
© 2018 Thorlabs
5 Thorlabs Worldwide Contacts
9
5 Thorlabs Worldwide Contacts
For technical support or sales inquiries, please visit us at www.thorlabs.com/contact for our most up-to-
date contact information.
USA, Canada, and South America
Thorlabs, Inc.
techsupport@thorlabs.com
Europe
Thorlabs GmbH
France
Thorlabs SAS
Japan
Thorlabs Japan, Inc.
UK and Ireland
Thorlabs Ltd.
techsupport.uk@thorlabs.com
Scandinavia
Thorlabs Sweden AB
Brazil
Thorlabs Vendas de Fotônicos Ltda.
China
Thorlabs China
