THRIVE AGRITECH OPTIDRIVE PD4000 User manual
Installation Manual
OptiDrive DC Remote Power System
1
Contents
Background ..................................................................................................................................... 2
General Guidelines.......................................................................................................................... 2
Hardware Overview ........................................................................................................................ 3
19” Rack Recommendation ............................................................................................................ 4
AC Input Wiring............................................................................................................................... 5
PDS12 Shelf AC input Connector ................................................................................................ 5
PD4000 AC Input Connector ....................................................................................................... 6
DC Output Connections .................................................................................................................. 7
Output Connections.................................................................................................................... 7
Dimming Control............................................................................................................................. 8
0-10V / 0-24V Control................................................................................................................. 8
Appendix A: AC Input Ratings ......................................................................................................... 9
Reccomended Breaker Size......................................................................................................... 9
PD4000 input voltage range ....................................................................................................... 9
PDS12 shelf input voltage range................................................................................................. 9
Appendix B: Input Buss Bars ......................................................................................................... 10
PD4000 Input Bus Bars.............................................................................................................. 10
PDS12 Shelf Input Bus Bars....................................................................................................... 12
Appendix C: Output Ratings.......................................................................................................... 13
Appendix D: Signal Connector Pinouts ......................................................................................... 14
PD4000 Module ........................................................................................................................ 14
PDS12 Shelf ............................................................................................................................... 15
2
Background
This manual provides instructions for the installation and electrical interconnections of the
OptiDrive DC Remote Power System. Please contact customer support with any installation
questions.
Thrive Agritech’s OptiDrive DC Remote Power System has been designed specifically to provide
a centralized current source for medium to large scale LED lighting and horticulture
applications. The unique input design allows all standard AC inputs 208 VAC to 600 VAC from
single to 3 phase sources. The output of each 4-kW module provides flicker free current source
from 0 to 16 A at an output voltage range between 100 VDC to 300 VDC. High nominal
operating voltage provides the benefits of lower cost standard wiring and higher efficiency with
minimal voltage drop over long distance.
The 19” rack mount shelf is designed for hot plug replacement of the 4 kW modules insuring
high reliability and simple maintenance.
General Guidelines
•All power should be off before installation.
•Follow all National Electrical Codes (NEC) and local codes.
•Safety Standard of UL62368-1 must be complied with.
•Use only safety agency approved products such as circuit breakers, fuses, AC input cords
and DC output wires.
•Maximum ambient around the power supply shall not exceed +50C
•The power supply shall not be located in the grow room or wet environment.
•Do not connect load (Lights) until power supply has been confirmed to be set to the
correct configuration.
3
Hardware Overview
The PD4000 is a hot-swappable, pluggable power module for use with the PDS12 shelf and
RK1833KM 19” rack.
PD4000. 4,000W high voltage remote DC driver
PD4000 Power Module
PDS12. Shelf holds PD4000 modules
PDS12 Shelf
RK1833BKM. 19” 18U Server Rack Cabinet holds PDS12 Shelves
RK1833BKM Rack
4
19” Rack Recommendation
The recommended rack cabinet for the PDS12 shelves is a StarTech 19" 18U Server Rack
Cabinet model number RK1833BKM. A link to the rack cabinet is here.
It is recommended to mount the PDS12 shelves in a 19” server rack. Do not stack more than
two PDS12 shelves. The recommended racking is shown below. Use one, full width support
shelf for every two PDS12 shelves. Leave 3 feet of clearance in the front and rear of the rack to
airflow and maintenance access.
Recommended racking of PDS12 shelves in RK1833BKM Server Rack Cabinet
5
AC Input Wiring
Installation shall be in accordance with the local electrical codes (NEC for USA) and the
installation shall be done by a qualified electrician.
PDS12 Shelf AC input Connector
The PDS12 shelf AC input connector is a 3-phase input connector. Insert the AC input wires into
the connector shown in the figures below. The connector will accept 3-phase 3- wire and 3
phase, 4-wire (3 phase + neutral). AC input breaker or disconnect must be located within 10
feet of the PDS12 shelf.
PDS12 Shelf AC Input Connector 3-Phase, 3 Wire
PDS12 Shelf AC Input Connector 3-Phase, 4 Wire
6
PD4000 AC Input Connector
The PD4000 module is a single-phase AC input. Insert the AC input wires into the connector
shown in the figure below. For stranded wires, use ferrules on the L1 and L2 connection. Use a
4 mm ring terminal on the GND connection.
L1/L2 Ferrules reference PN PANDUIT FSD76-8-D or similar.
Earth GND connection reference PN STA-KON B14-4 or similar.
PD4000 AC Input Connector
Output
Terminal
Signal
Connector
Communication
Connector
Earth
7
DC Output Connections
The PD4000 module is 4000W, 250VDC, 16A nominal and can operate as a programmable
voltage source or current source. The voltage or current can be programmed using 0-10V
controls or MODBUS digital control.
Output Connections
The wire size from the PD4000 to the lights is dependent on the distance to the lights, the
power rating of the lights and the local electrical code. The output terminal on the PD4000 and
PDS12 shelf are push-in, spring connections. When using stranded wire, a ferrule must be used.
Ferrules reference PN PANDUIT FSD76-8-D or similar. When the lighting system has an earth
ground connection, connect the ground wire to the GND stud with a 4 mm ring terminal PN
STA-KON B14-4 or similar.
PD4000 Output Connector
PDS12 Output Connectors
8
Dimming Control
The PD4000 power module and PDS12 Shelf support traditional 0-10V and 0-24V dimming and
MODBUS RTU digital control.
0-10V / 0-24V Control
Each module can be independently controlled or connected to a common controller using
either the 0-10V or 0-24V standard. Connect the controller using a Molex Micro-Fit connector
with 18 AWG –22 AWG twisted pair wire or shielded wire.
Molex 12 position connector: PN 0430251208
Female Crimp Terminal: 43030
PDS12 Shelf 0-10V Control
PD4000 Shelf 0-10V Control
9
Appendix A: AC Input Ratings
Reccomended Breaker Size
PDS12 Shelf 3-Phase AC input
PD4000 Module 1-Phase input
PD4000 input voltage range
LOW INPUT LINES
208Vac (nominal) Voltage Range: 187Vac to 230Vac
220Vac (nominal) Voltage Range: 198Vac to 242Vac
240Vac (nominal) Voltage Range: 216Vac to 264Vac
HIGH INPUT LINES
347Vac (nominal) Voltage Range: 312Vac to 382Vac
380Vac (nominal) Voltage Range: 342Vac to 418Vac
480Vac (nominal) Voltage Range: 432Vac to 528Vac
PDS12 shelf input voltage range
LOW INPUT LINES
208 Vac (nominal) Voltage Range: 187 –229Vac
HIGH INPUT LINES
346 Vac (nominal) Voltage Range: 311 –381Vac
380 Vac (nominal) Voltage Range: 342 –418Vac
480 Vac (nominal) Voltage Range: 432 –528Vac
10
Appendix B: Input Buss Bars
The PD4000 module and PDS12 shelf have configurable inputs to accommodate low line and
high line input voltage ranges.
PD4000 Input Bus Bars
The PD4000 input voltage bus bars are located inside the chassis opening shown. The bus bar
configuration is printed on the opening cover.
PD4000 AC input bus bar location
There are two options for module buss bars, low line (parallel) and high line (series).
PD4000 Module Low Line Bus Bar
12
PDS12 Shelf Input Bus Bars
The PDS12 Shelf also has input voltage configuration bus bars similar to the PD4000 modules.
The access door is located on the top side of the chassis near the input connector. The bus bar
configuration is printed on the opening cover.
The PDS12 Shelf also has a keying feature to ensure that the module and the shelf have
compatible input configurations. Only modules marked with “P” can be plugged into a shelf
configured for “P” and the same goes for “S”. Note, all slots on the PDS12 must be configured
to the same input voltage level.
PDS12 Shelf Input Voltage Bus Bars
