Corsair VX450W User manual

PERFORMANCE | RELIABILITY | INNOVATION
Extending Corsair’s legendary reputation in performance and quality,
the new Corsair VX family of power supplies features the industry’s
most efficient power management and ultra-quiet design for
mainstream users.
Unlike most power supplies in the market, the Corsair VX
incorporates a single +12V power rail that delivers continuous power
under heavy loads. This conservative design ensures reliable
operation in today’s most demanding system configurations and adds
compatibility for future platforms.
The unique combination of rock solid performance and incredible
value puts the Corsair VX family of power supplies in a class of its
own. Ideal for home theater PCs and ENERGY STAR PCs, the VX line
maximizes energy savings and minimum noise generation thanks to
double-forward switching circuitry design.
Each Corsair VX power supply is backed with an industry-leading
5-year warranty and 24/7 on-demand customer service.
Rock Solid Performance, Incredible Value

Corsair VX550W Specifications: Model CMPSU-550VX
AC INPUT: 90-264V CURRENT: 4.5-9A FREQUENCY: 50Hz-60Hz
DC OUTPUT
AC INPUT RATING
DC OUTPUT RATING
MAX LOAD
MAXIMUM
COMBINED
WATTAGE TOTAL POWER: 550W
+3.3V +5V +12V -12V +5Vsb
30A 28A 41A 0.8A 3A
140W 492W 9.6W 15W
Visit our website at
www.corsair.com
PERFORMANCE | RELIABILITY | INNOVATION
©2007 Corsair
The VX Series logo and the Corsair logo are all
trademarks of Corsair.
All other names and products are trademarks of their
respective owners.
• ATX 2.2 and ATX 2.01 compatible
• Ultra-quiet 120mm double ball-bearing thermally
controlled fan
• High efficiency, up to 85% under a wide load range
• Single +12V rail offers maximum compatibility with latest
components
• Supports SATA and PCI-E devices
• High-quality Japanese capacitors
• Active Power Factor Correction (PFC) with PF value of
0.99
• Auto-Switching universal AC input from 90~264V.
• Over Current/Voltage/Power Protection, Under Voltage
Protection, and Short Circuit Protection
• Extra long fully-sleeved cables support full size tower
chassis
• Standard ATX PS/2 size:
5.9"(W) x 3.4"(H) X 5.5"(L)
50mm(W) x 86mm(H) x 140mm(L)
• MTBF: 100,000 Hours
Core Features:
Corsair VX450W Specifications: Model CMPSU-450VX
AC INPUT: 90-264V CURRENT: 4.5-9A FREQUENCY: 50Hz-60Hz
DC OUTPUT
AC INPUT RATING
DC OUTPUT RATING
MAX LOAD
MAXIMUM
COMBINED
WATTAGE TOTAL POWER: 450W
+3.3V +5V +12V -12V +5Vsb
20A 20A 33A 0.8A 2.5A
130W 396W 9.6W 12.5W
Legendary Corsair Warranty
and Customer Service
Corsair stands behind the VX product family
with an industry leading 5 year (60 months)
warranty. Because questions occur at all hours,
on-line customer support is accessible 24/7 at
www.askthepowerguy.com
You’ll find FAQs and helpful hints from experts
and other users, as well as easy directions for
organizing returns if needed
CMPSU-450VX CMPSU-550VX
CMPSU-450VXUK
CMPSU-450VXEU
CMPSU-550VXUK
CMPSU-550VXEU
450W 550W
CMPSU-450VXJP CMPSU-550VXJP
CMPSU-450VXCN CMPSU-550VXCN
JAPAN
CHINA
CMPSU-450VXAU CMPSU-550VXAU
AUSTRALIA
EUROPE
UK
USA
PART NUMBER
HIGH QUALITY
CAPACITORS FOR
SUPERIOR RELIABILITY
QUIET DOUBLE BALL
BEARING 120MM FAN
FULLY SLEEVED
CABLES
