THUNDER TIGER Ghost plus User manual

QUICK START GUIDE
This product is not a toy. Before you assemble and use this product, please
read this manual thoroughly.
This product and its contents may different from the graphics shown on this
manual and are subject to change without prior notice due to product
improvements and specification changes.
FEATURES
1. Enlarged frame space provides abundant assembly space for electron systems and easier to install various auxiliary equipment required for
aerial photography
2. Intelligent power display system on the surface provides battery capacity check and anti-spark design
3. Can use either proprietary battery or use standard LiPo batteries and saving cost
4. Compatible for major flight control systems & gimbals on the market
5. Built-in “Follow Me” function let your quadcopter can “Follow You” to everywhere
6. Retractable landing skids provide better view of the camera lens
7. High performance 3-Axis gimbal suitable for the GOPRO(Optional)
8. High performance handycam carrier for the Sony PJ series(Optional)
SPECIFICATIONS
Product Name
Frame type
Diagonal distance
Frame weight
Motor stator size
Motor KV
ESC current
ESC voltage
Propeller size
Takeoff weight
Max hover time (est.)
Ghost+
Quadcopter
450mm
1.55Kg(motor,esc,prop. Inc’d)
28x14mm
450rpm/V
30A
6S Lipo(22.2V)
11”x5”
2.25Kg(6S/6000mAh)
25mins(6S/6000mAh)
318
298
323
283
450
No.4030-F11
More information can view the tutorial videos on our TTR official website (www.ttrobotix.com)
or YouTube channel (https://www.youtube.com/user/ThunderTigerVideo)
thundertiger.com
Manufactured / Hersteller :
Thunder Tiger Corp.(Ningbo)
28 Jin-Feng Road, Liang Hui
Industrial Park, Yuyao, Zhejiang
315400 China JK6226

-01-
Thank you for purchasing the TTR product. This product is a high-precision quadcopter. Any misuse may result in damage to property,
injury, or even death. The user must conform to the law and use the equipment responsibly. This product is not suitable for people
under the age of 18. Please read the instruction manual and tutorial videos before using the product, or visit the TTR web page at
www.ttrobotix.com refer to relevant updates or information.
Please keep this product out of reach of children under 3 years old.
Always fly this product away from people and dangers such as buildings, roads and property. We suggest you fly your quadcopter
at specially designated areas.
Please do not fly this product when affected by drunkenness, tiredness, drugs, dizziness fatigue, nausea or any other condition that
might impair your ability to control the quadcopter.
Please make sure all components of the device are connected well and working properly, otherwise, this product may be damaged,
destroyed or even burnt.
Please do not fly this product in unfavorable conditions.
Remote Controlled (RC) Aircraft Model is Intended used for leisure activities.
WARNING
Thunder Tiger warrants to the original purchaser that the Product purchased will be free from defects in materials and workmanship
at the date of purchase. (Removal or tampering of the WARRANTY VOID stickers from the Product voids this warranty.) This
warranty is not transferable and does not cover cosmetic damage, or damage due to acts of God, accident, misuse, abuse, negligence,
commercial use, or due to improper use, installation, operation, maintenance, or modification of or to any part of the Product, or
attempted service by anyone other than a Thunder Tiger authorized customer service center. After reading and following all steps in
the owner’s manual please attach a tether line to this product and check that all functions are working properly. This is your first
flight check, and may be covered under warranty at the discretion of Thunder Tiger and/or its authorized customer service centers. If
you have any problems land the Product immediately and contact an authorized customer service center.
WARRANTY
The Electrical Components of this product are covered under an extended electronics warranty program. Please contact a customer
service center for additional information. If you feel you are experiencing an issue with the flight controller we require a data log and/
or the flight controller for warranty claims.
EXTENDED ELECTRONICS WARRANTY
Any additional components attached to this item are not covered under any portion of this warranty, and are done so at your own
risk. Opening this product, removal of void stickers, or damage from misuse or negligence VOIDS ANY AND ALL WARRANTIES
EXPRESSED OR IMPLIED!
PLEASE NOTE:

-02-
CONTENTS INCLUDED
TOOLS REQUIRED FOR ASSEMBLY
Philips Screwdriver(⊕1) Hobby KnifeThreadlocker Scissors
OPTIONAL PARTS & ACCESSORY
Handycam Gimbal,
SONY PJ Series
FPV Set,5.8G
11" Propeller Set, 4pcs Smart Phone Holder Set6S Li-Po Battery
Balance Charger for
Li-Po Battery
Hex Wrench Set
2.5mm
2mm
1.5mm
Landing Skid Set, 4pcs Compass Holder Wrench
2.4G RadioGHOST+
GOPRO 3-Axis Gimbal
OSD Unit

-03-
FEATURE
Propellers
Motors
Compass
Retract Landing Skid
Direction Lights
FRONT VIEW
Battery Capacity Indicators
Power Switch
Battery Box
TOP VIEW BOTTOM VIEW
Binding Button
Flight Status Indicators
Micro-USB Port
24V Power Wire Out
Gimbal Signal
Wire Out (Y1) Gimbal Signal
Wire Out (Y2)

-04-
RADIO FUNCTION INTRODUCTION
Flight Mode Switch
Reract Landing Skid Switch
Antenna
Gimbal Angle Knob(Tilt)
Joystick
Stick Mode Switch
Charger Jack
Intelligent Mode Switch
Gimbal Angle Knob(Roll/Pan)
Binding Button
Power Switch
Mode 1 Mode 2 Quadcopter Movement
Aileron
Elevator
Rudder
Throttle
BASIC FLIGHT OPERATION
Forward Direction (Indicates Front Side)
Front
Front
Front
Front
Up
Down
Backward
Forward
Right
Left
Right
Left

-05-
COMMANDER TRANSMITTER MODE - 1
CH 1CH 4
CH 2
CH 7
CH 5 CH 6
CH 9
CH 8
CH 3
FUNCTION INTRODUCTION
Retract Landing Skid
Flight Mode
Intelligent Mode
Roll or Pan
IOC ON
IOC OFF
Forward
Backward
Power LED
Binding
ON / OFF
Power
Rudder
M1 / M2 Selection
Aileron
Take Off
Landing Assist
Return Home
100% Full speed
55% Hovering
25% Start
0% Standby
Charging Jack
Gimbal TrimGimbal Trim
Elevator Throttle
Tilt
1. MODE 1
Altitude Control (CH 3) is at
right joystick / Up and Down
Forward / Backward Control( CH 2) is at left joystick / Up and
Down
2. CH 2 / CH 3 position will be switched when changing the
mode.
3. CH 1~CH 4 Joystick Function
CH 1: Aileron - Roll Control
CH 2: Elevator - Forward / Backward Control
CH 3: Throttle - Altitude Control
CH 4: Rudder - Yaw Control
4. CH 5: Intelligent Mode
IOC (Intelligent Orientation Control)
IOC OFF: When IOC switches to the “OFF” mode, the IOC
function will be dismissed.
IOC ON: When IOC switches to the “ON” mode, the
quadcopter will be heading locked intelligently and oriented
to its original take off point.
5. CH 6: Flight Mode
Take Off Mode
When the GPS antenna receives 7 signals from the
satellite, it will switch to the GPS mode automatically.
Landing Assist
The Landing Assist will automatically decelerate and
stabilize the quadcopter when in landing, the function will be
activated when quadcopter is within 2M from the ground.
Return Home
The Return Home feature will autopilot the quadcopter back
to the original take off point and proceed the landing
automatically.
6. CH 7: Gimbal Trim
Trim the Roll or Pan of the Gimbal
7. CH 8: Gimbal Trim
Trim the Tilt of the Gimbal
8. CH 9: Retract Landing Skid
To control the Retract Landing Skid uplock / downlock

-06-
COMMANDER TRANSMITTER MODE - 2
CH 2
CH 7
CH 5 CH 6
CH 9
CH 8
CH 3
FUNCTION INTRODUCTION
Retract Landing Skid
Flight Mode
Intelligent Mode
Roll or Pan
Forward
Backward
Power LED
Binding
ON / OFF
Power
M1 / M2 Selection
Take Off
Landing Assist
Return Home
100% Full speed
55% Hovering
25% Start
0% Standby
Charging Jack
Gimbal TrimGimbal Trim
Elevator
Throttle
Tilt
1. MODE 2
Altitude Control (CH 3) is at
left joystick / Up and Down
Forward / Backward Control( CH 2) is at right joystick / Up and
Down
2. CH 2 / CH 3 position will be switched when changing the
mode.
3. CH 1~CH 4 Joystick Function
CH 1: Aileron - Roll Control
CH 2: Elevator - Forward/Backward Control
CH 3: Throttle - Altitude Control
CH 4: Rudder - Yaw Control
4. CH 5: Intelligent Mode
IOC (Intelligent Orientation Control)
IOC OFF: When IOC switches to the “OFF” mode, the IOC
function will be dismissed.
IOC ON: When IOC switches to the “ON” mode, the
quadcopter will be heading locked intelligently and oriented
to its original take off point.
5. CH 6: Flight Mode
Take Off Mode
When the GPS antenna receives 7 signals from the
satellite, it will switch to the GPS mode automatically.
Landing Assist
The Landing Assist will automatically decelerate and
stabilize the quadcopter when in landing, the function will be
activated when quadcopter is within 2M from the ground.
Return Home
The Return Home feature will autopilot the quadcopter back
to the original take off point and proceed the landing
automatically.
6. CH 7: Gimbal Trim
Trim the Roll or Pan of the Gimbal
7. CH 8: Gimbal Trim
Trim the Tilt of the Gimbal
8. CH 9: Retract Landing Skid
To control the Retract Landing Skid uplock / downlock
IOC ON
IOC OFF
CH 1CH 4
Rudder Aileron

-07-
INTRODUCTION
The GHOST+ is an all in one, ready to fly quadcopter designed for aerial photography.Before shipping from the factory,
it has been configured and fully tested. It means you just need a few assembly steps as shown below, then you can
enjoy your flight.
LANDING SKID
For SAFETY reason, it is advised that you watch the tutorial videos and this manual completely before flying the
quadcopter.
CAUTION
!
More information can view the tutorial videos on our TTR official website (www.ttrobotix.com) or YouTube channel
(https://www.youtube.com/user/ThunderTigerVideo)
QUICK START GUIDE
Install left and right
side the same way
1. Make sure skid assembled as shown.
2. Make sure hex bolt head fit into the
hex shape hole properly.
2
1
Install the landing skid into the body as
shown and secure screws tightly.

-08-
Put the compass set into the body as shown and secure screws tightly.
COMPASS SET
DO NOT pull the connected
wire too hard.
Phillips Tapping Screw, M2.5 x 8

-09-
Black adapter for
counter-clockwise motor
shaft(M2 & M4)
PROPELLER
Diagram for Propeller
Assembly
Please note the orientation
of the propeller. If they are
not assembled properly as
illustrated, quadcopter can
not takeoff and may result
in unexpected damage.
Install the propeller on the motor
shaft and use the adapter to tighten
the propellers. Be sure to match the
rotate direction sign on propeller
and body arm.
Install left and right
side the same way
Ensure props rotate
freely after assembly
Do not use threadlocker
and do not over tighten
adapter
Silver adapter for clockwise
motor shaft(M1 & M3)
FRONT
C.C.W.
M3
C.W.
M4
C.C.W
M1
C.W.
M2
Make sure the direction on the
propller is placed on the correct arm

-10-
SMART PHONE HOLDER
Assembly the smart phone holder as shown, and use the socket screws to correctly attach the smart phone holder
on the radio.

-11-
RADIO
1. Be sure Intelligent Mode, Flight Mode and Gear switched to the
uppermost position.
2. Install 6 x AA batteries.
A continuous beeping sound emitted from the radio indicates LOW BATTERY VOLTAGE, please change battery.
!CAUTION
BATTERY BOX
6S battery power wire
1 pcs of 6S battery link introduction
6S battery balance charger connector
2 pcs of 3S batteries link introduction
3S battery #2
balance charger connector
Main power connector(link to charger or body) Main power connector(link to charger or body)
3S battery #1
balance charger connector
3S Battery #1
XT60 connector
3S Battery #2
XT60 connector

-12-
POWER ON & OFF
Pressing the power button once, you can see the current BATTERY CAPACITY even power off.
CAUTION
!
FLIGHT STATUS INDICATORS
1. Press the power button once, then press and hold for 2 seconds to turn on the power.
2. Press the power button once, then press and hold for 2 seconds to turn off the power.
After power on, the flight status indicators will light up and show the flight status.
1. Final stage urgent low voltage
alert's voltage is single voltage alert
value to deduct 0.05V.
2. When it is final stage urgent low
voltage alert, the Ghost+ will land
originally (user could adjust landing
position during landing but CAN
NOT push the throttle stick).
100%
90%10%
80%
70%
60%
50%
40%
30%
20%
You can see the current battery capacity
from the indicator. Refer to the following
photo for details:
The indicators are defined below:
LED is GREEN
LED is RED
LED is YELLOW
Description
Flight Status LED situation
Horizontal Alignment
Vertical Alignment
Manual altitude (Satellite ≦ 4)
Manual altitude (Satellite
= 5)
LED blinks RED 3 times one loop
LED blinks GREEN 2 times one loop
LED blinks RED 2 times one loop
LED blinks RED 2 times one loop
LED blinks RED 3 times one loop
LED solid in RED
LED solid in GREEN
LED solid in RED
LED solid in YELLOW
Auto hovering
(Satellite ≧ 6)
First stage low voltage alert
Final stage urgent low voltage alert
Return Home
Magnetic compass calibration
IMU Error

-13-
TTR HERO APP DOWNLOAD
1. Download the TTR HERO App from the Google Play Store.
2. You can also use the QR Code below to scan and download the TTR HERO App.
TTR HERO APP CONNECTION
1. Make sure the Wi-Fi function on your smart phone is switched on.
2. Connect to the SSID TTRXXXXXXX and enter the password from
the factory, which should appear in your Wi-Fi signals list approx.
3. Click the TTR HERO App on your smart phone.
TTRXXXXXXX
DOWNLOAD
APP FOR FREE NOW
TTR HERO
Scan QR Code above

-14-
MAGNETIC COMPASS CALIBRATION
1. Click "Magnetic Compass" button on TTR HERO App "Advanced Settings" page.
2. Select "Horizontal Alignment" in the dialog box, and click "OK" button to start Horizontal calibration.
7. Now will automatically display two circles(a BLUE one and a RED one). If the circles as shown are match well, means
the calibration has been successful. If not, then need to do the calibration again.
OK NG
3. Carefully rotate Ghost+ horizontally two times. Ensure that the Green LED light remains ON during this procedure.
4.
Click "Magnetic Compass" button again then select "Vertical Alignment" and click "OK" button to start Vertical calibration.
5. Carefully rotate Ghost+ horizontally two times. Ensure that the Red LED light remains ON during this procedure.
6. Click "Magnetic Compass" button again then select "Save Alignment" and click "OK" button to finish the procedure.
Step 3
Front
Step 5
Front

-15-
ENJOY YOUR FIRST FLIGHT
Mode 1
Mode 2
1. Placing the Ghost+ on the ground and make sure the back side of the Ghost+ towards to you.
2. Switch on the radio first then turn on the Ghost+ power.
3. If you want to use your smart phone, please make sure TTR HERO App is well connected and switched on.
4. Pull both sticks on the radio as shown to start motors and start flying.
5. Pull the throttle stick to bottom as shown to stop motors after landing.
Stop the motors after the Ghost+ landed.DO NOT stop the motors during flight.
CAUTION
!

-16-
EXPLODED VIEW
PV1804
AQ6469
PV1813
AT6203
AQ6545
PV1814
AQ6468
8036
AQ6550
PV1813
PV1813
AQ6470
PV1808
2390R
8047-G
Front
PV1814
PV1813
AQ6551
PV1814
PV1808
PV1813
PV1813
2390L
AQ6470
Use the RED direction
light module Use the GREEN
direction light module
Secure all screws shown on this page, the marked parts
with dropping a few threadlocker especially.
The “Front Arrow” MUST
point towards the front side
of the quadcopter.

-17-
EXPLODED VIEW
Secure all screws shown on this page, the marked parts with dropping a few threadlocker especially.
PV1812
PV1813
PV1813
PV1813
PV1813
PV1809
PV1813 PV1813
PV1807
PV1806
AQ6546
PV1813

-18-
EXPLODED VIEW
2850
PV1805
PV1811
AC7180
AC7180
PV1803
2852
Diagram for Propeller
Assembly
Please note the orientation
of the propeller. If they are
not assembled properly as
illustrated, quadcopter can
not takeoff and result in
unexpected damage
C.W.
C.W.
C.C.W
FRONT
C.C.W.
M3 M4
M1
M2

SPARE PARTS
-19-
PV1805
LANDING SKID SET, 2PCS
AQ6470
DIRECTION LIGHT MODULE
PV1814
BODY SHELL SET
AQ6551
STATUS LED MODULE
PV1809
COMPASS HOLDER
PV1806
RETRACT SKID GEAR BOX A SET
AP0004
SMART PHONE HOLDER SET
2390L
BL MOTOR(C.C.W.),OBL M2814 450KV
AT6203
POWER CONNECTING WIRE
AQ6545
GPS MODULE
PV1811
PROPELLER SET-1150, 2PCS
PV1807
RETRACT SKID GEAR BOX B SET
AQ6468
MAIN POWER SYSTEM BOARD
PV1812
BATTERY TRAY
2390R
BL MOTOR(C.W.),OBL M2814 450KV
PV1803
BATTERY BOX
AQ6546
COMPASS MODULE
PV1804
POWER LIGHT COVER
AQ6469
POWER DISPLAY LED MODULE
PV1813
SCREW SET
AC7180
PROPELLER ADAPTER SET, 2PCS
AQ6550
WIFI MODULE SET,GHOST
PV1808
LED CASE
x8
x8
x2
x2
x4
x8
x32
x3
x6
x9
x8
2540
6S CHARGER
