THUNDER TIGER Sept. Fury User manual

No. 4573
Unlimited Pylon Racer
JE6788 V2
Specifications:
Wing Span: 673/4" (1720mm)
Length: 60" (1525mm)
Weight: 5500g( 12 lbs.)
Engine: .90 2C,1.20 4C req'd
Radio: 5~8ch 6~8servos req'd
Warranty
This kit is guaranteed to be free from defects in material and workmanship at the date of purchase.
It does not cover any damage caused by use or modification. The warranty does not extend beyond
the product itself and is limited only to the original cost of the kit. By the act of building this user-
assembled kit, the user accepts all resulting in liability for damage caused by the final product. If the
buyer is not prepared to accept this liability, it can be returned new and unused to the place of
purchase for a refund. Neither your dealer nor Thunder Tiger Distributors, can accept kits for return if
construction has begun.
Notice: Adult Super Vision Required
This is not a toy. Assembly and flying of this product requires adult super vision.
Read through this book completely and become familiar with the assembly and flight of this airplane.
Inspect all parts for completeness and damage. fIyou encounter any prob lems, call us for help.
BALANCE
Control Throws
1 3/4"
3/4"
1/2"
1/2"
1/2"
1/2"
3/4"
3/4"
Aileron-Low Rate
Aileron-High Rate
Elevator-Low Rate
Elevator-High Rate
Locate A Good Flying Site
Academy of Model Aeronautics
5151 East Memorial DR
Muncie, IN 47302-9252
www.modelaircraft.org
A Note On Batteries
Congratulations
Set the control throws as followings for a starting point. After you
familiar with its flying characteristics then these control throw can
be tailored to fit your flying style.
IMPORTANT - Do not attempt to fly your model before
completing this very important section. Amodel that is not
properly balanced will be unstable and could causeserious
damage and/or injury. Adjust the battery location or add
weight as needed to achieve level balance.
Center of Gravity
Now that youhave completed theassembly of your Sept.
Fury we feel that you have a very capable and good
looking sports scale plane. We hope that youwill enjoy
this model andget many hoursof flying pleasurefrom its
use. Thank you for purchasing this Sept. Fury from
Thunder Tigerand we look forward to providingyou with
other greatR/C productsin thefuture.
The batteries arethe heartof your radio system. Makesure
you have fully charged batteries! With recharge-able
batteries, follow the manufacturers instructions to make
sure the batteries are fully charged, especial thefirst time
the radio is used. We would recommend you use larger
capacity (1000mAh) if you use high performance servosas
they will draw more current than ordinary servos.
If there is not a chartered club field in your community,
you will need tofind a large area freeof obstructions, and
has a smooth grass or asphalt surface to be used as a
runway. Forsafetysake, itshould be located wellaway from
houses, buildings, schools, power linesand airports.If you
will be flying within 6 miles of an airport, you shouldcheck
with the airportmanager beforeflying yourmodel.
Generally, the best place to fly your modelis atan AMA
(Academy of ModelAeronautics) chartered club field. Your
local hobby dealer cantell you if there is such a club in your
area orwrite theAMAfor information. It isalso a good idea
to jointhis organizationbefore flying your model sincethey
offer liability insurance that can protect youif yourmodel
causes damageor injury toothers.
124
Measure theC.G. whileplane isdry.The balancepoint is
about 3 3/4"(95mm) behind the leadingedge where there
is apanel line onfuselage.
Assembly Manual
3"
Flap
1"
1"
Rudder-Low Rate
Rudder-High Rate
1 3/4"
3/4"
3 3/4"
(95mm)
1000mAH

The Sept.Fury is designed for advanced pilots andit requires advancedassembling and flyingskill. Before you
begin, checkthe entirecontents ofyour kitagainst the parts drawingand photosto makesure thatno partsare missing
or damaged.This will alsohelp you tobecome familiar witheach component ofyour plane. Ifyou find thatany of theparts
are eithermissing ordamaged, pleasecontact ThunderTigerDistributors forCustomer Service.
Introduction................................................2
Recommended Tools &Materials ...............3
Parts Drawings........................................4-5
Parts CheckList.........................................6
Wing................. ...................................7-10
Landing Gear......................................11-12
Fuselage..................................................13
Tail......................................................14-16
Congratulations onthe purchaseof oneof ourfinestARFs to date. Theever-popular Sept.Furypiloted byMichael Brown
qualified inthe UnlimitedClass at468.266 mphof the2002 NationalChampionships Air Race & Air Show, whichwas held
in Reno Stead Field.For moreinformation pleasebrowse www.septemberpops.com formore information.
INTRODUCTION
PRE-ASSEMBLY NOTES
TABLE OF CONTENTS
Rudder .......................................................17
TailGear ....................................................18
Engine........................................................19
Fuel Tank....................................................20
Radio..........................................................21
Cowling......................................................22
Decal .........................................................23
Balance......................................................24
3
ITEMS YOUMAY NEED
TTR1115 - PrecisionFueler Valve
Adhesives:
Instant setting Cyanoacrylateadhesive (thin CA)
Slow setting Cyanoacrylateadhesive (thick CA)
5-10 Minute Epoxy(fast)
20-30 MinuteEpoxy (slow)
Tools:
Model knife,T-Pins,MASK tape
Small screwdrivers, mediumscrewdrivers
Scissors
Steel straightedge
Long nose pliersand diagonal cuttingpliers
Drill and drillbits (1/16",3/32", 3.4mm)
M4x0.7 Tap
Sanding block
Fine felttip penand softlead pencil
Straight building board
R/C System:
6 Channel radiowith 7 servosplus one retractservo
Five 12" extensionwires.
one Ycords
Engine:
2 cycle:91~1.08
4 cycle:1.2~1.5
Propeller:
Appropriate forengine typeand preferred
performance
RECOMMENDED TOOLS & MATERIALS
Adhesives - You will need two typesof adhesivesfor the
Sept.Fury -Epoxy and Instant(cyanoacrylate) adhesives.
We recommendthat youpurchase both5-minute and30-
minute epoxyto cutdown onassembly time,but youcan
get by withonly 30-minute epoxy if time isnot important.
Youwill alsoneed asmall bottleof both"Thick" and"Thin"
instant CAadhesive.
Tools -Model assemblycan bemuch easierif theproper
tools are used. Therefore, we have included in our
checklist tothe left, a complete listing ofall thetools we
used to assemble our prototype models. As you will
notice, many household tools can be utilized during
construction.
Engine-TheThunder Tiger
PRO-91is the ideal engines
for this airplane.This quiet-
running engine is easy to
start, requires no special
break-in periods, easy to
maintain and will last for
years.
Most Pitts style mufflers
will fit this Sept. Fury .
However, we recommend
the use of Thunder Tiger
custom - made Sept. Fury
muffler with two exhaust
pipes that divert the smoke
in tothe two concavities of
the fuselage to obtain a
more scale- like apperance.
This muffler fits TT and OS.
60~.90engines.
Thunder Tiger has teamed up with the MichaelBrown Racing team to bring this legendary airplane to your hands;Thunder
Tigeris proudlyto presentthe onlyofficially licensed 1/7threplica of the "Sept.Fury"to all theR/C hobbyist alike worldwide!
It's areplica that has stayed true to the "Sept.Fury" in itspurest form,pre-painted fiberglassfuselage andcowl, scaledetails
like panel lineand retractwell withgear door, etc. With it,you can now experience thethrill of piloting oneof the best racing
planes in the history! Fly it low, flyit fast toexperience the ultimate thrilland pylonracing excitement of the"Sept.Fury".
2
Trial fiteach partbefore gluingit inplace. Makesure youare usingthe correctpart andthat itfits wellbefore assembling.
No amount of glue can make up for apoor-fitting part. Always apply Loctite ( not furnished) to all screwsand nuts to
prevent themfrom loosening.
Before beginningthe assemblyread theinstructions thoroughlyto givean understandingof thesequence ofsteps anda
general awareness ofthe recommended assemblyprocedures.
RECOMMENDED TOOLS & MATERIALS
Muffler (P/NTTR9791)

Wheel Axle (2)
Collar (2)
3x3mm Setscrew (2)
2.3x12mm
Washer Wood Screw (4)
Cowling (1)
Upper Retainer B (2)
Lower Retainer (2)
Aluminum Spinner (1)
Dowel (4)
3x16mm Sink Head Screw (8)
CA Hinge (6)
Adaptor (1)
Spinner Bolt (1)
Bushing (1)
Aluminum Spinner (1)
Back Plate (1)
Bushing (1)
FRP Wing Joiner Tube (1)
Left Wing (1) Right Wing (1)
3x20mm Wood Screw (2)
CA Hinge (14)
Back plate (1)
Adaptor (1)
Steering Horn (1)
Upper Retainer A(2)
2.6x5mm Wood Screw (2)
Tail Wheel Fork (1)
M2 Nut (2)
Threaded Pushrod (2)
2.3x12mm Washer Screw (16)
Pushrod End Retainer (1)
Clevis (2)
TorqueWire (1)
M2 Nut (2)
2x8mm Machine Screw (2)
Decal B (1)
Silver Decal (L/1,R/1)
Decal A (1)
Elevator Wood Pushrod (1)
Control Horn (L/2)
Blind Nut (4)
EZ Connector (1) M2 Nut (1)
1.5mm Hex Wrench (1) 3x3mm Setscrew (1)
T Washer (8)
6/32 x 20mm Socket Cap Screw (4)
Mounting Beams (2)
Rubber (8)
Flap Pushrod (2)
Throttle Pushrod (1)
Joiner Wire (2)
Clevis(4)
Retract Pushrod (2)
Control Horn (S/4)
Fuselage(1)
Doubler(28)
Rudder (1)
CA Hinge (3)
Rubber Band (2)
2x8mm Washer Wood Screw (24)
FRP Tail Cover (1)
Wheel (2)
FRP Cockpit (1)
Canopy (1)
2x5mm Wood Screw (4)
90-degree Nipple (1)
Silicone Tube (1)
5x40mm Socket Cap Screw (4)
Wire (3.6M/1)
M2 Nut (4)
4mm Hex Wrench (1)
Brass Tube (8)
Threaded End (4)
Clevis (4)
2x22mm Machine Screw (4)
2x15mm Machine Screw (4)
Joiner Tube (2)
Back Plate (4)
M2 Nut (2)
2x30mm Machine Screw (2)
Cap (1)
480cc Tank (1)
Crank Weight (1) Straight Nipple (1) Fuel Stopper (1)
Horizontal Tail (1)
VT Upper Trailing Edge (1)
VT Lower Trailing Edge (1)
Fiberglass Cloth (1)
3x3mm Setscrew (2)
Plywood Parts (A)
Plywood Parts (B)
Plywood Parts (C)
Spinner Bolt (1)
Retract ( L/1, R/1)
M2 Washer (1)
Wheel Spacer (1)
Wheel Door (L/1, R/1) Wheel Well (L/1, R/1)
Aileron Pushrod (2)
Aileron Servo Case (L/1, R/1)
Flap Servo Case ( L/1, R/1)
M2 Nut (4)
Z-Bend End (2)
4x20mm
Sink Head Screw (2)
TailWheel (1)
Ball End (2)
Ball (2)
Blind Nut(2)
3x5mm Setscrew (1)
2x5mm Wood Screw (4)
2.3X12mm Washer Wood Screw (4)
FRP Tube(1)
4x 20mm Socket Cap Screw (4)
2.6x26mm
Sink Head Screw (1)
AS6429 Fuselage
AS6428 PlywoodParts
AS6430 MainWing
AS6431 HorizontalTail No.3291 AluminumSpinner
(3-Blade) No. 3290Aluminum Spinner
(2-blade)
AS6425 Elevator Torque Wire No.3009 SuperliteRetract AS6433 Cowling
No. 3299Wheel AS6432 Canopy No.3265 FuelTank
AS6435 Pushrods AS6441 ControlHorn
PE0009 EZConnector No. 3012Anti-VibrationEngine Mount AS6434 Pull-Pull System
AS6438 ScaleTailGear AS6439 ElevatorLinkage Set AS6436 Decal
AS6437 RetractDecoration AS6440 HardwareSet
OPTINAL PARTS
PARTS DRAWINGS PARTS DRAWINGS
54
Coveling 200X80mm

PARTS CHECK LIST WING
1. Glue theCA hingesin aileron first.
2. Next attachthe aileron inplace then applyCA onboth
sides. Makesure aileronis firmlyglued.
3. Locate theaileron servowell then usea hobby knifeto
cut an"X".
4. Usinga sealingiron totack downthe coveringinside
the servowell. Trim theexcess covering away.
5. Locate the left wingservo case /hatch cover; secure
the aileronservo asshown.
6. Connect an extension wire for Aileron servo, heat-
shrink ortape theconnectors toprevent fromloosening.
7
6
Elevator WoodPush Rod (1)
Elevator Pushrod Retainer(1)
Thread Pushrod(2)
Control Horn (L/2)
Control Horn (S/4)
Backplate (S/4)
Canopy (1)
Wheel Door (L/1,R/1)
Wheel Well(L/1, R/1)
Upper RetainerA (2)
Upper Retainer B(2)
Lower Retainer (2)
Retract (L/1, R/1)
Wheel Axle (2)
Wheel (2)
Brass Tube(8)
Straight ThreadedEnd (4)
Z BendThreaded End (2)
Wire (2)
TailGear (1)
TailWheel Fork (1)
Wheel Spacer (1)
Steering Horn (1)
3x5mm Set Screw(1)
TailWheel (1)
Blind Nut (2)
2.6X26mm Sink HeadScrew (1)
Decal A(1)
Decal B (1)
Silver Decal (2)
Kit Contents:
FRP Fuselage(1)
FRP Cockpit(1)
FRP Tail Cover (1)
FRP Cowling(1)
FRP WingJoiner Tube(L/1)
FRP Tube(S/1)
Left Wing (1)
Right Wing (1)
Rudder (1)
Horizontal Tail (1)
Elevator (L/1, R/1)
Aileron Servo Case(L/1, R/1)
Flap Servo Case(L/1, R/1)
Plywood Parts(A)
Plywood Parts(B)
Plywood Parts(C)
VT LowerTrailing Edge(1)
VT UpperTrailing Edge(1)
Doubler(28)
Dowel (4)
Covering (1)
Fiber Cloth (1)
Joiner Wire (2)
Joiner Tube(2)
Rubber Band (2)
CA Hinge(23)
2x5mm WoodScrew(8)
2.6x 5mm Wood Screw (2)
2x8mm WasherWood Screw(24)
2.3x12mm WasherWood Screw(24)
3x20mm WoodScrew (2)
2x8mm Machine Screw(2)
2x15mm Machine Screw(4)
2x22mm Machine Screw(4)
2 x30mm MachineScrew (2)
3x16mm Sink HeadScrew (8)
4x20mm Sink HeadScrew (2)
3x3mm Setscrew (5)
EZ Connector(1)
M2Washer(1)
Torque Wire(1)
M2 Nut(15)
Clevis (10)
Collar (2)
Ball End(2)
Ball (2)
Al. Spinner(3-blade, 1)
Backplate (1)
Bushing (1)
Adaptor (1)
Spinner Bolt(1)
Engine MountingBeam (2)
T Washer (8)
Rubber (8)
Blind Nut(4)
Socket CapScrew 5mm x 40(4)
Hex Wrench4mm (1)
Socket CapScrew 6/32 x 20mm(4)
Socket CapScrew 4x20mm (4)
Tank(1)
Silicone Tube (1)
Straight Nipple(1)
90-degree Nipple(1)
Crank Weight(1)
Fuel Stopper(1)
Fuel Cap(1)
Throttle Pushrod(1)
Retract Pushrod(2)
Flap Pushrod(2)
Aileron Pushrod(2)
Hex Wrench1.5mm (1)

WING WING
7. UseThrottle Pushrod to guide the wirethrough the
wing panels.Fix thewire withmask tapeto preventfrom
falling backinto wingpannel.
8. Link aileron servoswires to CH1 onreceiver. Make
sure the direction iscorrect. Setthe servohorn inthe
neutral thensecure the servo horn screw nextsecure
the servocase inplace withfour 2.3x12mmwasher
wood screws.
9.Please notethat theaileron isthick; carefullydrill the
(5/64")2mm holes andmake sure theback plate isflush
with the hingeline at theother side of aileron. Secure
the control hornin place with 2x22 machine screws.
Trim awaythe excessscrew fromthe backplate. Install
the pushrod with metalclevis, M2nut andthread ona
piece ofsilicone tubeasshown.
10. If you would use Flap function then proceed the
following steps. If notthen skip tostep 24. Dothe same
procedure for Flap Servo Case. (Left FlapServo Case
shown) and thread thewire through thewing panel and
tape thewire endon wingroot.
11. Temporally secure the Flap Servo Casein place
with 2.3x12mm Washer WoodScrews.
12. Carefully cut away covering. The knife maylean
against the flap then carefully cutalong withthe flap
leading edge.
13. Next cut away the covering between Flap I and Flap II.
14. Carefullycut awaythe flapfrom trailingedge.
15. Ironthe coveringat thetrailing edge.
16. Locatethe joinerwire andguide tube.Make markat
the center ofthe joiner sideof the FlapI and FlapII.
17. Carefully drillingthe joiner side atmark. Note that it
is angle atthe joiner side please drillthe hole perpend-
icular to thesurface. Drill 2.5mm hole onFlap Iand 2mm
hole onFlap II.
18. Insert guide tube in Flap I and light apply CA glue.
Glue threaded end ofjoiner wirein FlapII, alsoapply a
drop ofCA glue.Cut twohinge slotsand glueCA hinges
in place.
98
Flap II
Flap I
Flap II
Flap I

WING
19. Securecontrol hornon FlapI with2x15mm machine
screw.Note thecontrol hornshould awayfrom theedge
at least8mm. The 8mm isto clearthe riblocated atthe
center of bothflaps.
20. Leave 0.5mm clearance between ribs and flapthen
draw the hinge line. Next cut hinge slots to accommodate
the hinges on flaps.
21.Join twoflaps theninsert themto the wing in place.
Make surethere isno contactwith eachother thenapply
CA atthe hinge area.Move the flap again andmake sure
it workssmoothly.
22. Repeatthe sameprocedure onthe rightwing. Link
two aileronservo wireswith Ycord and plug to CH1 on
receiver. Plug theleft flapto Ch6and rightflap toCh7.
Refer toyour radiomanual andset upFlap.
1.Reset first.
2.Flap ATV 140% 140%
3.AUX1 ATV 140% 140%
4.Airbrake on Flap100%
5.PMIX7 AUX1-AUX1
Position 1:0%
Position 2:0%
Position 3:0%
Position 4:45%
Position 5:90%
6.Trim thetwo flaps atsame throws byadjusting the trim
knob and pushrodif necessary.
23. Epoxythe dowelsat wingroot inplace asshown.
24. Locatethe plasticretract well;trim alongthe molded
line.
25. CA the retractwell inplace, trimthe excessplastic
so it islevel with thewing root.
26. Placethe retractin placeand drill5/64"(2mm) holes
on the retractmount.
27. Locatethe retract pushrod andball end,thread the
ball end as shown. TheZ-bent endto the center ofthe
ball end isabout 218mm.
28. Insert the pushrod from wingroot then connectto
retract. Note:The ballend with "Tiger" side shouldface
upside ofwing.
1110
LANDING GEAR
Here is theset up procedureif using FF9:

29. You mayneed to trim the wires of retract so the
wheel axle islever tothe wingroot. Secure theretract in
place withfour 3x15mm SinkHead Screws. Flats should
be ground on thelanding gear legsfor thesetscrew to
prevent the wheelaxle fromrotating under load.
1312
30.Locateand trimthe wheeldoor retainersas shown.
31. Trim theretract doorto fitthe retractwell.
32.Sand theupper retainer Band placeit inthe strutcoil
then apply CAon retainer. Nextplace thewheel doorin
place, theretainer will beglued onwheel doorprecisely.
33. Securethe retractdoor withthe retainers ( A,B )at
the strutcoil with2.6x5 mmwood screw.
34. Secure the lower retainer onwheel doorwith two
2x5mm wood screws.
35.Install the wheel and secure collar with 3x3mm set screw.
Make sure wheel rotates freely.
36. Locatethe twoside framesand rearbulkhead. Trail
fit in thefuselage. Make sure the side frameinsert to
the front bulkhead properly. Make mark on fuselage.
Remove all wood parts then use 200 grit sandpaperto
sand where you marked. Epoxy therear bulkheadin
place.
37.Locate servotrays andservo traydoubler thenglue
the doubler in place. There are two fueltank frames.
Make surethe shorterslot isin thefront andlonger slot
is inthe rear.
38. Theside frame iseither marked Lor R.Make sureL
is atleft side and Ris atright side. Always trial fitall
wood partsbefore youglue it. Suggest to glue the one
side frame inplace first, nextthe other sideframe with
servo tray at the same time. Fuel tank retainer and
retract servo mountstrips at thelast.
LANDING GEAR FUSELAGE
39. Gluethe shortguide tubein fuselage.
40. Trail fitthe two wing halvesand join them withthe
fiberglass tube.Never pushtoo hardas itmay damage
the tube-stop rib inside the wingpanel. Trim holesor
dowels mightbe necessaryto geta goodfit .

TAIL
15
14
43.Epoxy the firewall in place.You mayinsert the firewall
to Lsideframe then push in theother side. Make sure the
firewall with right thrust angleas shown.
44.Assemble theAnti-Vibration EngineMount.
45.Install theAnti-Vibration EngineMount in placewith
5x40mm Socket Cap Screw and Blind Nut. You just
screw in thecap screw thenthe blind nutwill punch into
the firewall.
46. Trial fitthe batterybox, thenepoxy thebattery box
and bottom reinforced plyin place.When cured,lightly
apply epoxy onall firewalls areaas well asthe battery
box so the plywood could be fuel-proof. Justmix the
epoxy with nomore that 50% mix of alcoholthen brush
on firewall.
47.Remove thebalsa insert from thevertical fin.Then
use flat fileto file thein side ofthe tail toget a smooth
surface.
48.Trialfit horizontal tailin fuselage, centerit thenmake
marks ontail atfour sides.
49.Carefully usehobby knifeto cutlines insidethe lines
about 1~2mm. Remove coveringas shown. Never cut
too deepto hurtthe balsaplanking.
50.Cut awaythe coveringof leadingedge atthe rootof
elevator where the torquerod isgoing tobe installed.
CA three hingesin elevatorat thistime.
51.Trail fitthe elevatoron tailwith torquerod installed.
Do not glue atthis step. When satisfied, remove the
elevator andtorque rod.
TAIL
TAIL
41. Locate the hole that is located at thebottom wing
between retract the flap servohatch. Drill a5/64" (2mm)
hole through the fiberglass tube ofthe main winghalves,
and make surethey are firmly close tothe fuselage then
secure 3x20mm wood screws. Main wing is removable
for convenient in transportation. For best performance,
epoxy two wing halves isstrongly recommended.
42.Sandwich the three firewalls together; note thecross
laser cutmark should beon thetop andsmallest one at
the bottom.

RUDDER
17
16
TAIL
54.Locate the fiber cloththen cut intotwo pieces atabout
100 x80mm (4 " x 3").
55. Apply 30 min epoxy at the gluearea andcarefully cote
the fiber cloth.
56.Lubricant oil to the hinges ofelevator torque rod. You
may sprayWD-40 onthe hobbyknife thenuse the knife
tip tocontact the torqueshaft andthe oilwill go into the
hinge. Epoxy theelevator joiner inplace.
57.Locate the elevator pushrod parts asshown, epoxy
the plywood inside thewood rod at twoends with wires.
Thread the M2 nuts and clevises and make surethe
whole elevator pushrod has no free play. Note the
orientation of the pushrod andclevis.
58. Apply a small tube ontothe clevis then connectthe
elevator pushrod to the elevator torque rod. Aflat head
screwdriver will help snapping the clevises onto the
torque rod link. Trim the elevator center notch for enough
throws (down) as page 24shown.
59.Install elevator servo, note the servo horn orientation.
Then adjust the clevises to make sure elevators are level
when servo is in neutralposition. Whensatisfied, remove
the elevator pushrod temporarily andsecure M2 nuts and
clevises firmly.
60.Trail fit the Vertical FinBracket inthe Vertical Fin, you
may need to sand to fit in place. When satisfied, use
furnished covering and iron on the covering as shown.
61. GlueVerticalFin Bracketin placeand makesure the
upper one and lower one are in line. Applyepoxy at
torque rodhole nextinstall theelevator inplace. CAall
hinges andmake sureelevator isfirmly secured.
62.CA the Rudder on Vertical Fin with three CAhinges.
Next install the control horns on the rudder with two
2x30mm machine screws and M2 nuts.
63.Locate the straightthreaded end,brass tube,M2 nuts,
clevises and wire. Cut wirein length90mm. First thread
the M2 nut and clevis then secure the M2 nut on clevis.
Then route the wire through the tube and makeit acircle.
RUDDER
52.Sand the tail saddle toincrease the roughness as well
as inside of the flange as the fiber cloth will beapplied
later.
53. Insert andcenter thetail in place. Use books or boxes
to support tailends makesure it islevel to the main wing.
You may needto file the flange to get a good fit. Use
furnished rubber bands to reduce the gapand fix the tail
in place. Apply thick CAor epoxy whensatisfied.

19
18
66.Adjust thewire to make the circle as small aspossible
then use the pliers to crimp thewire firmly.
67. Drill the pull-pull wire exithole and threadthe wire
into fuselage to the rudder servo.Do the sameway to
servo end and use Z bend end rod. Do not crimp the
brass tubeat this moment until tail gear pull pull wires
are ready.
TAIL GEAR
68.Locate thetail gearmount, doublersthen gluethem
together then press theBlind Nutin thehole. Itwill be
easier touse hammeror mice.
69. Securethe tailgear mountright inthe frontwith four
2x8mm washer woodscrews.
70. Locatethe tailgear bag,and assemblethe tailgear
as shown. Note theorientation ofsteering arm,trim the
outer hole away as it is too long to installin thetail.
Secure steeringarm inplace with3x5mm setscrew.
71. Securethe tailgear assemblyon thetail gearmount
with 4x20mm sinkmachine screws.
72. Do the same procedure of the pull-pull wire on tail
gear.
73.Adjust the threaded end at theservo end to getbetter
tension of the four wires and make sure both rudder and
tail gear arein linewith each other.Crimp the tubes when
satisfied.
74. Locate the bottom tail cover, make the opening
according tothe tailgear.
75. Trim thetail coverand fitin place. Drill eight1.5mm
holes then glue doublers at the holearea. Itmight be
needed tosand thedoubler toadapt tothe curvesurface.
Drill theholes againon doublersthen securethe bottom
tail coverwith 2x8mmwasher woodscrews.
TAIL GEARTAIL GEAR
64. Next thread the wire through the clevislinkage then
tread to the tubeagain.
65.Make theother circleas shown.

21
20
FUEL TANK
78.Install the Sept. Fury Exclusive Muffler(TTR9791),
which contains 2 angled exhaust pipes and aim to the
concavity of the fuselage for true scale looking.
79.Install Ttube fittingand fueltube plugas shown,this
will help you toknow fuel is fullwhen pumping.
80. Install the EZconnector on thethrottle servo horn
with M2 washer and M2 nut. Afterwards, thread the
throttle pushrodthrough theEZ connectand securethe
servo hornon theservo. Adjust theservo withthe radio
on, oncesatisfied withthe result,proceed tosecure the
throttle pushrodwith a3x3mm setscrew.
81. Locate the retractservo tray, glue the doubler as
shown. Then,install theretract servoon theservo tray.
82. Secure the whole assembly in place with four 2.3x12mm
washer wood screws. Next secure two Steel Balls on the
servo horn with 2x8mm machine screw and M2nuts. The
distance between two balls is 24mm. Fine adjust the retract
pushrod, and make sure the ball link with "Tiger" is facing
up. Switch on the retract gear tomake surethe retract gear
works smoothly.
83. Placea battery in the batterycase; use doubleside
tape to secure it in the fro ntof battery case.You can use
the excess servo tray plywood to make a block tohold
battery in place. It requiresan extensionwire to connect
to theswitch harness. Approximately 300-350g ofweight
will be added inthe front of thebattery case.See balance
section in page24 and add proper weightsto get right CG.
84. Secure battery boxcover withfour 2x8mmwasher
wood screws.
85. Connect all servo wires tothe receiver; wrapthe
receiver with foamto fully protectthe receiver.Insert
receiver between frameand fiberglass wallin fuselage.
86.Route theantenna alongthe fuselageand exitat the
tail gearopening. Tape thewire inplace asshown.
Locate thefuel tankand itsaccessories. Assemble the
tank asshown. Installthe fueltank inplace, connectthe
fuel lines andexit from thefirewall for enoughlength to
carb andmuffler.
RADIO
ENGINE
76.Place theEngine (ThunderTigerPRO-91 Shown)in
the Engine Mount then proceed to make mounthole
marks onthe enginemount wheredrive washeris 53/4"
(147mm) to the firewall.
77. Remove the engine and engine mount. Drill the 3.4mm
holes based on those marks then tap the hole with M4x0.7
thread tap. Connect throttle pushrod then secure the engine
with M4x20mm socket cap screws. Make a Z bent on throttle
pushrod as indicated.

23
22
COWLING
88. Drill needle valve extension wire exit hole. When
satisfied, secure the cowling in place with 2.3x12mm
Washer Wood Screws.Suggest toinstall PrecisionFueler
(TTR1115) for easy fueling.
89. Installthe propellerand furnishedspinner. What we
used hereis MasterAirscrew13x8.
90. Suggest to file the cowl located nearthe ventof
carburetor asshown, theengine will getenough airand
run smootherif youinstall a2 strokeengine.
91. Applyinstrument panelin the cockpit. Nexttrim the
canopy and trial fit the canopyon the cockpit. Glue the
plywood doublers and drill four 1/16" ( 1.5mm ) holes.
Secure the canopy with four 2x5mm washer wood screws.
Pilot shownis not included.
94.Trial fitthe upperCockpit on fuselage, drilleight 1/16"
(1.5mm) holes and glue small plywood doublers inside
the fuselageat the holes area. Drill the doublers again
and secure the cockpit in place with 2x8mm washer wood
screws.
92.Refer to thebox label thenapply all decals.Suggest
to jointhe firedecals togetherbefore applyingon
fuselage.
93.The photosshown isthe decalat retractgear door.
YourSept. Fury is nowready tofly, carefully setup the
control throws andbalance your planewell before each
and every flight; never take chances or rush fly your
Sept. Fury.
87. Install the engine cowling; first gluethe plywood
doublers inside thefuselage atwhere holeis . Trialfit
the cowlingin placeand temporarily secureit withmask
tape. Drill1/16"(1.5mm) at theplace where doublers
are.
95.You mayneed toremove thecowling and applysilver
decal asshown.
DECAL
