Thunder tiger Agusta a109 User manual

JK6020 V.2

This kitis guaranteedto befree fromdefects inmaterial andworkmanship atthe dateof purchase.

It does not cover any damage caused by use or modification. The warranty does not extend

beyond theproduct itselfand islimited onlyto theoriginal costof thekit. Bythe actof buildingthis

user-assembled kit, the user accepts all resulting in liability for damage caused by the final

product. If the buyer is not prepared to accept this liability, it can be returned new and unused to

the placeof purchasefor arefund.

Warranty

Notice: Adult SupervisionRequired

This isnot atoy. Assemblyand flyingof thisproduct requiresadult supervision.

Read through this bookcompletely and become familiarwith the assembly and flight of this A109.

Inspect all parts for completeness and damage. Browse www.thundertiger.com for customer

service ifyou encounterany problems.

No.3842

No.3842-W

MEMO

Assembly Manual

Specifications:

Fuselage Length (lessrotor): 65.4"(1660mm)

Fuselage Width (lessrotor): 14.2"(360mm)

Fuselage Height: 13.4"(340mm)

Full-Equipped Weight:14.2 lbs(6450g)

Before beginning the assembly read the instructions thoroughly to give an understanding of the sequence of steps and a

general awareness ofthe recommended assemblyprocedures.

By following these instructions carefully and referring to the corresponding pictures, the assembly of your model will be

both enjoyable and rewarding. The result will be a well built, easy to assemble scale model, which you will be proud to

display.

This A109 is designed for intermediate to advanced pilots, and this manual assumes a basic knowledge of R/C model

construction.

PRE-ASSEMBLY NOTES

1. Beforeyou startto assemblethis fuselageon yourhelicopter,we suggestyou tofirst finetune yourhelicopter inthe air.

2. Double-check allscrews, then secureand Loctite allthe loose screws.

3. Theinstruction manualis writtenfor Raptor 90, if user shouldchoose to install it on otherbranded helicopters,we would

suggest youto studythe manualthoroughly andsee howit installedon aRaptor 90.

Before you begin, check the entire contents of your kit against the parts list and photos to make sure that no parts are

missing ordamaged. Thiswill alsohelp you to becomefamiliar with each componentof your model. If you find that anyof

the parts areeither missing ordamaged, please contactyour localThunder Tigerauthorized distributors forreplacements.

Neither yourdealer norThunder Tiger authorizeddistributor canaccept kitsfor returnif constructionhas begun.

Trial fiteach partbefore gluingit inplace. Makesure youare usingthe correctpart andthat itfits wellbefore assembling.

BEFORE YOUR ASSEMBLY

Adhesives:

Instant setting Cyanoacrylateadhesive (thin CA)

Slow setting Cyanoacrylateadhesive (thick CA)

10 MinuteEpoxy (fast)20~30Minute Epoxy(slow)

RECOMMENDED TOOLS& MATERIALS

Tools:

Model Knife, 1/2" MASKTape, Small& MediumScrew-

drivers, Scissors, Longnose Pliers, Drill andDrill Bits

(1/8", 5/64"), 150 Grid Sand Paper, Rat Tail andhalf-

round file,Fine FeltTipPen &Soft LeadPencil, Reamer,

Hex Wrenches.

R/C System:

6 Channel Heliradio req'd

GYRO systemreq'd

Helicopter:

Raptor 90SE kitSuggested

Youwill need twotypes of adhesivesfor theA109 Epoxy

and Instant (cyanoacrylate) adhesives. We recommend

that you purchaseboth 5-minute and30-minute epoxy to

cut down on assembly time, but you can get by with only

30-minute epoxy if time is not important. You will also

need a small bottle of both "Thick" and "Thin" instant CA

adhesive.

Model assembly can be much easier if the proper tools

are used. Therefore, we haveincluded in ourchecklist

to the left,a complete listingof all thetools we usedto

assemble our prototype models. As you will notice,

many household tools can be utilized during

construction.

ITEMS YOUMAY NEED

TABLEOF CONTENTS

Introduction....................................................................................................................................................2

Recommended Tools & Materials......................................................................................................................3

Item You May Need..........................................................................................................................................3

Parts Drawings.............................................................................................................................................4-5

Parts Check List..............................................................................................................................................6

Assembly...................................................................................................................................................7-15

MEMO..........................................................................................................................................................16

TTR4891 - Raptor90 SEKIT

TTR1111- 3-wayFuel Filter

Congratulations onthe purchase of ourfinest scale heli fuselage to date. This famous A109 fits ThunderTiger Raptor 90,

the light fuselage comes factory pre-painted with all necessary hardware. It is very easy to assemble and only takes you

few hours of enjoyable installation to put this scale body on your helicopter. This replica A109 is just like a real thing,

hovering this109 thatwill definitelymake youstand outon theflying field.

TTR1112 -AL.Fuel Filter Ignition Extension.

INTRODUCTION

PRE-ASSEMBLY NOTES
