THUNDER TIGER mini Titan V2 Series User manual

INSTRUCTION MANUAL
組裝說明書
INSTRUCTION MANUAL
組裝說明書
This radio control model is not a toy! Before beginning assembly, please read
this manual thoroughly.
本產品為高性能模型非一般玩具，組裝與操作前請詳閱本產品說明書。
The contents are subject to change without prior notice due to product
improvements and specificatrion changes.
本套件所附之零件可能跟圖示有所差異。因產品後續之設計研發或功能不斷改善之原
因，我們將保留產品規格變更權力，不再另行通知使用者。
No.4712 / 4713
All manuals and user guides at all-guides.com
all-guides.com

-1-
INTRODUCTION
INTRO & CAUTION / 簡介與注意事項
OTHER ITEMS REQUIRED / 其餘必須配件
MANUAL FORMAT / 說明書使用方式
ASSEMBLY / 組裝步驟
MAIN ROTOR / 主旋翼機構組裝
LINKAGE ROD INSTALLATION / 連桿組裝
MAIN FRAME ASSEMBLY / 本體組裝
MAIN GEAR SET / 主齒輪組裝
TAIL BOOM / 尾管組裝
TAIL ROTOR SYSTEM / 尾旋翼機構組裝
TAIL UNIT-TORQUE-TUBE / 尾部總成組裝-軸傳版
TAIL UNIT-BELT-DRIVEN / 尾部總成組裝-皮帶版
TAIL SUPPORT / 尾管支撐架組裝
MOTOR MOUNT / 馬達安裝
SERVO INSTALLATION / 伺服機裝配
ELECTRIC DEVICE / 電子設備安裝
SET-UP SECTION / 設定程序說明
CANOPY & MAIN BLADE / 機殼罩及主旋翼
RADIO SYSTEM SETUP / 遙控系統設定
SWASHPLATE TYPE SETTING / 十字盤模式設定
ELECTRIC DEVICE CONNECTION / 電子設備連接說明
SWASHPLATE & SERVO MOVEMENT SETTING / 十字盤及伺服機動作設定
COLLECTIVE PITCH SETTING / 主旋翼螺距設定
TAIL CONTROL AND GYRO SETUP / 尾舵控制及陀螺儀設定
SETTING UP DATA FOR YOUR REFERENCE / 設定參考值
BLADE TRACKING ADJUSTMENT / 主旋翼軌跡調整
SETTING UP OF LINKAGE / 連桿設定
AFTER FLIGHT CHECKLIST / 飛行後的檢查項目
USING OF LI-PO BATTERY / 鋰聚電池使用注意事項
HELI ACCESSORIES / 選購配件
SPARE PARTS / 零件包
EXCLUSIVE SPARE PARTS : BELT-DRIVEN / 皮帶版專用零件包
EXCLUSIVE SPARE PARTS : TORQUE-TUBE / 軸傳版專用零件包
SPARE PARTS LIST / 零件包表格
EXCLUSIVE SPARE PARTS LIST : BELT-DRIVEN / 皮帶版專用零件包表格
EXCLUSIVE SPARE PARTS LIST : TORQUE-TUBE / 軸傳版專用零件包表格
OPTION PARTS / 選配零件
POWER & ELECTRONICS / 動力及電子配件
ACCESSORY / 其他相關產品
EXPLODED VIEW / 爆炸圖檢索
2
4
5
6
10
11
13
14
15
17
18
19
20
21
22
23
24
24
24
25
25
26
27
28
29
29
29
30
36
38
39
40
43
44
45
45
46
47
CONTENTS
All manuals and user guides at all-guides.com

-2-
INTRODUCTION / 簡介
Thank you for purchasing the Thunder Tiger mini Titan E325 V2 series electric R/C helicopter. This new
helicopter is the latest innovation by Thunder Tiger. It has the perfect combination of flying stability and the
agility for 3D flying. This helicopter is an excellent choice for flying enthusiasts like you. For convenient
assembly and safe operation of the helicopter, please read the instructions carefully. Retain the user
manual in case you need it for any information or reference.
感謝您購買雷虎科技小型電動直昇機 mini Titan E325 V2 系列產品，本項產品為雷虎科技全新開發機種，兼具高度穩
定性與3D飛行特性，是熱衷小型電動直昇機的您不可錯過的選擇。請於使用本產品前詳盡閱讀使用手冊，以利於組裝
工作順暢進行與安全操控本產品。請妥善保存使用說明書，以利後續調整與維修參考用途。
CAUTION / 警告
1. R/C models are not toys. This product is a high-precision flying machine. Possibilities of unexpected
crashes may occur due to electronic interference, incorrect operation, or poor mechanical maintenance.
Although it is a small-sized helicopter, the rotor blades rotate at high speeds, which may cause serious
damage, injury, or death if the model hits people or property. Therefore, extreme caution must be
exercised during operation.
2. Thunder Tiger ensures parts packaged in this product is of the highest quality. However, after assembly
and usage, parts damaged due to wear or misuse will not be replaced under any circumstances. If you
have any questions regarding its operation and repair, Thunder Tigers service agents are able to
provide free technical guidance.
3. This product is only recommended for users ages 16 and up. Because flying a R/C helicopter is difficult,
beginners must receive guidance and supervision from experienced pilots to minimize unexpected danger.
Practice in spacious areas, far away from obstacles such as buildings, trees, electrical towers, or crowds.
4. To decrease the cost of repair and maintenance for beginners, it is recommended to fly the helicopter
with a practice rack and to learn basic flying skills with a computer R/C flying simulator. (Crashes in
simulators are free to repair!)
1. 本項遙控直昇機產品並不是玩具，是一項結構精密、高專業度模型產品，如果未經正確組裝與操控，將可能對操控
者或其他人造成身體傷害。使用者必須了解，若未確實進行飛行前安全檢查或操控不當，而造成人員受傷或物體損
壞，使用者必須負起法律責任。
2. 本產品由高品質零組件組成，雷虎科技對於安裝過程、使用過後..等人為因素造成損壞事件不負損壞賠償之責。如您
需要本產品相關組裝、調整或其他協助，可與雷虎科技全省經銷商聯繫。
3. 本項產品禁止十六歲以下青少年與孩童使用。強烈建議初學者應取得技術支援後再進行飛行，以避免危險發生。請
於空曠地區操控本產品，並避免於建築物、樹木、電塔..等障礙物區域飛行。
4. 建議初學者可安裝練習架或透過電腦模擬軟體練習，可達到實際練習效果與符合經濟效益。
AMA INFORMATION / 特別注意事項
Operating a model helicopter requires a high degree of responsibility and skill. If you are a newcomer to the
hobby, it is best to seek help and guidance from accomplished model helicopter pilots. This will greatly
speed up the learning process and have you flying successfully in a reasonable amount of time. We also
would strongly urge you to join the Academy of Model Aeronautics. The AMA is a non-profit organization
that provides its members with a liability insurance plan as well as monthly magazine entitled Model Aviation.
All AMA charter aircraft clubs require all pilots to hold a current AMA sporting license prior to operation of
their models at club fields. For further information, contact the AMA at:
Academy of Model Aeronautics
5151 East Memorial Drive
Muncie, IN 47302
[phone]
操控遙控直昇機對於飛行安全要求極高，需要高度的負責任態度配合，以及較高的操控技巧。如果您是一位初學者，
建議您必須向當地專業模型經銷商，或是遙控直昇機相關組織以及經驗豐富的玩家尋求相關協助，以獲得您所需要的
訊息以及專業知識。如此可有效協助您縮短學習的時間，更容易學會遙控直昇機的組裝、設定與操控技巧。
All manuals and user guides at all-guides.com

-3-
FLIGHT SAFETY CHECKLIST / 飛行前安全確認工作項目
POST FLIGHT INSPECTION / 飛行結束安全檢查事項
CAUTION / 注意事項
1. Make sure that the transmitter battery is fully charged before flying.
2. Make sure all control surfaces are operated properly before flying.
3. Do a range check of the radio before the first flight. The electronic equipment must operate properly
at a range of at least 5 meters (18 ft) even with the transmitter antenna collapsed.
4. Make sure there are no other pilots using the same radio frequency with yours and that there are no
other radio interference on your frequency.
5. Be sure to turn on the transmitter first with the throttle stick in the idle position. Plug the battery into the
ESC last.
6. The main rotor and the tail rotor spin at very high RPM. Make sure nothing can come in contact with
the rotor blades during flight.
7. Always maintain a safe distance from the helicopter during flight.
8. Never fly the helicopter in the rain or in excessive wind conditions.
9. Always operate and fly the helicopter in a safe and responsible manner.
10. Never fly the helicopter over other pilots, spectators, cars or anything that could result in injury or
property damage.
1. 確認接收機與發射機電池，均已確實充電完成。
2. 確認所有操控介面運作順暢。
3. 確認無其他無線電波干擾，且不與其他同好同時使用相同頻率。
4. 確實將油門搖桿放置於低速，再將發射機電源開啟，然後再將電池接上。
5. 確認遙控器發射器與接收機工作正常，將機體放至於距離5公尺外，確認遙控器是否正常，機體控制動作是否正確。
6. 主旋翼與尾旋翼轉速相當高，運轉時須避免任何障礙物與旋翼接觸。
7. 飛行時，需與遙控直升機保持安全距離。
8. 勿於下雨天或是強風的狀態下操控遙控直升機。
9. 請以安全為第一考量，並以高度負責任的態度參與遙控直升機活動。
10. 禁止於人群、車輛..或任何其他障礙物上方飛行遙控直升機，避免意外發生。
1. Inspect the model thoroughly to insure no parts have come loose or become damaged during the flight
and landing. Replace damaged parts and tighten loose screws before flying again.
2. Clean the helicopter body.
3. Lubricate all moving parts to ensure smooth operation for the next flying.
4. Replace any worn ball links and damaged bearings.
5. Store the model in a cool, dry place. Avoid putting it under direct sunlight or near a source of heat.
Following these simple rules will allow you to enjoy the thrill of model helicopter flying for many years.
1. 飛行結束後確認機體所有的零件與螺絲是否有損壞或鬆動，更換損壞零件與確實固定鬆動的螺絲。
2. 機體清潔乾淨。
3. 檢查所有活動零組件是否運作順暢，以利下次飛行。
4. 更換所有鬆動的連桿、接頭，以及損壞的軸承。
5. 將機體存放於陰涼通風處，避免機體放置於陽光直射處或接近熱源。
確實執行上述幾項簡單的步驟，將可確保您的愛機維持數年的壽命！
When the model has crashed, inspect the flybar, rotor shaft and the blade spindle to make sure they are
not bent. If any item is damaged, it must be replaced with a new part to ensure safe operation. Do not
glue any broken or damaged plastic parts. Do not repair broken rotor blades. It is very important to
inspect the motor, speed control and the battery.
Always inspect the following items:
Gears, Ball links, Link rods, Bearings, Main shaft, Flybar, Spindle, Tail boom and support, Fins, Tail rotor
shaft, Belt, Main blades, Tail blades, the Motor, the Speed control and the Battery.
機體一但發生墜落事件，請確實檢查平衡桿、主軸、橫軸是否有彎曲變形，如果有任何的損壞，請立即更換原廠新
的零組件，確認機體操作安全！切勿使用任何接著劑嘗試黏合塑膠零件；請勿使用修復過的主旋翼。馬達、速控器
、電池的安全檢查工作亦相當重要。
發生機體墜落事件後，請確實檢查下列項目：
齒輪組、球頭連桿、連桿頭、軸承、主軸、橫軸、尾軸、平衡桿、平衡片、尾管、尾管支撐架、垂直與水平尾翼、
尾驅動輪、皮帶、主旋翼、尾旋翼、馬達、速控器、電池。
All manuals and user guides at all-guides.com

-4-
OTHER ITEMS REQUIRED / 另購裝備
RADIO SET
Transmitter
(helicopter type only,
6 or more channels)
POWER SYSTEM
Li-Po Battery Speed Controller Brushless Motor Battery Charger
TOOLS REQUIRED FOR ASSEMBLY
Screw Driver Needle Nose Pliers Ball Link Pliers Nipper Scissors
Hobby Knife CA Glue Threadlocking Grease Hex Wrench
Epoxy Rubber Band Two-Sided Rubber
發射機（6動以上直昇機用）
遙控器組
電子類裝備
組裝工作所需工具
鋰聚合物電池
螺絲起子
模型專用美工刀 六角板手
環氧樹指
（A、B膠）
橡皮筋 雙面膠
快乾膠 螺絲防鬆膠 潤滑油
尖嘴鉗 連桿專用鉗 斜口鉗 剪刀
速控器 無刷馬達 充電器
Receiver
接收機
Micro Servos
(Control Surface x3,
Rudder Servo x1)
伺服機 x3、尾舵伺服機 x1
Gyro
陀螺儀
All manuals and user guides at all-guides.com

-17-
TAIL UNIT-TORQUE-TUBE / 尾部總成組裝-軸傳版
Bag N
HNX2-10B
SOCKET BUTTON HEAD SELF TAPPING SCREW, M2×10
半圓頭內六角自攻螺絲 M2×10
HSA2-6
BUTTON HEAD SOCKET SCREW, M2X6
半圓頭內六角螺絲 M2X6
Ensure the leading edge of the blades rotate this way as drawing.
(Turn the Main Gear clockwise, both the main rotor head and tail rotor head turn clockwise)
請注意旋翼轉動方向應與圖示相同。
(順時針方向撥動主齒盤時，主旋翼頭及尾旋翼皆朝順時針轉動。)
(12)
(4)
(3)
(1)
(1) (2)
(2)
(12)
Step 1 / 步驟一
Insert the Bracket Spacers into the Tail Boom Bracket, and then secure into the main frames.
將固定座支柱穿入尾管固定座中後，鎖固於側板上。
Step 2 / 步驟二
1. Insert the tail boom through the bracket and push to the end.
Check the mess of the front bevel gear set by rotating the
main gear set, both main & tail rotor head rotates effortlessly
if the mess is proper. Please pull the tail boom a little bit
backward if the rotation is not smooth.
2. Tighten the 4 lower Tapping Screws to fix the tail boom on
the bracket.
TORQUE-TUBE
T22
1. 將尾管插入固定座中並推至底。撥動主齒盤組確認前傘齒
組齒隙，如齒隙正確則主旋翼及尾旋翼均會順暢轉動。如
轉動不順暢，請將尾管稍向後拉，以獲得正確齒隙。
2. 鎖緊下方兩側4顆螺絲，將尾管迫緊於固定座上。
HMJ12-6B
TAPPING SCREW M1.2×6
圓頭十字自攻螺絲 M1.2×6
HNN2-10B
TAPPING SCREW(W/WASHER) M2×10
圓頭墊圈自攻螺絲 M2×10
No.
1
2
3
4
5
6
Qty
2
2
2
2
8
1
Material No.
BK1082
HMJ12-6B
BK0923
HNN2-10B
HNX2-10B
HMV1060ZZY
Description
ROD GUIDE
TAPPING SCREW M1.2×6
TAIL SERVO TRAY
TAPPING SCREW(W/WASHER) M2×10
SOCKET BUTTON HGAD SELF TAPPING SCREW, M2x6
BERING, d6xD10xW3
名稱
固定環
圓頭十字自攻螺絲 M1.2×6
尾伺服機座
圓頭墊圈自攻螺絲 M2×10
半圓內六角頭自攻螺絲, M2x6
滾珠軸承, d6xD10xW3
No.
7
8
9
10
11
12
Qty
1
1
1
2
1
4
Material No.
BK1897-1
HMV1370ZZY
BK1567
BK1886
BK2610
HSA2-6
Description
FRONT BEVEL GEAR MOUNT
BEARING d7XD13xW4
FRONT BEVEL GEAR 11T
BRACKET SPACER
TAIL BOOM BRACKET
BUTTON HEAD SOCKET SCREW, M2x6
名稱
前傘齒輪座
珠軸承, d7xD13xW4
傘齒輪 11T
固定座支柱
尾管固定座
半圓頭內六角螺絲 M2x6
(9)
(8)
(11)
(10)
(6)
(5)
(5)
(7)
Ensure smooth, non-binding movement when assembling
確認組件靈活度
Apply threadlocker
使用螺絲防鬆膠
How to read the instruction manual?
說明書導讀
A: Indicates the assembly step number and the parts bags
that are to be assembled.
B: Displays actual size drawings, and part quantities used.
C: All parts, except screws, are identified by its order
numbers. When purchasing spare parts, identify the part
required and cross reference this to the spare parts list in
the end of this maunal, which shows the purchasable
spare parts and the corresponding order numbers.
D: This instruction manual uses several symbols. Pay careful
attention to them during construction. Details are given
at the bottom of each page.
E: If a label marked here indicates the page is the exclusive
assembly steps for a particular model type; please follow
the exclusive instructions according to the model type you
purchased.
A: 顯示組立步驟及需組立之零件包順序。
B: 零件實際對照尺寸及使用數量。
C: 請比對零件形狀以及後附零件料號對照圖示找出需求零件料號。
D: 操作說明符號可更有效協助組裝者使用此說明書，請依說明書符
號指示進行組裝步驟。
E: 出現此標籤表示本頁為特定模型版本之專屬組裝說明，請依您所
購買之版本依說明進行組裝步驟。
Example 說明範例
CBA
B
E
D
C
T22（#262） THREADLOCKER / 螺絲防鬆膠
CA CA GLUE / 快乾膠
Note / 注意
Assembly drawings will contain icons that indicate use of
Threadlocker or CA glue as needed.
Examples of the icons are as right shown:
請依組裝步驟圖示，使用防鬆膠或接著劑。
圖示範例如右：
-5-
Apply CA Glue
使用快乾膠黏合
Assemble as many times as specified
依指示組裝所需數量
Assemble left and right side the same way
左右側組件相同
Assemble in right order
依標示順序組裝
Drill holes with the specified diameter
依標示尺寸鑽孔
Hint
組裝提示
Must be purchased separately
改裝品需另購
Cut off shaded portion
依標示部分裁切
Ensure smooth, non-binding movement when assembling
確認組件靈活度
Pay close attention here
注意組裝步驟
Cut off excess
裁剪多餘部分
Apply grease
使用潤滑油膏(黃油)
Apply threadlocker
使用螺絲防鬆膠
The parts in the kit are packed according to each major assembly steps. The part number and quantity are always shown
in the square box on each page. As good practice, only open up the bag that you need for the paticular assembly.
零件均依照組裝步驟包裝，請依照組裝程序，逐一開啟零件包，避免零件遺失。
Note / 注意
MANUAL FORMAT / 說明書使用方式
SYMBOLS USED THROUGHOUT THE MANUAL / 符號說明
All manuals and user guides at all-guides.com
all-guides.com

-6-
MAIN ROTOR / 主旋翼機構組裝
Bag A
No.
2
3
4
5
Qty
1
1
1
2
2
2
Material No.
BV2615
BV1408
BV1403
BK1456
HNU2-6Z
BV1404
Description
MATEL MAIN ROTOR HUB SET
MATEL MAIN ROTOR HUB SET
METAL SEESAW HUB
COLLAR, d2×D3×2.7t
SHOULDER SCREW M2x6
METAL MIXING LEVER
HNU2-6Z
SHOULDER SCREW M2x6
圓頭十字軸套螺絲M2×6
BK1456
COLLAR, d2×D3×2.7t
軸環, d2×D3×2.7t
名稱
金屬主旋翼固定座組
金屬主旋翼固定座組
金屬穩定桿固定座組
軸環, d2×D3×2.7t
圓頭十字軸套螺絲M2×6
金屬控制搖臂組
No.
6
7
8
9
10
Qty
2
4
4
2
2
Material No.
BK1480
BK1203
HSP16-6N
BK1481
HNU2-9Z
Description
COLLAR, d2×D3×5.6t
LINKAGE BALL(ø3.8)
COUNTERSUNK SCREW M1.6×6
FLAT WASHER d2xD3.7x0.5t
SHOULDER SCREW M2x9
名稱
軸環
, d2×D3×5.6t
連接頭 (ø3.8)
圓頭十字螺絲 M1.6×6
墊片 d2xD3.7x0.5t
圓頭十字軸套螺絲 M2×9
Note the orientation of the Chamfer
on the Metal Seesaw Hub.
注意金屬穩定固定座倒角方向。
(1*)
(2)
chamfer
倒角
chamfer
倒角
*available depending on the kit you purchased.
使用零件因購買套件有所不同。
1*
HSP16-6N
Countersunk Screw M1.6×6
圓頭十字螺絲 M1.6×6
BK1203
Linkage Ball(ø3.8)
連接頭 (ø3.8)
HNU2-9Z
SHOULDER SCREW M2x9
圓頭十字軸套螺絲 M2×9
BK1480
COLLAR, d2×D3×5.6t
軸環 , d2×D3×5.6t
BK1481
FLAT WASHER d2xD3.7x0.5t
墊片 d2xD3.7x0.5t
Assemble left and right side the same way
左右側組件相同
LR
LR
(10)
(7) (5)
(8)
(8) (7)
(9)
(6)
(4)
(3)
T22
T22
Ensure smooth, non-binding movement when assembling
確認組件靈活度
Apply threadlocker
使用螺絲防鬆膠
Secure all screws shown on this page with a drop of thredlocker.
本頁顯示之螺絲請使用適量防鬆膠鎖固。
All manuals and user guides at all-guides.com

-7-
MAIN ROTOR / 主旋翼機構組裝
Bag B
HME3-3B
SET SCREW M3×3
無頭內六角螺絲 M3×3
BK1203
Linkage Ball(ø3.8)
連接頭 (ø3.8)
No.
1
2
3
4
Qty
2
2
2
2
Material No.
BK1499
BK1500
BK1203
HSP16-6N
Description
METAL FLYBAR CONTROL ARM-1
METAL FLYBAR CONTROL ARM-2
LINKAGE BALL(ø3.8)
COUNTERSUNK SCREW M1.6×6
名稱
金屬穩定翼轉臂
-1
金屬穩定翼轉臂 -2
連接頭 (ø3.8)
圓頭十字螺絲 M1.6×6
No.
5
6
7
Qty
1
2
2
Material No.
BK1410-1
HME3-3B
BK1413
Description
SUS FLYBAR ROD
SET SCREW M3×3
FLYBAR PADDLE（GREEN）
名稱
不鏽鋼穩定桿
無頭內六角螺絲 M3×3
穩定翼 （ 綠 ）
T22
T22
CA
T22
T22
(1)
(6)
(6)
(5)
(7)
(7)
(2)
(4)
(3)
CA
83mm
83mm
70mm 70mm
54mm
HSP16-6N
Countersunk Screw M1.6×6
圓頭十字螺絲 M1.6×6
Assemble left and right side the same way
左右側組件相同
LR
Ensure the leading edges of the Paddles are
toward the same side to the Metal Flybar Control
Posts.
確認穩定翼前緣與穩定翼控制轉臂方向相同。
Thread the Paddles onto the Flybar Rod, equal the
length to the Flybar Control Arms of each side.
旋上穩定翼於穩定翼桿上，確認兩側的穩定翼至控制臂
距離相等。
Line up the Paddles with the Flybar Control Arms.
對正穩定翼與穩定翼控制臂呈水平狀態。
Ensure smooth, non-binding movement when assembling
確認組件靈活度
Apply threadlocker
使用螺絲防鬆膠
Secure all screws shown on this page with a drop of thredlocker.
本頁顯示之螺絲請使用適量防鬆膠鎖固。
Line up the hole of the Flybar Control Arm
and the flat spot of the Flybar Rod when
securing the screw.
安裝平衡桿時，請確認對正穩定翼控制臂上鎖
固孔位與平衡桿上平面凹槽。
LR
Apply C.A Glue
使用快乾膠黏合
All manuals and user guides at all-guides.com

-8-
MAIN ROTOR / 主旋翼機構組裝
Bag B
Apply grease
使用潤滑油膏(黃油)
The large Internal
Diameter
always goes toward
the Main Rotor Hub
內徑較大的一側，面向
主旋翼中心座組。
The small Internal
Diameter
always goes toward
the Blade
內徑較小的一側，面向
主旋翼組。
HMC26-8B
SOCKET SCREW M2.6×8
內六角螺絲 M2.6×8
BK1079
COLLAR
軸環
HMO26
FLAT WASHER d2.6
華司 d2.6mm
HSP16-6N
COUNTERSUNK SCREW M1.6×6
圓頭十字螺絲 M1.6×6
BK1203
LINKAGE BALL(ø3.8)
連接頭 (ø3.8)
Apply some amount of silicon oil or
Vaseline on the Spindle for easy
assembly.
在橫軸上塗抹此許矽膠油脂或凡士林可使
組裝更為容易。
Checking Tips: >
轉動角度： >
（轉動角度大者，內孔大；轉動角度小者，內孔小）
No.
1
2
4
5
6
Qty
2
2
2
2
1
2
2
Material No.
BK1203
HSP16-6N
BV1893
BV1402
BK0906
BK1900
BK1079
Description
LINKAGE BALL(ø3.8)
COUNTERSUNK SCREW M1.6×6
METAL ROTOR GRIP
METAL ROTOR GRIP
FEATHERING SHAFT
FLAP DAMPER , 65°
COLLAR
名稱
連接頭
(ø3.8)
圓頭十字螺絲 M1.6×6
金屬旋翼轉座組
金屬旋翼轉座組
主旋翼固定軸
避震墊圈, 65度
軸環
No.
7
8
10
11
12
Qty
2
2
2
2
2
2
2
Material No.
HMO26
HMX0409Y
BK0918
BK1079
HMC26-8B
HMV840ZZY
HMV940ZZY
Description
FLAT WASHER d2.6
THRUST BEARING d4xD9x4
WASHER d4xD7.8x0.1mm
COLLAR
SOCKET SCREW M2.6×8
BALL BEARING d4xD8xw3
BALL BEARING d4xD9xw3
名稱
墊片
d2.6mm
止推軸承 d4xD9x4
墊片 d4xD7.8x0.1mm
軸環
內六角螺絲 M2.6×8
滾珠軸承 d4xD8xw3
滾珠軸承 d4xD9xw3
(2)
T22
T22
(4)
(5) (6)
(2)
(8)
(9*)
(3*)
(12) (9*) (7) (10)(3*)(11)
(7) (10)
(1)
The bearings inside the Main Rotor Grips are
factory pre-assembled. The below drawing is
for your reference.
滾珠軸承已由原廠組裝完成，組裝順序如下圖示：
Diagram for Thrust Bearing Assembly
止推軸承安裝示意圖
Completed View
組裝完成
Apply threadlocker
使用螺絲防鬆膠
Secure all screws shown on this page with a drop of thredlocker.
本頁顯示之螺絲請使用適量防鬆膠鎖固。
Assemble left and right side the same way
左右側組件相同
LR
LR
Ensure smooth, non-binding movement when assembling
確認組件靈活度
3* 9*
*available depending on the kit you purchased.
使用零件因購買套件有所不同。
All manuals and user guides at all-guides.com

-9-
MAIN ROTOR / 主旋翼機構組裝
Bag B+C
70mm / 2.7”
HSP17-7N
Countersunk Screw M1.7×7
圓頭十字螺絲 M1.7×7
HSP16-6N
Countersunk Screw M1.6×6
圓頭十字螺絲 M1.6×6
HNU2-9Z
SHOULDER SCREW M2x9
圓頭十字軸套螺絲 M2×9
BK1480
COLLAR, d2×D3×5.6t
軸環 d2×D3×5.6t
HME3-3B
Set Screw M3×3
無頭內六角螺絲 M3×3
BK1481
FLAT WASHER d2xD3.7x0.5t
墊片 d2xD3.7x0.5t
T22
T22
T22
T22
(15)
(13)
(12)
(1)
(4) (5)
(2)
(10)
(8)
(9)
(11) (7)
(6)
(3)
(14)
The length from the end of the Min Shaft to the
Lock Ring is 70mm/2.7”.
固定套環安裝位置為距離主軸底部約70mm/2.7”處
（如圖示）。
Apply threadlocker
使用螺絲防鬆膠
Secure all screws shown on this page with a drop of thredlocker.
本頁顯示之螺絲請使用適量防鬆膠鎖固。
Ensure smooth, non-binding movement when assembling
確認組件靈活度
BK1086
SOCKET SCREW M2×14
內六角半牙螺絲 M2×14
HML2
M2 NUT
M2 螺帽
No.
1
2
3
4
5
6
7
8
Qty
1
1
2
2
2
2
2
2
Material No.
BK1502
BK1086
HML2
BV1406
BK1014
HSP17-7N
BK1480
HSP16-6N
Description
HARDENED MAIN SHAFT
SOCKET SCREW M2×14
M2 NUT
M. FLYBAR C. LEVER
WASHOUT LINKAGE
COUNTERSUNK SCREW M1.7×7
COLLAR, d2×D3×5.6t
COUNTERSUNK SCREW M1.6×6
名稱
高強度主軸
內六角半牙螺絲 M2×14
M2 螺帽
金屬穩定翼控制臂組
連接座
圓頭十字螺絲 M1.7×7
軸環 d2×D3×5.6t
圓頭十字螺絲 M1.6×6
No.
9
10
11
12
13
14
15
Qty
2
2
2
1
1
1
1
Material No.
BK1203
BK1481
HNU2-9Z
BV1405
BV1419A
BK1020
HME3-3B
Description
LINKAGE BALL(ø3.8)
FLAT WASHER d2xD3.7x0.5t
SHOULDER SCREW M2x9
METAL WASHOUT BASE SET
METAL Swashplate
MAIN SHAFT LOCK RING
SET SCREW M3×3
名稱
連接頭
(ø3.8)
墊片 d2xD3.7x0.5t
圓頭十字軸套螺絲 M2×9
金屬控制臂座組
金屬十字盤
止擋圈
無頭內六角螺絲 M3×3
The hole should point up.
請注意，有孔位的一端應朝上
All manuals and user guides at all-guides.com

-10-
LINKAGE ROD INSTALLATION / 連桿組裝
Bag D
No.
1
2
3
Qty
4
3
14
Material No.
BK0932
BK1063
BK0922
Description
BALL LINK d3.8x10mm
LINKAGE ROD D1.3x7mm
BALL LINK d3.8x12mm
名稱
單頭連接桿
連接桿
單頭連接桿
No.
4
5
6
Qty
2
2
2
Material No.
BK1064
BK1066
BK1065
Description
LINKAGE ROD 1.3X10mm
LINKAGE ROD 1.3x24.5mm
LINKAGE ROD 1.3x29mm
名稱
連接桿
連接桿
連接桿
(D)
18
7
10
24.5
29
X2
(C)
X2
(B)
X2
For 3D flying
3D飛行設定
For novice
初學者設定
(A)
X2
18
7(E)
X1
Scale=1:1
(unit:mm)
36.5
41.5
23
10
(B)
X2
25
T mark on the Ball
Link goes toward
outside.
球頭上T字凸起向外
Assemble the Linkage Rods as drawings. The linkage length is measured by the center of the
2 Ball Links. These drawings are printed actual size; you can lay the linkage sets on the left
drawings to measure the correct length.
請參考圖示組裝連桿及連桿頭。連桿長度距離的計算應以兩端連桿頭中心點為基準。圖示尺寸與實物
相同，您可直接對照左方圖示以快速獲得正確長度。
Attach the linkage sets on the main rotor head set.
Please refer below drawing.
參考下圖正確連接連桿組及主旋翼組。
BK0922
Ball Link d3.8x12mm
單頭連接桿
BK0932
Ball Link d3.8x10mm
單頭連接桿
(1)
(2)
(6) (D)
(C)
(B)
(3)
(4)
(5)
(3)
(3)
(A)
For 3D flying
3D飛行設定
For novice
初學者設定
(1)
(2) (E)
Torqu-Tube Version
Belt-Driven Version
7
X1
20
All manuals and user guides at all-guides.com
all-guides.com

-11-
*available depending on the kit you purchased.
使用零件因購買套件有所不同。
BELT-DRIVEN VRSION
BELT-DRIVEN VRSION
*available depending on the kit
you purchased.
使用零件因購買套件有所不同。
MAIN FRAME / 本體組裝
Bag E+F
HSA2-6
Button Head Socket Screw, M2x6
半圓頭內六角螺絲
HMY1-5
Pin ø1×5.3
插銷 ø1×5.3L
HMD2-6
Flat Head Phillips Screw, M2x6
平頭十字螺絲 M2x6
HNX2-10B
Socket Button Head Self Tapping Screw M2×10
半圓頭內六角自攻螺絲M2×10
No.
3
4
6
Qty
2
2
1
1
1
2
1
1
16
Material No.
BK1892
BK1892-1
BV1882
BV1882-1
BV1883
BK1878
BK1881
BK1881-1
HSA2-6
Description
CARBON MAIN FRAME
CARBON MAIN FRAME
UPPER BEARING SET
UPPER BEARING SET
LOWER BEARING SET
FRONT SERVO TRAY
RARE SERVO TRAY
RARE SERVO TRAY
BUTTON HEAD SOCKET SCREW, M2X6
名稱
碳纖側板
碳纖側板
上軸承座組
上軸承座組
下軸承座組
前伺服機座
後伺服機座
後伺服機座
半圓頭內六角螺絲 , M2X6
No.
9
10
11
12
Qty
1
1
1
1
1
1
1
4
Material No.
BV1897-1
BV2609
BV1412
BV1898
BK1445
HMY1-5
HMD2-6
HNX2-10B
Description
TAIL BEARING FLANGE SET
TAIL BEARING FLANGE SET
METAL PULLEY SET (14T)
METAL PULLEY SET (14T)
TAIL GEAR 28T
PIN ø1×5.3
FLAT HEAD PHILLIPS SCREW, M2X6
SOCKET BUTTON HEAD SELF TAPPING SCREW M2x10
名稱
傘齒輪座組
尾傳動齒軸承座組
金屬皮帶輪組
(14T)
尾曲動軸組
金屬尾驅動齒
28T
插銷 ø1×5.3L
平頭十字螺絲 M2x6
半圓頭內六角自攻螺絲M2x10
(5*)
(5*)
(2*)
(3)
(1*)
(6)
(6)
(6)
(6)
(6)
(6)
(4)
(1*)
(11)
(7*)
(8*)
(10)
(9) (11)
(10)
(12)
(9)
(7*)
(8*) (12)
(12)
(12)
T22
T22
T22
5*
1*
2*
7*
8*
All manuals and user guides at all-guides.com

-12-
MAIN FRAME / 本體組裝
Bag G
(3)
HME3-3B
Set Screw M3×3
無頭內六角螺絲 M3×3
(8)
(4)
(4)
(10)
(7)
(9)
No.
1
2
3
4
5
Qty
1
1
1
12
1
Material No.
BK2601
BK2604
BK2606
HNX2-6B
BK1887
Description
ANTI-ROTATION BRACKET
BATTERY TRAY
BOTTOM BRACKET
SOCKET BUTTON HEAD SELF TAPPING SCREW M2x6
STANDOFF SPACER
名稱
十字盤相位導軌
電池板
機身底板
半圓頭內六角自攻螺絲M2x6
定位柱
No.
6
7
8
9
10
Qty
2
1
1
1
8
Material No.
BK1888
BK2602
BK2603
BK1473
HNX2-6B
Description
CANOPY STANDOFF
ANTENNA HOLDER
CANOPY CLIP
LANDING SKID (BLACK)
BUTTON HEAD SOCKET SCREW, M2x6
名稱
機殼支柱
天線管座
機殼固定夾
腳架
（ 黑 ）
半圓頭內六角自攻螺絲M2x6
1. Assemble the Battery Tray, Anti-rotation Bracket and Bottom Bracket by Tapping Screws
(M2 x 6, #4) as drawing.
2. Assemble the Canopy Standoff & Standoff Spacer on the main frame set, secure tightly
with a drop of thrardlocker.
3. Assemble the Landing Skid, Canopy Clip & Antenna Holder as drawing, and then attach
the skid set on the main frame set.
1. 參考圖示將電池板、十字盤相位導軌及機身底板以自攻螺絲組裝至側板組。
2. 使用適量防鬆劑將將機殼支柱及定位柱組裝至側板組。
3. 先組裝腳架、機殼固定夾及天線管座，然後再將腳架組安裝至側板組。
(1)
(2)
(5)
(6)
T22
(6)
T22
(4)
(4)
HNX2-6B
Socket Button Head Self Tapping Screw M2×6
半圓頭內六角自攻螺絲M2×6
All manuals and user guides at all-guides.com

-13-
MAIN GEAR SET / 主齒輪組裝
Bag H & I
HMC2-14B
Socket Screw M2×14
內六角螺絲 M2×14
HML2
M2 Nut
M2
螺帽
1. The One Way Bearing and the Spacer are pre-assembled.
2. Assemble the Main Gear and the Autorotation Tail Drive
Gear with the One Way Bearing Shaft.
1. 單向軸承與墊片原廠已安裝完成。
2. 以單向軸套組合主齒輪與尾驅動齒輪。
BK0931
Flat Washer d6×D10×0.3
單向軸套墊 圈 d6×D10×0.3
1mm
Spacer
六角軸環
One Way Bearing
單向軸承
Main Gear 150T
主齒輪
(1)
(3)
(2)
(4)
The Words on the
One Way Bearing
is toward bottom
單向軸承刻字端朝下
No.
1
2
3
4
Qty
1
1
2
1
Material No.
BK0933
BV0934
BK0931
BK0930
Description
AUTOROTATION TAIL DRIVE GEAR
MAIN GEAR (W/BEARING)
FLAT WASHER D6×D10×0.3
ONE WAY BEARING SHAFT
名稱
尾驅動輪
(124T)
主齒輪 ( 含軸承 )
單向軸套墊 圈 d6×D10×0.3
單向軸套
No.
5
6
7
8
Qty
1
1
1
1
Material No.
BK1020
HME3-3B
HMC2-14B
HML2
Description
MAIN SHAFT LOCK RING
SET SCREW M3×3
SOCKET SCREW M2×14
M2 NUT
名稱
止擋圈
無頭內六角螺絲 M3×3
內六角螺絲 M2×14
M2 螺帽
1. Slide the main gear set into the main frame set.
2. Insert the Main Shaft into the Upper Bearing Housing, main
gear set & Lower Bearing Housing.
3. Line up the holes of the Autorotation Tail Drive Gear, One Way
Bearing Shaft & Main Shaft, and then insert the Socket Screw
to fix them with a M2 Nut. Add a drop of threadlocker when
securing, but do not over tighten.
4. Attach the Main Shaft Lock Ring on the end of the Main Shaft.
Secure the ring by a Set Screw with a drop of threadlocker,
note there should be no play of the Main Shaft.
1. 將主齒輪組套入側板組中。
2. 將主軸穿過上軸承座、主齒輪組及下軸承座。
3. 對正尾驅動主齒、單向承軸及主軸上孔位後，穿入內六角螺絲並加上
螺帽，並使用適量防鬆劑固定。注意! 請勿過度緊迫螺絲!
4. 將止擋環套入主軸尾端，使用適量防鬆膠鎖上，正確安裝時，主軸不
會有上下移動之空間。
(7)
(8)
(5)
(6)
T22
T22
T22
Screw Driver
螺絲起子
All manuals and user guides at all-guides.com

-14-
Insert the Belt into the Tail Boom.
First tape the belt & insert the end
of the belt as shown, and not twist
the belt.
將皮帶穿過尾管。用膠帶將皮帶尾端貼
合可使皮帶較容易穿過尾管；並請勿扭
轉皮帶。
TAIL BOOM / 尾管組裝
Bag J
Apply some silicon oil or Vaseline
onto the rubber surface for easy
install into the tail boom.
塗抹些許矽膠油脂或凡士林於橡膠套
表面上，將尾驅動軸組裝入尾管時，
會較為容易。
TORQUE-TUBE VERSION
BELT-DRIVEN VERSION
Secure all screws shown on this page with
a drop of thredlocker.
本頁顯示之螺絲請使用適量防鬆膠鎖固。
Add a drop of thin CA glue on the Drive
Shaft next to where the Bearing should
be, and then slide it over the position
quickly; the distance from the end of
shaft is approx. 180mm / 7.08”
在尾傳動軸上軸承固定位置前方，塗抹少量
快乾膠，迅速滑動軸承至定位固定；該定位
大約距離傳動接頭
180mm / 7.08”處
(2)
(8)
90°
(1*)
(4)
(6*)
The slot is toward upper side.
尾管上缺口朝上
Tape / 膠帶
The slot o n the boom is
right angle to the Metal
Tail Rotor Shaft. (View
from nose to tail)
請注意，尾管上缺口應與尾
旋翼軸呈直角狀態。
（由機首向機尾方向看）
T22
T22 (15)
(6*)
(15)
(11)
(14)
(9*)
(8*)
No.
2
3
4
5
7
Qty
1
1
1
4
2
2
1
1
1
Material No.
BK2628
BK1073
BK1004-1
HME3-2.5B
BK1584
BK1569
BV2612
BK1872
BK1567
Description
DRIVE SHAFT SET, d2xD4x359L
BELT MXL-3T（413T）
TAIL BOOM 356MMXø14
SET SCREW M3x2.5
T-PIN d2x12
TORQUE TUBE END
METAL TAIL UNIT HOUSING
METAL TAIL UNIT
BEVEL GEAR, 11T
名稱
驅動軸 , d2xD4x359L
皮帶 MXL-3t（413T）
尾管 356mmxø14
無頭內六角螺絲 M3x2.5
T型銷 d2x12
驅動軸接頭
軸傳金屬尾座
金屬尾座
傘齒輪
, 11T
No.
10
11
12
13
14
15
Qty
1
1
1
1
2
3
1
1
1
6
Material No.
BV1576
BV0973A
BV2613
BV1874
HSA3-6
HSA2-6
BK1578
HMV840ZZY
BK1875
HMD2-5B
Description
TAIL ROTOR SHAFT
MATEL TAIL ROTOR SHAFT SET
METAL TAIL SIDE COVER SET
METAL TAIL SIDE COVER- L
BUTTON HEAD SOCKET SCREW, M3x6
BUTTON HEAD SOCKET SCREW, M2x6
SHOCK-AXIS RUBBER WASHER, d8xD11x6
BERING, d8xD8xW3
TAIL UNIT SPACER
FLAT HEAD PHILLIPS SCREW, M2X5
名稱
尾旋翼橫軸組
尾旋翼軸組
軸傳金屬尾座側蓋
金屬尾座側蓋組 - 左
半圓頭內六角螺絲 M3x6
半圓頭內六角螺絲 M2x6
軸傳避震墊圈, d8xD11x6
滾珠軸承, d8xD8xW3
尾座支柱
平頭十字螺絲 M2x5
(2)
(5)
(1*)
(3)
(3)
(4)
The slot is toward
upper side.
尾管上缺口朝上
T22
T22
T22
T22
T22
T22
T22
180mm
(12)
(13)
(6*)
(7)
(8*) (9*) (10)
(11)
(11)
Apply grease
使用潤滑油膏(黃油)
1* 8*
9*
6*
HMD2-5B
Flat Head Phillips Screw, M2x5
平頭十字螺絲 M2x5
HSA2-6
Button Head Socket Screw, M2x6
半圓頭內六角螺絲 M2x6
CA
*available depending on the kit you purchased.
使用零件因購買套件有所不同。
All manuals and user guides at all-guides.com

-15-
TAIL ROTOR SYSTEM / 尾旋翼機構組裝
Bag K
HMC2-16B
SOCKET SCREW M2×16
內六角螺絲 M2×16
HSP16-6N
COUNTERSUNK SCREW M1.6×6
圓頭十字螺絲 M1.6×6
BK1203
LINKAGE BALL(ø3.8)
連接頭 (ø3.8)
HMF2-6N
COUNTERSUNK SCREW M2×6
圓頭十字螺絲 M2×6
No.
1
2
3
4
5
6
7
8
9
Qty
1
1
1
1
2
1
1
1
2
2
2
Material No.
BK0990
BK0991
BK1203
HSP16-6N
HMV520ZZWY
HNF2-6B
BV1421A
BK1091
HMC2-16B
BV1894
BV1411
Description
TAIL PITH CONTROL LEVER-1
TAIL PITH CONTROL LEVER-2
LINKAGE BALL(ø3.8)
COUNTERSUNK SCREW M1.6x6
BALL BEARING, d2xD5xW2.5
COUNTERSUNK SCREW M2x6
METAL TAIL PITH CONTROL SET
DOUBLE JOINT LEVER
SOCKET SCREW M2x16
METAL TAIL GRIP SET
METAL TAIL GRIP SET
名稱
尾旋翼控制桿 -1
尾旋翼控制桿 -2
連接頭 (ø3.8)
圓頭十字螺絲 M1.6x6
滾珠軸承 d2xD5xW2.5
圓頭十字螺絲 M2×6
金屬尾旋翼攻角控制組
雙關連接桿
內六角螺絲 M2x16
金屬尾旋翼轉座組
金屬尾旋翼轉座組
No.
11
12
13
14
15
16
17
18
19
Qty
2
4
1
2
2
2
2
2
2
Material No.
BK1000
HNU2-9Z
BK0972
HMV520ZZWY
BK1080
HMC2-8B
BK0961
HMC2-12B
HMM2Z
Description
TAIL PITCH LINK
SHOULDERED SCREW M2×9
TAIL ROTOR HUB
BEARING D2×D5×2.5
SAFTY WASHER
SOCKET SCREW M2×8
TAIL ROTOR BLADE
SOCKET SCREW M2×12
LOCK NUT M2
名稱
尾旋翼連接頭
圓頭十字軸套螺絲 M2×9
尾旋翼固定座
滾珠軸承 d2×D5×2.5
墊圈
內六角螺絲 M2×8
尾旋翼
內六角螺絲 M2×12
止鬆螺帽 M2
(7)
(1)
(6)
(2)
(3)
(4)
(5)
(8)
(5)
(9) (9)
Ensure smooth, non-binding
movement when assembling
確認組件靈活度
Note the orientation of the triangle mark
on the Double Joint Lever.
請注意雙關連接桿上三角形凸標的方向。
T22
T22
HNU2-9Z
SHOULDERED SCREW M2×9
圓頭十字軸套螺絲 M2×9
HMC2-8B
SOCKET SCREW M2×8
內六角螺絲 M2×8
BK1080
SAFTY WASHER
墊圈
HMV520ZZWY
BEARING D2×D5×2.5
滾珠軸承 d2×D5×2.5
Secure all screws shown on this page with a drop of thredlocker.
本頁顯示之螺絲請使用適量防鬆膠鎖固。
10*
Assemble left and right side the same way
左右側組件相同
The orientation of the
Satefy Washer
注意墊片安裝方向
Attach the Tail Rotor Blades to the Metal Tail Pitch
Housing as drawing. Ensure the leading edges of
the blades are toward proper side as shown.
參考圖示將尾旋翼安裝於金屬尾旋翼夾座。請確認旋翼
前橼朝向正確方向(如圖示)。
chamfer
倒角
T22
T22
(12) (11)
(10*) (14) (15) (16)
(8)
(19)
(17)
(18)
(13)
(10*)
(11)
(14)(15)(16)
*available depending on the kit you purchased.
使用零件因購買套件有所不同。
All manuals and user guides at all-guides.com
all-guides.com

-16-
TAIL ROTOR SYSTEM / 尾旋翼機構組裝
Bag L
Secure all screws shown on this page with a drop of thredlocker.
本頁顯示之螺絲請使用適量防鬆膠鎖固。
HME3-3B
SET SCREW M3×3
無頭內六角螺絲 M3×3
HNU2-9Z
SHOULDERED SCREW M2×9
圓頭十字軸套螺絲 M2×9
No.
3
4
Qty
1
2
Material No.
BK1501
HSA2-6
Description
3D CARBON TAIL FIN
BUTTON HEAD SOCKET SCREW, M2X6
名稱
3D 碳纖維垂直安定面
半圓頭內六角螺絲
No.
1
2
Qty
1
2
Material No.
HME3-3B
HNU2-9Z
Description
SET SCREW M3×3
SHOULDERED SCREW M2×9
名稱
無頭內六角螺絲 M3×3
圓頭十字軸套螺絲 M2×9
Ensure smooth, non-binding
movement when assembling
確認組件靈活度
HSA2-6
BUTTON HEAD SOCKET SCREW, M2X6
半圓頭內六角螺絲
(4)
Step 3 / 步驟三
Attach the Carbon Tail Fin to the Tail Unit as shown.
將碳纖垂直安定翼固定於尾管座。
Completed View
組裝完成
(3)
(1)
(2)
Step 2 / 步驟二
Fit the Tail Pitch Control Links to the Tail Pitch Control
Set. Do not over tighten the Socket Screw and ensure
the tail linkages run effortlessly.
將控制連桿與控制臂連接，請使用適量螺絲防鬆劑，勿過度鎖
緊固定螺絲，並確認機構可以靈活作動。
Step 1 / 步驟一
1. Slide the tail rotor set into the Tail Rotor Shaft.
Line the hole up with the concave on the shaft.
2. Secure the tail rotor set tightly by the Set
Screw with a drop of threadlocker.
1. 將組裝完成的尾舵控制臂與夾片組安裝至尾橫軸。
2. 無頭內六角螺絲需準確安裝於尾橫軸固定孔位，並
使用防鬆膠。
T22
T22
T22
(2)
Line up the concave of tail rotor
shaft and the hole of hub.
尾橫軸上凹槽對正轉座上螺絲孔。
All manuals and user guides at all-guides.com

-17-
TAIL UNIT-TORQUE-TUBE / 尾部總成組裝-軸傳版
Bag N
HNX2-10B
SOCKET BUTTON HEAD SELF TAPPING SCREW, M2×10
半圓頭內六角自攻螺絲 M2×10
HSA2-6
BUTTON HEAD SOCKET SCREW, M2X6
半圓頭內六角螺絲 M2X6
Ensure the leading edge of the blades rotate this way as drawing.
(Turn the Main Gear clockwise, both the main rotor head and tail rotor head turn clockwise)
請注意旋翼轉動方向應與圖示相同。
(順時針方向撥動主齒盤時，主旋翼頭及尾旋翼皆朝順時針轉動。)
(12)
(4)
(3)
(1)
(1) (2)
(2)
(12)
Step 1 / 步驟一
Insert the Bracket Spacers into the Tail Boom Bracket, and then secure into the main frames.
將固定座支柱穿入尾管固定座中後，鎖固於側板上。
Step 2 / 步驟二
1. Insert the tail boom through the bracket and push to the end.
Check the mess of the front bevel gear set by rotating the
main gear set, both main & tail rotor head rotates effortlessly
if the mess is proper. Please pull the tail boom a little bit
backward if the rotation is not smooth.
2. Tighten the 4 lower Tapping Screws to fix the tail boom on
the bracket.
TORQUE-TUBE
T22
1. 將尾管插入固定座中並推至底。撥動主齒盤組確認前傘齒
組齒隙，如齒隙正確則主旋翼及尾旋翼均會順暢轉動。如
轉動不順暢，請將尾管稍向後拉，以獲得正確齒隙。
2. 鎖緊下方兩側4顆螺絲，將尾管迫緊於固定座上。
HMJ12-6B
TAPPING SCREW M1.2×6
圓頭十字自攻螺絲 M1.2×6
HNN2-10B
TAPPING SCREW(W/WASHER) M2×10
圓頭墊圈自攻螺絲 M2×10
No.
1
2
3
4
5
6
Qty
2
2
2
2
8
1
Material No.
BK1082
HMJ12-6B
BK0923
HNN2-10B
HNX2-10B
HMV1060ZZY
Description
ROD GUIDE
TAPPING SCREW M1.2×6
TAIL SERVO TRAY
TAPPING SCREW(W/WASHER) M2×10
SOCKET BUTTON HGAD SELF TAPPING SCREW, M2x6
BERING, d6xD10xW3
名稱
固定環
圓頭十字自攻螺絲 M1.2×6
尾伺服機座
圓頭墊圈自攻螺絲 M2×10
半圓內六角頭自攻螺絲, M2x6
滾珠軸承, d6xD10xW3
No.
7
8
9
10
11
12
Qty
1
1
1
2
1
4
Material No.
BK1897-1
HMV1370ZZY
BK1567
BK1886
BK2610
HSA2-6
Description
FRONT BEVEL GEAR MOUNT
BEARING d7XD13xW4
FRONT BEVEL GEAR 11T
BRACKET SPACER
TAIL BOOM BRACKET
BUTTON HEAD SOCKET SCREW, M2x6
名稱
前傘齒輪座
珠軸承, d7xD13xW4
傘齒輪 11T
固定座支柱
尾管固定座
半圓頭內六角螺絲 M2x6
(9)
(8)
(11)
(10)
(6)
(5)
(5)
(7)
Ensure smooth, non-binding movement when assembling
確認組件靈活度
Apply threadlocker
使用螺絲防鬆膠
All manuals and user guides at all-guides.com

-18-
TAIL UNIT-BELT-DRIVEN / 尾部總成組裝-皮帶版
Bag M
HNX2-10B
SOCKET BUTTON HEAD SELF TAPPING SCREW, M2×10
半圓頭內六角自攻螺絲 M2×10
HSA2-6
BUTTON HEAD SOCKET SCREW, M2X6
半圓頭內六角螺絲 M2X6
Ensure the leading edge of the blades
rotate this way as drawing. (Turn the Main
Gear clockwise, the main rotor grips turns
clockwise and the Tail Blades turn counter
clockwise.)
請注意旋翼轉動方向應與圖示相同。
（順時針方向撥動主齒盤時，主旋翼頭夾座順
時針、尾旋翼逆時針轉動。）
Tail pulley
皮帶輪
Tail / 機尾
Nose / 機頭
Drive Gear Set
尾驅動輪組
(1)
(6)
(5)
Step 1 / 步驟一
1. Remove the tap from the end of the belt. Insert the tail unit
into the main frame set, twist the belt toward right for 90°
and then warp around the pulley.
2. First tighten the 4 upper Tapping Screws（HNN2-10B,#1）to
attach the Tail Bracket on the main frame set.
1. 移除皮帶末端膠帶。將尾部套入主側板組中，同時將皮帶向右扭轉
90度後，繞過皮帶輪。
2. 先緊鎖上方的兩側4顆螺絲，將尾管固定座固定在主側板組上。
(2)
(1)
Step 2 / 步驟二
1. Pull the Tail Boom out slightly by grasping
the Tail Unit with one hand and the main
frame set with the other. Adjust until the
belt deflects by about 0.2mm (0.08”).
2. Tighten the 4 lower Tapping Screws（
HSA2-6B,#2）to fix the Tail Bracket on the
main frame set.
1. 一手固定主側板組，另一手握住尾部將尾管向外
拉，使皮帶拉緊。適當的皮帶緊度應於推壓皮
帶時陷下少於0.2mm(0.08”)。
2. 將下方的兩側4 顆螺絲螺緊，將尾管固定座固
定於主側板組。
90°
(2)
Apply threadlocker
使用螺絲防鬆膠
HMJ12-6B
TAPPING SCREW M1.2×6
圓頭十字自攻螺絲 M1.2×6
HNN2-10B
TAPPING SCREW(W/WASHER) M2×10
圓頭墊圈自攻螺絲 M2×10
No.
1
2
3
4
Qty
2
2
2
2
Material No.
BK1082
HMJ12-6B
BK0923
HNN2-10B
Description
ROD GUIDE
TAPPING SCREW M1.2×6
TAIL SERVO TRAY
TAPPING SCREW(W/WASHER) M2×10
名稱
固定環
圓頭十字自攻螺絲 M1.2×6
尾伺服機座
圓頭墊圈自攻螺絲 M2×10
No.
5
6
7
8
Qty
1
2
4
4
Material No.
BK2610
BK1886
HNX2-10B
HSA2-6
Description
TAIL BOOM BRACKET
BRACKET SPACER
SOCKET BUTTON HEAD SELF TAPPING SCREW, M2×10
BUTTON HEAD SOCKET SCREW, M2X6
名稱
尾管固定座
固定座支柱
半圓頭內六角自攻螺絲 M2×10
半圓頭內六角螺絲 M2X6
(4) (4)
(2)
(2) (1) (3) (3)
(1)
Hint
組裝提示
BELT-DRIVEN
T22
Ensure smooth, non-binding movement when assembling
確認組件靈活度
All manuals and user guides at all-guides.com

-19-
TAIL SUPPORT / 尾管支撐架組裝
Bag P
HMC2-10B
SOCKET SCREW M2×10
內六角螺絲 M2×10
HMC2-14B
SOCKET SCREW M2×14
內六角螺絲 M2×14
HML2
M2 NUT
M2
螺帽
HSP16-6N
COUNTERSUNK SCREW M1.6×6
圓頭十字螺絲 M1.6×6
BK1203
LINKAGE BALL (ø3.8)
連接頭 (ø3.8)
HNN2-10B
TAPPING SCREW(W/WASHER) M2×10
圓頭墊圈自攻螺絲 M2×10
BK0922
BALL LINK D3.8x12mm
單頭連接桿 D3.8x12mm
CA
CA or Epoxy
瞬間膠或環氧樹脂
No.
1
2
3
4
5
6
Qty
1
2
4
1
2
1
Material No.
BK1026
BK1027
BK1025
BK1889
HMC2-10B
HMC2-14B
Description
BRACKET
ROD ø3×255mm
TAIL SUPPORT ROD END
FRAME SPACER
SOCKET SCREW M2×10
SOCKET SCREW M2×14
名稱
尾支撐桿座
碳纖棒 ø3×255mm
尾支撐桿接頭
機身支柱
內六角螺絲 M2×10
內六角螺絲 M2×14
No.
7
8
9
10
11
12
Qty
1
1
2
1
1
2
Material No.
HML2
BK1071
BK0922
HSP16-6N
BK1203
HNN2-10B
Description
M2 NUT
TAIL LINKAGE ROD ø1.3
BALL LINK D3.8x12mm
COUNTERSUNK SCREW M1.6×6
LINKAGE BALL (ø3.8)
TAPPING SCREW(W/WASHER) M2×10
名稱
M2 螺帽
尾拉桿
ø1.3
單頭連接桿 D3.8x12mm
圓頭十字螺絲 M1.6×6
連接頭 (ø3.8)
圓頭墊圈自攻螺絲 M2×10
(5)
(2) (7)
(10)
(11)
(12)
(12)
(8)
(9)
(9)
(3)
(1)
(4)
(3)
(6)
(2)
T22
Step 2 / 步驟二
1. Remove the tail servo wheel prior to attaching the Linkage Ball.
2. For the rudder servo, mount the Linkage Ball at 10.5mm from
the center of the servo arm as beginning. Please refer to the
manual of your gyro to choose the length of the arm.
3. Secure the servo to the Tail Servo Tray and attach the
rod to the servo arm.
1. 從尾舵伺服機上將伺服機擺臂拆下，安裝連桿頭。
2. 將連桿頭安裝於距離擺臂中心位置10.5mm處作為初始設定，
建議您參考陀螺儀說明書安裝。
3. 將伺服機安裝於尾舵伺服機固定座，並與連桿連接。
Step 1 / 步驟一
1. Apply CA or Epoxy when assembling the Tail Support Rod End.
2. Install the Tail Support Bracket and fit the Tail Support Rod.
1. 使用快乾膠接合尾支撐桿接頭與碳纖棒。
2. 將支撐桿座與支撐桿接合。
Secure all screws shown on this page with a drop of thredlocker.
本頁顯示之螺絲請使用適量防鬆膠鎖固。
Apply threadlocker
使用螺絲防鬆膠
Apply C.A Glue
使用快乾膠黏合
All manuals and user guides at all-guides.com
