Tic B series User manual

B-series Instruction Manual

B series

Outdoor Omnidirectional

In-Ground/Surface-Mount Speaker

B06 / B16 B03 / B13 /B50

Instruction Manual

B-series Instruction Manual

Before you begin

A passive outdoor loudspeaker system is one of the best audio entertainment investments you can make for both residential and commercial installations.

Investing the time and labour to install a wired speaker system will provide the safest and most dependable sound solution that can be easily upgraded and

customized over time.

Before connecting the speakers, please take the time to design and review the overall system, making sure the speakers are well-situated to provide an even

coverage with adequate sound level. Depending on the specific model, the speaker may or may not include a wire tail. You will likely need to purchase

additional speaker wires to connect the entire sound system. The longer the distance covered, the higher gauge of speaker wires should be used to maximize

audio performance.

When selecting and connecting an amplifier to a passive loudspeaker, it is important to understand the relationship and impact of impedance load and power

wattage between amplifier and loudspeaker. Caution must be used to ensure impedance load of loudspeaker system is compatible with the selected

amplifier’s operable range, especially when loudspeakers are wired in parallel, series, or a combination of the two. Incorrect impedance matching may cause

irreparable harm to your audio equipment.

When considering power of your amplifier, most audio professionals and audiophile will recommend an amplifier with an output power above the

loudspeaker’s power handling rating. This is the ideal set up to maximize audio performance as the extra power will ensure delivery of sufficient power during

short periods of audio peaks along with fuller dynamic range and effortless loud volume output. However, the ability to deliver extra power may cause

potential damage to the loudspeaker, especially when playing loudly in a sustained period. Caution and restrain must be used to ensure longevity of the

loudspeaker under the ideal set up. If longevity and safe operation is more important than optimal audio performance, you should select an amplifier with a

RMS power rating at or slightly below the loudspeaker’s rating. Please consult a professional installer if you are unsure about impedance and power level

matching.

If you need help or have further question, please contact us at www.ticaudio.nl.

B-series Instruction Manual

Wiring Diagram

Choose the appropriate wiring option depending on your model and overall system design.

* Colorized version of wiring diagrams and manual is available on our website (www.ticcorp.com). In typical installations, positive terminals are connected to red wires and

negative terminals are connected to black wires.

B-series Instruction Manual

Installation/Maintenance Note

•The B series speaker can be installed in-ground or surface-mounted. In-ground installation is generally optimal since burying speaker in-ground will

enhance its resonance, providing a fuller audio experience. When mounted on a surface, please ensure the wiring is safely secured and does not

become a tripping hazard. When burying the speaker in-ground please make sure to keep the open part of the speaker free from soil, and in addition

a small part of the bottom section as well (see below picture).

•For in-ground installation, only burial-grade insulated speaker wires should be used. Conduit can be used alternatively in conjunction with standard

speaker wires. Wire/conduit should be buried 10 - 15 cm underground.

•For connecting/extending speaker wires, we highly recommend using waterproof wire connector (ie. SPC-CN1).

•Alternately, silicon can be applied to the opening of standard wire nut to provide water protection.

•The B series is designed to be water-resistant, but not to be fully waterproof. It is not designed to be protected against total water submersion, such

as heavy flooding. With the raised, downward facing profile, it’s unlikely for the speaker to be submerged in water under normal rain and snow

condition. Please use caution and consider relocating the speaker when there is chance for heavy flood or snowfall.

•System should be fully tested above surface before speakers and wires are buried.

•If sound is muddled or multiple speakers are not in sync, please check to ensure wire polarity is correct.

•To clean speaker, you can rinse with fresh water from directly above the speaker and wipe with a cloth. If needed, use mild detergent to remove dirt.

B-series Instruction Manual

70v Operation

B13/B16 speaker can operate in both standard 8Ωmode and 70v mode. The 70v option, which is a constant voltage system, offers ease of installation for

audio system with larger quantities of loudspeakers and minimize the concern for power loss over long distance wire runs. However, there are also

disadvantages to 70v system such as limitations to mono output and degradation of signal, especially in low frequencies, though in general this is not

noticeable. 70v is the preferred choice in large installations, such as commercial projects, for both PA systems and background music systems. If you are

unsure about 70v, please contact TIC or a trusted AV professional for consultation. If you are using B13/B16 with a regular amplifier, please set dial to 8Ωand

connect as normal.

To operate in 70v mode. you must utilize a 70v amplifier. Simply set the dial to any of the wattage settings and connect the speaker to a 70v amplifier that

has power output at least 20% greater than the summation of all speaker's wattage settings within the sound system. The 20% headroom ensures optimal

performance and longevity to both amplifier and speakers. The correct wattage setting will depend on your volume and sound sculpting requirement and the

power output of your amplifier.
