Tiger Deluxe Animal User manual

TIGER
DELUXE
ANIMAL
LOG CABIN
GENERAL ASSEMBLY
INSTRUCTIONS
TIG/INS53

BEFORE YOU GET STARTED
02 gersheds.com 0113 205 4189 sales@gersheds.com
PLEASE READ INSTRUCTIONS CAREFULLY
• Checkthepackandmakesureyouhaveallthepartslisted.
• Whenyouarereadytostart,makesureyouhavetherighttoolsathand(notsupplied).
• Ensurethereisplentyofspaceandacleandryareaforassembly.
TIMBER
Aswithallnaturalmaterials,mbercanbeaectedduringvariousweathercondions.Fortheduraonof
heavyorextendedperiodsofrain,swellingofthewoodlogsmayoccur.Warpingofthewoodmayalsooccur
duringexcessivedryspellsduetoaninteriormoistureloss.Unfortunately,theseprocessescannotbeavoided
butcanbemigated.Itissuggestedthattheoutdoorbuildingissprayedwithwaterduringextendedperiodsof
warmsunshineandshelteredasmuchaspossibleduringrainorsnow.
Pleasedonotpaintortreatyourcabinmbersbeforeassemblyastheymuststaydryforasnugtongueand
groovet.Tovalidateyourguaranteeandensurelongevityoftheproduct,itisESSENTIALthatyourbuildingis
treatedwithanappropriatehigh-qualityoilorsolventbasedpreservaveAFTERassembly,bothinternallyand
externally,thenannuallythereaer.
BUILDING A BASE
Caremustbetakentoensuretheproductisplacedonasuitablebase.Whenthinkingaboutwherethebuilding
andbaseisgoingtobeconstructed,ensurethattherewillbeaccesstoallsidesformaintenanceworkand
annualtreatment.
Ensurethebaseisrmandlevelandisbuiltonrmground,topreventdistoron.
Theconstructedbasemustbeatleastthesizeoftanalisedoorbearersasreferencedinsuppliedconstruct
diagram.Itisalsorecommendedthattheoorbeatleast25mmabovethesurroundinggroundleveltoavoid
ooding.
TYPES OF BASE
• Durableplascgrid*.
• Concrete75mmlaidontopof75mmhard-core.
• Slabslaidon50mmofsharpsand.
• Timberbase-Selfconstructed/Buypre-made.
*We recommend a Fastt EcoBase for your building. It is durable, lightweight, exible, and easy to put in place.
Please see gersheds.com for details.
WOOD WARPING
MAY OCCUR
WINTER
EXPANSION
SUMMER
CONTRACTION
PLASTIC BASE TIMBER BASE BROKEN SLABS BARE SOIL LOOSE GRAVELCONCRETE BASE SLAB BASE

Pleaseretaininstruconsforfuturereference
CAUTION:
Allbuildingsshouldbeerected
bytwocompetentadults.
CAUTION:
Itisadvisabletowearsafety
glovesduringbuildinginstallaon.
Whilst all products manufactured are made to the highest standards of safety, we cannot accept responsibility for your safety whilst erecng or
using this product.
GO WITH THE PRO!:
Weunderstandhowbusylifecanbe.OurPro-Installaonservicecantakethestressandstrainoutofassemblingyour
qualityTigerbuildingforyou.Werecommendusingprofessionalanddedicatedinstallerstoerectyourbuilding.Withtheir
knowledgeandexperience,theywillensurethatyourcabinisputproperlyinplacereadyforyoutoenjoyyourspacefor
yearstocome.
IfyouhavenotbookedourPro-Installaonserviceandwouldliketoarrangeaninstallaon,pleasecontactourfriendly
customersupportteamon0113 205 4189(Mon–Fri9am-5pm)oremailsales@gersheds.com.
•Thepro-installteamwillcontactyoutoarrangeasuitablemeanddatefortheng.
•Sitback,relaxandletourprofessionalhomeinstallaonservicedoallthehardworkforyou!
•PleaseviewourProInstallaonpageonourwebsiteforfulltermsandcondions.
MADE IN THE UK SINCE 1913.
Wehavebeenmakingourhighquality,
greatvaluegardenbuildingsherein
Britainfordecades.
03

BEFORE YOU GET STARTED
TOOLS REQUIRED
Werecommendusingthefollowingtools(notsupplied):
SCREWDRIVER +
Unpacking supplied cabin.
• Removeallwrappingfromdelivery.Fromtoptoboom,cutbandingholdingallcomponentstogetherand
 removethecabincomponents.
NOTE: PARTS MAY HAVE BECOME LOOSE OR MOVED DURING TRANSPORTATION.
•Laycomponentsonadry,horizontalsurface.
RUBBER MALLET DRILL LADDER TAPE MEASURE SHARP KNIFE SPIRIT LEVELHAMMER
WOOD SAW
FIXING KIT CONTENTS:
SPANNER
04 gersheds.com 0113 205 4189 sales@gersheds.com
C20
CloutNails(20mm Galvanised - QTY 300)
N40
Nails(40mm Galvanised - QTY 30)
N65
Nails(65mm Galvanised - QTY 300)
S40
Screws(40mm - QTY 30)
S60
Screws(60mm - QTY 8)
S80
Screws(80mm - QTY 16)
CB40
M6CoachBolts(40mm - QTY 8)
BA40
Nails(40mm Bright Annular - QTY 400)

Pleaseretaininstruconsforfuturereference
ASSEMBLY
• Assemblyisstraighorwardifyoufollowthesestep-by-stepinstrucons.
• Werecommendgengeverythingalignedproperlybeforescrewingtogetherandthat
 screwholesshouldbepre-drilledtoavoidsplingthember.(Donotcomepre-drilled).
IMPORTANT
• Beforeassembly,pleasemakesureyouhaveasuitablebasereadytoerectyourbuildingon.
• YourbaseMUSTbermandleveltoensurethatthebuildingisassembledproperlyandissquare.
• Pleasecarefullyremovethepackagingandunpackthecomponentsinyourdelivery.
NOTE: ADDITIONAL TIMBER MAY BE INCLUDED AS PACKING MATERIALS.
• DO NOTstartyourbuildunlyouhavecheckedthatallthepartsofyourbuildingarepresentandinasuitablecondion.
• Ifyouareorganisingathirdpartytoinstallyourbuilding,itisbestpraccenottoschedulethisimmediatelyonreceiptof
 yourorder,togiveyoumetocheckyourdelivery.
BUILDING PACK CONTENTS:
ForfulldetailsofwhatshouldbeincludedpleaseseetheProductConstructDiagramanditemisedcunglist
thatissuppliedwiththedelivery.TheyarealsoavailableonrequestinpdfformfromourhelpfulCustomer
Supportteam–pleasecall0113 205 4189orusetheItemsDeliveredQueryformatgersheds.com/contact.
05

TIGER DELUXE ANIMAL LOG CABIN GENERAL INSTRUCTIONS
Step 1:
UNPACKING CABIN COMPONENTS:
• Unpackallcomponentsfromyoursuppliedcabinpack(s)andplaceeachindividualcomponentinthecorrect
 orderusingthesuppliedconstructdiagramandpartslistasaguide.Ensureallcomponentsarepresentandin
 thecorrectposionbeforebeginningassembly.
• Eachloginterlocksinastaggeredpaern.
NOTE: SOME LOGS FEATURE ADDITIONAL FULL NOTCHES & HALF NOTCHES.
• Beforesecuring,ensurethatthelogsareedproperlyintheirrespecvetongueandgrooves,gently
 tappingdownwithamallet.(Detail A1 & A2)
TOP TIP
Use packing materials to protect when
tapping logs into place.
A1 A2
06 gersheds.com 0113 205 4189 sales@gersheds.com

Pleaseretaininstruconsforfuturereference
Step 2:
LAY THE FLOOR
• Posionpreassembledooronatandlevelsurface.
B
07
Step 3:
BEGIN BUILDING WALLS
• Placetherstlayeroflogsaroundtheedgeoftheoorassemblyasshown.
• Screwhalflogstothetanalisedbearersbelowusing1xS80percorner.(Detail B)
S80

Step 4:
INSTALL GABLE TOPS
• Connuebuildinginterlockinglogsunleavesheight.(Detail C)
08 gersheds.com 0113 205 4189 sales@gersheds.com
TIGER DELUXE ANIMAL LOG CABIN GENERAL INSTRUCTIONS
Step 5:
SECURE STORM BRACES
• Fixstormbracestotheinsideofgableswith2xCB40provided.AlwaysleavetheboomCB40slackenough
 toletthestormbracemoveasthecabinexpandsandcontracts.(Detail D1 & D2)
NOTE: ENSURE THE STORM BRACES ARE SECURED INTO THE GABLE TOP ON EACH SIDE.
C
EAVES HEIGHT
D1 D2
STORM BRACE

Pleaseretaininstruconsforfuturereference
Step 6:
INSTALL ROOF PANELS
• Aachroofpanelsasshown.Therewillbeaslightgapbetweentheroofpanelsattheapexofcabin.(Detail E1)
• Secureapexpurlinsbypushingpanelstogetherandxingwith4xN65evenlyspacedalonglength
 perpanel.(Detail E2)
• Secureintowallsusing4xN65perroofpanel.
• Secureintogabletopsusing2xN65pergabletopperroofpanel.
09
TOP TIP
You may need someone to hold roof panels together
while you secure roof panels at the apex.
E2E1
N65N65

Step 7:
FELT CABIN ROOF
• Rollfeltoutontoacleanatsurface30minutesbeforeyouneeditsoithasachancetoaenout.
• Measurelengthofroofandallow75mmoverhangateachend.Cuteachstripoffelttosize.Useastraight
 edgetoguidecung.
• Rollcutfeltpiecealonglowsideofroof,Secon1,leavingsucientoverhangtofolddownontoroofedge.
• Donotfoldunderneathroof.(Detail F1 & F2)
• Oncefeltisrolledout,xfelttoroofboardsusingCN13ateachend,makingsurethefeltisstraight.Fixto
 roofskirngatapprox.100mmintervals.(Detail F3)
 Ensurethefeltisght,thensecurethetopsideoffeltusingCN13atapprox.100mmintervals.
• Repeatforremainingfelt,workingfromthelowsideofrooftothehighside,overlappingthefeltby75mm
 unltheroofisfullycovered.
• Foldtheoverhangingfeltatendsunderroofpanelandtackinplace.
10 gersheds.com 0113 205 4189 sales@gersheds.com
TIGER DELUXE ANIMAL LOG CABIN GENERAL INSTRUCTIONS
F1 F2 F3
INCORRECT FELT CORRECT FELT
CN20
CN20
CN20
ROOF BOARD
SECTION 1

Pleaseretaininstruconsforfuturereference
11
Step 8:
ATTACH ROOF FASCIA BOARDS (BARGEBOARDS)
• Aachrooffasciasusing4xN40perfasciaboard.Nailthroughtoppurlinandboomroofbaen.Complete
 thelookwithnialsoverthejoinatapex.Secureusing2xN40pernial.
NOTE: THERE ARE NO BARGEBOARDS SUPPLIED FOR LOW SIDE OF ROOF AS THIS WILL PREVENT
EFFECTIVE WATER DRAINAGE.
Step 9:
FIT DOOR (CAT CABIN ONLY)
• Checkthedoorsaresquareandscrewthefasciaboardsexternally,intothelogsbehindwith6xS40evenly
 spacedasshown.(Detail G)
S40
S40
S40
S40
S40
S40
G
