Timberlab Faro User manual

www.timberlab.eu
Manual Faro

3-03-2022
Timberlab B.V.
Harskamperweg 32
6731 AB Otterlo
Follow this installation guide for a safe installation.
General
- Follow this installation guide for a safe installation.
- Installation and connection of the lighting armature should be done by a certified installer
– Disable main supply before starting installation activities!
- Timberlab is not responsible for adjustments of modifications on the armature
- The armature is not dimmable!
- The earthing will be (is) connected to the RVS lid
- We do not recommend the use of concrete mortar for filling in the area around the column. If
necessary/deriable, depending on the type of soil a stabilising sand can be applied.
Maintenance advice
The wood does not require any maintenance. In the course of time, the wood will grey in a natural way.
If a treatment is chosen, a moisture regulating surface treatment should always be applied. Ask your
supplier for advice! If desired, the LED module can be cleanded with a soft brush.
Warranty
The product comes with a two-year guarantee. Wood is a natural product. This wood is, unless expressly
stated otherwise, fresh, undried, sawn and/or planed (if applicable). No furhter woodworking was
performed. There is always a chance of warping and/or (dry) cracking of the wood. This may occur upon
delivery or later. This is not a production error but a natural characteristic of the wood. Warranties do not
apply for this.
The product code is generated by selecting the options and taking the number in brackets ().
Product Wood species Certification In ground/ post holder Colour temperature Version Voltage Variations
KVAC
Faro (19) Larch (1) N/A (0) L1+500mm (00) N/A (0) 32mm hole (0) 230V (1) N/A (00)
Chestnut (2) FSC (1) L1+PH05 (05) with cable (1) socket (02)
Oak (3) PEFC (2) L1 without post
holder (95)
Connection
box (08)
Accoya (4)

3-03-2022
NL
50cm
Ø21 cm
4. Connect
50cm
Ø21 cm
4. Connect
Faro excl cable
1. Drilling
Drill or dig holes in the ground.
2. Place
Place the Faro in the hole.
3. Digging
-Dig out to 40cm deep.
Make sure there is no voltage on
the ground cables
- Place the ground cables.
- Feed the cables through the
Faro.
5. Finishing
- Straighten the pole with
the help of a spirit level.
- Close the hole
in the ground.
Faro incl cable
3. Digging
-Dig out to 40cm deep.
Make sure there is no voltage
on the ground cables
-Place the ground cables
2. Place
Place the Faro in the hole.
1. Drilling
Drill or dig holes in the ground.
5. Finishing
-Straighten the pole with
the help of a spirit level.
-Close the hole
in the ground.
Connect
with an IP68
Castjoint
ground cable
Stainless steel cap
Driver
ground cable
