Timberlab Futuro Wallbox 78 User manual

www.timberlab.eu
Manual Futuro Wallbox

21-03-2022
Timberlab B.V.
Harskamperweg 32
6731 AB Otterlo
Follow this installation guide for a safe installation.
General
- Follow this installation guide for a safe installation.
- Installation and connection of the lighting armature should be done by a certified installer
– Disable main supply before starting installation activities!
- Timberlab is not responsible for adjustments of modifications on the armature
- The armature is not dimmable!
- The earthing will be (is) connected to the RVS lid
- We do not recommend the use of concrete mortar for filling in the area around the column. If
necessary/deriable, depending on the type of soil a stabilising sand can be applied.
Maintenance advice
The wood does not require any maintenance. In the course of time, the wood will grey in a natural way.
If a treatment is chosen, a moisture regulating surface treatment should always be applied. Ask your
supplier for advice! If desired, the LED module can be cleanded with a soft brush.
Warranty
The product comes with a two-year guarantee. Wood is a natural product. This wood is, unless expressly
stated otherwise, fresh, undried, sawn and/or planed (if applicable). No furhter woodworking was
performed. There is always a chance of warping and/or (dry) cracking of the wood. This may occur upon
delivery or later. This is not a production error but a natural characteristic of the wood. Warranties do not
apply for this.
The product code is generated by selecting the options and taking the number in brackets ().
Product Wood species Certification In ground/ post holder Colour temperature Version Voltage Variations
KVAC
Futuro
Wallbox (78) Oak (3) N/A (0) L1+600mm (00) N/A (0) 32mm hole (0) 230V (1) N/A (00)
PEFC (2)

21-03-2022
60 cm
Ø30 cm
Futuro wallbox excl cable
6. Place
Place the Futuro in the hole.
5. Drilling
Drill or dig holes in the ground.
1. Screw
Unscrew the stainless steel lid
2. Detach
Remove the nut. You can now pull the
wallbox out of the post at the front
3. Connect
Connect the wallbox. Follow the wallbox
manual when doing this.
4. Mount
Place the wallbox back in. Tighten the nut and
screw the lid back on.
