Timotion TDH6 User manual

Hand Control Programming- TDH6
Version 4 August 2021
1 of 10
1
20210811
User Manual
Hand Control
Programming-
TDH6

Hand Control Programming- TDH6
Version 4 August 2021
2 of 10
2
Contents
Contents .....................................................................................................................................................................2
Disclaimer ..................................................................................................................................................................3
1. User Interface Guide.............................................................................................................................................4
2. Reset....................................................................................................................................................................5
3. Adjusting the Height.............................................................................................................................................6
4. Setting the Memorized Position ...........................................................................................................................6
5. Setting the Upper and Lower Height Limit ............................................................................................................7
6. Presetting the Desk Starting Height .....................................................................................................................8
7. Switching Metric and Imperial Unit .......................................................................................................................8
8. Restore Factory Setting ........................................................................................................................................9
9. Error Codes ..........................................................................................................................................................9
10. Power Saving Function - Waking Up the Control .................................................................................................10

Hand Control Programming- TDH6
Version 4 August 2021
3 of 10
3
Disclaimer
This user manual is ONLY for generic TiMOTION products. Manufacturers may have altered product settings
causing them to differ from this user manual. Please contact the manufacturer for a revised manual if the
product settings are different than this manual.

Hand Control Programming- TDH6
Version 4 August 2021
4 of 10
4
1.User Interface Guide
3-digit height display
Memory setting buttons
Up and down buttons

Hand Control Programming- TDH6
Version 4 August 2021
5 of 10
5
2.Reset
1. Simultaneously press and for 3 seconds. Continue pressing the buttons until both columns are
in the lowest position. When finished with the reset, the control box will make a “beep” sound and the
buttons can be released.
2. When finished with the reset, the display will show the starting height.
3. Users must conduct a reset when operating the desk for the first time.

Hand Control Programming- TDH6
Version 4 August 2021
6 of 10
6
3.Adjusting the Height
Press or button until the desk reaches the preferred height.
4.Setting the Memorized Position
TDH6 supports a maximum of 4 memory positions.
How to memorize a position:
1. Adjust the desk to the desired height.
2. Press M button for three seconds, the display will flash, then press the memory button 1, 2, 3 or 4 you’d
like to save.
3. Press (and hold) button 1, 2, 3 or 4 to move the desk to the memorized position. (Note 1)
Note 1: It depends on the control box setting whether or not the memory button needs to be held.

Hand Control Programming- TDH6
Version 4 August 2021
7 of 10
7
5.Setting the Upper and Lower Height Limit
A. Setting the upper height limit:
(1) Adjust the desk to the preferred upper height limit.
(2) Press and buttons together for less than 3 seconds, holding and release button. (Note 2)
(3) Re-press for more than 3 times at a slow pace.
(4) A beeping sound will notify you that the process has been completed.
B. Disable the upper height limit:
(1) Move the desk to the upper height limit being set.
(2) Repeat instructions #2~4 above to disable the upper limit setting.
C. Setting the lower height limit:
(1) Adjust the desk to the preferred lower height limit.
(2) Press and buttons together for less than 3 seconds, holding and release button. (Note 3)
(3) Re-press for more than 3 times in a slow pace.
(4) A beeping sound will notify you that the process has been completed.
D. Disable the lower height limit:
(1) Move the desk to the lower height limit being set.
(2) Repeat instructions #2~4 above to disable the lower limit setting.
Note 2: Some control boxes may not support setting the upper and lower height limit functionality.
Note 3: More than 3 seconds will direct to “Reset” mode.

Hand Control Programming- TDH6
Version 4 August 2021
8 of 10
8
6.Presetting the Desk Starting Height
(1) Press button until the desk reaches its lowest position and then release button. Re-press
button again for 5 seconds and the digital display will flash for 10 seconds.
(2) Adjust the starting height number with the or button.
(3) After 10 seconds, the display will stop flashing and this will confirm that you have successfully set the
starting height.
7.Switching Metric and Imperial Unit
(1) Press memory buttons 1, 2 and M for 5 seconds.
(2) The digital display will show “C-I”. If no further instruction is input within 5 seconds, the system reverts to
normal operation mode.
How to choose a metric unit
Press button 1, the digital display will show “C” to stand for centimeter.
How to choose an imperial unit
Press button 2, the digital display will show “I” to stand for inch.

Hand Control Programming- TDH6
Version 4 August 2021
9 of 10
9
8.Restore Factory Setting
(1) Refer to Chapter 2-Reset: after the “beep” sound, press and buttons together for 15 seconds, the
control box will twice make a “beep” sound, and the digital display will show “---. “
(2) The settings below will restore to the original factory settings:
Memorized position
Desk starting height
Upper and lower height limit
T-touch or TCS1 sensitivity
9.Error Codes
The digital display shows the error codes below to suggest the issues that users may encounter during the
operation. (Note 4)
Error code
Descriptions
000
Resetting
E00
Not reset completely
E01
Overuse protection
E02
Unbalance protection
E03
Anti-collision
E04
T-touch Protection
E11
M1 Motor over-current protection
E12
M2 Motor over-current protection
E13
M3 Motor over-current protection
E21
No Hall sensor from M1
E22
No Hall sensor from M2
E23
No Hall sensor from M3
E31
No current from M1
E32
No current from M2
E33
No current from M3
Note 4: Some control boxes may not support this function.

Hand Control Programming- TDH6
Version 4 August 2021
10 of 10
10
10. Power Saving Function - Waking Up the
Control
The digital display automatically turns off if no buttons are pressed within 25 seconds. Press any button
to light up the display again.
The system goes into <0.1W standby mode (Note 5) if no buttons are pressed within 30 seconds. Long
pressing any button will wake up the system and show desk height on the digital display.
Note 5: It depends on the control box whether it will support 0.1W standby mode or not.
