MP1900A User Guide
Productoverview
Thanksforusingourproduct.Pleasereadthisuserguidecarefully
beforeoperating,andkeepitwell.
MP1900Aisalightweightuniversalrechargeablebattery,youcan
enjoyhoursofextendedtimeonmobilephone,iPhone/iPad/iPod,
PDA,PSP,GPS,blackberryandotherportableconsumerelectronic
products.WithMP1900A,makingitaversatilesolutionforthe
powerneedsofmobileproductsinanytimeanywhere.
Specification
Weight：63g
Dimension：101mm(L)*42.5mm(W)*9.8mm(H)
Cellstyle：Li‐polymer
Capacity：1900mAh(7Wh)
Apple30pinConnector’svoltage/current:5.2V/1A
USBOUTport’svoltage/current:5.2V/1A;
MicroUSBCharginginport’svoltage/current：5V/0.45A
Chargingtime：5h~6h
Batterypower：7.0Wh
Illustrationde s c r i p t i on 
1.CapacityDisplayTouchedkey：
Itwillbedisplaycapacitystatewhilecontactthecapacitydisplay
touchedkeybyyourfinger.
2.CapacityIndicatedLED：Therearetwodifferentcolors(blue&
orange)toindicatethecapacitystatus.

1)Charging:a.0~80%fullycharged:Orangecolor
b.Over80%fullycharged:Bluecolor
2)Discharging:a.100%~10%capacity:Bluecolor
b.Below10%capacity:Orangecolor.
YoushouldchargeforMP1900Aintime.













3.MicroUSBcharginginport：
ChargeforMP1900AbyattachedUSBtomicroUSBcabletoplugin
thisportfromtheUSBportofcharger；thechargingvoltage
/current：5V/0.45A.
4.Twooutputport：
1)Apple30pinConnector:
TheApple30pinConnectorcandirectpluginAppledevice.Itis
settingfastchargeforiPad/iPhone/iPod,iPad2canbecharged
into15%capacityoriPhone4Scanbechargedinto70%capacity
within1hour
1.CapacityDisplay
Touchedkey
2.CapacityIndicatedLED
3.MicroUSB
charginginport
4‐1: Apple30
pinConnector
4‐2:USBOUTport

2)USBOUTport:
TheUSBOUTportissettingfastchargeforMotorola,Sony,Nokia
mobilephonebyattachedcable.Italsocanslowcharging(500mA)
foriPhone/iPod.ButiPadcan’tbechargedbythisport.
5.MP1900AoutputwillautoturnONwhiletheApple30pin
ConnectorpluginloadingdeviceortheUSBOUTportconnected
withit.Itspowerwillturnoffautomaticallyafter30secwhilethe
loadingdevicedisconnectedwithoutputportbyunplugcableor
connector,whichcansavethepowerwhenitidle.
Howtouse:
1.ChargingforMP1900A:
















TheChargerwith
USBOUTport
Chargingby
attachedUSBto
MicroUSBoutput
cable
PluginMicroUSB
charginginport

2.ChargingforyourdevicebyMP1900A:
a.ChargingforiPad/iPhone/iPodbyApple30pinConnector 












C.ChargingforSmartPhonefromtheUSBOUTportofMP1900Aby
TheattachedUSBtoMicroUSBoutputcable:












Apple30pin
Connectorplugin
iPad/iPhone/iPod
directly
Plugin USBOUT port
PlugintheMicroUSBchargingin
portofphone
ChargingbyattachedUSBto
MicroUSBoutputcable

Standardpackage
1.MP1900Amainbody
2.USBtoMicroUSBoutputcable
Troubleshooting
PleaseusethefollowingstepsifMP1900Acannotchargeforyour
device.
1.VerifythatMP1900Ahasbeencompletelycharged.
2.CheckthattheUSBchargingcableisconnectedwellwith
MP1900Amainbody,andcheckwhetherthetipissuitablefor
thepowersocketofyourdevice,ifnot,pleasereplaceanother
tip.
3.Checkyourthedigitaldeviceisinstalledthebattery（Some
digitaldevicecannotworkifnotinstalledbattery）
4.Checkwhetheryourdigitaldeviceisdesignedwithcharging
inputvoltagelimitedcircuit,ifso,MP1900Amaybecannot
chargeandpowerforthedevice.
Warranty
YourMP1900Aisguaranteedagainstoriginaldefectsinmaterials,
manufactureandworkmanshipforoneyearfromthedateof
purchase.
