Tineco FLOOR ONE S7 Series User manual
FLOOR ONE S7 STEAM SERIES
Smart Cordless Steam Floor Washer
Instruction Manual
Инструкция за употреба
Návod k obsluze
Brugervejledning
Bedienungsanleitung
Εγχειρδιο οδηγιν
Manual De Uso
Kasutusjuhend
Käyttöohje
Mode D’emploi
Használati útmutató
Manuale D’istruzioni
Naudojimo instrukcija
Lietošanas rokasgrāmata
Handleiding
Bruksanvisning
Instrukcja obsługi
Manual de Instruções
Manual de instruciuni
Руководство по эксплуатации
Návod na použitie
Navodila za uporabo
Bruksanvisningen
Kullanım Kılavuzu
*Actual product may differ from illustration.
TINECO IS HERE TO HELP.
We’ll get back to you within 1 business day. www.tineco.com
EN
1
CONTENTS
Important Safety Instructions...............................................................2
Specications........................................................................................6
Overview................................................................................................7
Accessories............................................................................................9
Assembly .............................................................................................10
Operation............................................................................................11
Maintenance .......................................................................................16
Troubleshooting..................................................................................20
Warranty ..............................................................................................21
TINECO IS HERE TO HELP.
We’ll get back to you within 1 business day. www.tineco.com
MORE LANGUAGES
ARE AVAILABLE ON OUR OFFICIAL WEBSITE
EN
2
Important Safety Instructions
SAVE THESE INSTRUCTIONS
Household use only.
When using an electrical appliance, basic precautions should always be followed, including
the following:
READ ALL INSTRUCTIONS BEFORE USING (THIS APPLIANCE). Failure to follow the
warnings and instructions may result in electric shock, re and/or serious injury.
WARNING – To reduce the risk of re, electric shock, or injury:
1. This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children should not play with the
appliance. Cleaning and user maintenance shall not be performed by children without
supervision.
2. The appliance is not to be used by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction.
3. Use only indoors, on non-carpeted oor surfaces such as vinyl, tile, sealed wood, etc.
Be careful not to run over loose objects or edges of area rugs. Stalling the brush may
result in premature belt failure.
4. Do not allow to be used as a toy. Close attention is necessary when used by or near
children, pets or plants.
5. Use only as described in this manual. Use only manufacturer’s recommended
attachments.
6. Do not use with a damaged cord or plug. If appliance has been dropped, damaged,
left outdoors, dropped into water, or is not working as it should, return it to a service
center.
7. Do not handle charger, including charger plug, and charger terminals with wet hands.
8. Do not put any object into openings. Do not use with any opening blocked; keep free
of dust, lint, hair, and anything that may reduce air ow.
9. Keep hair, loose clothing, ngers, and all parts of your body away from openings and
moving parts.
10. Use extra care when cleaning on stairs.
11. Do not use to pick up ammable or combustible liquids, such as gasoline, or use in
areas where they may be present.
12. Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot
ashes.
13. Do not use without lter.
14. Prevent unintentional activation. Ensure the switch is in the off-position before picking
up or carrying the appliance. Carrying the appliance with your nger on the switch or
energizing appliance that have the switch on invites accidents.
15. Always switch off the appliance before making any adjustments, changing accessories,
or storing the appliance. Such preventive safety measures reduce the risk of starting the
appliance accidentally.
EN
3
16. Recharge only with the charger specied by Tineco. A charger that is suitable for one
type of battery pack may create a risk of re when used with another battery pack.
17. Use appliances only with specically designated Tineco battery packs. Use of any other
battery packs may create a risk of injury and re.
18. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, ush with water. If liquid comes into eye contact, seek
medical help. Liquid ejected from the battery may cause irritation or burns.
19. Do not use a battery pack or appliance that is damaged or modied. Damaged or
modied batteries may exhibit unpredictable behavior resulting in re, explosion or risk
of injury.
20. Do not expose a battery pack or appliance to re or excessive temperature. Exposure
to re or temperature above 266°F (130°C) may cause an explosion.
21. Follow all charging instructions and do not charge the battery pack or appliance
outside of the temperature range specied in the instructions. Charging improperly or
at temperatures outside of the specied range may damage the battery and increase
the risk of re.
22. Have servicing performed by a qualied repair person using only identical replacement
parts. This will ensure that the safety of the product is maintained.
23. This appliance contains battery cells that are non-replaceable. Do not modify or
attempt to repair the appliance or the battery pack except as indicated in the
instructions for use and care.
24. Always turn off this appliance before connecting or disconnecting the motorized
nozzle.
25. Do not charge or store the appliance outdoors or inside the car. Only charge, store or
use the battery in a dry indoor area where the temperature is higher than 39.2°F (4°C)
but lower than 104°F (40°C). The charger is for indoor use only.
26. Do not use to pick up ultrane particles, such as lime, cement, sawdust, gypsum
powder, or ashes.
27. Do not use to pick up sharp objects, such as metallic nails, pieces of glass, metal paper
clips, or pins.
28. Do not use to pick up hazardous material and chemicals, such as solvent, drain cleaner,
strong acids, or strong alkali.
29. Stop using immediately if the appliance is overheating, making unusual noises,
producing unusual odors, performing low suction, or leaks electricity.
30. Turn cleaner OFF and disconnect from electrical outlet for long-term storage.
31. Always clean the Dirty Water Tank after each use to avoid potential blockage, which
may lead to low suction power, motor overheating, or reduce the service life of the
appliance.
32. Store appropriately indoors in a dry place after use.
33. Do not place or submerge appliance in standing water or try to clean ooded areas.
34. All data and technical instructions of this manual are based on results from lab
tests of Tineco or designated third parties. The company reserves all rights for nal
explanations.
35. The plug must be removed from the socket-outlet before cleaning or maintaining the
appliance.
36. A hazard may occur if the appliance runs over the supply cord.
37. Do not use the appliance when the water depth is more than 5mm above the surface.
EN
4
38. Liquid or steam not directed towards equipment containing electrical components
39. Appliance to be unplugged after use and before user maintenance
40. The appliance shall not be left unattended while it is connected to the supply mains
41. The appliance is not to be used if it has been dropped, if there are visible signs of
damage or if it is leaking;
42. Keep the appliance out of reach of children when it is energized or cooling down.
43. If a vacuum cleaner can be equipped with a hand-held accessory with rotating parts a
warning has to be given concerning entrapment.
44. If the power cord of this device is damaged, it must be replaced by the manufacturer
or its customer service or a similarly qualied person in order to avoid hazards (only for
adapters).
Range of Usage
1. The cordless hard oor cleaner is to be used on indoor hard oors, such as vinyl, tile,
sealed wood, etc. Use on a rough surface may not get the best performance.
2. Keep your appliance away from heat sources, such as replace or heater, to avoid
casing deformation.
3. Do not use to pick up ammable or combustible liquids, ultrane particles, sharp
objects, hazardous material, chemicals or anything that is burning or smoking, as
described above.
About the Appliance
1. Do not modify or attempt to repair the appliance except as indicated in the instructions
for operating and cleaning.
2. Charge the appliance with the Tineco adaptor. Input Voltage: AC 100-240V. Both high
and low voltages can damage the adaptor, appliance, or even cause danger to the user.
3. Use extra care when cleaning on stairs.
4. Ensure that the Power Switch is in the OFF-position before picking up or carrying
the appliance. Do not lay at or lean the appliance so as to prevent dirty water from
entering into the motor.
5. To avoid being tripped accidentally, please put away the appliance on the charging
dock.
6. Always install the Dirty Water Tank and Clean Water Tank properly before use.
7. Do not allow the appliance or charger to get wet to avoid risk of re or injury caused by
a short circuit.
EN
5
Recycling Instructions according to Battery Law
The rechargeable battery which is not detachable contains materials that
are harmful to the environment and therefore must be removed from the
device before disposal. The device must be switched off before removing the
rechargeable battery. Only qualied personnel may remove the battery.
Batteries and rechargeable batteries must not be disposed of in household
waste! Every consumer is obliged to hand in all batteries and rechargeable
batteries, regardless of whether they contain harmful substances or not, at
a collection point in his or her municipality/district or at a retailer, so that
they can be disposed of in an environmentally friendly manner. Batteries and
rechargeable batteries should only be returned when discharged.
Batteries and rechargeable batteries are therefore marked with the symbol left.
Recycling Instructions according to WEEE
The adjacent symbol of a crossed out dustbin on wheels indicates this device
is subject to Directive 2012/19/EU. This directive states at the end of the life
this device must not be disposed of through regular household refuse but must
be returned to special collection sites, recycling depots or waste management
companies. This disposal is free of charge to you.
The following applies to the German market:
When you buy a new device, you have the right to return the corresponding old
device to your dealer. Retailers of electrical and electronic equipment with a
sales area of at least 400 square meters and grocers with a sales area of at least
800 square meters who regularly sell electrical and electronic equipment are
also obliged to take back old equipment free of charge, even without buying
a new one, if the old equipment are in no dimension larger than 25 cm. The
importer offers you take-back options directly in the shops and markets. You
can also nd out about local return options from your retailer.
If your old device contains personal data, you are responsible for deleting it
yourself before you return it. If this is possible without destroying the old device,
remove the old batteries or rechargeable batteries and lamps before you return
the old device for disposal and bring them to a separate collection. In the case
of built-in rechargeable batteries, it must be pointed out when disposing of
them that the device contains a rechargeable battery. You can nd out other
options for disposing of the worn-out product from your community or city
administration.
For EU Countries:
For EU Declaration of Conformity information, please visit www.tineco.com.
EN
6
Symbols:
Read the instruction manual
Class II
Short-circuit-proof safety isolating transformer
Switch mode power supply
For indoor use only
Direct current
Alternating current
Steam
Specications
Product FLOOR ONE S7 STEAM SERIES
AC Input 100-240V~
Voltage 25.2V 3900mAh Lion
Rated Power 240W
Running Time AUTO: 40mins,STEAM/BOOST:20mins
Charging Time 4~5 hrs
Water Flow Rate 20~200ml/min
CWT Capacity ~0.8L
DWT Capacity ~0.72L
Waterproof IPX4
EN
7
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
A. STEAM/BOOST STEAM Button
B. Power On/Off
C. Digital Display
D. Dirty Water Tank Release
E. Dirty Water Tank Handle
F. LED Headlights
G. Self-cleaning Button
H. Tube
I. WiFi/Mute/Language Switch Button
J. Clean Water Tank (CWT)
K. Dirty Water Tank (DWT)
L. Brush
M.Brush Roller Cover
N. Brush Roller
O. Cleaning Tool
P. Dry Filter & Holder
Q. Accessory Holder
R. Adaptor
S. Charging Dock
Overview
EN
8
Digital Display
A. AUTO Mode
B. Steam Making
C. STEAM Mode
D. WiFi Indicator
E. DWT Full
F. CWT Empty
G. BOOST STEAM Mode
H. Brush Roller Tangled
I. Boiler Error
J. Battery
K. Battery level / Steam
preparation countdown
L. Self-cleaning
M.Dirt Monitoring Loop
(Blue to red according to the
dirt amount)
A B C D E F G H I J K ML
EN
9
Accessories
Note:
Accessories may vary between markets. If you require more accessories, please go to www.tineco.com
or store.tineco.com.
Brush Roller
Soft roller head with bristles can be used to vacuum and wash
at the same time. It can be easily cleaned with the self-cleaning
function.
Dry Filter
Dry lter and lter net can block large particles and debris, ensure
the appliance’s durability.
* Please install the dry lter before use, or it may lead to weak
suction.
Cleaning Tool
A full brush to clean the DWT, brush chamber and opening.
The tool also has a bristled end to remove dirt and mud on the
roller and DWT.
EN
10
Assembly
How to Assemble/Disassemble
Note:
For water tank and brush assembly, please refer to “Operation” and “Maintenance”.
click
To assemble the handle, insert it into the
appliance until you hear a click.
In the event that the handle needs to be
disassembled, press the spring to release the
handle with a tool (like a screwdriver) and lift the
released handle from the appliance.
Install the dry lter holder and accessory holder
on the dock.
EN
11
Operation
Preparing for Use
• Before rst use, please charge the appliance for 4-5 hours (refer to “Charging Instructions” for details).
* Based on results from Tineco lab tests. Lab temperature 39.2°F (4°C) ~ 104°F (40°C).
Press the button the appliance will start
in AUTO mode by default, then press
button to switch to STEAM mode, BOOST
STEAM mode or AUTO mode. Press the
again to turn off the appliance after cleaning is
complete.
WiFi/Mute/Language Switch Button
• Press to turn on/off the voice prompt.
• Press twice to switch languages. (More voice
language options will be added, please refer
to the actual product.)
• Hold for 3 seconds to connect to network.
The appliance will stop working when put upright
and start running again when reclined.
* Do not recline more than 142° to avoid water
leakage.
Place the appliance on the charging dock
vertically after use for charging and storing.
Note:
• Selection of the appropriate mode depends on the actual demand.
• Do not vacuum foamed liquid.
• To vacuum water left on the surface, the appliance will keep running for 3 seconds after power off.
EN
12
Filling Clean Water Tank
MAX
Press the Clean Water Tank release button
to remove it from the appliance.
Open the tank cap, and then ll the tank with tap
water to the Max line.
click
Note:
Only use water under 140°F/60°C, don't mix
chemical solution.
DO NOT USE HOT WATER.
Place the tank back into the appliance. You
should hear a “click” sound if done correctly.
Charging Instructions
To charge the appliance, place the appliance on the
charging dock and plug the adaptor into a power
outlet.
1. To charge the appliance, connect the external
charging cord to the charging dock and plug it into
the wall outlet.
2. To avoid tripping hazards, please place the
appliance on the charging dock near a wall during
charging.
Warning:
• Only charge the appliance with the adaptor supplied by Tineco.
• In case of long-term non use, the appliance must be charged once every 3 months for optimal
performance. It may take 4-5 hours for a full charge.
• Store indoors in a dry place. Do not expose the appliance to sunlight or freezing temperatures.
Recommended temperature range: 39.2°F (4°C) ~ 104°F (40°C).
EN
13
Cleaning Mode Selection
AUTO Mode
• In AUTO mode, the iLoop sensor automatically detects how
dirty the oor is and applies the appropriate amount of clean
water and suction power accordingly.
• A red dirt monitoring loop indicates pollutant intensive area,
and a blue loop indicates less pollutants are detected. This
mode automatically applies the best cleaning solution.
STEAM Mode
• Press button to enter into STEAM mode. It will take 20-50s
to prepare steam. And there will be 6 holes to spray steaming.
Apply STEAM Mode when deep cleaning is needed.
BOOST STEAM Mode
• Press button to enter into BOOST STEAM mode. It will take
20-50s to prepare steam. And there will be 2 holes to spray
steaming. Apply BOOST STEAM mode when cleaning for
heavy-polluted area is needed.
SUCTION Mode
• With wi connected, open the APP and select the SUCTION
mode on APP, the appliance will enter into SUCTION mode.
• In SUCTION mode, the appliance will absorb water. We
recommend using this mode on wet surfaces.
Note:
Keep sharp objects away from the digital display screen to avoid scratches and scrapes.
EN
14
Runtime
• In AUTO mode: ~40 minutes
• In STEAM / BOOST mode: ~13 minutes
• Estimated runtime data was obtained by a Tineco Laboratory.
Charging Time
• A full charge takes approximately 4-5 hours.
• Estimated data was obtained by Tineco Laboratory under ambient temperatures between
39.2°F (4°C) to 104°F (40°C).
App
All the functions can be performed using Tineco App. Download the app from App Store, Google Play
and Tineco Ofcial Site.
TinecoTineco
www.tineco.com
Support
App Downloads
GET IT ON
Google Play
Download on the
App Store
App
Downloads
Note:
The default language for voice prompt is English, you can set other languages via App.
EN
15
Voice Prompt (Contents may vary, pleaseinkindprevail.)
Status Reminder
Voice prompts on Voice prompts enabled.
Voice prompts off Voice prompts disabled.
Connect Tineco app Download Tineco app and connect with
appliance.
Turn on the appliance Auto mode.
Switch to Steam mode Steaming Mode.
Switch to Boost Steam mode Boost Steaming Mode.
First time to start the Steam mode/Boost steam
mode
Steam preparation for the rst time is relatively
long, please wait.
Press the STEAM/BOOST STEAM mode button Start preparing the steam.
Steam is ready for use Steam is ready for use.
Clean Water Tank is empty Insufcient water in the Clean Water Tank. Please
add water.
Dirty Water Tank is full Dirty Water Tank is full.Please empty and clean
the Dirty Water Tank.
Need self-cleaning after decting Please turn on self-cleaning function to ensure
effective cleaning.
After self-cleaning
Self-cleaning complete.Please empty and clean
the Dirty Water Tank and the Pipe underneath it
to prevent odors.
Bettery level 10%~20% Battery low.
Bettery level 0%~10% Battery low. Please charge the appliance.
Turn off the appliance Powered off. Place appliance on charging dock.
Ready for charging Charging.
Clean Water Tank is empty during the appliance
working
Insufcient water in the Clean Water Tank,turned
into AUTO mode.
Clean water tank is empty during Steam/Boost
steam mode
Insufcient water in the Clean Water Tank, unable
to make steam.
Dirt water tank is uninstalled Please install the dirty water tank.
Brush cover is uninstalled Please install the brush roller cover correctly.
When Motor, pump or battery goes wrong Error! Please contact customer service.
Select Suction mode on APP Suction Mode.
Detect it is dirty during the appliance works To optimize cleaning performance, please
perform self-clean cycle.
User press the self-cleaning button when the
appliance is dormant
Please place appliance on the charging dock to
begin self-cleaning.
EN
16
Maintenance
Note:
• For optimal performance and odor avoidance, always clean and dry DWT, lters, brush roller, brush
roller cover completely after each use.
• Please make sure each part is installed correctly or the appliance may not work properly.
• Do not soak the appliance.
• Some water may remain in the appliance due to factory inspection.
• After maintenance, place the appliance on the charging dock vertically. Do not expose the appliance
to direct sunlight, store it indoors in a dry place.
Main Body
To reduce the risk of injury, switch off before
performing maintenance.
Use a cloth to clean the surface with neutral
detergent. The cloth should be dry to prevent
water from entering the appliance.
Solid red light
When iLOOP illuminates red, remove Dirty Water
Tank, clean the dirt sensor with a damp cloth or
the cleaning tool.
EN
17
Dirty Water Tank
• When dirty water reaches the Max line, the appliance then stops working, shows a remainder on the
display and plays a voice prompt.
• Pull up the tank lid to empty the DWT. Use the cleaning tool to remove remaining debris. Rinse the
inside of the DWT and then place back into the appliance.
Dirty Water Tank Lid
If the Dirty Water Tank lid and the lter inside are blocked, remove the tank lid and the lter, rinse both
parts with water.
Dry Filter
Grasp recessed area on each side of the dry lter and pull upward. Rinse the lter under running water
and it must be completely dry before recombining with the DWT lid.
*A spare dry lter is provided with your appliance for convenient replacement.
click
EN
18
Self-cleaning
1. Place the appliance on the charging dock after use,
the sensor will auto-detect the level of dirt.
2. Press the self-cleaning button, and the appliance will
select the self-cleaning mode based on the actual
battery level for self-cleaning.
3. Once complete, please clean the Dirty Water Tank.
And the appliance will begin charging.
Note:
• Ensure the charging dock is plugged under Self-
cleaning mode:
• When battery level<10%, press the Self cleaning button,
charging instead of self-cleaning will be activated rst.
• When battery level>10%, press the Self-cleaning
button, self-cleaning with normal water temperature will
be activated.
• When battery level>20%, press the Self cleaning button,
self-cleaning with steam will be activated.
• Before self-cleaning cycle, please clean the DWT and
ensure the water level in the CWT>40%.
Brush Roller Cover
②
①
Squeeze latches on the cover and pull upward to
remove.
Rinse with water.
While replacing, always latch the brush cover into
place to avoid leakage.
click
click
EN
19
Brush Roller
Remove the brush roller by grabbing the
brush roller tab and pulling out.
Use the cleaning tool to remove hair and debris
wrapped around the roller and rinse the roller
with water. Put the brush roller back into the
accessory holder, and allow it to dry completely
before reinstalling.
Wash and remove hair and debris from the
brush roller chamber with water and cleaning
tool.
Replace the brush roller by inserting its end into
the left side of the holder, then attach the roller
tab to the magnetic buckle on the right side to
lock into place.
Note:
• A spare brush roller is provided with your appliance for convenient replacement.
• To maintain optimal performance, replace the brush roller every 8 months.
SCAN THE QR CODE BELOW TO
GET PRODUCT CARE VIDEOS.
Other manuals for FLOOR ONE S7 Series
3
Table of contents
Languages:
Other Tineco Steam Cleaner manuals
