Tiptop Audio Z8000 User manual

RESET DIRECTION CLOCK
RESET DIRECTION CLOCK
A B C D
1
2
3
4
DIR
RT CK CK
CVA CVB CVC CVD
CV1
CV2
CV3
CV4
1
2
3
4
A
B
C
D
Z8000 MATRIX SEQUENCER/PROGRAMMER
DIR
RT
www,tiptopaudio..com

The Z8000 Matrix Sequencer is a powerful tool in a small package. Contained within
it's structure are the following:
a) Four 4 step sequencers on the horizontal (1/2/3/4).
b) Four 4 step sequencers on the vertical (A/B/C/D).
c) One 16 step sequencer aggregating all four horizontal 4 step sequencers in order
from top to bottom, left to right ( ).
d) One 16 step sequencer aggregating all four vertical 4 step sequencers in order from
left to right, top to bottom ( ).
Thus, giving you a total of ten sequencers in all.
INPUT/OUTPUT
Each and every sequence has its own individual CV output as well as Clock, Direction
& Reset inputs. The grouped 4 step sequencers each share anormalized connection
to the Clock. Allowing, for instance; a single clock to guide all four horizontal 4 steps
from only one connection. The same applies for the four vertical sequences. (ex:
plugging in a new timing signal into the third Clock while the first Clock still has its jack
in place would make sequences 1 & 2 of the group run at a separate rate than
sequences 3 & 4.) On the other hand Direction & Reset Inputs are not normalized in
order to keep these functions independent. The Tiptop Stackcable is ideal to be used
to distribute a Reset signal to many sequences at once.
Reset is simple. A gate high signal triggers that particular sequencer to reset back to
step one.
Direction works so that with a gate low the sequencer travels forward. A gate high
signal dictates the sequencer travels backwards.
The Z8000 has a very fast response time and will be triggerd by long and even very
short pulses. The electrical noise caused by inserting a plug into a normalized clock
input might cause some of the sequencers to step, this behavior is normal. A
cascaded Reset signal using Stackcables will reset all sequencers in a group back in
line if desired. The CV output of each sequencer can be set to 0-10V or 0-5V using the
jumpers on the back of the module. Factory set is 0-10V on all outputs.
INTRODUCTION

The Z8000 uses multicolored LEDs to help with visual feedback. The red lights are
assigned to the eight 4 steps, the green lights are assigned to the two 16 steps & lastly
the yellow lights engage when a 4 step red light & 16 step green light intersect that
specific LED. In addtion to that, when two 4 step sequencer red lights engage the light
intensity of that led increases by about 35%.
Whether the sequencer is clocked or not, its knobs and lights are still on and
functioning. (ex: the red led of step A of sequencer 1 is on, plug the CV1 out and turn
that knob, you will hear that the step is “alive”.
LEDs
RESET DIRECTION CLOCK
RESET DIRECTION CLOCK
A B C D
1
2
3
4
DIR
RT CK CK
CVA CVB CVC CVD
CV1
CV2
CV3
CV4
1
2
3
4
A
B
C
D
Z8000 MATRIX SEQUENCER/PROGRAMMER
DIR
RT

CV OUT RANGE
Changing the CV out range.
On the back of the Z8000 are jumpers that are used to set the CV out range of each
sequencer in the Z8000, they are labeled CV RANGE. When the jumpers are set on
both pins the range is 0-10V and when are removed the range is 0-5V. The factory
default is 0-10V. There are total of 10 jumpers you can adjust. The horizontal and
vertical 16 steps are the two on the top with graphics that match the front panel
graphics. The eight 4 steps sequencers have lines indicating horizontal and vertical,
each one can be set individually. There are two more jumpers on the bottom, they are
not labeled and are used during production.
APPLICATIONS
The Z8000 is very simple to use but can create some extremely complex control
patterns. Each sequencer can be made to step very slow or very fast up to audio
rate. Each CV output has the capability to drive many inputs. One of the fun
applications with the Z8000 is to patch one of the sequencer’s CV out back to the
clock
frequency input, creating a “swing” in the movement from step to step. The Z8000 has
10 CV outputs that can modulate 10 prameters in your modular, having them change
polyrhythimcally, making things move.
Although the word ‘sequencer’ is mostly known as playing a sequence of tones
(controlling the pitch of a VCO), the Z8000 is by no means restricted to doing only
that. The Z8000 is a note sequencer but also a modulation sequencer and a
programmer of events that happen in a predetermined time.
The Z8000 modular structure makes it interesting to combine with various clock
modifiers such as Clock dividers, Clock sequencers, etc.
As a note sequencer the Z8000 will work well with the QuantiZer to create melodies
within a scale. Please check the QuantiZer user manaul for more information
about that.
We hope you will enjoy your Z8000.
