Kvaser DB9-Power Inlet User manual

Kvaser DB9-Power Inlet User’s Guide
Copyright 2018-2018 Kvaser AB, Mölndal, Sweden
http://www.kvaser.com
Printed Monday 26th November, 2018
We believe that the information contained herein was accurate in all respects at the time of printing.
Kvaser AB cannot, however, assume any responsibility for errors or omissions in this text. Also note
that the information in this document is subject to change without notice and should not be construed
as a commitment by Kvaser AB.

Kvaser DB9-Power Inlet User’s Guide 2 (12)
(This page is intentionally left blank.)
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser DB9-Power Inlet User’s Guide 3 (12)
Contents
1 About this manual 4
2 Introduction 5
2.1 Welcome to Kvaser DB9-Power Inlet . . . . . . . . . . . . . . . . . . 5
2.2 Major features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3 Kvaser DB9-Power Inlet hardware 7
3.1 Power Distribution . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4 Appendices 8
4.1 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5 Disposal and Recycling Information 9
6 Legal acknowledgements 10
6.1 Usage warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6.2 EU Regulatory Compliance . . . . . . . . . . . . . . . . . . . . . . . 11
7 Document Revision History 12
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser DB9-Power Inlet User’s Guide 4 (12)
1 About this manual
This manual is intended for Kvaser DB9-Power Inlet users. This document
contains a description of the hardware’s properties.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser DB9-Power Inlet User’s Guide 5 (12)
2 Introduction
This section will describe the functions and features of the Kvaser DB9-Power Inlet.
2.1 Welcome to Kvaser DB9-Power Inlet
Figure 1: Kvaser DB9-Power Inlet
Kvaser DB9-Power Inlet is a power injector for CAN busses from a DC power jack
into one female D-SUB9 connector. The Kvaser DB9-Power Inlet also has one
unpowered male D-SUB9 connector for connecting to the CAN network. The
Kvaser DB9-Power Inlet provides a simple and safe way to supply Kvaser bus
powered interfaces with power, such as Kvaser’s Blackbird and Memorator series.
Device Product Number (EAN)
Kvaser DB9-Power Inlet 73-30130-00973-8
Table 1: Kvaser DB9-Power Inlet device and product number.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser DB9-Power Inlet User’s Guide 6 (12)
2.2 Major features
•Acts as a power injector through the female D-SUB9 connector only.
•Connects to power supply using a standard 2.0 mm DC power connector.
•A complementary 12 V, 1 A power supply is included.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser DB9-Power Inlet User’s Guide 7 (12)
3 Kvaser DB9-Power Inlet hardware
Kvaser DB9-Power Inlet is a power injector for CAN buses which supplies power
from pin 1 (center) of the DC 2.0 mm Power jack to pin 9 on the female D-SUB9
connector. DC ground, pin 2 (outside) of the power jack is connected to pin 3 of
both the female and male D-SUB9 connector. Pin 1 to 8 of the female and male
D-SUB9 connector are interconnected, see Table 2.
male D-SUB9 female D-Sub9 DC Jack
1 1 Not connected
2 2 Not connected
3 3 2 (outside)
4 4 Not connected
5 5 Not connected
6 6 Not connected
7 7 Not connected
8 8 Not connected
Not connected 9 1 (center)
Table 2: Pin configuration of the Kvaser DB9-Power Inlet.
3.1 Power Distribution
The Kvaser DB9-Power Inlet should be powered from an external 12 V 1 A power
supply, via a 2.0 mm x 6.3 mm connector, providing a power source for Kvaser CAN
interfaces via CAN_V+ (pin 9) in the female D-SUB9 connector.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser DB9-Power Inlet User’s Guide 8 (12)
4 Appendices
In this section you will find technical information about the Kvaser DB9-Power Inlet.
4.1 Technical data
In Table 3 below you will find the Kvaser DB9-Power Inlet’s technical specifications.
Galvanic isolation No
Supply Voltage Up to 35 V, 1 A
Dimensions 55 x 90 x 30 mm
Weight 100 g
Operating temperature −30 ◦C to +80 ◦C
Storage temperature −40 ◦C to +85 ◦C
Relative humidity 0 % to 85 % (non-condensing.)
Table 3: Technical Specifications.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser DB9-Power Inlet User’s Guide 9 (12)
5 Disposal and Recycling Information
When this product reaches its end of life, please dispose of it
according to your local environmental laws and guidelines.
For information about Kvaser’s recycling programs, visit:
http://www.kvaser.com/en/kvaser/recycling-policy.html
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser DB9-Power Inlet User’s Guide 10 (12)
6 Legal acknowledgements
6.1 Usage warning
WARNING FOR ALL USERS
WARNING! - YOUR USE OF THIS DEVICE MUST BE DONE WITH CAUTION AND A FULL
UNDERSTANDING OF THE RISKS!
THIS WARNING IS PRESENTED TO INFORM YOU THAT THE OPERATION OF THIS DEVICE
MAY BE DANGEROUS. YOUR ACTIONS CAN INFLUENCE THE BEHAVIOR OF A CAN-BASED
DISTRIBUTED EMBEDDED SYSTEM, AND DEPENDING ON THE APPLICATION, THE
CONSEQUENCES OF YOUR IMPROPER ACTIONS COULD CAUSE SERIOUS OPERATIONAL
MALFUNCTION, LOSS OF INFORMATION, DAMAGE TO EQUIPMENT, AND PHYSICAL
INJURY TO YOURSELF AND OTHERS. A POTENTIALLY HAZARDOUS OPERATING
CONDITION IS PRESENT WHEN THE FOLLOWING TWO CONDITIONS ARE
CONCURRENTLY TRUE: THE PRODUCT IS PHYSICALLY INTERCONNECTED TO A REAL
DISTRIBUTED EMBEDDED SYSTEM; AND THE FUNCTIONS AND OPERATIONS OF THE
REAL DISTRIBUTED EMBEDDED SYSTEM ARE CONTROLLABLE OR INFLUENCED BY THE
USE OF THE CAN NETWORK. A POTENTIALLY HAZARDOUS OPERATING CONDITION MAY
RESULT FROM THE ACTIVITY OR NON-ACTIVITY OF SOME DISTRIBUTED EMBEDDED
SYSTEM FUNCTIONS AND OPERATIONS, WHICH MAY RESULT IN SERIOUS PHYSICAL
HARM OR DEATH OR CAUSE DAMAGE TO EQUIPMENT, DEVICES, OR THE SURROUNDING
ENVIRONMENT.
WITH THIS DEVICE, YOU MAY POTENTIALLY:
•CAUSE A CHANGE IN THE OPERATION OF THE SYSTEM, MODULE, DEVICE,
CIRCUIT, OR OUTPUT.
•TURN ON OR ACTIVATE A MODULE, DEVICE, CIRCUIT, OUTPUT, OR FUNCTION.
•TURN OFF OR DEACTIVATE A MODULE, DEVICE, CIRCUIT, OUTPUT, OR
FUNCTION.
•INHIBIT, TURN OFF, OR DEACTIVATE NORMAL OPERATION.
•MODIFY THE BEHAVIOR OF A DISTRIBUTED PRODUCT.
•ACTIVATE AN UNINTENDED OPERATION.
•PLACE THE SYSTEM, MODULE, DEVICE, CIRCUIT, OR OUTPUT INTO AN
UNINTENDED MODE.
ONLY THOSE PERSONS WHO:
(A) ARE PROPERLY TRAINED AND QUALIFIED WITH RESPECT TO THE USE OF THE
DEVICE,
(B) UNDERSTAND THE WARNINGS ABOVE, AND
(C) UNDERSTAND HOW THIS DEVICE INTERACTS WITH AND IMPACTS THE FUNCTION
AND SAFETY OF OTHER PRODUCTS IN A DISTRIBUTED SYSTEM AND THE APPLICATION
FOR WHICH THIS DEVICE WILL BE APPLIED, MAY USE THE DEVICE.
PLEASE NOTE THAT YOU CAN INTEGRATE THIS PRODUCT AS A SUBSYSTEM INTO
HIGHER-LEVEL SYSTEMS. IN CASE YOU DO SO, KVASER AB HEREBY DECLARES THAT
KVASER AB’S WARRANTY SHALL BE LIMITED TO THE CORRECTION OF DEFECTS, AND
KVASER AB HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY OVER AND ABOVE THE
REFUNDING OF THE PRICE PAID FOR THIS DEVICE, SINCE KVASER AB DOES NOT HAVE
ANY INFLUENCE ON THE IMPLEMENTATIONS OF THE HIGHER-LEVEL SYSTEM, WHICH
MAY BE DEFECTIVE.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser DB9-Power Inlet User’s Guide 11 (12)
6.2 EU Regulatory Compliance
Company Name:
Postal address:
Postcode:
City:
Telephone number:
E-mail address:
Product:
EU Declaration of Conformity (DoC)
We
Kvaser AB
Aminogatan 25
431 53
M¨olndal
[phone]
[e-mail]
declare that the DoC is issued under our sole responsibility and belongs to the following product:
Kvaser DB9-Power Inlet
Object of the declaration (identification of apparatus allowing traceability):
Product: Kvaser DB9-Power Inlet
Type: 73-30130-00973-8
The object of the declaration described above is in conformity with the relevant Union harmonisation
legislation:
RoHS recast Directive 2011/65/EU (Art. 4.1)
The following harmonised standards and technical specifications have been applied
(title, date of standard/specification):
EN 50581 (2012)
Signed for and on behalf of:
M¨olndal
Place of issue
2018-10-04
Date of issue Claes Haglund, Supply Chain and Quality director
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser DB9-Power Inlet User’s Guide 12 (12)
7 Document Revision History
Version history for document UG_98213_db9_power_inlet:
Revision Date Changes
1.0 2018-05-04 Initial version
1.1 2018-05-16 Updated supply voltage and compliance text
2.0 2018-10-15 Updated EU Regulatory Compliance, minor textual
updates
