Titan NETMASTER TP-NM-R/2000 User manual

NETMASTER TP-NM-R/2000
BACnet MS/TP to IP Router c/w Remote Access

t: [phone] ● e: [email protected] ● w: www.titanproducts.com
UK DESIGNED, DEVELOPED AND MANUFACTURED
Ref: SKU 224
Description
The Titan Products TP-NM-R/2000 NetMaster Router is a high performance, intelligent and secure communications
product designed to route BACnet MS/TP network points to BACnet IP.
The TP-NM-R/2000 is fully compatible with the Titan Products Remote Access App download for IOS and Android devices.
When added to a BACnet network and broadband router, the TP-NM-R/2000 allows the user to remotely control the
compatible BACnet devices connected to the network or set a exible time schedule remotely for these devices through a
smart phone or tablet device.
Designed and manufactured by Titan Products in the UK, the router’s feature set includes, remote access capabilities,
secure setup HTML5 webpages, secure BACnet routing and Backup and Restore.
The TP-NM-R/2000 also offers advanced 10/100 Mbps Ethernet communications and supports MS/TP baud rates from
9,600 to 76,800 bps. Flexible routing for 2 x BACnet/IP networks is available as standard while all web pages are password
protected for added security. Intelligent BACnet/IP networking is catered for via standard features such as BACnet
Broadcast Management Device (BBMD) and Foreign Device Registration (FDR).
The TP-NM-R/2000 can be easily updated on site to the latest software while installation is quick and easy with the
DIN rail mounted enclosure. Backup and Restore functionality allows the TP-NM-R/2000 to update the rmware of any
connected Titan MS/TP devices within the network.
Features
•
Full compatible with Titan Remote Access App
•
Backup and Restore
•
BACnet MS/TP to BACnet/IP Routing
•
2 x BACnet/IP Networks
•
Powerful Routing capabilities
•
Embedded HTML5 webpages for network
commissioning and set up
•
Responsive HTML5 web pages for smart mobile
support
•
Download updates on site
•
Windows CE Operating System
•
BACnet Broadcast Management Device (BBMD)
Support
•
Foreign Device Registration (FDR) Support
•
MS/TP Slave Proxy Support
•
10/100 Mbps Ethernet
•
MS/TP baud rates range for 9600 to 76800 bps
•
Password protected web pages
•
Optically isolated MS/TP port
•
DIN Rail Mounted
•
24V AC/DC Supply
Specication
Power Supply 24V AC/DC +/-10%
Power Consumption 5VA MAX
CPU ARM9
CPU Frequency 454 MHz
Operating System Windows CE
Memory 64Mb SDRAM
128Mb NAND Flash
Connections 1 x RJ45 10/100 shielded
Fast-Ethernet Port
1 x serial port EIA-485
BACnet MS/TP opto-isolated
termination
1 x USB (OTG) used for
programing tool
LED Indication RxD LED
TxDLED
Power LED
Network Bias Resistors 2 x 560 Ohms (software selectable)
Termination Resistor 1 x 120 Ohms (software selectable)
Communications 10/100 Mbps Ethernet
Optically isolated MS/TP port
MS/TP baud rates range for 9600 to
76800 bps
Operating Temperature 0 – 40°C
Operating Humidity 20 – 80% RH Non-condensing
IP Rating IP20
Enclosure Plastic Rating L94-VO
Mounting DIN Rail
Dimensions 160mm wide x 90mm high x 32mm
Reset Switch Yes
Country of Origin UK
Product Code TP-NM-R/2000

t: [phone] ● e: [email protected] ● w: www.titanproducts.com
UK DESIGNED, DEVELOPED AND MANUFACTURED
Ref: SKU 224
Dimensions
Connections
90mm
160mm
32mm
BACnet RS485 MSTP
3 Wire
COM +ive -ive
LED
Ethernet
IP RJ45
IP
Reset
Power
Supply
24V AC/DC
0v 24V

t: [phone] ● e: [email protected] ● w: www.titanproducts.com
UK DESIGNED, DEVELOPED AND MANUFACTURED
Ref: SKU 224
BACnet MS/TP Network Connections & Information
Based on the standards for RS485 networks, a BACnet MS/TP network layer allows for only a daisy-chained network
conguration, consisting of a single cable routed between controllers. Note: Star and Ring network topologies are not
supported.
The network electrically supports a maximum of 127 nodes, however BUS network size capability is determined by factors
such as network trafc and BMS capabilities and Titan Products recommend maximum network size of 64 devices.
To comply with the EIA-485 standard, the maximum number of nodes per segment shall be 32 and any additional nodes
will require the use of repeaters. If only Titan controllers are on the MS/TP network, the number of controllers may be
increased but this will depend on the network trafc, the baud rate being used and the length/route of the cable.
A termination resistor of 120 ohms should be connected at each of the end devices. Bias resistors should be used to bias
the network at either a single point or at each end of a network segment.
Note: End of line resistor optional selection within NetMaster software
User Screens
The TP-NM-R/2000 NetMaster Router from Titan Products is supplied with an intuitive and easy to use user interface for
set up. All user screens are designed using HTML5 framework and offer responsive web pages which automatically adapt
and resize for the screen type and device being used. This ensures the user interface remains easy to use on all devices
including desktop, laptop and smart phone and tablet screens.
Screen
Screen
120 ohm resister
(normally)
Terminal
Com + -
MS/TP Device
Com + -
MS/TP Device
+
Com -
TP-NM-R
NetMaster
(normally)
NetMaster

t: [phone] ● e: [email protected] ● w: www.titanproducts.com
UK DESIGNED, DEVELOPED AND MANUFACTURED
Ref: SKU 224
The user screens are accessed through a web browser once the TP-NM-R/2000 NetMaster Router is connected
to the local IP network via the TP-NM-R/2000’s IP address (192.168.1.151 default) using the default username
‘ADMIN’ and password ‘admin’. Note that this password can be changed in the Admin screens.
It is recommend to bookmark http://192.168.1.151/Admin/AdminLogin.asp (edit IP address if required) if
bookmarking the webpages within the TP-NM-R/2000. This will ensure the most current network information
is shown once logged in.
Note: It is possible to reset the IP address and username / password to their default settings by pressing down the IP reset
button for approximately 10 seconds. The LED will begin to ash slowly and then turn off. When the LED is off, release the
reset button and the following settings will be restored. Please power cycle the TP-NM-R/2000 after the resetting.
• IP Address (192.168.1.151)
• Subnet Mask (255.255.255.0)
• Default Gateway (192.168.1.254)
• Username ‘admin’ and password ‘admin’
The user screens allow the user to view:
• The NetMaster TP-NM-R/2000 Home Screen and current rmware settings
• The NetMaster TP-NM-R/2000 set up
• Admin pages
• BBMD, FDR setup & Broadcast Distribution Tables
• MS/TP and Network diagnostics screens
• Firmware update screens
• Backup & Restore screens
• Contact screens

t: [phone] ● e: [email protected] ● w: www.titanproducts.com
UK DESIGNED, DEVELOPED AND MANUFACTURED
Ref: SKU 224
Setup
Device Setup:
Device ID A unique network wide device number in the range 0 to 4194302. Ensure this is unique
to all other devices on the network.
Device Name This is the name of the device E.g. Router 1.
APDU Timeout This is the time to wait in m/s before re-transmitting an unacknowledged message
APDU Retries This is maximum number of times an unacknowledged message is re-transmitted
Locations This is the physical location the device is installed
Description This is a description of the installed device
IP Primary Setup:
IP Address The default IP Address is 192.168.1.151. This must to be set to a valid IP address which is
unique to the local network. In the case of the default network this would be 192.168.1.x
where x is in the range 0-254.
Subnet Mask This is the current Subnet Mask address of the router (255.255.255.0 default). Devices on
the same subnet should all use the same subnet mask.
Default Gateway The default is 192.168.1.254. This should be set to the IP address of the router that is
assumed to know how to forward packets on to other networks, dening where to send
packets for IP addresses for which they can determine no specic route.
UDP Port This the port being used for BACnet and must match other devices on the same
BACnet Network.
Multicast Address Please enter a valid Multicast address or remove if not required.
BACnet Network Number This is the BACnet Network number for BACnet IP.
IP Secondary Setup:
Enable Port Enable/Disable the secondary IP port
UDP Port This the port being used for BACnet and must match other devices on the same BACnet
Network.
Multicast Address Please enter a valid Multicast address or remove if not required.
BACnet Network Number This is the BACnet Network number for BACnet IP.
Public IP Address If the TP-NM-R/2000 is being accessed through a NAT router, please enter the public IP
address of the NAT router or remove if not required.
MS/TP Setup:
MAC Address This is a unique MAC reference given to each device on the network. This needs to
be unique for each devices and ranges from 0-127.

t: [phone] ● e: [email protected] ● w: www.titanproducts.com
UK DESIGNED, DEVELOPED AND MANUFACTURED
Ref: SKU 224
Baud Rage Select the Baud Rate from the drop down menu. The baud rate should be the same for
each device on the network.
Max Masters The maximum permitted MS/TP master device address. If unknown, or future devices are
expected, then this should be left at the default 127.
Max Info Frame The number of messages that can be sent once a token has been received. A value of
between 10 and 20 is recommended.
Enable Bias It is recommended to bias the network at either a single point or at each end of a
segment.
Enable Termination It is recommended to terminate both ends of the network using 120 ohm resistors.
BACnet Network Number This is the BACnet Network number for MS/TP Port.
Router Setup:
Send Establish Connection This instructs a BACnet half router to establish communications when the PTP link is
to Network currently inactive.
Establish Connection The time in seconds that the PTP connection should remain active in the absence of
Termination Time messages being sent. Use a value of 0 to indicate a permanent connection.
BBMD (BACnet Broadcast Management Device) & FDR (Foreign Device Registration) Setup
The BACnet Broadcast Management Device (BBMD) page is used
to control the Broadcast Distribution Table (BDT) for the primary
and secondary IP Ports. It also displays any Foreign Devices that are
registered on each Port.
Note: The maximum number of BDT entries is set to 50 for each port.
The Maximum number of Foreign Devices is also set to 50 for each
Port.
BDT entries can be added, removed and the whole table submitted
using the webpage buttons. The table can also be updated via
BACnet. To add a BDT, enter the IP address of the BBMD devices
and its associated Distribution Mask
(default = 255.255.255.255). Once all BBMD devices have been
added for each port select submit.
Note: If the IP Router being used can transmit broadcast messages, the Distribution Mask can be set to the same mask as on
the IP Router. This will cause any broadcast messages to be handled by the IP router.
Foreign Devices are BACnet devices that are on a different IP Subnet to the TP-NM-R/2000 and have been registered with
it to send/receive BACnet broadcasts.

t: [phone] ● e: [email protected] ● w: www.titanproducts.com
UK DESIGNED, DEVELOPED AND MANUFACTURED
Ref: SKU 224
MS/TP Setup
The MS/TP page displays the manually setup MS/TP slave
proxy devices and any detected devices on the MS/TP Port. The
maximum Slave Proxy entries is set to 100.
Slave Proxy entries can be added, removed and the whole table
submitted using the buttons on the webpages. Each entry consists
of an MS/TP MAC address and associated Device ID while any
other required parameters are automatically retrieved from the
slave device.
The detected MS/TP devices (both Master and manually setup
Slaves) are displayed in the table with their MAC address and
associated Device ID. Please allow a couple of minutes for the
devices to be added/removed from the table once edited.
Diagnostics
The TP-NM-R/2000 includes a Diagnostics webpage which provides real time information of the routers performance and
active applications. This is designed to help with any troubleshooting while on site. For more information contact Titan
Products.
Updating the TP-NM-R/2000
To update the TP-NM-R/2000 router to the latest software please follow the below instructions:
• Check the ‘Update Enabled’ check box on the Admin login page
• Open Internet Explorer and enter the TP-NM-R/2000 FTP address into the URL address bar (default FTP
address = ftp://192.168.1.151/)
• Copy and Paste the update le to the TP-NM-R/2000
• Once the update le has been uploaded, uncheck the ‘Update Enabled’ check box on the Admin login page
and the router application will be re-started.
• All updates are encrypted and can only be accessed with a password.
LED Indication
LED Indication: LED Status Action
Permanently On Router is ON and operating
Flashing Slowly Router re-setting
Flashing Quickly Router applying any updates

t: [phone] ● e: [email protected] ● w: www.titanproducts.com
UK DESIGNED, DEVELOPED AND MANUFACTURED
Ref: SKU 224
Remote Access
When connected to a Broadband router via an Ethernet connection, the TP-NM-R/2000 NetMaster router with Remote
Access allows the user to adjust their comfort settings and set up a comprehensive time schedule for any connected and
compatible MS/TP Titan controllers on the network via the Titan Products Remote Access App download.
The Titan Products App is available for download via the Apple App Store and the Google Play Store for Android devices.
Backup and Restore
Backing up software les:
Select the Update tab to view connected controllers and Backup options.
To back up the rmware, conguration or RDU screen les within a controller, select the le type you would like to Backup
under the Backup dropdown. The le will then begin to download.
Once the Backup has completed, you will be able to click the le and save.

t: [phone] ● e: [email protected] ● w: www.titanproducts.com
UK DESIGNED, DEVELOPED AND MANUFACTURED
Ref: SKU 224
Updating the controllers with new software or restoring from a backup:
From with the Update tap, select the controllers you would like to update or restore and press the Update Controllers
button.
Browse and select the le from the connected PC or Laptop you would like to use to update the controllers. The update
will then begin.
Once updated, Firmware Success will show. The controllers are now updated to the new software.
