Titan TTI821GGT User manual

TTI821GGT
Original Instructions_MNL_TTI821GGT_V1_211025
WARNING: Read the instructions before using the product!
EN
Cordless grass
trimmer
18V 25cm SOLO

EN
02
Let’s
Getting started...
In more detail...
get started...
These instructions are for your safety. Please read through them
thoroughly before use and retain them for future reference.
Safety information
Your product
Before you start
Product functions
Operation
Care and maintenance
Troubleshooting
Recycling and disposal
Guarantee
Technical specications
Declaration of conformity
02
03
15
16
20
21
25
30
33
34
35
37
39

EN
03
TTI821GGT by TITAN
Getting started...
Safety information
Safety warnings
General safety warnings
1. Never allow children, persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge or people unfamiliar with these
instructions to use the machine, local regulations may
restrict the age of the operator.
2. Children shall not play with the appliance.
3. Cleaning and user maintenance shall not be made by
children.
1. Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
2. Do not operate power tools in explosive
atmospheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
3. Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose
control.
General power tool safety warnings
Work area safety
WARNING! Read all safety warnings,
instructions, illustrations and specications
provided with this power tool. Failure to follow
all instructions listed below may result in electric
shock, re and/or serious injury.
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers to
your mains-operated (corded) power tool or
battery-operated (cordless) power tool.

EN
04
TTI821GGT by TITAN
Getting started...
Electrical safety
1. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodied plugs and matching outlets will reduce risk of
electric shock.
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
3. Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electric shock.
5. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock.
6. If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
Personal safety
1. Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under the
inuence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personal injury.
Safety warnings
Safety information

EN
05
TTI821GGT by TITAN
Getting started...
2. Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
3. Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch on
invites accidents.
4. Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to
a rotating part of the power tool may result in personal
injury.
5. Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpected situations.
6. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair can
be caught in moving parts.
7. If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
8. Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
severe injury within a fraction of a second.
Safety information

EN
06
TTI821GGT by TITAN
Getting started...
Power tool use and care
1. Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
2. Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
3. Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting
the power tool accidentally.
4. Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained
users.
5. Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
6. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
Safety warnings
Safety information

EN
07
TTI821GGT by TITAN
Getting started...
7. Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a hazardous
situation.
8. Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
Battery tool use and care
1. Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of re when used with
another battery pack.
2. Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and re.
3. When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause burns
or a re.
4. Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation or burns.
5. Do not use battery pack or tool that is damaged or
modified. Damaged or modified batteries may exhibit
unpredictable behaviour resulting in re, explosion or risk
of injury.
Safety information

EN
08
TTI821GGT by TITAN
Getting started...
6. Do not expose a battery pack or tool to fire or
excessive temperature. Exposure to re or temperature
above 130 °C may cause explosion.
7. Follow all charging instructions and do not charge
the battery pack or tool outside the temperature
range specified in the instructions. Charging
improperly or at temperatures outside the specified
range may damage the battery and increase the risk of
re.
Service
1. Have your power tools serviced by a qualied repair
person using only identical replacement parts. This
will ensure that safety of the power tool is maintained.
2. Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers.
Electrically powered grass trimmer safety warnings
IMPORTANT
READ CAREFULLY BEFORE USE
KEEP FOR FUTURE REFERENCE
Training
1. Read the instructions carefully. Be familiar with the
controls and the proper use of the product.
2. Never allow children, persons with reduced physical,
sensory or mental capabilities or lack of experience and\
knowledge or people unfamiliar with these instructions to
use the product. Local regulations may restrict the age of
the operator.
3. Keep in mind that the operator or user is responsible for
accidents or hazards occurring to other people or their
property.
Safety warnings
Safety information

EN
09
TTI821GGT by TITAN
Getting started...
Preparation
1. Before use check the supply and extension cord for
signs of damage or aging. If the cord becomes damaged
during use, disconnect the cord from the supply
immediately. DO NOT TOUCH THE CORD BEFORE
DISCONNECTING THE SUPPLY. Do not use the
machine if the cord is damaged or worn.
2. Before use, always visually inspect the machine for
damaged, missing or misplaced guards or shields.
3. Never operate the machine while people, especially
children, or pets are nearby.
Operation
1. Keep supply and extension cords away from cutting means.
2. Wear eye protection and stout shoes at all times while
operating the machine.
3. Avoid using the machine in bad weather conditions
especially when there is a risk of lightning.
4. Use the machine only in daylight or good articial light.
5. Never operate the machine with damaged guards or
shields or without guards or shields in place.
6. Switch on the motor only when the hands and feet are
away from the cutting means.
7. Always disconnect the machine from the power supply
(i.e. remove the plug from the mains, remove the
disabling device or removable battery)
1) whenever the machine is left unattended;
2) before clearing a blockage;
3) before checking, cleaning or working on the machine;
4) after striking a foreign object;
5) whenever the machine starts vibrating abnormally.
8. Take care against injury to feet and hands from the
cutting means.
Safety information

EN
10
TTI821GGT by TITAN
Getting started...
9. Always ensure that the ventilation openings are kept
clear of debris.
Maintenance and storage
1. Disconnect the machine from the power supply (i.e.
remove the plug from the mains, remove the disabling
device or removable battery) before carrying out
maintenance or cleaning work.
2. Use only the manufacturer’s recommended replacement
parts and accessories.
3. Inspect and maintain the machine regularly. Have the
machine repaired only by an authorized repairer.
4. When not in use, store the machine out of the reach of
children.
Additional safety warnings for battery pack
1. Battery pack needs to be charged before use.
Always refer to the charger’s instruction and charge it
properly.
2. Remove the battery pack from the product when
not in use.
3. Don’t maintain the battery pack on the charger
when not in use.
4. After extended periods of storage, it may be
necessary to charge and discharge the battery pack
several times to obtain the maximum performance.
5. Longer life and better performance can be obtained
if the battery is charged when the air temperature
is between 18 °C and 24 °C. Do not charge the
battery in air temperature below 5 °C or above 40 °C.
This is important as it can prevent serious damage to
the battery.
Safety warnings
Safety information

EN
11
TTI821GGT by TITAN
Getting started...
6. Do not charge battery in a damp or wet location.
Following this rule will reduce the risk of electric shock.
7. Do not disassemble the battery and avoid
mechanical damage to the battery. Risk of short
circuit and fumes may be emitted. Ensure fresh air
and seek medical assistance in the event of discomfort.
8. When disposing of battery pack, keep the battery
pack of different electrochemical systems separate
from each other.
Vibration and noise reduction
To reduce the impact of noise and vibration emission,
limit the time of operation, use low-vibration and
low-noise operating modes as well as wear personal
protective equipment.
Take the following points into account to minimise the
vibration and noise exposure risks:
1. Only use the product as intended by its design and these
instructions.
2. Ensure that the product is in good condition and well
maintained.
3. Use correct attachments for the product and ensure they
are in good condition.
4. Keep tight grip on the handles/grip surface.
5.
Maintain this product in accordance with these instructions
and keep it well lubricated (where appropriate).
6. Plan your work schedule to spread any high vibration
tool use across a longer period of time.
7. Prolonged use of the product exposes the user to
vibrations that can cause a range of conditions
collectively known as hand-arm vibration syndrome
(HAVS) e.g. fingers going white; as well as specific
diseases such as carpal tunnel syndrome. To reduce
this risk when using the product, always wear protective
gloves and keep your hands warm.
Safety information

EN
12
TTI821GGT by TITAN
Getting started...
Emergency
Familiarise yourself with the use of this product by
means of this instruction manual. Memorise the
safety directions and follow them to the letter. This
will help to prevent risks and hazards.
1. Always be alert when using this product, so that
you can recognise and handle risks early. Fast
intervention can prevent serious injury and damage to
property.
2. Switch the product off and remove the battery pack
if there are malfunctions. Have the product checked
by a qualified professional and repaired, if necessary,
before you operate it again.
Residual risks
Even if you are operating this product in accordance
with all the safety requirements, potential risks of
injury and damage remain. The following dangers
can arise in connection with the structure and design
of this product:
1. Health defects resulting from vibration emission if the
product is being used over long periods of time or not
adequately managed and properly maintained.
2. Injuries and damage to property due to broken
attachments or the sudden impact of hidden objects
during use.
3. Danger of injury and property damage caused by ying
objects.
Safety information
Safety warnings

EN
13
TTI821GGT by TITAN
Getting started...
Symbols
On the product, the rating label and within these instructions you will nd among
others the following symbols and abbreviations. Familiarise yourself with them
to reduce hazards like personal injuries and damage to property.
V Volt, (direct current voltage)mAh Milliampere per hour
/min or Per minute °C Degree Celsius
min-1
g Gram kg Kilogram
mm Millimetre m Metre
cm Centimeter m/s² Metres per second squared
dB(A) Decibel (A-rated)
Lock / to tighten Unlock / to loosen.
or secure.
Read the instruction Note / Remark.
manual.
Caution / Warning.
xxWyy Manufacturing date code; year of manufacturing (20xx) and week of
manufacturing (Wyy)
Wear hearing protection. Wear eye protection.
Wear a dust mask. Wear protective gloves.
Wear protective, slip-resistant footwear.
Safety information
WARNING! This product produces an
electromagnetic eld during operation! This eld
may under some circumstances interfere with
active or passive medical implants! To reduce
the risk of serious or fatal injury, we recommend
persons with medical implants to consult their
doctor and the medical implant manufacturer
before operating this product!

EN
14
TTI821GGT by TITAN
Getting started...
Inspect the area where the product is to be used and remove all
objects which can be thrown by the product. If objects are hidden
while operating stop the motor and remove the object.
Keep other people out of working area during operation. A distance
of at least 15 m must be observed.
Contact of the guide bar tip with any object should be avoided.
Guaranteed sound power level value in 91 dB.
WEEE symbol. Waste electrical products should not be disposed of
with household waste. Please recycle where facilities exist. Check
with your Local Authority or local store for recycling advice.
Crossed out dust bin. Batteries and battery packs should not be
disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or local store for recycling
advice.
Do not dispose of battery packs in rivers or immerse in water.
Do not dispose of battery packs in re. They will explode and cause
injury.
Safety information
91
Wear tight-tted protective clothes.
Switch the product off and remove battery pack before assembly,
cleaning, adjustments, maintenance, storage and transportation.
This product is of protection class III.
Do not expose the product to rain or wet conditions (moisture).
Objects thrown by the product could hit the user or other bystanders.
Always ensure that other people and pets remain at a safe distance
from the product when it is in operation. In general, children must not
come near the area where the product is.
Symbols

EN
15
TTI821GGT by TITAN
Getting started...
Your product
Do note expose battery packs to heat in excess of 40 ºC. Do not
charge or store the battery pack in temperatures below 5 °C (41 °F)
and above 40 °C (104°F).
The product complies with the applicable European directives and
an evaluation method of conformity for these directives was done.
UK Conformity Assessed.
1
2
3
4
5
13a
13b
13c
13d
13e
13g
13h
11a
11b
6
7
8
9
10
14
12 13
11
16c
16b
16a
16 17
15
15a
Safety information / Your product

EN
16
TTI821GGT by TITAN
Getting started...
Your product
1. Main handle
2. Lock-off button
3. On/off switch
4. Rear safeguard
5. Battery docking port
6. Upper pole
7. Unlock button for
angle adjustment
8. Locking sleeve for
length adjustment
9. Lower pole
10. Unlock button for tilt
adjustment
a. Indicator*
b. Indication line*
11. Guard
a. Screw
b. Knife
c. Screw hole*
d. Knife protector*
12. Plant protector
13. Trimmer head
a. Cover
b. Release latch (x2)
c. Trimming spool
d. Trimming line
e. Housing
f. Sliding slot (x2)*
g. Release push
button
h. Eyelet
i. Screw hole*
14. Motor housing
15. Auxiliary handle
a. Lock button
16. Battery pack
a. Battery capacity
indicators
b. Battery capacity
button
c. Release button
17. Charger
NOTE: Parts marked with * are not shown in this overview. Please
refer to the respective part in the instruction manual.
Unpacking
1. Unpack all parts and lay them on a at, stable surface.
2. Remove all packing materials and shipping devices if applicable.
3. Make sure the delivery contents are complete and free of any damage. If
you nd that parts are missing or show damage do not use the product but
contact your dealer. Using an incomplete or damaged product represents a
hazard to people and property.
4. Ensure that you have all the accessories and tools needed for assembly and
operation. This also includes suitable personal protective equipment.
WARNING! The product and the packaging are not children’s toys!
Children must not play with plastic bags, sheets and small parts!
There is a danger of choking and suffocation!
Your product / Before you start

EN
17
TTI821GGT by TITAN
Getting started...
You will need
(items not supplied)
Suitable personal protective equipment
Suitable crosshead screwdriver
(items supplied)
Guard (11)
Battery pack (16)
Charger (17) and its manual
NOTE: The accessories required depend on the intended application.
Ask your dealer for advice.
Setup
WARNING! The product must be fully assembled before operation!
Do not use a product that is only partly assembled or assembled with
damaged parts!
Follow the assembly instructions step-by-step and use the pictures
provided as a visual guide to easily assemble the product!
Do not connect the product to battery pack (16) before it is completely
assembled!
NOTE: Take care of small parts that are removed during assembly or
when making adjustments. Keep them secure to avoid loss.
Guard
1. Turn the trimmer head (13) upside down.
2. Untighten the screw (11a) and keep it handy.
3. Put out the plant protector (12) rstly (Fig. 1, step 1), then align and slide
the guard (11) onto the sliding slots (13f) of the trimmer head (13) (Fig. 1,
step 2). Fully insert the guard (11) and make sure that the screw holes (11c,
13i) are well aligned.
4. Secure the guard (11) with the screw (11a) in clockwise (Fig. 1, step 3).
12
11a
11c
11
13
13I
13f
11c
11
2.
1.
Fig. 1
Before you start

EN
18
TTI821GGT by TITAN
Getting started...
Setup
WARNING! Never use the trimmer head (13) without the guard (11)
properly tted.
NOTE: Always remove knife protection (11d) before use.
Battery pack
Attaching / releasing the battery pack
1. Align the battery pack (16) with the sliding slots of the battery docking port (5)
under the rear safeguard (4) and slide the battery pack in to attach it. Ensure
it clicks in place (Fig. 2).
2. Press the release button (16c) and remove the battery pack (16) from the
battery docking port (5) (Fig. 3).
5
4
16
Fig. 2
516
16c
2.
1.
Fig. 3
Charging the battery pack
The battery pack (16) for this product has been shipped in a low charge condition.
Charge it fully before rst use.
Refer to the charger’s instruction manual (TTB804CHR) for the details.
Before you start

EN
19
TTI821GGT by TITAN
Getting started...
Battery capacity indicators
The battery pack (16) is equipped with the battery capacity indicators (16a) which
are used to give an indication of the battery pack’s remaining capacity. Press the
battery capacity button (16b) to check battery capacity (Fig. 4). The LEDs will
stay lit for approximately 5 seconds.
76-100%
51-75%
26-50%
5-25%
<5%
16
16b
16a
Fig. 4
Before you start

20
EN TTI821GGT by TITAN
In more detail...
In more
detail...
Product functions
Operation
Care and maintenance
Troubleshooting
Recycling and disposal
Guarantee
Technical specications
Declaration of conformity
21
25
30
33
34
35
37
39
