SAFETY AND OPERATING MANUAL
Original Instructions
26CC PETROL HEDGE TRIMMER TTL688HDC
V60920 / BX220IM

Kingfisher
International Products Limited
or email [email protected]

SAFETY INSTRUCTIONS
Warnings! Read this instruction carefully before operating this tool. Make sure
that you are familiar with the controls and properly operate the machine.
Following this instructions, you can reduce the risk of fire, electric shock and
personal injury.
GENERAL SAFETY INSTRUCTIONS
1. This product is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the product by a person responsible for
their safety.
2. Children should be supervised to ensure that they do not play with the product.
IMPORTANT
Read carefully before use
Keep for future reference
Training
1. Become familiar with the instruction manual before attempting to operate the product.
Preparation
1. This product can cause serious injuries. Read the instructions carefully for the correct
handling, preparation, maintenance, starting and stopping of the product. Become familiar
with all controls and the proper use of the product.
2. Never allow children to use this product.
3.Beware of overhead power lines.
4.Avoid operating while people, especially children, are nearby.
5.Dress properly! Do not wear loose clothing or jewellery, which can be caught in moving
parts. Use of sturdy gloves, non-skid footwear and safety glasses is recommended.
6.Use extra care when handling fuels. They are flammable and the vapours are explosive. The
following points should be observed.
-Use only an approved container.
-Never remove the fuel cap or add fuel with the power source running. Allow engine and
exhaust - components to cool down before refuelling.
-Do not smoke.
-Never refuel indoors.
-Never store the product or fuel container inside where there is an open flame, such as near a
water heater.
-If fuel is spilled, do not attempt to start the power source, but move the product away from the
spillage before starting.
-Always replace and securely tighten the fuel cap after refuelling.
-If the fuel tank is drained, this should be done outdoors.
26CC PETROL HEDGE TRIMMER TTL688HDC

7.If the cutting mechanism strikes any foreign object or the product starts making any unusual
noise or vibration, shut off the power source and allow the product to stop. Disconnect the
spark plug wire from the spark plug and take the following steps.
-Inspect for damage.
-Check for, and tighten, any loose parts.
-Have any damaged parts replaced or repaired with parts having equivalent specifications.
8.Wear hearing protection!
9.Wear eye protection!
10.In an emergency switch the product off by immediately releasing the throttle trigger and
setting the ignition switch to its off position “STOP”.
Operation
1.Stop the engine before
-Cleaning or when clearing a blockage,
-Checking, carrying out maintenance or working on the product,
-Adjusting the working position of the cutting blade,
-Leaving the product unattended.
2.Ensure that the product is correctly located in a designated working position before starting
the engine.
3.While operating the product, always ensure that the operating position is safe and secure.
4.Do not operate the product with a damaged or excessively worn cutting blade.
5.To reduce fire hazards, keep the engine and silencer free of debris, leaves and excessive
lubricant.
6.Always ensure that all handles and guards are fitted when using the product. Never attempt
to use an incomplete product or one fitted with an unauthorised modification.
7.Always use two hands to operate a product fitted with two handles.
8.Always be aware of your surroundings and stay alert for possible hazards of which you may
not be aware due to the noise of the product.
9.Never carelessly touch the product, you can burn yourself. While the product is in operation
or shortly thereafter, its parts such as the exhaust pipe, engine, and other surfaces are
extremely hot! Pay attention to the markings on the product.
10.Make sure that the air intake of the combustion engine is clear. Keep the air intake free of
dust, dirt particles, gases and fumes.
11.Make sure that air circulation is adequate and good. The product must be easily accessible
from all sides.

Maintenance and storage
1.When the product is stopped for servicing, inspection or storage, shut off the power source,
disconnect the spark plug wire from the spark plug and make sure all moving parts have come
to a stop. Allow the product to cool before making any inspections, adjustments, etc.
2.Store the product where the fuel vapour will not reach an open flame or spark. Always allow
the product to cool down before storing.
3.When transporting or storing the product, always fit the cutting blade transport guard.
Additional safety warnings
1.Keep all parts of the body away from the cutting blade. Do not remove cut material or hold
material to be cut when blades are moving. Make sure the switch is off when clearing jammed
material. A moment of inattention while operating the product may result in serious personal
injury.
2.Carry the product by the handle with the cutting blade stopped. When transporting or storing
the product always fit the cutting blade cover. Proper handling of the product will reduce
possible personal injury from the cutting blade.
3.Hold the product by insulated gripping surfaces only, because the cutting blade may contact
hidden wiring. Cutting blades contacting a "live" wire may make exposed metal parts of the
product "live" and could give the operator an electric shock.
4.Keep hands and feet away from the cutting blade at all times and especially when switching
on the engine.
5.Do not try to grasp or remove trimmings when the product is running. Only remove trimmings
when the product is switched off and disconnected from the power supply.
6.Check the work area for foreign objects before operation, e.g. wire fences. Take care that
the cutting blade does not come into contact with wire or other metal objects.
7.Never hold the product by the guard.
8.Always be sure of a safe and secure operating position, whilst using the product. Always be
sure of your footing when using steps and when using your product. Never use the product
standing on steps or a ladder. Do not work over shoulder height.
9.Always ensure the safety guard supplied is fitted before using the product. Never attempt to
use an incomplete product or one fitted with an unauthorised modification.
10.Check cutting blade regularly for damage, and if damaged repair immediately.
11.Do not overload the product.
12.Check immediately if the product starts to vibrate abnormally. Excessive vibration can
cause injury.
13.Stop the engine and switch the product off when the cutting blade is blocked. Unplug the
spark plug connector and remove the blockage. Inspect the cutting blade for damage before
using the product again.
14.Follow the maintenance and repair instructions for this product. Never carry out any
modifications of the product. Never change the pre-set rotary speed or the engine and product
settings. Information about maintenance and repair is provided in this instruction manual.
26CC PETROL HEDGE TRIMMER TTL688HDC

Fuel handling
1.Always switch the product off, disconnect the spark plug connector and let the product cool
down, before refuelling it. Fuel and fuel vapour are highly flammable. Take care when handling
fuel. Never smoke when you are refuelling the product. Do not refuel the product, if there is an
open fire in the vicinity!
2.Always use suitable aids such as funnels and filler necks. Do not spill any fuel on the product
or its exhaust system. There is a risk of ignition. Remove spilled fuel carefully from all parts of
the product. Any residue which may be present must have completely volatilised, before the
product is put into operation!
3.Never use the product in environments where there is a risk of explosion. Exhaust gases
and fuel fumes are noxious. Fuel fumes can ignite.
4.Never breathe in any fuel fumes, when you are refuelling the product. Never fill the tank in
enclosed spaces, such as basements or sheds. There is a risk of poisoning and explosion!
5.Avoid skin contact with petrol.
6.Do not eat or drink, while you are refuelling the product. If you have swallowed petrol or oil,
or if petrol or oil has got into your eyes, then seek the advice of a doctor immediately.
7.Close the tank lid immediately after filling the tank. Make sure that it is properly closed.
8.Never use the product without an air filter.
9.Fuel vapour pressure may build up inside the fuel tank depending on the fuel used, weather
conditions and the tank venting system. To reduce the risk of burns and other personal
injuries, remove the filter cap carefully to allow any pressure build up to release slowly.
10.Be aware of fire risks, explosion and inhalation risks.
11.Do not smoke while operating the product, handling fuel or near fuel.
12.Ensure the spark plug lead is secured, a loose lead may cause electrical arcing that could
ignite combustible fumes and cause a fire or explosion.
13.Check regularly for leaks from the fuel cap and fuel lines.
14.Use caution when handling fuel. To avoid any accidental fires, move the product at least 3
metres (10') from the fuelling point before starting the engine.
15.Tighten the fuel cap thoroughly after refilling the fuel tank.
16.Do not operate the product if it is leaking fuel. Do not remove the fuel tank cap while the
engine is running.
17.Do not store cans of fuel or refill the fuel tank in any place where there is a boiler, stove,
wood fire, electrical sparks, welding sparks, or other sources of heat or fire which might ignite
the fuel.
18.If you have spilt fuel on yourself or on your clothes, change your clothes and wash any part
of your body that has come in contact with fuel before turning the engine on again.
19.If fuel is ignited, put out the fire with a dry powder fire extinguisher.

Vibration
The European Physical Agents (Vibration) Directive has been brought in to help reduce hand
arm vibration syndrome injuries to power tool users. The directive requires power tool
manufacturers and suppliers to provide indicative vibration test results to enable users to
make informed decisions as to the period of time a power tool can be used safely on a daily
basis and the choice of tool.
Further Advice can be found at www.hse.gov.uk
Vibration
The declared vibration emission value should be used as a minimum level and should be used
with the current guidance on vibration.
Calculating the actual period of the actual period off use can be difficult and the HSE website
has further information.
The declared vibration emission been measured in accordance with a standard listed test
stated above and may be used to compare one tool with another. The declared vibration
emission value may also be used in a preliminary assessment of exposure.
WARNING! The vibration emission value during actual use of the power tool can
differ from the declared value depending on the ways in which the tool is used
dependant on the following examples and other variations on how the tool is
used:
How the tool is used and the materials being ground or cut.
The tool being in good condition and well maintained.
The use the correct accessory for the tool and ensuring it is sharp and in good condition.
The tightness of the grip on the handles.
And the tool is being used as intended by its design and these instructions.
This tool may cause hand-arm vibration syndrome if its use is not adequately
managed.
WARNING! Identify safety measures to protect the operator that are based on an
estimation of exposure in the actual conditions of use (taking account of all
parts of the operating cycle such as the times when the tool is switched off and
when it is running idle in addition to the trigger time). Note The use of other tools
will reduce the users' total working period on this tool.
Helping to minimise your vibration exposure risk.
Maintain this tool in accordance with these instructions and keep well lubricated (where
appropriate).
Avoid using tools in temperatures of 10°C or less.
Plan your work schedule to spread any high vibration tool use across a number of days. Health
Surveillance.
26CC PETROL HEDGE TRIMMER TTL688HDC

Health Surveillance
All employees should be part of an employer's health surveillance scheme to help identity any
vibration related diseases at an early stage, prevent disease progression and help employees
stay in work.
Emergency
Familiarise yourself with the use of this product by means of this instruction manual.
Memorise the safety directions and follow them to the letter. This will help to prevent
risks and hazards.
1.Always be alert when using this product, so that you can recognise and handle risks early.
Fast intervention can prevent serious injury and damage to property.
2.Stop the engine and unplug the spark plug connector if there are malfunctions. Have the
product checked by a qualified professional and repaired, if necessary, before you operate it
again.
3.In case of fire stop the engine and unplug the spark plug connector. Take fire-extinguishing
measures immediately if the product switch is no longer accessible.
WARNING!Never use water to extinguish a product on fire. Burning fuel must be
extinguished with special extinguishing agents. We recommend that you keep a
suitable fire extinguisher within reach in your work area!
Residual risks
Even if you are operating this product in accordance with all the safety requirements,
potential risks of injury and damage remain. The following dangers can arise in
connection with the structure and design of this product:
1.Health defects resulting from vibration emission if the product is being used over long
periods of time or not adequately managed and properly maintained.
2.Injuries and damage to property due to broken accessories or the sudden impact of hidden
objects during use.
3.Danger of injury and property damage caused by flying objects
WARNING! This product produces an electromagnetic field during operation!
This field may under some circumstances interfere with active or passive
medical implants! To reduce the risk of serious or fatal injury, we recommend
persons with medical implants to consult their doctor and the medical implant
manufacturer before operating this product!.

26CC PETROL HEDGE TRIMMER TTL688HDC
SYMBOLS
On the product, the rating label and within these instructions you will find among others the
following symbols and abbreviations. Familiarise yourself with them to reduce hazards like
personal injuries and damage to property.
kW Kilowatt
cm³ Cubic centimetre
min-¹ or /min per minute
mm Millimetre
kg Kilogram
dB(A) Decibel (A-rated)
m/s² Metres per second squared
l Litre
yyWxx Manufacturing date code; year of manufacturing (20yy) and week of
manufacturing (Wxx).

26CC PETROL HEDGE TRIMMER TTL688HDC
Choke lever: Start (Close Position) - Run (Open Position)

13
16

26CC PETROL HEDGE TRIMMER TTL688HDC

The sound values have been determined according to noise test code given in EN ISO 10517,
using the basic standards EN ISO 11201 and EN ISO 3744
Wear hearing protection! The sound intensity level for the operator may exceed 80 dB(A) and
ear protection measures are necessary!
The declared vibration value has been measured in accordance with a standard test method
(according to EN ISO 10517) and may be used for comparing one product with another. The
declared vibration value may also be used in a preliminary assessment of exposure.
This tool may cause hand-arm vibration syndrome if its use is not adequately managed.
615mm
27mm
5.6kg
approx. 1230×250 260×mm
The conformity assessment followed was according to Annex III of the directive for equipment listed in
schedule 1 / article 13 the chosen conformity assessment route Internal cintrol of production (schedule
10 / Annex V) - Guaranteed Sound Power Leel 109 dB (A).
106.9
2.32

26CC PETROL HEDGE TRIMMER TTL688HDC
WARNING! Depending on the actual use of the product the vibration values can
differ from the declared total! Adopt proper measures to protect yourself against
vibration exposures! Take the whole work process including times the product is
running under no load or switched off into consideration!
Proper measures include among others regular maintenance and care of the
product and cutting attachments, keeping hands warm, periodical breaks and
proper planning of work processes!
INTENDED USE
This petrol hedge trimmer is designated with an engine displacement of 26 cm³. The product is
intended for trimming hedges, bushes and shrubs. Observe the technical data for the
maximum cutting capacity. Do not cut branches exceeding the stated maximum capacity.
For safety reasons it is essential to read the entire instruction manual before first operation
and to observe all the instructions therein.
This product is intended for private domestic use only, not for any commercial trade use. It
must not be used for any purposes other than those described.
Assembly instructions
WARNING! Before using the product, familiarise yourself with the operating
features read the entire instruction manual paying particular attention to the
safety rules and operating procedures.
UNPACKING
1.Unpack all parts and lay them on a flat, stable surface.
2.Remove all packing materials and shipping devices if applicable.
3.Make sure the delivery contents are complete and free of any damage. If you find that parts
are missing or show damage do not use the product but contact your dealer. Using an
incomplete or damaged product represents a hazard to people and property.
4.Ensure that you have all the accessories and tools needed for assembly and operation. This
also includes suitable personal protective equipment.
BLADE COVER
1.Remove the blade cover (17) from the cutting device (1) before operation (Fig. 1).

NOTE: Always attach the blade cover (17) when the product is not in use, for
storage and transportation.
To attach the blade cover, align and push the blade cover onto the cutting
device (1).
HANDLE ADJUSTMENT
Adjust the handle to fit the application.
1.Pull the unlock lever (9) backward and hold it in position (Fig. 2).
2.Adjust the handle (5) to required position and release the unlock lever (9). Keep turning the
handle until it snaps securely into place (Fig. 3-6).
WARNING!Only adjust the handle position when the engine is switched off!
Always ensure that the handle locks in one of the end positions, never use it in
any intermediate position!

26CC PETROL HEDGE TRIMMER TTL688HDC
FUEL AND ENGINE OIL
NOTE: This product is not supplied with fuel-oil mixture in the engine! Before
operating this product it is essential to fill it with fuel-oil mixture!
This product is equipped with a 2-stroke engine, the fuel and oil tank are combined and it is
essential to fill a fuel-oil mixture before operating this product. Observe the technical
specifications for suitable fuel and engine oil.
WARNING!
Fuel and oil are highly inflammable! Fumes will explode if lit! Ensure
that there are no naked flames around the product! Do not smoke while filling
fuel and oil!
1.Place the product on a stable, level surface. We recommend laying a non-flammable sheet
under the product.
2.Mix a regular-grade unleaded petrol and a quality engine oil for air cooled 2-stroke engines
in a suitable container (Fig. 7). Fill half the quantity of the petrol to be used into the container.
Then add the entire quantity of oil and shake the prepared fuel mixture. Add the remaining
quantity of petrol. Shake the fuel mixture thoroughly before filling the fuel tank.
3.Use an anti-oxidant added quality oil expressly labelled for air-cooled 2 stroke engine use
(JASO FC GRADE OIL or ISO EGC GRADE).
4.Do not use BIA or TWC (2 stroke water-cooling type) mixed oil.
5.The recommended mixing ratio for petrol:oil is 40:1.
NOTE: Never mix fuel and oil directly in the tank of the product. Use a fuel mixing
container that helps to ensure the correct mixing ratio. Shake gently to ensure a
thorough mix of fuel and oil.

6.Unscrew and remove the fuel tank cap (12).
7.Fill correctly mixed fuel/oil into the tank using a fuel funnel fitted with a filter to avoid debris
entering the tank. Do not overfill. Leave a minimum 5 mm of space between the top of the fuel
and the inside edge of the tank (11) to allow for expansion (Fig. 8).
8.Avoid spilling and overfilling the tank.
9.Wipe up spilled fuel with a soft cloth and refit the fuel tank cap (12).
10.Always dispose of fuel, used oil and soiled objects according to local regulations (see
section “Recycling and disposal”).
NOTE: Fuel and oil deteriorate over time. It may be difficult to start the engine if
you use fuel which has been kept for more than 30 days.
Towards the end of the season, it is advisable to put only as much fuel in the tank
as you need for each use, since it should be completely used up before storing
the product.
Empty remaining fuel from the tank when storing the product for over 30 days.
HANDLE CONTROLS
There are three controls at the handle (5) with the following function:
1.The ignition switch (10) electrically stops the engine. Before you start the engine, you
always need to put the ignition switch (10) to the "I" position.
2.The throttle interlock (6) prevents unintentional activation of the throttle trigger (8) until
manually pressed.
3.Adjust the engine speed with the throttle trigger (8).
NOTE: The throttle trigger will not work if the unlock lever (9) did not snap
securely into place.

26CC PETROL HEDGE TRIMMER TTL688HDC
Operating instructions
GENERAL OPERATION
1.Check the product as well as accessories for damage before each use. Do not use the
product if it is damaged or shows wear.
2.Double check that accessories or cutting device are properly fixed.
3.Always hold the product on its handles (3,5). Keep the handles dry to ensure safe support.
4.Ensure that the air vents (21) are always unobstructed and clear. Clean them if necessary
with a soft brush. Blocked air vents may lead to overheating and damage to the product.
5. Switch the product off immediately if you are disturbed while working by other people
entering the working area. Always let the product come to a complete stop before putting it
down.
6.Do not overwork yourself. Take regular breaks to ensure you can concentrate on the work
and have full control over the product.
TRIMMING TIMES
STARTING/STOPPING
Cold start (Fig.10, 11)
WARNING! Make sure that the cutting device is not touching the ground or other
objects when starting the product!
Make sure that the rear handle is in the upright position.
1.Place the product on level ground and ensure that no objects or obstructions could come in
contract with the blades.
2.Set ignition switch (10) to “I” (ON) position.
3.Press the primer (13) 5-6 times.
4.Move the choke lever (16) to “ start” position.
5.Hold the top cover firmly with your left hand and put your right knee onto the rear handle (5).

6.Pull the recoil starter handle (4) lightly until you feel resistance, then pull it briskly 3-4 times.
The engine would normally not start at this stage.
WARNING! Allow the rope to return slowly and in a controlled manner each time it
is pulled!
7.Move the choke lever (16) to “ Run” position. Pull the starter handle to start the engine.
If it can not start, move on to the next steps. Squeeze the throttle interlock (6) and the throttle
trigger (8) 2-3 times, the pull the recoil starter handle (4) to start motor.
Warm start (Fig.12, 13)
WARNING! Make sure that the cutting device is not touching the ground or other
objects when starting the product!
1.Set the ignition switch (10) to “I” (ON) position.
2.Do not press the primer (13).
3.Move the choke lever (16) to “ Run” position.
4.Hold the top cover firmly with your left hand and put your right knee onto the rear handle (5).
5.Pill the recoil starter handle (4) lightly until you feel resistance, then pull it briskly 1-2 times.
Do it again until the engine starts.
WARNING! Allow the rope to return slowly and in a controlled manner each time it
is pulled!
