Titan TTB826HDC User manual

TTB826HDC
Original Instructions_MNL_TTB826HDC_V1_211027
WARNING: Read the instructions before using the product!
EN
Pole Hedge
Trimmer
550W 50cm

EN
02
Let’s
Getting started...
In more detail...
get started...
These instructions are for your safety. Please read through them thoroughly
before use and retain them for future reference.
Safety information
Your product
Before you start
Product functions
Operation
Care and maintenance
Troubleshooting
Recycling and disposal
Guarantee
Technical specications
Declaration of conformity
02
03
12
13
17
18
21
24
28
28
29
31
33

EN
03
TTB826HDC by TITAN
Getting started...
Safety information
Safety warnings
1. Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
2.
Do not operate power tools in explosive atmospheres,
such as in the presence of ammable liquids, gases
or dust. Power tools create sparks which may ignite the
dust or fumes.
3. Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose control.
Electrical safety
1. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
General power tool safety warnings
Work area safety
WARNING! Read all safety warnings,
instructions, illustrations and specifications
provided with this power tool. Failure to follow
all instructions listed below may result in electric
shock, re and/or serious injury.
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers
to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.

EN
04
TTB826HDC by TITAN
Getting started...
3. Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock.
5. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock.
6. If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
Personal safety
1. Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under the
inuence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personal injury.
2. Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce personal
injuries.
3. Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source, picking up or carrying the tool. Carrying
power tools with your nger on the switch or energising
Safety warnings
Safety information

EN
05
TTB826HDC by TITAN
Getting started...
power tools that have the switch on invites accidents.
4. Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal injury.
5. Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpected situations.
6. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair can
be caught in moving parts.
7. If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
8. Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
severe injury within a fraction of a second.
Power tool use and care
1. Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
2. Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
3. Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting
the power tool accidentally.
4. Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool
Safety information

EN
06
TTB826HDC by TITAN
Getting started...
or these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
5. Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused
by poorly maintained power tools.
6. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
7. Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a hazardous
situation.
8. Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
Service
1. Have your power tools serviced by a qualied repair
person using only identical replacement parts. This
will ensure that safety of the power tool is maintained.
Hedge trimmer safety warnings:
1. Keep all parts of the body away from the blade. Do
not remove cut material or hold material to be cut
when blades are moving. Blades continue to move
after the switch is turned off. A moment of inattention
while operating the hedge trimmer may result in serious
personal injury.
Safety warnings
Safety information

EN
07
TTB826HDC by TITAN
Getting started...
2. Carry the hedge trimmer by the handle with the
blade stopped and taking care not to operate any
power switch. Proper carrying of the hedge trimmer will
decrease the risk of inadvertent starting and resultant
personal injury from the blades.
3. When transporting or storing the hedge trimmer,
always fit the blade cover. Proper handling of the
hedge trimmer will decrease the risk of personal injury
from the blades.
4. When clearing jammed material or servicing the
unit, make sure all power switches are off and the
power cord is disconnected. Unexpected actuation
of the hedge trimmer while clearing jammed material or
servicing may result in serious personal injury.
5. Hold the hedge trimmer by insulated gripping
surfaces only, because the blade may contact hidden
wiring or its own cord. Blades contacting a "live" wire
may make exposed metal parts of the hedge trimmer
"live" and could give the operator an electric shock.
6. Keep all power cords and cables away from cutting
area. Power cords or cables may be hidden in hedges
or bushes and can be accidentally cut by the blade.
7. Do not use the hedge trimmer in bad weather
conditions, especially when there is a risk of lightning.
This decreases the risk of being struck by lightning.
Additional safety warnings for pole hedge trimmer
1. To reduce the risk of electrocution, never use the
pole hedge trimmer near any electrical power lines.
Contact with or use near power lines may cause serious
injury or electric shock resulting in death.
2. Always use two hands when operating the pole
hedge trimmer. Hold the pole hedge trimmer with both
hands to avoid loss of control.
3. Always use head protection when operating the pole
Safety information

EN
08
TTB826HDC by TITAN
Getting started...
hedge trimmer overhead. Falling debris can result in
serious personal injury.
4. Before operating the hedge trimmer, the user should
make sure the locking device(s) of any moving
elements (e.g. the extended shaft and pivoting
element), if any, are in the locked position.
Vibration and noise reduction
To reduce the impact of noise and vibration emission,
limit the time of operation, use low-vibration and low-
noise operating modes as well as wear personal
protective equipment.
Take the following points into account to minimise the
vibration and noise exposure risks:
1. Only use the product as intended by its design and these
instructions.
2. Ensure that the product is in good condition and well
maintained.
3. Use correct attachments for the product and ensure they
are in good condition.
4. Keep tight grip on the handles/grip surface.
5. Maintain this product in accordance with these instructions
and keep it well lubricated (where appropriate).
6. Plan your work schedule to spread any high vibration tool
use across a longer period of time.
7. Prolonged use of the product exposes the user to
vibrations that can cause a range of conditions collectively
known as hand-arm vibration syndrome (HAVS) e.g.
ngers going white; as well as specic diseases such as
carpal tunnel syndrome. To reduce this risk when using
the product, always wear protective gloves and keep your
hands warm.
Safety warnings
Safety information

EN
09
TTB826HDC by TITAN
Getting started...
Emergency
Familiarise yourself with the use of this product by
means of this instruction manual. Memorise the safety
directions and follow them to the letter. This will help to
prevent risks and hazards.
1. Always be alert when using this product, so that you
can recognise and handle risks early. Fast intervention
can prevent serious injury and damage to property.
2.
Switch the product off and disconnect from the
power supply if there are malfunctions.
Have the
product checked by a qualied professional and repaired,
if necessary, before you operate it again.
Residual risks
Even if you are operating this product in accordance
with all the safety requirements, potential risks of injury
and damage remain. The following dangers can arise
in connection with the structure and design of this
product:
1. Health defects resulting from vibration emission if the
product is being used over long periods of time or not
adequately managed and properly maintained.
2. Injuries and damage to property due to broken
attachments or the sudden impact of hidden objects
during use.
3. Danger of injury and property damage caused by
ying objects.
Safety information
WARNING! This product produces an
electromagnetic field during operation! This field
may under some circumstances interfere with
active or passive medical implants! To reduce
the risk of serious or fatal injury, we recommend
persons with medical implants to consult their
doctor and the medical implant manufacturer
before operating this product!

EN
10
TTB826HDC by TITAN
Getting started...
Symbols
On the product, the rating label and within these instructions you will nd among
others the following symbols and abbreviations. Familiarise yourself with them
to reduce hazards like personal injuries and damage to property.
V~ Volt, (alternating voltage) Hz Hertz
/min or Per minute W Watt
min-1 g Gram
cm Centimeter kg Kilogram
mm Millimetre m Metre
dB(A) Decibel (A-rated) m/s² Metres per second squared
Lock / to tighten or secure. Unlock / to loosen.
Read the instruction Note / Remark.
manual.
Caution / Warning.
xxWyy Manufacturing date code; year of manufacturing (20xx) and week of
manufacturing (Wyy)
Wear hearing protection. Wear eye protection.
Wear a dust mask. Wear protective gloves.
Wear protective, slip-resistant footwear.
Wear tight-tted protective clothes.
Wear head protection, where there is a risk of falling objects.
Switch the product off and disconnect it from the power supply
before assembly, cleaning, adjustments, maintenance, storage and
transportation.
Do not expose the product to rain or wet conditions (moisture).
Keep hands away from moving cutting device!
Safety information

EN
11
TTB826HDC by TITAN
Getting started...
Keep sufcient distance away from electrical power lines.
Objects thrown by the product could hit the user or other bystanders.
Always ensure that other people and pets remain at a safe distance
from the product when it is in operation. In general, children must not
come near the area where the product is.
Disconnect the product from the mains plug if the cord is damaged or
entangled. DON’T TOUCH THE CORD BEFORE DISCONNECTING
THE SUPPLY.
Guaranteed sound power level value in 105 dB.
The product is of Protection class II. That means it is equipped with
enhanced or double insulation.
The product complies with the applicable European directives and an
evaluation method of conformity for these directives was done.
UK Conformity Assessed.
WEEE symbol. Waste electrical products should not be disposed of
with household waste. Please recycle where facilities exist. Check
with your Local Authority or local store for recycling advice.
Safety information
105

EN
12
TTB826HDC by TITAN
Getting started...
Your product
Your product
1. Cutting device (blade)
a. Blade tip protector
2. Motor head
a. Air vents
3. Unlock button for angle adjustment
4. Pole support
a. Bore (x2)*
5. Locking sleeve
6. Pole extension
a. Lock pin (x2)*
7. Locking lever for length adjustment
8. Front pole
9. Soft grip
10.Loop
11. Lock-off button
12.Rear handle
13.Power cord with plug
14.Rear safeguard
15.Cord retainer
16.On/off switch
17.Harness
a. Securing clip
b. Quick release
18.Blade cover
NOTE: Parts marked with * are not shown in this overview. Please
refer to the respective part in the instruction manual.
18
1a12a
2
3 4 567
8
910
11 12 13
14
1516
17a
17
17b

EN
13
TTB826HDC by TITAN
Getting started...
Before you start
Unpacking
1. Unpack all parts and lay them on a at, stable surface.
2. Remove all packing materials and shipping devices if applicable.
3. Make sure the delivery contents are complete and free of any damage. If
you nd that parts are missing or show damage do not use the product but
contact your dealer. Using an incomplete or damaged product represents a
hazard to people and property.
4. Ensure that you have all the accessories and tools needed for assembly and
operation. This also includes suitable personal protective equipment.
WARNING! The product and the packaging are not children’s toys!
Children must not play with plastic bags, sheets and small parts!
There is a danger of choking and suffocation!
You will need
Setup
(items not supplied)
Suitable personal protective equipment
Suitable extension cord for outdoor use
Lubricant for blade
(items supplied)
Harness (17)
Blade cover (18)
NOTE: The accessories required depend on the intended application.
Ask your dealer for advice.
WARNING! The product must be fully assembled before operation!
Do not use a product that is only partly assembled or assembled with
damaged parts!
Follow the assembly instructions step-by-step and use the pictures
provided as a visual guide to easily assemble the product!
Before using the product, familiarise yourself with the operating
features read the entire instruction manual paying particular attention
to the safety rules and operating procedures.
Do not connect the product to power supply before removing the
blade cover (11).

EN
14
TTB826HDC by TITAN
Getting started...
Before you start
Setup
Pole assembly
1. Loosen the locking lever (7) (Fig. 1, step 1) and pull out the pole extension (6)
(Fig. 1, step 2), then fasten the locking lever (7) (Fig. 1, step 3).
2. Move the locking sleeve (5) back onto the pole extension (Fig. 1, step 4).
3. Align the pole extension (6) with the pole support (4) and insert it. Make sure
the pins (6a) snaps in the bores (4a) for reliable connection (Fig. 1, step 5).
4. Fit the locking sleeve (5) on the thread of pole support (4) and tighten the
locking sleeve (5) clockwise to secure the connections (Fig. 1, step 6).
Blade cover
1. Remove the blade cover (18) from the cutting device (blade) (1) before
operation (Fig. 2).
2. Keep the blade cover (18) safely.
NOTE: Always attach the blade cover (18) when the product is not in
use, for storage and transportation.
To attach the blade cover (18), align and push the blade cover onto the
cutting device (blade) (1).
6 5
7
1.
5.
2.
4.
3. 6a
5
6
6a4a
4
6.
Fig. 1
18
1
Fig. 2

EN
15
TTB826HDC by TITAN
Getting started...
Before you start
Connection to power supply
1. Double the power cord (13) back, about 60 cm from the power guard and lead
the loop through the hole of the rear safeguard (14) (Fig. 3).
2. Pull it over the cord retainer (15) and gently tug on the power cord (13) to
ensure that it is rmly secured (Fig. 4).
3. Connect the plug of power cord (13) with a suitable socket.
NOTE: The product is equipped with a power cord with the length
of 10 m. If a proper extension cord is required for operation. The
extension cord must be suitable for outdoor use with sockets
protected against water splashing! Ensure the extension cord is of the
proper size and type for your product (≥ 1.0 mm²)!
Always use a residual current supply (RCD) protected supply.
15 14
13
Fig. 3
15 14
13
Fig. 4

EN
16
TTB826HDC by TITAN
Getting started...
WARNING! Check the voltage! The voltage must comply with the
information on the rating label!
If using an extension cord it must be suitable for outdoor use with
sockets protected against water splashing.
Ensure the extension cord is of the proper size and type for your
product:
· 1.5 mm2for up to 60 m
· 2.5 mm2for up to 100 m
Connection to power supply
4. Your product is now ready to be used.
Before you start

EN
17
In more detail...
TTB826HDC by TITAN
In more
detail...
Product functions
Operation
Care and maintenance
Troubleshooting
Recycling and disposal
Guarantee
Technical specications
Declaration of conformity
18
21
24
28
28
29
31
33

EN
18
In more detail...
TTB826HDC by TITAN
Intended use
Harness
This electric hedge trimmer TTB826HDC is designated with a rated power input
of 550 Watts.
The product is intended for cutting and trimming of hedges, bushes and shrubs
in domestic gardens. The maximum cutting capacity must be observed. Do not
cut branches exceeding the stated maximum capacity.
The use of this product in case of rain or humid environment is prohibited.
For safety reasons it is essential to read the entire instruction manual before
rst operation and to observe all the instructions therein.
This product is intended for private domestic use only, not for any commercial
trade use. It must not be used for any purposes other than those described.
The harness (17) helps the operator to carry the product.
1. Place the harness (17) so that it runs over the left
shoulder, crossing the chest and back. The securing
clip (17a) must be located at the right hip.
The quick release (17b) must be in front (Fig. 5).
2. Adjust the length of the harness (17) so that the
securing clip (17a) is approximately 15 cm below
your waist.
3. Attach the securing clip (17a) to the loop (10) (Fig. 6).
4. Lock the harness (17) onto the loop (10) by the
securing clip (17a) (Fig. 7).
Product functions
17
17b
17a
Fig. 5
10
17a
Fig. 6
10
17
17a
Fig. 7
17
17b
17a
Fig. 5
10
17a
Fig. 6
10
17
17a
Fig. 7

EN
19
In more detail...
TTB826HDC by TITAN
Harness
Length adjustment
5. In case of emergency hold the soft grip (9) of the front
pole (8) with the left hand, and use the right hand to
press two clips of the quick release (17b). The product
together with the securing clip (17a) will be released
automatically from the body because of the weight of
the product (Fig. 8).
1. Loosen the locking lever (7) (Fig. 9, step 1).
2. Adjust to the required length by pulling out or pushing in the pole extension (6)
(Fig. 9, step 2).
3. Secure the position of pole extension (6) by fastening the locking lever (7)
back to its original position (Fig. 9, step 3).
Product functions
WARNING! Always attach the product to the harness (17). Do not
carry it only with your hands!
WARNING! The length of the extension pole is limited! Stop pushing/
pulling as soon as you feel a resistance!
Extend the extension only to the length required to reach the hedges
being trimmed! Do not attempt to use the product at a length which
does not allow you to achieve proper footing and balance at all times!
17
17b
17a
Fig. 8
6
7
3.
2.
1.
Fig. 9
17
17b
17a
Fig. 8
6
7
3.
2.
1.
Fig. 9

EN
20
In more detail...
TTB826HDC by TITAN
The angle of the blade head can be adjusted into ve
positions (Fig. 10):
1. Press the unlock button (3) to unlock the
angleNadjustment and hold it in position.
2. Adjust the blade head to the desired position by
swing the pole support (4).
3. Release the unlock button (3) and keep moving
the pole support (4) until it locks in place.
4. Ensure the unlock button (3) snaps in place before
operation.
1. Ensure the cutting device (blade) (1) does not touch any objects. Remove
the blade cover (18) from the cutting device (blade) (1) before switching the
product on.
2. Hold the product with one hand on the soft grip (9) of the front pole (8) and the
other hand on the rear handle (12).
3. Pull back the lock-off button (11) and hold it in position (Fig. 11, step 1).
4. Squeeze the on/off switch (16) to switch the product on (Fig. 11, step 2).
Release the lock-off button (11) afterwards.
5. Release the on/off switch (16) to switch the product off.
Angle adjustment
Switching on/off
WARNING! The blade head can be adjusted in ve different positions.
Always ensure the blade head is securely locked! Do not attempt to
use the product with the head in an intermediate position!
Product functions
-90°
-60°
-30°
30°
0°
3 4
Fig. 10
2.
1.
11 12
16
Fig. 11
-90°
-60°
-30°
30°
0°
3 4
Fig. 10
2.
1.
11 12
16
Fig. 11
