Titgemeyer TIOS EL18 User manual

TITGEMEYER Tb1547GB(1113)1
■ TIOS®EL18 Battery-operated Lockbolt Tool
Operating instructions

3Phone: [phone] Fax: [phone] email: [email protected]LTb1547GB(1113)1
Contents
Notes on operating instructions ............................................................................... 4
Warnings, guidelines and action to be taken in the operating manual ..................... 5
Identification of rivet tool parts................................................................................. 6
Safety notes ............................................................................................................ 7
Basic requirements for handling the rivet tool.......................................................... 9
Technical specifications ......................................................................................... 10
List of parts............................................................................................................ 11
Description of rivet too........................................................................................... 12
Storing / maintaining, cleaning and disposing of rivet tool /................................. 13
Preparing, fitting and operating the rivet tool......................................................... 14
Selecting the pulling head...................................................................................... 16
Installing the lockbolt............................................................................................. 17
LED display (operating modes).............................................................................. 18
Cleaning the pulling unit........................................................................................ 19
Maintenance intervals ............................................................................................ 19
Replacing the pulling unit ...................................................................................... 20
Table for starting torques ....................................................................................... 21
Troubleshooting..................................................................................................... 21
Warranty ................................................................................................................ 22
Spare parts list TIOS EL18 / Optional accessories ................................................. 23
Declaration of conformity....................................................................................... 24
Service ................................................................................................................... 26

4Phone: [phone] Fax: [phone] email: [email protected]LTb1547GB(1113)1
TIOS®EL18 Battery-operated Lockbolt Tool
Operating instructions
Notes on operating instructions
Note
Perfected technology
Reading the operating instructions
Actions
Malfunctions
Illustrations and numbering of parts
Table for starting torques
Legislation dictates that the operator must be trained in using
electric rivet tools. Upon request, training courses are available through TITGEMEYER in
Osnabrück (Germany) or by contacting the customer directly.
This rivet tool represents the very latest in technology. To ensure the safe operation of this
professional tool, please follow all the safety recommendations.
Please ensure that you read through the operating instructions carefully before operating the
rivet tool for the first time.
All actions required under these operating instructions are described in these operating
instructions. Do not carry out any actions other than those described here.
If a malfunction occurs, the operator should only try to rectify those signalled by an “0”
(operator).
All descriptions and parts numbers found in the illustrations refer to the parts list on page 23.
For all thread sizes, a table of starting torques has been provided in the section entitled
“Maintaining the rivet tool”.

5Phone: [phone] Fax: [phone] email: [email protected]LTb1547GB(1113)1
TIOS®EL18 Battery-operated Lockbolt Tool
Operating instructions
Warnings, guidelines and action to be
taken by the operator
Always follow the guidelines and safety instructions. Icons have been used in certain sections
of these operating instructions for added emphasis. Please make a point of memorising the
icons and what they stand for:
Caution! Risk of injury! This icon warns of dangers.
Caution! Damage to materials! This icon warns of actions which could result in the rivet tool
or the blind rivets being damaged.
Note DThis icon refers to useful information.
• This bullet (•) highlights each paragraph where you will be required to take action.
Caution! Environmental damage! This icon warns of possible damage to the environment.
This icon indicates that you must first have read the operating instructions before beginning to
operate the rivet tool.

6Phone: [phone] Fax: [phone] email: [email protected]LTb1547GB(1113)1
TIOS®EL18 Battery-operated Lockbolt Tool
Operating instructions
Identification of rivet tool parts
AName plate
BSerial no.
(located underneath the housing -
remove battery!)
CCE mark
DName of supplier
ELED mode status
Recyclable
CE mark
Dispose of correctly
Keep away from fire
Dry environment
Indoor use only
Protection class II
Extra or double insulation
between electric circuit
and output voltage
(without equipment
earthing conductor)
Safety isolating
transformer
Short-circuit proof
Labels on the battery and/or
battery-operated tool

7Phone: [phone] Fax: [phone] email: [email protected]LTb1547GB(1113)1
TIOS®EL18 Battery-operated Lockbolt Tool
Operating instructions
Safety notes
Intended use
Foreseeable misuse
Safety notes
The TIOS EL15 battery-operated lockbolt tool may only be used to install lockbolts and blind
rivets, as described in these operating instructions.
The TIOS EL18 rivet tool is designed to install lockbolts with a max. diameter of 6.5 mm and
high-strength blind rivets with a diameter of 6.4 mm at a max. installation force of 18 kN.
This rivet tool may only be used as a manual tool!
The customer is solely responsible for any modifications made to the rivet tool.
The safety notes contained in these operating instructions must be strictly observed at all times.
Never throw or drop the rivet tool!
This tool has been made to the very latest engineering standards and in keeping with the
approved safety guidelines. It can be operated safely provided that the safety notes and
intended use are observed and that the appropriate personal protective equipment is worn.
• Danger, electrical tool:
Only allow trained electricians to carry out work on the rivet tool. Check the electrical equip-
ment at regular intervals. Repair any loose connections and damaged leads immediately.
• Observe the corresponding accident prevention regulations that apply in your country.
• Never point the tool at anyone while it is in use.
• Keep your work area clean, tidy and well-lit. Bad housekeeping and poorly-lit work areas
increase the likelihood of accidents.
• Never use electrical tools in explosion-prone areas where combustible liquids, gases or dust
particles are found. Electrical tools generate sparks which can ignite dust or vapours.
• Take environmental conditions into account. Never expose electrical tools to rain. Never use
electrical tools in humid or moist environments.
• Only use the rivet tool within its specified range of performance. Overloading it may result in
the tool being damaged or in risks to your safety.
• Always wear protective glasses. It is recommended that you wear suitable personal
protective equipment, such as protective clothing, non-slip safety shoes, a hard hat and ear
protection, depending on what electrical equipment is being used
• Remove the battery before changing the accessories or storing away the tool. This pre-
cautionary measure will ensure that the electrical tool does not start running accidentally.
• Repairs must only be performed by trained personnel using original spare parts which can
be obtained from Gebr. Titgemeyer GmbH & Co. KG. This will ensure that the tool remains
safe to use at all times.
• Only use the designated batteries in the electrical tools.
The use of other batteries may result in injury or fire.
• Only charge the batteries in the chargers recommended by the manufacturer. The battery
may be destroyed if inserted into an unsuitable charger.

8Phone: [phone] Fax: [phone] email: [email protected]LTb1547GB(1113)1
TIOS®EL18 Battery-operated Lockbolt Tool
Operating instructions
Safety notes
(continued from page 7)
• Whenever possible, always charge the lithium-ion battery immediately after using and never
store it when empty. The battery will keep its capacity constant for a longer time (max. loss
per year: 5%) if stored separately from the tool and charger.
• For safety reasons, the lithium-ion battery should not be left in an active charger for longer
than 36 hours. Whenever possible, remove the battery from the charger as soon as it is fully
charged.
• Whenever possible, always remove the battery from the device before transporting. This will
prevent you from unintentionally switching the device on and also prevent the battery from
running down very low.
• Never expose the lithium-ion battery to high temperatures (+ 50 °C) or direct sunlight. If the
battery becomes hotter than 50 °C while in operation (charging or discharging), immediately
remove it from the charger or rivet tool.
• Keep unused batteries away from paper clips, coins, keys, nails, screws and any other small
metal objects that might bridge/short-circuit the contacts. Never open or short-circuit the
battery. Short-circuiting the battery contacts may result in burns, fire or explosions.
• Batteries may leak when subjected to extreme use or temperatures. Keep your skin and eyes
away from a leaking battery at all times. The liquid contained in a battery is corrosive and
may cause chemical burns in human tissue. Should the liquid come into contact with the
skin, immediately wash it off with soap and water and then with lemon juice or vinegar. If the
liquid comes into contact with the eyes, rinse with water for 10 minutes and then seek the
advice of a doctor immediately.
• Never charge the battery in temperatures BELOW 10 °C or ABOVE 40 °C.
• The charger must never be connected to a step-up transformer, generator or DC socket.
• Ensure that the ventilation slots on the charger are never covered or clogged.
• Never store the electrical tool or battery in areas where temperatures exceed 50 °C.
• Never store the battery in a box or enclosed container. The battery must be stored in a
well-ventilated area.
• No changes, modifications or alterations may be made to the tool without the manufacturer’s
permission. No conversions may be performed without first being approved in writing by
Gebr. Titgemeyer GmbH & Co. KG. Any parts not in fully-working order must be replaced
without delay.

9Phone: [phone] Fax: [phone] email: [email protected]LTb1547GB(1113)1
TIOS®EL18 Battery-operated Lockbolt Tool
Operating instructions
WARNING!
Risk of physical injury
CAUTION!
Risk of personal injury
or damage to the tool
Maintenance and care
Service instructions
Note
EU Declaration of Conformity
Warranty
• Attach the spent mandrel collector before using the tool. Failure to do so will cause the
mandrels to shoot out on breaking which may result in injury.
• Check that no parts of the tool are damaged. All damaged parts must be repaired before
being used. Working with damaged tool parts increases the likelihood of injury.
• If working at elevated heights, always wear a safety harness. Avoid dropping rivets and avoid
dropping the tool at all costs. Failure to do so may result in injuries and significant damage.
• First remove the battery before cleaning the tool or performing any general maintenance
work.
• Keep your face away from the ventilation slots at all times.
• Avoid substances such as lubricating oil and lubricating grease coming into contact with the
skin. These substances can cause inflammation of the skin. If they do come into contact with
the skin, carefully rinse the affected area to remove them.
• Avoid working in unsecured positions, as you could fall or injure yourself.
• Maintain the rivet tool with great care. Follow the operating instructions when performing
maintenance and cleaning work. Keep the handle free from dirt and grease.
• Use the tool with care and be sure to operate it correctly. Ensure that the surrounding
conditions are right when working with this tool. Always maintain full concentration during
your work.
• Only the lockbolts and blind rivets specified in these operating instructions may be used.
The operator may only perform the maintenance and repair work described in
these operating instructions.
All maintenance and repair work not described in these operating instructions must be
performed by trained personnel who have undergone a corresponding training course with
TITGEMEYER. See the address on the last page for further information on training courses.
The manufacturer accepts no liability for damage resulting from improper repairs or the use of
non-original spare parts.
The TIOS EL18 rivet tool has been manufactured and tested in accordance with the European
directives. The Declaration of Conformity can be found on the next to last page.
Any improper use of this rivet tool, which results in the rivet tool being damaged, will render
the warranty void.
Basic requirements for handling the rivet tool

10 Phone: [phone] Fax: [phone] email: [email protected]LTb1547GB(1113)1
TIOS®EL18 Battery-operated Lockbolt Tool
Operating instructions
Technical specifications
TIOS®EL18 rivet tool
Rapid charger
TIOS®LIO2830 single charger
TIOS®LIO1820 battery
TIOS®LIO1840 battery
(not supplied)
Range of application
Installation force
Installation stroke
Installation speed
Weight
Height
Width
Nose cap ø
Nose cap length
Battery
Motor
Workspace light
Vibration DIN EN 60745-1
Noise emissions LPA
Lockbolt up to 6.5 mm in diameter
18 kN
max. 25 mm
max. 22 mm/sec.
2.2 kg (1.9 kg without battery)
290 mm
322 mm (without pulling unit)
22.5 mm
58 mm (check deviations)
18 V lithium-ion
Brushless
LED
an < 2.5 m/s
2
< 75 dB(A), short-term > 80 dB(A)
Input voltage
Output voltage
Charging time
Weight
230V / 50Hz
18V
approx. 60 min.
0.55 kg
Power supply
Capacity
Cell type
Number of cells
Weight
18 V Li-Ion
2.0 Ah
lithium-ion manganese
5
0.33 kg
Power supply
Capacity
Cell type
Number of cells
Weight
18 V Li-Ion
4.0 Ah
lithium-ion manganese
5
0.57 kg

11Phone: [phone] Fax: [phone] email: [email protected]LTb1547GB(1113)1
TIOS®EL18 Battery-operated Lockbolt Tool
Operating instructions
List of parts
Note
1. 1 TIOS EL18 battery-operated blind rivet tool
2. 1 TIOS LIO1820 battery
3. 1 TIOS LIO2830 single charger
4. 1 spent mandrel collector
5. Operating Instructions
The pulling head is not supplied.
This must be ordered separately.
See also table on page 16.
1
2
3
4
5

12 Phone: [phone] Fax: [phone] email: [email protected]LTb1547GB(1113)1
TIOS®EL18 Battery-operated Lockbolt Tool
Operating instructions
Description of rivet tool
Required tools
1. Lock nut
2. Housing
3. Spent mandrel collector
4. LED mode status
5. Trigger
6. TIOS LIO1820 battery
7. Hand guard
8. LED light
You will need the following tools to perform all the adjustments, care and maintenance work.
Tools:
– Open-end spanners: SW 13 and SW 17
– Allen key: 1/4 inch
8
7
1
2
3
4
5
6

13Phone: [phone] Fax: [phone] email: [email protected]LTb1547GB(1113)1
TIOS®EL18 Battery-operated Lockbolt Tool
Operating instructions
Storing the rivet tool
Until used for the first time
Longer storage after use
Disposing of the
rivet tool
Maintaining and cleaning
the rivet tool
Caution
Important
If you do not need to use the rivet tool immediately, please store it in its original packaging in
a dry, dust-free place.
Clean the rivet tool (see “Maintaining and cleaning the rivet tool”).
Remove the battery whenever the rivet tool is not in use.
If you do not intend to use the battery for a lengthy period of time, fully charge the battery
and then store in a dry, dust-free place.
Store the rivet tool in a dry, splash-proof place.
Store the rivet tool in a well-ventilated room that is well-protected from heavy dust.
Ensure that no aggressive chemicals or vapours are present in the storage area.
Never store the electrical tool or battery in areas where temperatures exceed 50 °C
Dispose of the rivet tool components in the proper manner. Neither the rivet tool nor its
individual parts should be mixed with household waste. They should be disposed of at a
special collection centre for electronic waste.
Do not dispose of the battery as solid waste. It should be taken to a battery recycling plant
or returned to the manufacturer for disposal.
Risk of injury due to improper care! All maintenance, care and service work on rivet tools
must be conducted by suitably trained personnel. If the tool is used as intended, the operator
should be at no risk. The operator may only carry out the work described in these operating
instructions.
Risk of injury due to falling rivet tool!
Danger of material damage due to corrosion!
Do not use any aggressive cleaning agents or flammable liquids to clean the tool!
Do not spray any cleaning agents, solvents or readily flammable substances into
the vents or openings in the housing.
The following tasks are recommended:
Clean the rivet tool and check for any mechanical faults depending on how and where it
has been used.
If the rivet tool is to be stored for a longer period, first clean the tool,
then lightly grease all the exposed metal components (see “Maintenance intervals”).

14 Phone: [phone] Fax: [phone] email: [email protected]LTb1547GB(1113)1
TIOS®EL18 Battery-operated Lockbolt Tool
Operating instructions
Preparing and fitting the rivet tool
Initial setup
Mandrel collector
Charging battery
Description of LED status
on the charger
1. Read the operating instructions and keep in a safe place.
2. Perform a visual inspection of the devices to check for defective or loose parts
(damage in transit).
3. Plug the charger into the mains.
4. Insert the battery into the charger (check the display!).
5. Charge the battery (approx. 60 min).
6. Attach the spent mandrel collector. To do this, rotate the collector about a quarter turn and
pull backwards to detach. Fully empty the collector and then reattach by following the above
steps in reverse.
7. Insert the battery into the rivet tool until you hear an audible “click”.
(To remove the battery, press the catch downwards and pull the battery forwards).
8. Press the start trigger.
9. The rivet tool is now ready for use.
• Note:
A magnetic contact switch is installed on the mandrel collector. If the collector has not been
fitted or if the contact is not closed, the tool will not operate.
Left LED Right LED
Battery charged
Defective battery
Battery too hot
or too cold
Charging
battery
Mains
Defective
charger

15Phone: [phone] Fax: [phone] email: [email protected]LTb1547GB(1113)1
TIOS®EL18 Battery-operated Lockbolt Tool
Operating instructions
Inserting the battery
Emptying the mandrel collector
• Note:
An audible “click” will be heard if the battery is properly inserted.
• Note:
A magnetic contact switch is installed on the mandrel collector.
Operating the rivet tool
Caution
Caution
Risk of injury due to flying rivet heads! For this reason, no blind rivets should be loaded when
checking the rivet tool. Always wear protective glasses.
Risk of injury due to discharging mandrel! Only use this tool with an undamaged spent
mandrel collector. And always ensure that the collector is correctly in position.

16 Phone: [phone] Fax: [phone] email: [email protected]LTb1547GB(1113)1
TIOS®EL18 Battery-operated Lockbolt Tool
Operating instructions
Selecting the pulling head To install different sizes and types of lockbolts and blind rivets, you can change the pulling
head on the rivet tool. If a different pulling head is already fitted, remove this one first by
following the installation steps in the operating instructions in reverse order.
Always be sure to check the pulling head for signs of exterior damage before installing.
Pulling heads will need to be ordered separately.
The tables below can be used to determine what type of pulling head needs to be fitted.
* Blindniete: Nietschaftdurchmesser; Schließringbolzen: Schaft-Nenndurchmesser
Lockbolts
Blind rivets
Type
Standard
Maxigrip
M-LOCK and
MAGNA BULB
BOM
ø*
5.0
6.5
5.0
6.5
5.0
6.5
5.0
Material
Al / Steel / Stainless steel
Al / Steel / Stainless steel
Al / Steel
Al / Steel
Al / Steel / Stainless steel
Al / Steel / Stainless steel
Steel
Pulling head
99-3003
99-3006
99-1456
99-1477 UK
99-3303
99-3305
99-994
Montage
page 20
page 20
page 20
page 20

17Phone: [phone] Fax: [phone] email: [email protected]LTb1547GB(1113)1
TIOS®EL18 Battery-operated Lockbolt Tool
Operating instructions
Installing the lockbolt
What to remember!
Note
Important
Note
The pulling heads and lockbolts you are using may differ slightly from the ones shown in
the illustrations below.
Damage to materials! Always hold the tool at right angles (90°) to the area where you want t
o install the lockbolts. If held at another angle, the lockbolt will not install correctly.
For details on hole diameters and clamping areas, please refer to the specifications in the
rivet manufacturer's catalogue.
• Getting started
• Insert the lockbolt (a) into the pre-prepared hole
• Slide the locking ring (b) over the mandrel of the lockbolt (a), making sure it is correctly
positioned
• Hold the head of the lockbolt (a) in place. Slide the rivet tool and pulling head (Z) over
the mandrel of the lockbolt (a) and press firmly up against the locking ring (b).
• Press the trigger as far as it will go and hold down. The pulling head will slide over the
locking ring, causing it to deform and press the material into the grooves on the stem.
• Release the trigger. The detached mandrel is then discharged into the spent mandrel
collector when you install the next rivet/lockbolt.

18 Phone: [phone] Fax: [phone] email: [email protected]LTb1547GB(1113)1
TIOS®EL18 Battery-operated Lockbolt Tool
Operating instructions
LED display (operating modes)
The display is located at the back of the housing, below the spent mandrel collector.
The following statuses can be displayed on the LED display when the tool is in operation:
Description of decal:
LED status for rivet tool
Maintaining the rivet tool
Caution Risk of injury due to improper care! All maintenance, care and service work on rivet tools
must be conducted by suitably trained personnel. If the tool is used as intended, the operator
should be at no risk. The operator may only carry out the work described in these operating
instructions.
Replace or charge battery.
Malfunction: Defective charger
LED-display Description of status:
Function test after inserting the battery
and pressing the trigger.
Mandrel collector not or not correctly
fitted, or pressure-sensitive switch not
pressed.
Battery almost flat but still operable.
Battery flat, no longer operable.
Malfunction: Current overload due to
excessive break-load on the mandrel
or overheated tool (55 °C)
Malfunction: The rivet tool is out of
order and no longer works.
Aktion
Fit spent mandrel collector correctly and
press the pressure-sensitive switch.
Replace or charge battery.
Replace or charge battery.
Wrong blind rivet and/or lockbolt used,
or pulling unit is dirty or damaged.
Service the pulling unit or allow the tool
to cool down.
Fit mandrel collector correctly.
Contact your supplier.
Lighting LED comes on briefly;
LED display briefly turns red then green
LED display turns green
LED display flashes orange
LED display remains orange
LED display flashes red
LED display remains red

19Phone: [phone] Fax: [phone] email: [email protected]LTb1547GB(1113)1
TIOS®EL18 Battery-operated Lockbolt Tool
Operating instructions
Maintenance intervals
Interval
Daily before each use
Daily before each use
Daily before each use
Activity
Check for cracks
Check the pulling head for
rivet diameter as well as wear
and tear
Check the jaws and jaw case
How?
Visual inspection
Check pulling head for wear
and tear
Check the clamping jaws in
the pulling heads
Who?
Operator
Operator
Operator
Remarks
If tears appear, submit the
rivet tool to Maintenance.
Replace pulling head if
necessary
Clean or replace clamping
jaws if necessary (see “
Installing the pulling head”)
Cleaning the pulling unit
1
2
Loosen the jaw case using an SW 13 and SW 17 open-end spanner.
Remove the jaw case body (4) from the jaw case (Z) using an SW 17 open-end spanner
and 1/4 inch Allen key.
Clean all the parts thoroughly using a cleaning rag or compressed air.
Reassemble following the above steps in reverse order.
Before reassembly, grease the jaws with an acid-free oil.
Remove the battery before beginning any work on the rivet tool.
Loosen the lock nut (17) and remove by pulling it forwards.
Pull the pulling head (14) and guide bushing forwards and remove.
2
3
Z
Z
4

20 Phone: [phone] Fax: [phone] email: [email protected]LTb1547GB(1113)1
TIOS®EL18 Battery-operated Lockbolt Tool
Operating instructions
Replacing the pulling unit
1
2
Loosen the jaw case (Z) using and SW 13 and SW 17 open-end spanner.
Remove the jaw case body (4) from the jaw case (Z) using an SW 17 open-end spanner
and a 1/4Allen key.
When selecting the pulling unit, check that it meets the required specifications
(tool + fastener) – see table on page 16.
Reassemble following the above steps in reverse order.
Remove the battery (7) before beginning any work on the rivet tool.
Loosen the lock nut (2) and remove by pulling it forwards.
Ziehen Sie die Zugkopfhülse (Z) und die Führungshülse (3) nach vorne ab.
2
3
Z
Z
4
Note A degree of play within the pulling unit has been incorporated into the design.
This ensures that the battery-operated tool will always work as required.
4
7
