Titus Glissando TL 170 User manual

2.13
41
88.5
24
52.5
12.4
K
For S-type 170 and B-type 170 hinges
Glissando TL 170
Add-on Hinge Soft
Closing Solution
Made of steel and plastic
Technical details
951-0F15-650
Item number
Glissando TL 170
'snap-on'
Striking plate
Box content
100 pcs soft closing mechanisms
100 pcs striking plates
Soft closing mechanism
170°
For the following
cup types
Hinge opening angle
Screw-on
ready
Machine
insertion
ready
Pre-mounted
euro screws
Pre-mounted
chipboard
screws
Easy-fix
system
Pre-mounted
expando
dowels
Legend of hinge cup symbols
03_Glissando_soft_closing3.indd 13 26. 04. 16 13.27

2.14
2
3
4
5
5050
22 33 44 55
100100
150150
200200
250250
cmcm
NN
GlissandoGlissando
Soft Closing Systems
Turn towards ‘+’ to increase and
‘-’ to decrease the damping
Damping adjustment
· Gentle and reliable soft closing on doors
with wider opening angle
· Fits perfectly 45/9.5mm, 48/6mm
and 52/5.5mm hinge cups
· Furniture consumers’ preferred 'ConfidentClose'
· Tool free mounting
Mounting details
Recommended number per door
and positioning
Insert Glissando TL 170 into the holes on the hinge cup Press down
Toolless mounting
Place the striking plate into the hole on the hinge arm Press down
