Mocka Aspen User manual

mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Aspen Bedside Table
Thank you for yourpurchase. Please follow the instructions for correct
assembly.While we took great eort to ensure these assembly instructions
were correct at the time of printing, sometimes updates are required post
production. For the most up to date versions please refer to the product
page on our website.mocka.com.au/mocka.co.nz

Partlist
Aspen Bedside Table
mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
x1
1Top Panel
x1
x2
2
7
Bottom Panel
Drawer Front
x1
x6
3
8
9
left Side Panel
Drawer Base
x2
Right Drawer Side
x1
4Right Side Panel
x4
5Legs
x1
6Back Panel
x2
11 Drawer Back
10 x2
Left Drawer Side
Panel Layout
7
10
9
8
11
x2
1
2
3
4
6
5
5
5
5

Aspen Bedside Table
mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
HARDWARE SUPPLIED
A B C D
I J K
EF
bolt
x12
medium screw
x8
wedge
x4
dowel
x8
locking
nut x 12
small screw
x16
handle
x2
long screw
x12
cover
x8
40 mm
12 mm
30 mm
CL
CR
DL
DR
L+R
slide rail
x4
L+R
slide rail
x4
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall
anchor with all furniture sold and we recommend these are used to prevent your product tipping.
The fixing device provided should fit most wall types, but please note that dierent wall materials
may require dierent fixing devices from those supplied.
Z
Y
wall
anchor x 1
screw
x 1
safety
strap x 1
wall
screw x 1
washer
x 1
XWV
WALL STRAP
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
Phillips & Flathead screwdrivers
and hammer required

1
A x4
Hardware Needed
Hardware Needed
2
Aspen Bedside Table
mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
x4
E
x2
CL
Y x1
Wx1
A
CL
E
3
E
E
E
E
CL
CL
A
1
A
A
A
Y
W

Aspen Bedside Table
3
4
mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Hardware Needed
Hardware Needed
E x4
CR x2
CR
E
4
E
E
E
E
CR
CR
D
D
D
D
D
D
D
D
2
5
5
5
5
x8
D

Aspen Bedside Table
5
6
mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Hardware Needed
D
D
D
D
C
C
C
C
4
2
3
x4
C
x4
D
6
34

Aspen Bedside Table
7
Hardware Needed
8
mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Hardware Needed
x4
B
x4
C
Drawers x 2
Fx8
34
1
CC
CC
B
B
B
B
10
9
11
F
F
F
F

Aspen Bedside Table
9
10
mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
Hardware Needed
Drawers x 2
B
Drawers x 2
A x8
I x2
7
A
A
A
A
I
I
8
9
10
11

Aspen Bedside Table
11
12
mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
B x8
Hardware Needed
K x8
Drawers x 2
E x8
Hardware Needed
Drawers x 2
DL x2
DR x2
B
BB
B
B
9
10
B
I
II
BK
x 8
7
C
10
9
E
E
E
E
7
DL
DR
9
E
DR

Aspen Bedside Table
13
14
mocka.co.nz I mocka.com.au
ASSEMBLY INSTRUCTIONS
X x1
Hardware Needed
C
Strap
Washer
Wall
anchor
Wall
screw
X
Z
Wall
screw
Y x1
Note: Seek advice from a qualified
trades person on how to attach this
safety strap to your specific wall.
Z x1
Once assembled lift furniture into
place, do not drag.
J
6
J
J
J
J
J
Hardware Needed
J x4
