Lightolier Lytespan 83ED17RNS User manual

5-1/8"
130mm
3-5/16"
84mm
2
1
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2003 Genlyte Thomas Group LLC (Lightolier Division) • D0104
Lytespan® Track Lighting System 83ED17RNS
Page 1 of 2 Metal Halide ED-17 Reflector Narrow Spot
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Ordering Information
Catalog No. Finishes Lamps
83ED17RNS Anodized ED-17 or E-17 Clear,
Protected or Unprotected Ceramic Metal Halide
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Features
1. Narrow Spot Reflector: Aluminum, specular, anodized and sealed.
2. Hold Spring: (3) steel springs hold reflector into mating luminaire.
For Use With Luminaires
Track: 8387, 8388, 8389 Metal Halide Lytespot®series.
Track: 8307, 8317, 8307U, 8317U
Semi-Recessed: SRE1770MH, SRE1710MH
Recessed Pull Down; PDE1770MH, PDE1710MH
Finish
Specular Anodized and Sealed.
Labels
UL, cUL

Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2003 Genlyte Thomas Group LLC (Lightolier Division) • D0104
Job Information Type:
Narrow Spot Reflector - with 70W ED17 Master Color Ceramic Metal Halide Philips Protected (Clear) Lamp for Open Luminaires
AIMING ANGLE: 0° Horizontal Aiming 30° Horizontal Aiming 30° Vertical Aiming 45° Vertical Aiming
DFC L W DC FC L W DC FC L W DC FC L W
Beam Spread CBCP Rated
(To 50% CBCP) Life (Hrs.)
12’ 382 1.7’ 1.7’
16’ 215 2.2’ 2.2’
20’ 137 2.8’ 2.8’
24’ 95 3.4’ 3.4’
10’ 5.8’ 357 1.9’ 1.6’
12’ 6.9’ 248 2.2’ 1.9’
20’ 11.5’ 89 3.7’ 3.2’
25’ 14.4’ 57 4.7’ 4.0’
5’ 8.7’ 275 2.8’ 1.4’
6’ 10.4’ 191 3.4’ 1.7’
10’ 17.3’ 69 5.7’ 2.8’
12’ 20.8’ 48 6.8’ 3.4’
8’ 8’ 304 2.2’ 1.6’
10’ 10’ 194 2.8’ 2.0’
16’ 16’ 76 4.5’ 3.2’
20’ 20’ 49 5.6’ 4.0’
54,959 10,000
8˚ X 8˚
For 50W: Multiply values by .68 Rated Lamp Life 10,000
For 100W: Multiply values by 1.5 Rated Lamp Life 12,500
Lytespan® Track Lighting System 83ED17RNS
Page 2 of 2 Metal Halide ED-17 Reflector Narrow Spot
AIMING ANGLE: 0° 30° Horizontal 30° Vertical 45° Vertical
L Beam Length D Distance
W Beam Width A Aiming Angle
CDistance to center beam FC Footcandles
Land Ware the outer points where the candle power drops
to 50% of the maximum. FC are the initial footcandles at the
center of the beam.
Lamp data shown is typical. Consult lamp manufacturers for
availability and performance.
Narrow Spot Reflector - When used in 8307U and 8317U with 70W ED17 Master Color Ceramic Metal Halide Philips (Clear) Lamp
for Enclosed Luminaires
AIMING ANGLE: 0° Horizontal Aiming 30° Horizontal Aiming
DFC L W DC FC L W
DC FC L W DC FC L W
Beam Spread CBCP Rated
(To 50% CBCP) Life (Hrs.)
12’ 492 1.7’ 1.7’
16’ 277 2.2’ 2.2’
20’ 177 2.8’ 2.8’
24’ 123 3.4’ 3.4’
10’ 5.8’ 460 1.9’ 1.6’
12’ 6.9’ 320 2.2’ 1.9’
20’ 11.5’ 115 3.7’ 3.2’
25’ 14.4’ 74 4.7’ 4.0’
5’ 8.7’ 354 2.8’ 1.4’
6’ 10.4’ 246 3.4’ 1.7’
10’ 17.3’ 89 5.7’ 2.8’
12’ 20.8’ 62 6.8’ 3.4’
8’ 8’ 392 2.2’ 1.6’
10’ 10’ 251 2.8’ 2.0’
16’ 16’ 98 4.5’ 3.2’
20’ 20’ 63 5.6’ 4.0’
70,888 10,000
8˚ X 8˚
For 50W: Multiply values by .68
Rated Lamp Life 10,000
For 100W: Multiply values by 1.5
Rated Lamp Life 12,500
AIMING ANGLE: 0° 30° Horizontal 30° Vertical 45° Vertical
L Beam Length D Distance
W Beam Width A Aiming Angle
CDistance to center beam FC Footcandles
Land Ware the outer points where the candle power drops
to 50% of the maximum. FC are the initial footcandles at the
center of the beam.
Lamp data shown is typical. Consult lamp manufacturers for
availability and performance.
30° Vertical Aiming 45° Vertical Aiming
