TKF ACE Instruction Manual

Magnet locator
ACE-GL-613513-v01-e
date
:
25-06-2021
Spinnerstraat 15 | P.O. Box 6 | 7481 KJ Haaksbergen | the Netherlands | Phone: [phone] | Email: [email protected] 1/14
www.tkf-telecom.eu Subject to technical modifications | No rights can be derived from this information
Document history
version
date
comment
01
June 2021
First release
Guideline for device hardware version E
Software version 2021-05-06

Spinnerstraat 15 | P.O. Box 6 | 7481 KJ Haaksbergen | the Netherlands | Phone: [phone] | Email: [e-mail] 2/14
www.tkf-telecom.eu Subject to technical modifications | No rights can be derived from this information
General information
Only use the Magnet Locator in accordance with the operating instructions. Please read this instructions carefully and pay
particular attention to the safety instructions before using the device.
Manufacturer’s address
BV Twensche Kabelfabriek
P.O. Box 6
7480 AA, Haaksbergen
The Netherlands
Tel.: [phone]
E-mail: [email protected]
Explanation of the pictograms and other information
General warning.
Disposal of batteries as municipal waste is not permissible.

Spinnerstraat 15 | P.O. Box 6 | 7481 KJ Haaksbergen | the Netherlands | Phone: [phone] | Email: [e-mail] 3/14
www.tkf-telecom.eu Subject to technical modifications | No rights can be derived from this information
Description
Figure 1: Magnet Locator front
Figure 2: Magnet locator back
Operating controls and indicators
1- Marking hole
2- On/Off button
3- LED indicator for direction and depth
4- Quick guide
5- Connector for an external measuring module
6- Label with distributor address and serial number
7- Battery compartment
Delivery contents
•Magnet Locator
•4x AA batteries (LR6)
•Operating instructions
•Suitcase
Use of the product as directed
The Magnet Locator is a measuring device that can be used for the localization of magnets.
Its purpose is to find magnets that have been previously placed into a wall and to mark that spot for drilling. The Magnet
Locator has LED lights that indicate the direction in which the magnet is located. This allows the exact position of the
magnet to be found very quickly. Once the position is found, a flashing LED indicates the depth at which the magnet
is located within the wall.
By using magnets in combination with the Magnet Locator it is possible to bury non-metallic connections, such as fibre
optics, in walls in order to find and uncover them for later use.
The Magnet Locator was developed to detects magnets in walls and not any
other objects such electric cables, water or gas pipes. Iron-containing objects
in the wall can interfere with the measurement. Accordingly, the greatest care
and attention must always be exercised while working.

Spinnerstraat 15 | P.O. Box 6 | 7481 KJ Haaksbergen | the Netherlands | Phone: [phone] | Email: [e-mail] 4/14
www.tkf-telecom.eu Subject to technical modifications | No rights can be derived from this information
Measuring principle
According to a patented method (WO 2020/204710
A1), the position and distance of the magnet are
measured via 4 magnetic field sensors. Each magnetic
sensor measures the field strength of the magnet in
three dimensions. The evaluation is independent of the
orientation (north or south pole) of the magnet.
The vertical distance to the magnet is determined by
the angles of the field vectors and is independent of
the field strength. The distance is indicated by a
flashing signal lamp.
Figure 3: Flux lines of a cylindrical magnet with angles drawn in
Optionally, the device can be operated with an external measuring head.

Spinnerstraat 15 | P.O. Box 6 | 7481 KJ Haaksbergen | the Netherlands | Phone: [phone] | Email: [e-mail] 5/14
www.tkf-telecom.eu Subject to technical modifications | No rights can be derived from this information
Operation
On the front label of the Magnet Locator is a quick
guide that summarizes the operating steps (Figure 1 –
No 4).
Figure 4: quick guide on the front label
Inserting the batteries
1- Remove the batteries from the packaging and insert them in the device.
2- Check that the battery terminals are positioned correctly as shown on the label in the battery compartment (Figure
2 No. 7).
Do not use damaged batteries.
Disposal of batteries as municipal waste is not permissible.
Switching the Magnet Locator On and Off
Press the on/off button (Figure 1 No. 2).
The Magnet Locator automatically turns off after 2 minutes idle time.
Calibration through zero-adjustment
The Magnet Locator performs a zero adjustment after
each power-up to compensate for disturbances and
contributions, such as the earth's magnetic field.
During this process, all LEDs blink slowly for a few
seconds.
Hold the Magnet Locator in open space at the position
in which you want to measure later and switch it on
Figure 5: State of the front label during the calibration
For a measurement on a wall, hold the Magnet Locator vertically.
For a measurement on the ceiling, hold it horizontally above the head, etc.

Spinnerstraat 15 | P.O. Box 6 | 7481 KJ Haaksbergen | the Netherlands | Phone: [phone] | Email: [e-mail] 6/14
www.tkf-telecom.eu Subject to technical modifications | No rights can be derived from this information
After a successful calibration, the LED lights will
circulate and the Magnet Locator is ready
for use.
Figure 6: Front label with circulating LEDs
Finding the magnet position
Place the Magnet Locator on the surface where the
magnet is suspected. If the LEDs stop circulating, you
are close to a magnet. One or more LEDs will light up
on one side, indicating the direction in which the
magnet is located. Move the Magnet Locator slowly in
the indicated direction.
Figure 7: Moving the Magnet Locator towards the magnet, indicated by the
glowing LED
The Magnet Locator was developed to detects magnets in walls and not any
other objects such electric cables, water or gas pipes. Iron-containing objects
in the wall can interfere with the measurement. Accordingly, the greatest care
and attention must always be exercised while working.
The intention is to bring the central axis of the marking
hole directly above the magnet axis. If both axes are
above each other, all LEDs light up. Mark this position
with a pen through the marking hole
Figure 8: At the position of the magnet, all LEDs are glowing
Never drill directly through the Magnet Locator with a machine. Slipping off
can lead to the destruction of the sensors.

Spinnerstraat 15 | P.O. Box 6 | 7481 KJ Haaksbergen | the Netherlands | Phone: [phone] | Email: [e-mail] 7/14
www.tkf-telecom.eu Subject to technical modifications | No rights can be derived from this information
Measure the depth of the magnet
If the magnet is located at a depth of 35 –70 mm
inside the wall, one LED will start flashing after the
magnet has been found. The flashing LED indicates
how deep the magnet is in the wall according to the
label on the Magnet Locator.
The measurement depends on the dimension of the
magnet. The calculation is optimized for a long
cylindrical magnet with a diameter of 8 mm. The
accuracy of this measurement is then ±5 mm.
Figure 9: The flashing LED indicates the depth of the magnet within the wall
Iron parts in the wall or the orientation of the magnet within the wall can falsify
this value. The magnetic axis and the magnetic pole should be perpendicular
to the wall surface.
Using the external measurement module
By attaching the external measuring module, the
integrated sensor unit of the Magnet Locator is not
used anymore. Instead, the LEDs on the Magnet
Locator are related to the sensor unit in the external
housing.
The measurement procedure is basically the same as
in section 3.3 –3.5, except that the measurement
module must be held against the wall instead of the
Magnet Locator.
Figure 10: Moving the external measuring module towards the magnet,
indicated by the glowing LED
Figure 11: At the position of the magnet, all LEDs are glowing on the Magnet
Locator

Spinnerstraat 15 | P.O. Box 6 | 7481 KJ Haaksbergen | the Netherlands | Phone: [phone] | Email: [e-mail] 8/14
www.tkf-telecom.eu Subject to technical modifications | No rights can be derived from this information
Care and maintenance
Cleaning and drying
Use only a clean, soft cloth for cleaning. If necessary, moisten the cloth slightly with pure alcohol or a little water.
Do not use any other liquids as these may damage the plastic components.
Storage
Remove the batteries from the device before storing it for a long period. Leaking batteries may damage the device.
Observe the temperature limits when storing your equipment, especially in winter / summer if the equipment is kept inside a
motor vehicle (-40°C to +60°C).
Transport
Use the supplied suitcase or packaging of equivalent quality for transporting or shipping your equipment.
Always remove the batteries before shipping the device.

Spinnerstraat 15 | P.O. Box 6 | 7481 KJ Haaksbergen | the Netherlands | Phone: [phone] | Email: [e-mail] 9/14
www.tkf-telecom.eu Subject to technical modifications | No rights can be derived from this information
Safety instructions
Read and understand all instructions. In addition to the information relevant to safety given in each of the sections of these
operating instructions, the following points must be strictly observed at all times
Basic information concerning safety
•Modification of the device or tampering with its parts is not permissible.
•Observe the information printed in the operating instructions concerning operation, care and maintenance.
•Take the influences of the surrounding area into account. Do not use the device where there is a risk of fire or
explosion.
•Check that the device functions correctly each time before use
Intended use
The Magnet Locator was developed to detects magnets in walls and not any other objects such electric cables, water or gas
pipes. Iron-containing objects in the wall can interfere with the measurement. Accordingly, the greatest care and attention
must always be exercised while working.
Proper organization of the workplace
•Check the condition of the device before use. If the device is found to be damaged, send it back to your distributor
for repair.
•The user must check the accuracy of the device after it has been dropped or subjected to other mechanical
stresses.
•Do not drill directly through the marking hole. Slipping off can lead to the destruction of the sensors
Electrical
•Keep the batteries out of reach of children.
•Do not allow the batteries to overheat and do not expose them to fire. The batteries may explode or release toxic
substances.
•Do not charge the batteries.
•Do not solder the batteries into the device.
•Do not discharge the batteries by short circuiting as this may cause them to overheat and swell up.
•Do not attempt to open the batteries and do not subject them to excessive mechanical stress

Spinnerstraat 15 | P.O. Box 6 | 7481 KJ Haaksbergen | the Netherlands | Phone: [phone] | Email: [e-mail] 10/14
www.tkf-telecom.eu Subject to technical modifications | No rights can be derived from this information
Troubleshooting
Fault
Possible cause
Remedy
Magnet Locator does not turn on
Batteries are not equipped or dead
Check/Change batteries
The Magnet Locator is defective
Send back to supplier
Magnet Locator turns off
Batteries are dead
Change batteries
Power-off due to idle (2 min)
Turn on again
Not all LEDs glowing after startup
The Magnet Locator is defective
Send back to supplier
The LEDs do not start to circulate
Sensor unit defect
Send back to supplier
Measurements are inaccurate
The influence of metal in the wall is too
strong
Check the device on a metal free wall
False magnet orientation in the wall
The magnets pole has to be
perpendicular to the walls surface to get
a proper result of the position and depth
Faulty calibration
Repeat the calibration (section
“Calibration through zero-adjustment”)
Wrong magnet dimensions
The depth measurement is optimized for
cylindrical magnets with a diameter of 8
mm

Spinnerstraat 15 | P.O. Box 6 | 7481 KJ Haaksbergen | the Netherlands | Phone: [phone] | Email: [e-mail] 11/14
www.tkf-telecom.eu Subject to technical modifications | No rights can be derived from this information
Disposal
Improper disposal of the equipment may have serious consequences: The burning of plastic components generates toxic
fumes which may present a health hazard. Batteries may explode if damaged or exposed to very high temperatures,
causing poisoning, burns, acid burns or environmental pollution. Careless disposal may permit unauthorized and improper
use of the equipment. This may result in serious personal injury, injury to third parties and pollution of the environment.
Ask the supplier for further information about taking back the device for disposal.
For EC countries only
Disposal of electric tools together with household waste is not permissible.
In observance of European Directive 2002/96/EC on waste electrical and electronic equipment and its implementation in
accordance with national law, electric tools that have reached the end of their life must be collected separately and returned
to an environmentally compatible recycling facility.
Dispose of the batteries in accordance with national regulations.

Spinnerstraat 15 | P.O. Box 6 | 7481 KJ Haaksbergen | the Netherlands | Phone: [phone] | Email: [e-mail] 12/14
www.tkf-telecom.eu Subject to technical modifications | No rights can be derived from this information
Technical data
General
Power Supply
Battery 4 x AA 1.5 V (R6, LR6)
Alternatives:
•4x NiMH accumulators 1.2V (HR6)
•4x NiCd accumulators 1.2V (KR6, KR157/51)
The accumulators must be charged externally
Power Consumption
max. 370 mW
Operating Time
approx. 70h with 2960mAh alkali-manganese batteries
Operating Conditions
-10°C to +40°C; < 85% relative humidity, non-condensing
Storage
-40°C to +60°C; < 85% relative humidity, non-condensing
Housing Material
ABS plastic
Marking Hole
Inner diameter of 9.5 mm
Housing Dimensions
approx. 220 x 100 x 32 mm
Weight
approx. 350 g (incl. batteries)
Protection Class
IP54
Warranty
2 years
WEEE
WEEE-Reg-No. NL 060084145 (OPEN)
Accessories
external measuring module (optional)
Functions
Localization of Magnets
Calculation of the depth of the magnet in a wall
Automatic power-off at 2 min idle
Display
8 red LEDs for visual indication of the position of the magnet
Operating
Via a button on the front panel
External Interface
5-pin M8 connector for the external measuring module
Measurement Properties
Measuring Method
Arrangement of magnet sensors
Minimum Flux Density
650 µT for the position; The depth measurement is independent
from the flux density
Depth measurement
min. 35 mm up to max. 70 mm
Measurement accuracy OWST application
Position ±1 mm
Depth ± 5 mm
Patent Number
WO 2020/204710 A

Spinnerstraat 15 | P.O. Box 6 | 7481 KJ Haaksbergen | the Netherlands | Phone: [phone] | Email: [e-mail] 13/14
www.tkf-telecom.eu Subject to technical modifications | No rights can be derived from this information
Declaration of conformity

Spinnerstraat 15 | P.O. Box 6 | 7481 KJ Haaksbergen | the Netherlands | Phone: [phone] | Email: [e-mail] 14/14
www.tkf-telecom.eu Subject to technical modifications | No rights can be derived from this information
Warranty and copyright
© Copyright 2021
All rights reserved. No part of the
manual or the device including its
control program (software) is allowed
to be reproduced or duplicated without
written authorization of the author.
Verification of Suitability
BV Twentsche Kabelfabriek hereby
certifies that this product has been
inspected and tested before shipment
in accordance with the stated technical
data.
Warranty
The warranty is valid for two years
starting from the date of shipment and
comprises material and fabrication
errors.
Return Under Warranty
In case of warranty the device must be
returned to BV Twentsche
Kabelfabriek. On returning the device
under warranty, the buyer bears the
costs for the shipment to BV
Twentsche Kabelfabriek, while BV
Twentsche Kabelfabriek bears the
costs for returning the device to the
buyer. However, the buyer bears all
the costs for shipment, taxes and
duties, if the device is returned to BV
Twentsche Kabelfabriek from outside
the Netherlands.
Extent of Warranty
The warranty already mentioned does
not apply for errors due to inadequate
or insufficient maintenance on the part
of the buyer, due to unauthorized
modifications or maloperation, to
software or interfaces provided by the
buyer, or to operations beyond normal
ambient conditions. The buyer is
solely responsible for design and
assembly of electric circuits in
connection with this product.
BV Twentsche Kabelfabriek cannot be
made liable neither for customers'
circuits nor for malfunctions of the
product resulting from these. Any
further explicit or tacit warranty is
excluded; BV Twentsche Kabelfabriek
especially rejects any tacit warranty
concerning the qualification for a
special purpose or to marketability.
Exclusive Measures
The above-mentioned measures are
the only and exclusive measures on
the side of the buyer. BV Twentsche
Kabelfabriek is not liable for direct,
indirect, particular damages or
damages resulting from negligence or
consequential damages, no matter if
they are founded on warranty,
contract, offence or any further legal
theory. This does not apply as far as
BV Twentsche Kabelfabriek is
necessarily made liable by law.
Annotation
The information in this document is
subject to alterations without prior
announcement.
BV Twentsche Kabelfabriek does not
take over warranty for this material
including the marketability or its
qualification for any determined
purpose beyond.
BV Twentsche Kabelfabriek do not
take over liability for errors in this
manual or for accidental or
consequential errors within the context
of shipment, performance or usage of
this material. No portion of this
document may reproduced, translated
or transmitted, in any form or by any
means, electronic, mechanical,
photocopying, recording, or otherwise,
without the express written permission
of BV Twentsche Kabelfabriek.
Safety
Do not replace any parts and do not
make alterations to the product without
our explicit and written consent. Send
the product to BV Twentsche
Kabelfabriek for repair and
maintenance to safeguard that all
safety features be preserved. Handling
malpractices may lead to damage at
the device and possibly to injuries and
death of persons.
Haaksbergen, June 2021
BV Twentsche Kabelfabriek
