TLS Electronics BL 30100 HDBaseT User manual

User manual
BL 30100
HDBaseT

30100 BL HDBaseT
Ecco Cine Supply and Service GmbH Contact: [e-mail] 2
Table of contents
Table of contents................................................................................................2
Safety information..............................................................................................3
Introduction........................................................................................................4
Features.............................................................................................................4
Panel Description...............................................................................................5
Transmitter Front Side....................................................................................5
Transmitter Back Side.....................................................................................5
Receiver Front Side........................................................................................6
Receiver Back Side ........................................................................................6
Connection Diagram..........................................................................................7
Specifications.....................................................................................................7
Package Contents .............................................................................................8
Maintenance......................................................................................................8
Warranty Policy..................................................................................................8
Limitations of Warranty......................................................................................9
Exclusive Remedies ..........................................................................................9
RMA Policy ......................................................................................................10
Standard Replacement....................................................................................10
Once you have obtained an RMA number.......................................................10
Please note:..................................................................................................... 11
Warranty.......................................................................................................... 11
Return and RMA Policies................................................................................. 11

30100 BL HDBaseT
Ecco Cine Supply and Service GmbH Contact: [e-mail] 3
Thank you for purchasing this product. For optimum performance and safety,
please read these instructions carefully before connecting, operating or
adjusting this product. Please keep this manual for future reference.
SURGE PROTECTION DEVICE RECOMMENDED
This product contains sensitive electrical components that may be damaged by
electrical spikes, surges, electric shock, lightning strikes, etc. Use of surge
protection systems is highly recommended in order to protect and extend the life
of your equipment.
Safety information
To reduce the risk of electric shock, do not expose this product to
rain or moisture
Do not modify the wall plug. Doing so will void the warranty and
safety features
If the wall plug does not fit into your local power socket, hire an
electrician to replace your obsolete socket.
This equipment should be installed near the socket outlet and the
device should be easily accessible in the case it requires
disconnection

30100 BL HDBaseT
Ecco Cine Supply and Service GmbH Contact: [e-mail] 4
Introduction
30100 BL HDBaseT extends uninterrupted 1080p signal up to 230ft (70m) with
the HDBaseT technology. With pass through support of 4Kx2K, 1920x1200,
lossy & lossless audio, and bi-directional IR signals over a single category
cable, the HD extenders provide affordable, high quality, solutions for your
audio/video and IR control needs.
Features
Extends IR and audio/visual content up to 230ft @ 1080p over a single
category cable according HDBaseT specification
Supports 4Kx2K pass through up to 130ft
3.5mm jack IR I/O ports for emitting and receiving IR control signals for use
with IR remote controls and 3rd party control boxes
POH(Power over HDBaseT) feature removes the need for a power supply
at the receiver
Lossy and lossless multi-channel audio formats pass through (including
Dolby TrueHD and DTS-HD Master Audio)
Full 3D pass through
HDCP compliant
Note：
The POH function is designed for powering compatible transmitter or receiver
units of TLS only.

30100 BL HDBaseT
Ecco Cine Supply and Service GmbH Contact: [e-mail] 5
Panel Description
Transmitter Front Side
①HDMI input indicator
②HDMI input
③IR Receiver jack
④IR Transmitter jack
⑤Power indicator
⑥DC power input
Transmitter Back Side
①HDBaseT output indicator
②HDBaseT output

30100 BL HDBaseT
Ecco Cine Supply and Service GmbH Contact: [e-mail] 6
Receiver Front Side
①HDBaseT input indicator
②HDBaseT input
Receiver Back Side
①HDMI output indicator
②HDMI output
③IR Receiver jack
④IR Transmitter jack
⑤Power indicator
⑥DC power input

30100 BL HDBaseT
Ecco Cine Supply and Service GmbH Contact: [e-mail] 7
Connection Diagram
Specifications
Bandwidth
2.97Gbps per Color
Video input
Transmitter
1XHDMI Type A, 19-pin, female
Receiver
1xRJ45
Video output
Transmitter
1xRJ45
Receiver
1XHDMI Type A, 19-pin, female
IR input
1x3.5mm stereo jack
IR output
1x3.5mm stereo jack
Power Supply
12V/2ADC, screw type connector
Power Consumption
9.5W
Audio
Passes up to DolbyTrueHD or DTS-HD MasterAudio
Resolution
Video: up to 4Kx2K
VESA: up to 1920x1200
Distance
230ft @ 1080p over CAT5e/6
130ft @ 4Kx2K over CAT5e/6
Dimensions
105x73x27mm
Weight
200g
Temperature
Operating
32°F to 104°F (0°C to 40°C)
Storage
-4°F to 140°F (20°C to 60°C)
Rack-Mountable
Rack ears included

30100 BL HDBaseT
Ecco Cine Supply and Service GmbH Contact: [e-mail] 8
NOTE:Specifications are subject to change without notice. Weight and dimensions are approximate.
Package Contents
1x 30100 BL HDBaseT Set
1x 12V/2A DC power supply
1x IR Transmitter, 1x IR Receiver.
4x mounting brackets.
1x user manual.
Maintenance
Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or
benzene to clean this unit.
Warranty Policy
TLS electronics products are warranted against defects in material and
workmanship for two years from the date of shipment. During the warranty
period, TLS electronics will, at its option, repair or replace products that prove
to be defective. Repairs are warranted for the remainder of the original
warranty or a 90 day extended warranty, whichever is longer.
For equipment under warranty, the owner is responsible for freight to TLS
electronics and all related customs, taxes, tariffs, insurance, etc. TLS
electronics is responsible for the freight charges only for return of the equip-
ment from the factory to the owner. TLS electronics will return the equipment by
the same method (i.e., Air, Express, Surface) as the equipment was send to
TLS electronics.
All equipment returned for warranty repair must have a valid RMA number
issued prior to return and be marked clearly on the return packaging. TLS
electronics strongly recommends all equipment be returned in its original
packaging.

30100 BL HDBaseT
Ecco Cine Supply and Service GmbH Contact: [e-mail] 9
TLS electronics obligations under this warranty are limited to repair or replace-
ment of failed parts, and the return shipment to the buyer of the repaired or
replaced parts.
Limitations of Warranty
The warranty does not apply to any part of a product that has been installed,
altered, repaired, or misused in any way that, in the opinion of TLS electronics,
would affect the reliability or detracts from the performance of any part of the
product, or is damaged as the result of use in a way or with equipment that had
not been previously approved by TLS electronics.
The warranty does not apply to any product or parts thereof where the serial
number or the serial number of any of its parts has been altered, defaced, or
removed.
The warranty does not cover damage or loss incurred in transportation of the
product.
The warranty does not cover replacement or repair necessitated by loss or
damage from any cause beyond the control of TLS electronics, such as light-
ning or other natural and weather related events or wartime environments.
The warranty does not cover any labor involved in the removal and or
reinstallation of warranted equipment or parts on site, or any labor required to
diagnose the necessity for repair or replacement.
The warranty excludes any responsibility by TLS electronics for incidental or
consequential damages arising from the use of the equipment or products, or
forany inability to use them either separate from or in combination with any
other equipment or products.
A fixed charge established for each product will be imposed for all equipment
returned for warranty repair where TLS electronics cannot identify the cause of
the reported failure.
Exclusive Remedies
TLS electronics’s warranty, as stated is in lieu of all other warranties, expressed,
implied, or statutory, including those of merchantability and fitness for a
particular purpose. The buyer shall pass on to any purchaser, lessee, or other
user of TLS electronics’s products, the aforementioned warranty, and shall
indemnify and hold harmless TLS electronics from any claims or liability of such
purchaser, lessee, or user based upon allegations that the buyer, its agents, or

30100 BL HDBaseT
Ecco Cine Supply and Service GmbH Contact: [e-mail] 10
employees have made additional warranties or representations as to product
preference or use.
The remedies provided herein are the buyer’s sole and exclusive remedies.
TLS electronics shall not be liable for any direct, indirect, special, incidental, or
consequential damages, whether based on contract, tort, or any other legal
theory.
RMA Policy
When returning product to TLS electronics for any reason, the customer should
fill out the official RMA form to obtain a RMA number. Without the permission or
approval, TLS electronics will be no responsible for any return. This can be
initiated by emailing or calling your related sales.
All requests are processed within 48 hours.
Standard Replacement
For customers that agree to return defective product to TLS electronics first, a
Standard Replacement option is available.
An RMA number must first be issued by sales. This RMA number will need to
be referenced on the outside of the return shipment.
Upon receipt of the defective product, TLS electronics will, at its discretion,
either repair or replace the product and ship it out in the most expeditious
manner possible. Subject to availability, the replacement product will be
shipped on the business day following receipt of the defective product.
In the event the product returned to TLS electronics has been discontinued (i.e.
the product is no longer being manufactured by TLS electronics but is still
under warranty), TLS electronics will, at its discretion, either repair or replace
with recertified product.
Once you have obtained an RMA number
After obtaining an RMA number from TLS electronics, you must send the
product - freight prepaid - to TLS electronics. The TLS electronics RMA number
must be prominently displayed on the outside of your package. If you send your
product to TLS electronics without the RMA number prominently displayed on
the outside of the package, it will be returned to you unopened.

30100 BL HDBaseT
Ecco Cine Supply and Service GmbH Contact: [e-mail] 11
Please use a shipping company that can demonstrate proof of delivery. TLS
electronics does not accept responsibility for any lost shipments unless proof of
delivery to TLS electronics is provided.
Please note:
Product shipped to TLS electronics must be properly packaged to prevent loss
or damage in transit.
Shipping your RMA to TLS electronics using regular mailing envelopes is not
acceptable, as they do not protect the product from damage during shipping.
TLS electronics will not repair or replace a module that is shipped in such a way
that the product is not properly protected.
TLS electronics will not accept any product that has been damaged as a result
of accident, abuse, misuse, natural or personal disaster, or any unauthorized
disassemble, repair or modification.
Warranty
Warranty time is two year and from the date of original shipment.
This warranty shall be void if a serial number has been removed from the
product.
Upon determination of a legitimate defect covered by this warranty and at TLS
sole discretion, user should bear the transport cost during the warranty.
If product is out of warranty then repair charge is required. Minimum repair
charge: 10% of the retail price plus the cost of failed components. We will
repair the failed product after repair cost has been approved by Customers and
proper financial arrangements are made. Customer must cover round trip ship-
ment expenses.
Return and RMA Policies
Shipments will not be receiver and processed for warranty repair/replacement
without an TLS electronics RMA(Return Materials Authorization).

30100 BL HDBaseT
Ecco Cine Supply and Service GmbH Contact: [e-mail] 12
Ecco Cine Supply and Service GmbH
Germany
40721 Hilden
Marie-Curie-Str. 20
[e-mail]
www.tls-electronics.de
