TMI Products VD35 User manual

Issued on : 20. 03. 2015
ψ29. 50 mm
H 3.97 mm
Specification - 1
Specification - 2
Appearance
Casing
Hand Fitting
Hand Setting Stem
Dial
Assembly Plan - 1
Assembly Plan - 2
Hands
SII Products
Cal. VD36A
Version 1
Version 1
Version 1
Version 1
Version 1
Version 1
Version 1
Version No.Item
Version 1
Version 1
Version 1

MOVEMENT SPECIFICATION - 1
1. MOVEMENT DIMENSIONS
·
Outside diameter ψ29.50mm (12H~6H) x 26.00mm (3H~9H)
·
Casing diameter ψ28.80mm (12H~6H)
·
Total height 3.97 mm
·
Dimensions of small hands away from center 7.50 mm
2. TIME STANDARD
·
Type of quartz oscillator Tuning fork
·
Frequency of quartz oscillator 32,768 Hz
·
Accuracy Monthly rate: Less than 20 seconds per month at
normal temperature range
·
Regulation device Nil
·
Regulation hands unbalance Hour hand : Less than 0.50 µN·m ( 50mg·mm )
Minute hand : Less than 0.60 µN·m ( 60mg·mm )
Second hand : Less than 0.07 µN·m ( 7mg·mm )
Dual time hand : Less than 0.05 µN·m ( 5mg.mm )
·
Additional function Dual time hour (24 hours)
Dual time minute (60 minutes)
3. BATTERY
·
Type Silver oxide battery
·
Size ψ9.5 x t 2.0 ( mm )
·
Battery life Approx. 2 years
·
Recommended battery SR920SW ( SEIZAIKEN )
4. STEPPING MOTOR
·
Number of units 3 pieces
·
Type Two pole stepping motor
·
Step 180°every second
5. JEWEL
0 jewel
6. ANTIMAGNETISM
≧1600 A / m ( Will not affected by general household appliance )
( direct current magnetic field )
7. SHOCK RESISTANCE
On equal level with general quartz movement
8. OPERATING TEMPERATURE RANGE
From - 5 ℃to + 50 ℃
9. TEST OF ACCURACY
·
Equipment to be used SEIKO Quartz Tester QT - 99
Greiner Quartz Timer - C
Witschi Q-Tester 4000
·
Duration of measurement 10 seconds
·
Microphone to be used Electromagnetic detection type
10. ATTACHED PARTS
* All specifications are subject to change without notice.
SII Products Version: 1
0110 - 3400
Parts Name
Hand setting stem
Sticker
Silver oxide battery
Parts Code
0351-1780 (Normal)
Three Hands with 2 Eyes (Regulator Dual Time of 24H & 60M)
CAL.VD36A 12 3 / 4 Ligne Quartz Movement
3013 - 14G0

Movement Specification - 2
OPERATION
Version 1
SII Products
CAL. VD36A
3 step motors ( 3 hands, dual time of 24 hour )
24H hand
3 hands
First click position
Minute hand
Dual time
Free
Dual time correction
-1 hour / PUSH
Dual time correction
+1 hour / PUSH
Normal position
First click position
Dual time zero position reset mode
( AC finished = Reset relieved )
Dual time correction
-1 minute / PUSH
( Keep pushing :
hand moving fast )
Dual time correction
+1 minute / PUSH
( Keep pushing :
hand moving fast )
Time setting
Reset switch
Second setting device
Dual time (24H) correction
+1 step / PUSH
( Keep pushing :
hand moving fast )
Dual time (minute) correction
+1 step / PUSH
( Keep pushing :
hand moving fast )
*Hands demonstration while AC reset :
Dual time of 24 hour hand : 1 cycle
Dual time of minute hand :
Counter clockwise 1/2 cycle,
Clockwise 1/2 cycle.
Time setting
Reset switch
Second setting device
*After the Dual time hand reset to the [0:00]
position, push the crown back to normal position.
AC functions
(Keep buttons
"A" & "B"
pressed at the
same time for
2 seconds,
and then release
the buttons)

Maximum height from main plate surface
與機芯平面之最大高度
Total height incl. movement
機芯總高度
Type M 一般針高
Type L 高針
Center post 中心柱位

Type L 高針
Type M 一般針高
Type M 一般針高
Type L 高針
Hour wheel 時針輪
Center wheel 分針輪
Fourth wheel 秒針輪
Dual 24 hour wheel 兩地時間24小時針輪
Dual small minute wheel 兩地時間小分針輪
Type M 一般針高
Type L 高針

6,,3URGXFWV
$1$/2*8(48$57
=
7(&+1,&$/*8,'(

3$576&$7$/2*8
(
&DO9'9'
Revised on: 19. Feb. 2016

[SPECIFICATION]
*Cal VD36
・・・
・・・・・・
・・・
Cal.VD3 without calendar
3 Hands ( Hour , Minute , Second )
Dual time of 24 hour regulator hand
Dual time of 60 minute regulator hand
Calendar (Cal. D35 only)
Two pole stepping motor
Step motor 3 pieces
Electronic circuit reset switch
Second setting device
Date setting (Cal. D35 only)
Time difference correction
[ Time ]
Indicated by Hour , Minute , Second
Dual time of 24 hour regulator and dual time of 60 minute regulator hands
[ Dual time of 24 hour regulator and dual time of 60 minute regulator ]
±1hour / push
SR920SW (Silver oxide battery)
Battery life is approximately 2 years
Use 10-second gate
*Set the winding stem with crown at the normal position
0 Jewel
Cal.
PARTS CATALOGUE / TECHNICAL GUIDE
Cal. No.
Item
Cal.VD3 &VD36
ersion-01
VD3 &VD36
Time indication
Outside diameter
Driving System
Casing diameter
φ29.50 mm × 26.00 mm (3H-9H)
Cal. D35...4.57 mm
Cal. D36;3.97 mm
φ28.80 mm
Total height
Free
Movement
Movement
size
1
SII Products
Less than ± 20seconds : Monthly rate at normal temperature range
≧1600A/m
Jewels
Measuring gate by
quartz tester
Battery
Accuracy
First
click
Left rotation
Right rotation
-1hour/push Time difference correction
Additional mechanism
+1hour/push Time difference correction
-
Buttons
Antimagnetic
Button B
D35 D36
Free
Free
Date setting
Time setting with stop-second device
Time setting with stop-second device
Normal position
Crown
position
Button A
Second click

0012 079
0808 368 …Cal.VD35 only Auxiliary train wheel bridge screw
Date dial guard
Date dial …Cal.VD35 only
Refer to page 5 for each parts code
Auxiliary train wheel bridge
24 hours wheel
Refer to page 5 for each parts code
Refer to page 5 for
each parts code
0810 368 …Cal.VD35 only
0885 002
Date jumper
Intermediate 24 hours
wheel 0802 368 …Cal.VD35 only
Date driving wheel
0806 368 …Cal.VD35 only 0817 368 …Cal.VD35 only
Date corrector wheel
Intermediate date driving wheel
0737 891 …Cal.VD35 only 0836 369 …Cal.VD35 only
Intermediate wheel Intermediate wheel for date
for date corrector (D)
corrector holder
0962 891 …Cal.VD35 only
0962 891 …Cal.VD35 only
0885 002
Small minute wheel
Hour wheel Refer to page 5 for
Refer to page 5 for each parts code
each parts code
13
9
8
7
5
14
6
2
Intermediate 24 hours wheel
SII Products
2
17
16
15
Intermediate wheel for date corrector (B)
3
10
Intermediate wheel for date corrector (C)
4
11
12
PARTS CATALOGUE
Version-02
VD35&VD36
1
Type of oil Oil quantity mark
Moebius 9010
NORMAL QUANTITY
Moebius 9030 SUFFICIENT QUANTITY
Disassembling procedures Figs.
50
⇒
1
Reassembling procedures Figs.
1
⇒
50

Battery
Winding stem
Cal.VD35 …0351 177
0012 079
Cal.VD36 …0351 178
Switch spring screw
0012 079
Switch spring screw
Switch spring
Cal.VD35 …4250 096
Cal.VD36 …4250 098
4004 332
Circuit block
4270 358
Battery connection (-)
0012 079
0012 079
Train wheel bridge (B) screw
Train wheel bridge (B) screw
0125 331
0125 331
Train wheel bridge (B) Train wheel bridge (B)
0701 014
4146 177
Fifth wheel and pinion (B)
Step rotor (B)
4146 177
Step rotor (B)
4002 923
Coil block (B)
4002 923
Coil block (B)
4239 357
Rotor stator (B)
4239 357
Rotor stator (B)
0701 014
Fifth wheel and pinion (B)
*All parts code are subject to changewithout notice.
Version-03
VD35&VD36
18
19
31
30
25
24
29
PARTS CATALOGUE
32
23
20
20
21
22
27
28
26
SII Products
3
35
33
34
Type of oil Oil quantity mark
Moebius 9010
NORMAL QUANTITY
Moebius 9030 SUFFICIENT QUANTITY

0125 248
Train wheel bridge (A)
Fourth wheel and pinion
Refer to page 5 for each parts code
0701 904
Fifth wheel and pinion (A) 0231 904
Third wheel and pinion
4146 890
Step rotor (A)
0261 034
Minute wheel and pinion
Center wheel and pinion
Refer to page 5 for each
parts code
0281 904
Setting wheel
Train wheel setting lever
4002 904
Refer to page 5 for each
Coil block (A)
parts code
Setting lever
Refer to page 5 for
each parts code
0384 470
Yoke
4239 357
Rotor stator (A) 0282 890
Clutch wheel
Intermediate wheel for
*All parts code are subject to changewithout notice. date corrector (A)
SII Products
4
40
41
44
45
47
48
49
50
46
0962 890 …Cal.VD35 only
42
PARTS CATALOGUE
Version-02
VD35&VD36
43
36
37
38
39
Type of oil Oil quantity mark
Moebius 9010
NORMAL QUANTITY
Moebius 9030 SUFFICIENT QUANTITY
*1
*1

Remarks:
Date dial …Cal.VD35 only
*All parts code are subject to change without notice.
P-4
47
Setting lever
0383 368
0383 470
46
Train wheel setting lever
0391 368
0391 357
37
Fourth wheel and pinion
P-2
0271 406
17
16
Hour wheel
0271 407
Small minute wheel
0888 014
0888 013
0888 013
13
24 hours wheel
PARTS CATALOGUE
3H
3H
White
Black
0241 177
0241 178
0888 014
5
3
Part code
Position of
crown
Position of
date frame
Color of
figure
Color of
background
0878 220
3H
3H
Black
White
0878 221
No
SII Products
Version-02
VD35&VD36
Page
Auxiliary train wheel bridge
4
Parts code
0126 357
Parts form
Parts code
0126 368
VD35
VD36
Parts form
Parts name
42
Center wheel and pinion
0221 157
0221 156

・
The explanation here is only for the particular point of Cal. D35& D36
1.REMARKS ON INSTALLING THE BATTERY
(1) Battery
・
How to install the battery
Remove the hook of the switch springs battery clamp portion.
Insert the battery sideways, and have the hook of the switch springs battery clamp portion catch
the main plate.
Battery clamp position
Hook Main plate
Hook
(2) After the battery is replaced with a new one or after the Tweezers
battery is reinstalled following the repairing procedures,
Be sure to touch the short-circuit the AC terminal of circuit
block and the switch spring with conductive tweezers
to reset the circuit as illustrated at right.
(3) When the battery replaced with a new one, the time information stored in the built-in IC and the time
indicated by the dual time of 24 hour regulator and dual time of 60 minute regulator hands do not
correspond with each other.
Reset the dual time of 24 hour regulator and dual time of 60 minute regulator hands to "0" position
following the procedure below.
If the dual time of 24 hour regulator and dual time of 60 minute regulator hands
should move improperly, also follow the same procedure.
Note.
Refer to page 8 for each adjustment method.
TECHNICAL GUIDE
ersion-01
VD3 &VD36
6
SII Products
1
2
