Toa F-122CU User manual

FS
ERIES
C EILING
S PEAKERS
F-122CU
F-1522SC
F-2322C
F-2352C
F-2352SC
F-2852C
TOA F SERIES CEILING SPEAKERS are ideal for music
and paging applications such as audio/visual, business
music or retail sound systems. The new lineup consists
of six models with features and price points to suit
premium-to-economy applications; all built with the
same high quality and reliability the industry has
come to expect from TOA products. Key benefits
include smooth off-axis coverage, versatile range of
models, ease of installation, and competitive pricing.
For premium wide-dispersion performance, the new
F-122CU is a 5” full-range processed ceiling speaker,
UL1480/2043-Listed for Fire Protective, General
Purpose Signaling and Air-Handling Spaces. Other
new full-range models include the F-2322C with 5”
full-range driver and the ultra-compact F-1522SC with 4”
full-range driver.
Three new two-way co-axial models include the
F-2852C with 6.5” cone driver, the F-2352C with 5”
cone driver and the economy F-2352SC with 5” cone
driver. Each model has a special diffusor with built-in
dome tweeter for superior co-axial performance.
The F-122CU, F-2322C, F-2352C and F-2852C all
include integral metal back-cans with safety cable,
quick-mount hardware and removable Phoenix-style
connectors with loop-through points for adjacent
speakers. Built-in overload protection circuitry
ensures outstanding reliability.
All six new models include built-in multi-tap transformers
with 8/16 ohm direct modes, front baffle power tap
selection and double-locking, paintable grilles.
Accessories include HY-TB1 tile bridge rails, HY-TR1
trim ring and HY-BC1 surface back-can.
The F Series ceiling speakers are individually packaged
and backed with a five year warranty.
Related Products
BG-M Series Mixer/Amplifiers
BS-1030 Wall/Ceiling-Mount Box Speaker
FB-100 Corner-Mount Subwoofer
HB-1 In-Wall Subwoofer
Superior Sound Quality
Wide-Dispersion, Smooth Off-Axis Coverage
Fast And Easy Installation
UL-Listed And Compliant Models
Built-In 25/70.7 V Multi-Tap Transformer
Low Impedance Mode (8/16 Ohms)
Convenient Power Tap Selector On Front Baffle
Integral Metal Back-Can And Safety Cable
Low-Profile, Paintable Grille
Overload Protection Circuitry
Mounting Hardware Included
Competitive Pricing
Individually Packaged
Five Year Warranty
F-122CU
FULL-RANGE PROCESSED CEILING SPEAKER (5”)
UL1480/2043-Listed
5” full-range driver
Wide-dispersion: 180º (1-4k Hz avg.)
Optimized equalization with model E-03R module or AC-120 processor
Power Handling: 30 W (xfmr) / 120 W (8 ohms)
F-2352C
CO-AXIAL CEILING SPEAKER (5”)
Co-axial: 5” cone driver and dome tweeter
Wide-dispersion: 170º conical (1-4k Hz avg.)
Power Handling: 30 W (xfmr) / 120 W (8 ohms)
F-2852C
CO-AXIAL CEILING SPEAKER (6.5”)
Extended bass response
Co-axial: 6.5” cone driver and dome tweeter
Wide-dispersion: 120º conical (1-4k Hz avg.)
Power Handling: 60 W (xfmr) / 180 W (8 ohms)
F-2322C
FULL-RANGE CEILING SPEAKER (5”)
5” full-range driver
Wide-dispersion: 170º conical (1-4k Hz avg.)
Power Handling: 30 W (xfmr) / 120 W (8 ohms)
F-2352SC
LOW POWER CO-AXIAL CEILING SPEAKER (5”)
Co-axial: 5” cone driver and dome tweeter
Wide-dispersion: 155º conical (1-4k Hz avg.)
Power Handling: 6 W (xfmr) / 18 W (8 ohms)
F-1522SC
COMPACT FULL-RANGE CEILING SPEAKER (4”)
4” full-range driver
Wide-dispersion: 160º conical (1-4k Hz avg.)
Power Handling: 6 W (xfmr) / 18 W (8 ohms)
H
IGHLIGHTS

F SERIES
CEILING SPEAKERS
Tel: [phone]
Fax: [phone]
www.toaelectronics.com
W IDE -D ISPERSION
APPLICATIONS
Airports
Audio/Visual
Bars / Lounges / Nightclubs
Convention Centers
Corporate Boardrooms
Hotels / Hospitality
Houses of Worship
Museums
Offices
Patios
Residential Spaces
Restaurants
Retail Stores
Schools
Theaters
Theme Parks
Visit www.toaelectronics.com to download:
System Design Software
Speaker Design Guide
Video Animations
EASE Data
Installation Manuals
Architect and Engineering Specifications
CAD Files
High Resolution Images
P2

F SERIES
CEILING SPEAKERS
Tel: [phone]
Fax: [phone]
www.toaelectronics.com
F-122CU
5” F
ULL
-R
ANGE , 30 W
FULL-RANGE PROCESSED CEILING SPEAKER (5”)
Ideal for applications requiring premium sound quality
Special diffuser provides wide off-axis high frequency response
UL-Listed for Fire Protective, General Purpose Signaling and Air-Handling Spaces
(UL1480 UUMW/UEAY, UL2043)
Ported bass-reflex design
5” full-range driver
Wide-dispersion: 180º(1-4k Hz avg.)
Frequency Response: 70 to 20k Hz
Sensitivity: 90 dB SPL (1 W, 1 m)
Continuous Power Handling: 120 W
Built-in 25/70.7 V transformer (30 W max.) with 8/16 ohm direct modes
Convenient power tap selector on front baffle
Integral metal back-can and safety cable
Removable terminal block with loop-through terminations
Low-profile, paintable grille
Overload protection circuitry
Mounting C-ring included
Optimized equalization with E-03R module or AC-120 dual channel processor
Optional HY-TB1 tile rails, HY-BC1 surface-mount back-can and HY-TR1 trim ring
Five year warranty
P3

F SERIES
CEILING SPEAKERS
Tel: [phone]
Fax: [phone]
www.toaelectronics.com
F-2352C
5” C
O - AXIAL , 30 W
CO-AXIAL CEILING SPEAKER (5”)
Special diffuser provides wide off-axis high frequency response
Ported bass-reflex design
Co-axial: 5” cone driver and dome tweeter
Wide-dispersion: 170º conical (1-4k Hz avg.)
Frequency Response: 70 to 20k Hz
Sensitivity: 90 dB SPL (1 W, 1 m)
Continuous Power Handling: 120 W (8 ohms)
Built-in 25/70.7/100 V transformer (30 W max.) with 8/16 ohm direct modes
Convenient power tap selector on front baffle
Metal back-can and safety cable
UL Compliant for Air-Handling Spaces (UL2043)
Removable terminal block with loop-through terminations
Low-profile, paintable grille
Overload protection circuitry
Mounting C-ring included
Optional HY-TB1 tile rails, HY-BC1 surface-mount back-can and HY-TR1 trim ring
Five year warranty
P4

F SERIES
CEILING SPEAKERS
Tel: [phone]
Fax: [phone]
www.toaelectronics.com
F-2852C
6.5” C
O - AXIAL , 60 W
CO-AXIAL CEILING SPEAKER (6.5”)
Ideal for high ceiling applications
Special diffuser provides wide off-axis high frequency response
Ported bass-reflex design
Co-axial: 6.5” cone driver and dome tweeter
Wide-dispersion: 120º conical (1-4k Hz avg.)
Frequency Response: 60 to 20k Hz
Sensitivity: 91 dB SPL (1 W, 1 m)
Continuous Power Handling: 180 W (8 ohms)
Built-in 25/70.7/100 V transformer (30 W max.) with 8/16 ohm modes
Convenient power tap selector on front baffle
Metal back-can and safety cable
UL Compliant for Air-Handling Spaces (UL2043)
Removable terminal block with loop-through terminations
Low-profile, paintable grille
Overload protection circuitry
Mounting C-ring included
Optional HY-TB1 tile rails
Five year warranty
P5

F SERIES
CEILING SPEAKERS
Tel: [phone]
Fax: [phone]
www.toaelectronics.com
F-2322C
5” F
ULL -R ANGE , 30 W
FULL-RANGE CEILING SPEAKER (5”)
Ported bass-reflex design
5” full-range driver
Frequency Response: 70 to 20k Hz
Wide-dispersion: 170º conical (1-4k Hz avg.)
Sensitivity: 90 dB SPL (1 W, 1 m)
Continuous Power Handling: 120 W (8 ohms)
Built-in 25/70.7/100 V transformer (30 W max.) with 8/16 ohm direct modes
Convenient power tap selector on front baffle
Metal back-can and safety cable
UL Compliant for Air-Handling Spaces (UL2043)
Removable terminal block with loop-through terminations
Low-profile, paintable grille
Overload protection circuitry
Mounting C-ring included
Optional HY-TB1 tile rails, HY-BC1 surface-mount back-can and HY-TR1 trim ring
Five year warranty
P6

F SERIES
CEILING SPEAKERS
Tel: [phone]
Fax: [phone]
www.toaelectronics.com
F-2352SC
5” C
O - AXIAL ,6W
LOW POWER CO-AXIAL CEILING SPEAKER (5”)
Special diffuser provides wide off-axis high frequency response
Co-axial: 5” cone driver and dome tweeter
Wide-dispersion: 155º conical (1-4k Hz avg.)
Frequency Response: 80 to 20k Hz
Sensitivity: 89 dB SPL (1 W, 1 m)
Continuous Power Handling: 18 W (8 ohms)
Built-in 25/70.7/100 V transformer (6 W max.) with 8/16 ohm direct modes
Convenient power tap selector on front baffle
Four pole push-terminal input connector
Low-profile, paintable grille
Dust cover to protect components
Optional HY-BC1 surface-mount back-can and HY-RR2 mounting C-ring
Five year warranty
P7

F SERIES
CEILING SPEAKERS
Tel: [phone]
Fax: [phone]
www.toaelectronics.com
F-1522SC
4” F
ULL -R ANGE ,6W
COMPACT FULL-RANGE CEILING SPEAKER (4”)
Ultra-compact – only 4.2” (106 mm) deep!
4” full-range driver
Wide-dispersion: 160º conical (1-4k Hz avg.)
Frequency Response: 65 to 18k Hz
Sensitivity: 88 dB SPL (1 W, 1 m)
Continuous Power Handling: 18 W
Built-in 25/70.7/100 V transformer (6 W max.) with 8/16 ohm direct modes
Convenient power tap selector on front baffle
Four pole push-terminal input connector
Low-profile, paintable grille
Dust cover to protect components
Optional HY-RR1 mounting C-ring
Five year warranty
P8

F SERIES
CEILING SPEAKERS
Tel: [phone]
Fax: [phone]
www.toaelectronics.com
D IMENSIONAL
D RAWINGS
F-122CU (5” F
ULL -R ANGE , 30 W)
F-2352C (5” C O -A XIAL , 30 W)
F-2852C (6.5” C
O -A XIAL , 60 W)
F-2322C (5” F ULL -R ANGE , 30 W)
F-2352SC (5” C O -A XIAL ,6W)
F-1522SC (4” F
ULL -R ANGE ,6W)
P9
UNIT: mm

F SERIES
CEILING SPEAKERS
Tel: [phone]
Fax: [phone]
www.toaelectronics.com
A
CCESSORIES
HY-TR1
TRIM RING
For covering existing holes (11.8” max.) in retrofit applications
Fits models F-122CU, F-2322C, F-2352C, and F-2352SC
HY-TB1
TILE BRIDGE SUPPORT RAILS
Required for T-bar ceiling mounting (24”)
Fits models F-122CU, F-2322C, F-2352C, F-2852C, and F-2352SC
240
200
220 2-
Ø 20 knockout hole
Ø 22 or Ø 28
knockout hole
Unit: mm
HY-BC1
SURFACE BACK-CAN
For surface-mount applications in open ceilings
Low-gloss black paint finish
Fits models F-122CU, F-2322C, F-2352C and F-2352SC
AC-120
DUAL CHANNEL PROCESSOR FOR F-122CU
E-03R
900 SERIES PROCESSOR MODULE FOR F-122CU
