Toa F-121C/M Installation and operating instructions

APPLICATION NOTE ON TOA'S
UNIFORM DIRECTIVITY CEILING
SPEAKER
In open areas with low ceiling heights, dead spots often
occur in areas between speakers mounted in the ceiling.
Often, there is a noticeable difference in the quality of the
sound between the area directly below the speaker, or on
axis, and the area off-axis. Sound engineers and system
designers have known for many years that higher frequency
material is more narrowly dispersed from cone speakers
than lower frequency material. A listener standing on-axis
gets a better, more total sound than one standing off-axis.
The attenuation of higher frequencies is a problem because
of intelligibility loss as well as degradation of quality.
One solution is to decrease the distance between
ceiling speakers, thus putting more of the floor space and
listening area into the on-axis coverage. However, this will
drive up the cost of the system since more speakers, wire,
back boxes and labor will be consumed in the installation,
and more amplifier power will be needed.
A better solution
is to use TOA’s new F121C Uniform Directivity Ceiling
Speaker with the AC-120 Dedicated Equalizer. This speak-
er is equipped with a unique sound diffuser, housed in an
attractive mesh cone. The diffuser helps to smooth out the
dispersion of the higher frequencies, which eliminates the
dead spots even when the speakers are spread out. The
graphics shown on this page and the next dramatically
demonstrate how the frequency and polar response of the
F-121C compares with standard 4”ceiling speakers, and
shows that better sound with less speakers is possible
when the F-121C is used in restaurants, offices, shopping
malls, retail stores, and other space requiring ceiling mount-
ed speakers.
The F-121CM is transformer equipped with multi-
ple line taps for loudness selection.
Polar Response F-121C
•500Hz •1000Hz •2000Hz •4000Hz •8000Hz
Frequency Response of F-121C/F-121CM
0/Degrees
30/Degrees
60/Degrees
90/Degrees
20100 200 lk 2k
10 k
20 k
Frequency Response of 4” Ceiling Speaker
0/Degrees
30/Degrees
60/Degrees
90/Degrees
I
100 200 lk 2k 10k 20k
Polar Response 4”Ceiling Speaker
•500Hz •1OOOHz •2000Hz •4000Hz •8000Hz

Sound Level Distribution Patterns TOA F-121C/F-121CM
s 8000Hz t s 4000Hz t s 2000Hz t s 1000Hz t
Sound Level Distribution Patterns 4” Ceiling Speakers
Sibilants (“s”sounds) and plosives (“p”sounds) are fre- The above sound level distribution patterns were obtained
quent in all human speech. Compared to the F-121C from four speakers placed (as marked by the “+”signs) in
Uniform Directivity Ceiling Speakers, standard 4”and espe- an anechoic space measuring 65 ft. (W) X 65 ft. (W) by 6.5
cially 8”co-ax ceiling speakers do not adequately disperse ft. (H). The patterns above show the area represented by
these high frequency sounds.
1 W/m of sound pressure level.
04-97-f121ap
Printed in U.S.A. 4/97 BL
